Arm CMSIS csolution
Overview
This extension provides support for working with CMSIS solutions (csolution projects). It can be installed individually or together with other extensions contained in the Keil Studio Pack available for Visual Studio Code Desktop. Check the extension pack Readme first if you want to install the extensions using the pack.
The Arm CMSIS csolution extension can work in combination with the Arm Device Manager (Identifier: arm.device-manager
) and Arm Embedded Debugger (Identifier: arm.embedded-debug
) extensions.
This Readme explains how to set up your development environment to be able to work with CMSIS solutions in Visual Studio Code.
Once your development environment is ready, you can clone a csolution example project, install the CMSIS-Packs required for the example, and then start working with the example.
Note that you can convert a Keil MDK project in .uvprojx
format to a csolution project from the Arm CMSIS csolution extension as explained in this Readme.
For more information about supported hardware for CMSIS projects, go to keil.arm.com. For an overview on CMSIS-Packs, go to open-cmsis-pack.org.
Submit feedback
To submit feedback, please create an issue.
Table of contents
- Set up your development environment
- Work with a csolution example project
- Convert a Keil MDK project to a csolution project
- Create a csolution project
- Manage a csolution project and its software components
- Troubleshooting
- Known limitations
➤ Set up your development environment
Here are the main steps:
Install the following tools:
Initialize or update the catalog of public CMSIS-Pack versions.
Install and set up the clangd extension.
Modify extension settings.
On macOS
Some unsigned binaries need to be de-quarantined before you can run them. This is only required for newer versions of macOS.
Run the command from the terminal:
xattr -d com.apple.quarantine /path/to/bin
Run with sudo
if you get permission errors.
On Windows
Use the System Properties dialog box to set environment variables and add directories to the PATH.
Install the Arm Compiler for Embedded toolchain or the Arm GNU Toolchain (includes the GNU Compiler - GCC), or both.
On Windows or Linux, download Arm Compiler for Embedded version 6.18 from Arm Developer or use the Arm Compiler for Embedded toolchain available with Keil MDK.
Note: There is no build available for macOS at the moment.
Download the Arm GNU Toolchain version 11.2 from
Arm Developer. Choose the arm-none-eabi release for your platform.
Archive files are available for all platforms. Installers are available for macOS and Windows.
To check if the ARM GNU Toolchain was installed, navigate to the <arm-toolchain-installation-dir>/bin/
directory.
Check the installation by running the following command from the terminal:
arm-none-eabi-g++ --help
Install CMake and Ninja
The CMSIS-Toolbox uses the CMake build system with a Ninja generator, so you must install these tools before installing CMSIS-Toolbox.
Install the CMake and Ninja build tools with your system package manager or download the latest releases from the CMake and Ninja download pages.
brew install cmake
brew install ninja
- Installation from latest releases:
- Download the CMake installer from here: https://cmake.org/download/
- Download the Ninja executable from here: https://github.com/ninja-build/ninja/releases
If this has not already been handled by the system package manager, add cmake
and ninja
to the PATH.
Check the installation by running the following commands from the terminal:
cmake --version
ninja --version
Download the latest release of CMSIS-Toolbox for your platform from the
Releases page on GitHub.
Note: There is no Apple silicon build available yet, but the darwin64 version works with Rosetta.
Extract the content of the archive file.
Modify the *.cmake
file for the compiler toolchain you have installed. If you have several toolchains installed, modify the corresponding *.cmake
files. All the *.cmake
files are stored in <cmsis-toolbox-installation-dir>/etc/
.
For example, modify the section below:
############### EDIT BELOW ###############
# Set base directory of toolchain
set(TOOLCHAIN_ROOT "/home/runner/gcc-arm-none-eabi-10-2020-q4-major/bin")
set(PREFIX arm-none-eabi-)
set(EXT )
As follows:
############### EDIT BELOW ###############
# Set base directory of toolchain
set(TOOLCHAIN_ROOT "/Applications/ARM/bin")
set(PREFIX arm-none-eabi-)
set(EXT )
**Notes**:
- The exact toolchain version does not matter. For example, you can modify the `GCC.10.2.1.cmake` file if you have installed GCC 10.3.1.
- `TOOLCHAIN_ROOT` should be set to the _absolute_ path to the compiler bin directory where the toolchain binaries are stored.
- `EXT` gives the file extension of the executable binaries. Leave it empty for macOS and Linux. Use `.exe` for Windows.
Set the following environment variables:
CMSIS_COMPILER_ROOT
: Set to the path of the CMSIS-Toolbox etc
directory. For example, /<cmsis-toolbox-installation-dir>/etc
.
PATH
: Add the CMSIS-Toolbox bin
directory to the system path. For example, /<cmsis-toolbox-installation-dir>/bin
.
CMSIS_PACK_ROOT
: Set to the path of the CMSIS-Pack root directory that stores software packs. This can be any directory, but do not leave it undefined. If you had installed the CMSIS-Toolbox previously, or if you are a Keil MDK user, the default location for packs is $HOME/.cache/arm/packs
on Mac or Linux and %HOME%\AppData\Local\Arm\Packs
on Windows.
Configure an HTTP proxy (optional):
This step is only required if you are working behind an HTTP proxy. The tools can be configured using the following standard environment variables to use an HTTP proxy:
HTTP_PROXY
: Set to the proxy used for HTTP requests.
HTTPS_PROXY
: Set to the proxy used for HTTPS requests.
NO_PROXY
: Set to include at least localhost,127.0.0.1
to disable the proxy for internal traffic (which is required for the extension to work correctly).
On macOS:
The CMSIS-Toolbox is currently not signed, so you must de-quarantine its binaries as explained in the General comments section.
Run the command from the terminal:
xattr -d com.apple.quarantine <cmsis-toolbox-installation-dir>/bin/
*Example*: `> $xattr -d com.apple.quarantine <cmsis-toolbox-installation-dir>/path/to/bin/cbuild`.
Run with `sudo` if you get permission errors.
- Check the installation with:
cbuild --version
csolution --help
➤ Initialize or update the catalog of public CMSIS-Pack versions
If CMSIS_PACK_ROOT
is pointing to an empty directory, run the following command from the terminal to initialize the directory structure and download the latest pack index file:
cpackget init https://www.keil.com/pack/index.pidx
Otherwise, run the following command from the terminal to update the stored catalog (index file and the already downloaded package description files):
cpackget update-index
➤ Install and set up the clangd extension
Install the clangd extension from Visual Studio Code.
The clangd extension requires the clangd language server. If the server is not found on your path, add it with the clangd: Download language server command from the Command Palette. Check the clangd extension Readme for more information.
➤ Modify extension settings
Note: If you have not already installed the Arm CMSIS csolution extension with the Keil Studio Pack, install the extension individually.
Modify the extension settings to point at the tools installed previously.
Note: This is unnecessary if you add the toolbox bin directory to the PATH.
In Visual Studio Code, open the Settings:
- On Windows or Linux, go to: File > Preferences > Settings
- On macOS, go to: Code > Preferences > Settings
Find the CMSIS csolution extension under the Extensions category.
Set absolute paths for:
- The
cbuild
executable (available in the CMSIS-Toolbox bin directory) in the Cbuild Path field.
- The
csolution
executable (available in the CMSIS-Toolbox bin directory) in the Csolution Path field.
Restart Visual Studio Code.
C/C++ language support with clangd
There is no extra setup needed once clangd has been installed. The Arm CMSIS csolution extension generates a compile_commands.json
file for each project in a solution whenever a .cprj
file changes or when you change the context of a solution (Target and Build types). A .clangd
file is kept up to date for each project in the solution. The .clangd
file is used by the clangd extension to locate the compile_commands.json
files and enable IntelliSense. See the clangd documentation for more details.
You can turn off the automatic generation of the .clangd
file and compile_commands.json
file.
Go to Code > Preferences > Settings.
Find the CMSIS csolution extension under the Extensions category.
Clear the Auto Generate Clangd File and Auto Generate Compile Commands checkboxes.
➤ Work with a csolution example project
Now that your Visual Studio Code environment is set up, you can start working with a csolution project. You must clone an example project, install the CMSIS-Packs for the example, and then set a context.
Once you have explored what you can do with the csolution example project, check the "Tutorial" section in the Keil Studio Pack for Visual Studio Code Desktop Readme. The Tutorial explains how to connect your board, flash the csolution to your board, and launch a debug session.
➤ Clone a csolution example project
Clone the Blinky example project available in the following repository:
https://github.com/RobertRostohar/Demo_EW/
To clone a project in Visual Studio Code:
Go to View > Command Palette....
In the field that opens at the top of the window, type Git
, then select the Git:Clone command in the drop-down list.
Copy and paste the GitHub repository URL provided in the field that displays and press Enter.
A dialog box opens to select where to clone the repository.
Select a location.
Once the repository is cloned, open the Blinky example project in Visual Studio Code.
➤ Install the CMSIS-Packs required for the example
Install the CMSIS-Packs.
Open the cloned example project from Visual Studio Code, then open the Blinky.csolution.yml
file from the Explorer view.
The required packs are listed under the packs
key of the csolution.yml
file.
For example, one of the required packs for Blinky.csolution.yml
is ARM::V2M_MPS3_SSE_300_BSP@1.2.0
, where ARM
is the vendor, V2M_MPS3_SSE_300_BSP
is the name of the pack, and 1.2.0
is the version.
Run the following command from the terminal to add the packs:
cpackget add <vendor>::<name>@<version>
Note that you can add multiple packs at once as follows:
cpackget add <vendor>::<name>@<version> <vendor>::<name>@<version> <vendor>::<name>@<version>
➤ Explore what you can do with the csolution example project
Look at the csolution contexts.
Click the CMSIS icon
in the Activity Bar to open the Arm CMSIS csolution extension.
Look at the available contexts for the csolution in the CONTEXT panel. You can change the build target and build configuration.
- Active Solution: The name of the active csolution,
Blinky
(Blinky.csolution.yml
).
- Target: The build target
B-U585I-IOT02A
(a physical evaluation board from STMicroelectronics) or AVH_MPS3_Corstone-300
(a Virtual Hardware Target).
- Build: The build configuration
Debug
or Release
. A build configuration adds the flexibility to configure each build target towards a specific testing. Use Debug
for a full debug build of the software for interactive debug, or Release
for the final code deployment to the systems.
- Project: The name of the cproject,
Blinky
(Blinky.cproject.yml
).
Click the Explorer icon
and open the Blinky.csolution.yml
and Blinky.cproject.yml
files. YAML syntax support helps you with editing.
The .cprj
file is regenerated when changes are made to the csolution.yml
or cproject.yml
files.
1. Go to **View** > **Output**.
The **OUTPUT** tab opens.
1. Select **CMSIS Project Manager** in the drop-down list in the top right corner and check what has been logged.
Go the PROBLEMS tab and check for errors.
Right-click the .cprj
file corresponding to the context you selected and select Build.
Note: A Rebuild option is also available in the right-click menu. This option cleans output directories before building the project. Build and Rebuild can also be triggered from the Command Palette with the CMSIS: Build and CMSIS: Rebuild commands.
Check the TERMINAL tab.
Open the Blinky.c
file and check the IntelliSense features available. Check the Visual Studio Code documentation on IntelliSense to find out about the different features.
Note: You can turn off the automatic generation of the cprj
file.
Go to Code > Preferences > Settings.
Find the CMSIS csolution extension under the Extensions category.
Clear the Auto Generate Cprj checkbox.
➤ Convert a Keil MDK project to a csolution project
You can convert a Keil MDK project to csolution project from the Arm CMSIS csolution extension.
In Visual Studio Code, run the CMSIS: Convert MDK project to csolution command from the Command Palette.
Using the file picker that displays, select the .uvprojx
that you want to convert and click Select.
The conversion starts immediately.
Check the OUTPUT tab (View > Output). Conversion messages are logged under the MDK to csolution Converter category.
A "Conversion Successful" message displays once the conversion is done.
The *.cproject.yaml
and *.csolution.yaml
files are available in the folder where the .uvprojx
is stored.
➤ Create a csolution project
Note: The New CMSIS solution view is still under development. To get access to it, select the Experimental Features checkbox in the CMSIS csolution extension settings.
Create a CMSIS solution which contains an empty CMSIS project.
Before you can create a CMSIS solution, you must open a workspace in Visual Studio Code. Select File > Open Folder.... Use the system dialog box that opens to create and select a new folder to store your solution.
Click the CMSIS icon
in the Activity Bar to open the Arm CMSIS csolution extension.
Hover over the CONTEXT label and click the Create a solution icon
.
The New CMSIS solution view opens.
Click the Target drop-down list and select a device or a board from the lists available.
The Target type field is automatically populated with Device
or Board
depending on what you selected in the Target drop-down list. You can edit the value if you need.
In the Project name and Solution name fields, type a project name and a solution name.
Check the Solution preview. This displays the solution name and the project name, as well as the target hardware selected for the solution, the compiler, and the build types available.
Check the default options:
Initialize Git repo: The extension initializes the solution as a Git repository. Clear the checkbox if you do not want to turn your solution into a Git repository.
Make project active: The extension sets the newly created project that is part of the new solution as the active project. Build, Flash and Debug actions only apply to the active project. Clear the checkbox if you do not want to make the new project active.
Click Create. Keil Studio creates the solution in your workspace.
Click the Explorer icon
in the Activity Bar to check the files that have been created.
Open the entry for the folder you created <folder_name>.
A <solution_name>.csolution.yaml
and a <project_name>.cproject.yaml
files are created under a <solution_name> entry.
➤ Next steps
Explore the autocomplete feature available to edit the csolution.yaml
and cproject.yaml
.
Check the csolution: CMSIS Project Manager documentation for project examples.
Add CMSIS components with the Manage Software Components view. When you add components the cproject.yaml
file is updated.
➤ Manage a csolution project and its software components
The Manage Software Components view shows all the software components selected in the active project of a CMSIS solution. From this view you can see all the component details (called attributes in the Open-CMSIS-Pack documentation).
You can also:
- Modify the software components to include in the project and manage the dependencies between components for each build target you have defined in your solution.
- Build the solution using different combinations of pack and component versions, and different versions of a toolchain.
➤ Open the Manage Software Components view
In Visual Studio Code, open the solution you want to work on.
Click the CMSIS icon
in the Activity Bar to open the Arm CMSIS csolution extension.
Check the active project selected in the CONTEXT panel.
Hover over the CONTEXT label and click the Manage software components icon
.
The Manage Software Components view opens.
By default, the view displays all the components that are available for use. If you select the Show selected only checkbox, only the components included in the active project display.

With the Target drop-down list, you can select components for the different build targets you have in your solution.
The first column in the Manage Software Components view shows how many instances of the component are deployed in the project. If the component has a selected checkbox, one instance is deployed. If the checkbox is not selected, it is not deployed in the project. If a number input displays, multiple instances of this component can be deployed to a project.
The CMSIS-Pack specification states that each software component should have the following attributes:
- Component class (Cclass): A top-level component name. For example: CMSIS. For a full list of component classes, see Software Component Cclasses in the Open-CMSIS-Pack documentation.
- Component group (Cgroup): A component group name. For example: CORE for the CMSIS component class.
- Component version (Cversion): The version number of the software component.
Optionally, a software component might have these additional attributes:
- Component sub-group (Csub): A component sub-group that is used when multiple compatible implementations of a component are available. For example: Keil RTX5 implements CMSIS > RTOS2.
- Component variant (Cvariant): A variant of the software component is typically used when the same implementation has multiple top-level configurations, like Source for RTOS2 > Keil RTX5.
- Component vendor (Cvendor): The supplier of the software component. For example: Keil.
- Bundle (Cbundle): Allows you to combine multiple software components into a software bundle. Bundles have a different set of components available. All the components in a bundle are compatible with each other but not with the components of another bundle. For example: ARM Compiler for the Compiler component class.
Use the Search field, to search on the component groups and sub-groups.
➤ Modify the software components in your project
You can add components from all the packs available (it is not limited to the packs that are already selected for a given project).
Make sure the Show selected only checkbox is not selected to display all the components available.
Select a build target in the Target drop-down list. You can select components for the different build targets defined in the solution.
Use the checkboxes to select or clear components as required. If a number input displays instead of a checkbox, it means that multiple instances of this component can be deployed to a project. For some components, you can also select a vendor, variant, or version.
The cproject.yaml
file is automatically updated.
From the Validation panel, you can manage the dependencies between components and solve validation issues.
Issues are highlighted in red and have an exclamation mark icon
next to them. You can remove conflicting components from your selection or add missing component dependencies from a suggested list.
If there are validation issues, hover over the issues in the Validation panel to get more details. You can click the proposed fixes to find the components in the list. In some cases, you may have to choose between different fix sets. Select a fix set in the drop-down list, then apply the changes and click Apply Fix Set.

Note: In the current version, you can undo changes from the Source Control view or by directly editing the cproject.yaml
file.
➤ Troubleshooting
Errors such as ld: unknown option: --cpu=Cortex-M4
appear in the build output. In this example, the CMSIS-Toolbox is trying to use the system linker rather than Arm Compiler's armlink.
Ensure the CMSIS_COMPILER_ROOT
environment variable is set correctly. You may need to restart Visual Studio Code so it picks up the new environment.
Clean the solution. In particular, delete the out
and tmp
directories.
Run the build again.
➤ Known limitations
This extension is currently a preview. Known limitations include:
- No support for cdefaults.yml and clayer.yml files, for example target and build types from the cdefaults file do not appear in the CONTEXT view.
