Mermaid Diagram Pro
Enhanced Mermaid diagram support — templates, Mermaid Live preview, validation
11 built-in Mermaid diagram templates. Quick access to Mermaid Live Editor with your diagram pre-loaded. Validation of all diagram blocks in the active file.
Features
- 11 diagram templates — flowchart, sequence, class, ER, git graph, timeline, Gantt, pie chart, mind map, state diagram, C4 context
- Live preview — open any diagram in Mermaid Live Editor pre-loaded with your code
- Inline validation — count and list all mermaid code blocks in the active file
- SVG/PNG export guidance — instructions for mmdc CLI export
- Works in .md and .mmd files
Requirements
No external tools required for templates, preview, and validation. For local SVG/PNG export only: npm install -g @mermaid-js/mermaid-cli
Diagram Templates
flowchart — Decision flowsequence — Sequence diagramclassDiagram — OOP class hierarchyerDiagram — Entity relationshipgitGraph — Git branch visualizationtimeline — Project timelinegantt — Gantt chart with dependenciespie — Pie chartmindmap — Mind mapstateDiagram — State machinec4Context — C4 context diagram
Commands
| Command |
Description |
Mermaid Pro: Insert Diagram Template |
Insert a starter diagram |
Mermaid Pro: Preview Diagram at Cursor |
Open in Mermaid Live Editor |
Mermaid Pro: Export as SVG |
Instructions for mmdc CLI export |
Mermaid Pro: Validate All Diagrams in File |
Count and list all diagram blocks |
