Arm Keil Studio Pack for Visual Studio Code Desktop

Overview

This extension pack installs recommended extensions for Keil Studio development. The extensions included are listed in the Details of the pack in Visual Studio Code and detailed in the Extensions available in the pack section below.

The main Keil Studio extensions available are Arm CMSIS csolution, Arm Device Manager and Arm Embedded Debugger. They can work in combination and enable you to manage CMSIS solutions (csolution projects), flash projects to a device and undertake debugging.

This Readme explains how to install the extensions with the Keil Studio Pack and gives you the main steps to set up your development environment (check the CMSIS csolution extension Readme to get the full details). Once your environment is ready, check the Tutorial to understand what you can do with the extensions.

Submit feedback

To submit feedback, please create an issue.

Table of contents

  1. Extensions available in the pack
  2. Install the extensions
  3. Main steps to set up your development environment
  4. Tutorial
    • Connect your board
    • Build the csolution project
    • Flash the csolution project to your board
    • Launch a debug session
    • Check the serial output of your board

Extensions available in the pack

The main extensions available are:

  • Arm CMSIS csolution (Identifier: arm.cmsis-csolution): This extension provides support for working with CMSIS solutions (csolution projects).

  • Arm Device Manager (Identifier: arm.device-manager): This extension allows you to manage device connections for Arm Cortex-M based microcontrollers, development boards and debug probes.

  • Arm Embedded Debugger (Identifier: arm.embedded-debug): This extension allows you to do flashing and debugging on Arm Cortex-M based microcontrollers, development boards and debug probes implementing the Microsoft Debug Adapter Protocol (DAP).

  • Arm Remote Build (Identifier: arm.remote-build): This extension allows you to undertake remote builds of projects for Arm Cortex-M based microcontrollers. The extension only works with standalone CMSIS projects (containing a single .cprj project file). A token is required to access the service.

Install the extensions

  1. Go to the Extensions view.

  2. Search for Keil Studio Pack.

  3. Click the Install button for the extension pack.

    Visual Studio Code installs the extensions. All recommended extensions are now available in the Extensions view.

Main steps to set up your development environment

Once the extensions have been installed, there are extra installation and setup tasks to carry out. Check the CMSIS csolution extension Readme for more details.

Here are the main steps:

  • Install a compiler toolchain. Install the Arm Compiler for Embedded toolchain or the Arm GNU Toolchain (includes the GNU Compiler - GCC), or both.
  • Install CMake and Ninja.
  • Install CMSIS-Toolbox.
  • Initialize or update the catalog of public CMSIS-Pack versions.
  • Install and set up the clangd extension. This extension provides IntelliSense support for C/C++ projects and integrates with the CMSIS csolution extension.
  • Modify extension settings.

Tutorial

Once your Keil Studio development environment is set up, you can start working with a csolution project.

Check the "Work with a csolution example project" section in the CMSIS csolution extension Readme to:

  • Clone a csolution example project.
  • Install the CMSIS-Packs required.
  • Set a context for the csolution (select a build target and a build configuration).

When you are ready, follow the instructions below to:

  • Connect your board.
  • Build the csolution project.
  • Flash the project to your board.
  • Launch a debug session.

Connect your board

  1. Click the Device Manager icon Device Manager icon in the Activity Bar to open the Arm Device Manager extension.

  2. Connect your board to your computer over USB. In our example we use the B-U585I-IOT02A board from STMicroelectronics.

    The board is detected and a popup message displays.

  3. Click OK in the pop up message to use the device.

    Your board is now ready to be used for flashing and debugging.

Build the csolution project

There are several ways to build your project. You can do it from the Explorer or using the Build button. If you use the Build button, you must configure a task the first time you build your project.

  • From the Explorer:

    1. Click the Explorer icon Explorer icon in the Activity Bar.

    2. Right-click on the .cprj file corresponding to the context you selected for the project and select Build.

      Note: A Rebuild option is also available in the right-click menu. This option cleans output directories before building the project.

  • Using the Build button:

    1. Click the CMSIS icon CMSIS icon in the Activity Bar.

    2. Click the Build button Build button in the ACTIONS panel.

    3. In the drop-down list that opens at the top of the window, select the cmsis-csolution.build:Build task.

      A tasks.json file opens with some default configuration.

         ``{
             "type": "cmsis-csolution.build",
             "project": "${command:cmsis-csolution.getCprjPath}",
             "problemMatcher": [],
             "label": "cmsis-csolution.build: Build"
           }``


      Note: You only need to configure the task once.

    4. Click the Build button again to build the project.

      Note: If you click the drop-down next to the Build button, you can use the Clean Build option. Clean Build is the same as Rebuild in the right-click menu.

    5. Check the TERMINAL tab.

Note: Build and Rebuild can also be triggered from the Command Palette with the CMSIS: Build and CMSIS: Rebuild commands.

Flash the csolution project to your board

You must configure a task the first time you want to flash a csolution project to your board.

Configure a task

  1. Go to Terminal > Configure Default Built Task....

  2. In the drop-down list that opens at the top of the window, select the embedded-debug.flash:Flash Device task.

    The tasks.json file opens. This file contains the configuration for the build task added in the previous step. The following configuration displays for the flash task:

         ``{
             "type": "embedded-debug.flash",
             "serialNumber": "${command:device-manager.getSerialNumber}",
             "program": "${command:embedded-debug.getBinaryFile}",
             "cmsisPack": "<path or URL of CMSIS Pack for your device>",
             "problemMatcher": [],
             "label": "embedded-debug.flash: Flash Device",
             "group": {
                 "kind": "build",
                 "isDefault": true
               }
            }``

  3. For "program", replace "${command:embedded-debug.getBinaryFile}" by "${command:cmsis-csolution.getBinaryFile}".

  4. Download the CMSIS-Packs for the B-U585I-IOT02A board. The CMSIS-Packs are available on Arm Developer under the Devices category.

  5. For "cmsisPack", indicate the path where the CMSIS-Packs are stored.

    For example on Mac or Linux: "$HOME/Downloads/Keil.STM32U5xx_DFP.2.0.0.pack". On Windows: %HOME%\Downloads\Keil.STM32U5xx_DFP.2.0.0.pack.

    A path to unpacked CMSIS-Packs is also supported. Check the path set for the CMSIS_PACK_ROOT environment variable. If you had installed the CMSIS-Toolbox previously, or if you are a Keil MDK user, the path looks like this: $HOME/.cache/arm/packs/Keil/STM32U5xx_DFP/2.0.0/ (on Mac or Linux), or %HOME%\AppData\Local\Arm\Packs\Keil\STM32U5xx_DFP\2.0.0\ (on Windows).

  6. Save the tasks.json file.

Flash the csolution project

  1. Click the CMSIS icon CMSIS icon in the Activity Bar.

  2. Click the Flash button Flash button in the ACTIONS panel.

  3. Select STM32U585AIIx in the drop-down list that opens at the top of the window.

    The project is flashed to the board.

  4. Check the TERMINAL tab.

Launch a debug session

In order to debug, you must first add a configuration.

Add configuration

  1. Go to Run > Add Configuration....

  2. A launch.json file opens.

  3. In the drop-down list that opens after "configurations", select Arm: Embedded Debug.

    Some default configuration displays:

     ``{
         "configurations": [
             {
                 "name": "Embedded Debug",
                 "type": "embedded-debug",
                 "request": "launch",
                 "serialNumber": "${command:device-manager.getSerialNumber}",
                 "program": "${command:embedded-debug.getBinaryFile}",
                 "cmsisPack": "<path or URL of CMSIS Pack for your device>"
             }
         ]
     }``

  4. For "program", replace "${command:embedded-debug.getBinaryFile}" by "${command:cmsis-csolution.getBinaryFile}".

  5. For "cmsisPack", indicate the path where the CMSIS-Packs are stored. See Flash the csolution project to your board.

  6. Save the launch.json file.

Debug

  1. Click the CMSIS icon CMSIS icon in the Activity Bar.

  2. Click the Debug button Debug button in the ACTIONS panel.

  3. Select STM32U585AIIx in the drop-down list that opens at the top of the window.

    The RUN AND DEBUG view displays and the debug session starts. The debugger stops at the function "main" of your project.

  4. Check the DEBUG CONSOLE tab to see the debugging output.

Look at the Visual Studio Code documentation to learn more about the debugging features available in Visual Studio Code

Check the serial output of your board

The serial output shows the output of your board.

To check the serial output:

  1. Click the CMSIS icon CMSIS icon in the Activity Bar.

  2. Click the Open Serial button Open Serial button in the ACTIONS panel.

  3. Select a baud rate in the drop-down list that opens at the top of the window. The baud rate you select must be the same as the baud rate of the project.

    The serial output displays in the TERMINAL tab.
