Embedded Peripheral Inspector
Standalone SVD Viewer extension extracted from cortex-debug
Specifying SVD Files
The SVD Viewer extension uses System View Description (SVD) files to display information about the selected part, including the Cortex Peripherals view.
Choose one of the following methods to specify your SVD file in your
Use the CMSIS pack asset service
If the pack supports multiple devices and/or processors, you will be prompted to select these. Alternatively, set them in your configuration using the optional
TIP: The pack reference and device name can be automatically derived if you use the Arm Device Manager extension in VS Code using these commands:
Install a Cortex Debug Support Pack
Find a Cortex Debug Support Pack for your device and install it. You can then specify just the
Specify the path to your SVD file
Other vendors may ship SVD files when you install their software or device packs or you could write your own custom SVD file.
Once you have the SVD file, specify the location of it in your
Extending Peripheral Inspector
It is possible to extend the Peripheral Inspector with new file extension providers in your VSCode extension. This method will provide reading new file formats and load the peripherals information into the Peripheral Inspector.
For more details about the implementation, please check the Extending Peripheral Inspector document.
All variable key names used to extract data from debug launch configurations can be modified. This allows variable name clashes to be avoided as well as the need to duplicate configuration entries.
The following list outlines the setting names and default values:
