vscode-containerlab

A Visual Studio Code extension that integrates containerlab directly into your editor, providing a convenient tree view for managing labs and their containers.

Key Features

• Auto-discovery & Tree View: Automatically find .clab.yml/.clab.yaml files in your workspace and display them in a tree view. Labs are color-coded based on container states:

  • Green: All containers running
  • Red: All containers stopped
  • Yellow: Mixed (partial deployment)
  • Gray: Undeployed labs

• Context Menu Actions: For labs and containers, quickly deploy, destroy, redeploy (with or without cleanup), save, inspect, delete undeployed lab files, or open lab files and workspaces. For containers, additional commands include starting, stopping, attaching a shell, SSH, viewing logs, and copying key properties (name, ID, IP addresses, kind, image).

• Interface Tools: Capture traffic (via tcpdump/Wireshark or Edgeshark) and set link impairments such as delay, jitter, packet loss, rate-limit, and corruption. You can also copy an interface’s MAC address.

• Graphing & Visualization: Generate network graphs in multiple modes:

  • Draw.io (Horizontal): Generates a .drawio file in a horizontal layout. (pos labels will overwrite the layout)
  • Draw.io (Vertical): Generates a .drawio file in a vertical layout. (pos labels will overwrite the layout)
  • Interactive TopoViewer: Launches a dynamic, web-based view of your topology.
  • Interactive TopoEditor: Let's your create in a graphical way network topologies

• Clone Labs from Git: Easily clone labs from any Git repository or choose from a list of popular labs directly within the extension.

• Help & Feedback View: Access documentation, community links, and other helpful resources from a dedicated tree view.

• Inspection: Use webviews to inspect either all labs or a single lab’s deployed containers in a neatly grouped table.

• Remote Labs: Works perfectly with the: SSH-Remote extension to manage labs on remote servers.

• Remote Topology URLs: Deploy labs directly from GitHub or GitLab by providing a repository or file URL when using the "Deploy an existing lab" command.

Requirements

• containerlab must be installed and accessible in your system PATH. The extension will offer to install it if not found.

• (Optional) Edgeshark for packet capture features - can be installed directly from the extension using the "Install Edgeshark" command.

  Edgeshark Integration

  • Install Edgeshark: installs Edgeshark using docker compose

  • Uninstall Edgeshark: removes Edgeshark containers

  • Configure session hostname: set hostname for remote connections (packet capture)

  • If you want to live capture traffic using Wireshark, please download the cshargextcap plugin for the OS/distribution and install it.

Note: The extension will automatically prompt to add your user to the clab_admins group during setup to enable running containerlab commands without sudo.

Getting Started

1. Install the extension.
2. Open a folder or workspace in VS Code containing .clab.yml or .clab.yaml files. Or just clone a popular lab.
3. Click on the Containerlab icon in the Activity Bar to view your labs.
4. Right-click on a lab or container to see context menu commands (Deploy, Destroy, Redeploy, etc.).

Extension Settings

Configure the extension behavior through VS Code settings (containerlab.*):

🚀 Core Settings

🎯 Command Options

🖥️ Node Configuration

🎨 TopoViewer/Editor

*Default custom nodes include SRLinux and Network Multitool templates
**Default patterns: nokia_srlinux: "e1-{n}", cisco_xrd: "Gi0-0-0-{n}", etc.

📦 Packet Capture

🌐 Lab Sharing

Example Configuration

{
  "containerlab.deploy.extraArgs": "--timeout 5m --max-workers 88",
  "containerlab.destroy.extraArgs": "--graceful --cleanup",
  "containerlab.node.execCommandMapping": {
    "nokia_srlinux": "sr_cli",
    "arista_ceos": "Cli"
  },
  "containerlab.editor.interfacePatternMapping": {
    "nokia_srlinux": "e1-{n}",
    "cisco_xrd": "Gi0-0-0-{n}"
  }
}

Monitor Deployment Progress

When deploying labs, you can monitor the detailed progress in the Output window:

1. Open the Output panel (Ctrl+Shift+U or View -> Output)
2. Select "Containerlab" from the dropdown menu
3. Watch the deployment logs in real-time

Auto-refresh Behavior

• The Containerlab Explorer automatically refreshes based on the containerlab.refreshInterval setting
• Labs are consistently sorted:
  • Deployed labs appear before undeployed labs
  • Within each group (deployed/undeployed), labs are sorted by their absolute path

Known Issues

"I do not see any interfaces on my deployed lab"

Labs deployed with containerlab versions older than 0.64.0 may require a redeploy.

Running Tests

The extension includes a suite of unit tests located in the test folder. To run them:

1. Install dependencies with npm install if you haven't already.
2. Compile the test TypeScript using npm run test:compile.
3. Execute npm test to run Mocha and generate an HTML report in mochawesome-report.

See test/README.md for a short overview of the test setup and stub utilities.

Feedback and Contributions

If you’d like to request features or report issues:

• Open an issue on our GitHub repository.

• PRs are welcome! Let us know how we can improve the extension.

• GitHub Issues: Create an issue on GitHub.

• Discord: Join our Discord community

Enjoy managing your containerlab topologies directly from VS Code!
