NAB AL Tools

This extensions is a tool that helps with AL development.

Table of Contents

Features

• XLIFF Tools
  • NAB: Refresh XLF files from g.xlf
  • NAB: Match translations from external XLF file
  • NAB: Find next untranslated text (Ctrl+Alt+U)
  • NAB: Find untranslated texts
  • NAB: Find multiple targets in XLF files
  • NAB: Find translated texts of current line
  • NAB: Find code source of current line ("F12" in xlf files)
  • NAB: Sort XLF files as g.xlf
  • NAB: Update g.xlf
  • NAB: Update all XLF files
  • NAB: Copy <source> to <target>
  • NAB: Download Base App Translation files
  • NAB: Match Translations From Base Application
  • NAB: Create translation XLF for new language
  • Work with Dynamics 365 Translation Service (DTS)
• Documentation
  • NAB: Generate External Documentation
  • NAB: Generate ToolTip Documentation
• Command Line Interface
• Other Features
  • NAB: Edit Xliff Document
  • NAB: Export Translations to .csv
  • NAB: Import Translations from .csv
• Snippets

Requirements

Extension Settings

Contributing

Features

XLIFF Tools

The workflow for working with these XLIFF tools are

1. Write your code
2. Build your app, so that the g.xlf file gets updated
3. Execute "NAB: Refresh XLF files from g.xlf" from the Command Palette
4. Execute "NAB: Find next untranslated text" from the Command Palette and handle the untranslated/modified translation until you've handled them all

NAB: Refresh XLF files from g.xlf

Iterates the g.xlf file and updates all language xlf files. The default behavior is to insert the tags mentioned below. If the setting NAB.UseExternalTranslationTool == true the state attribute of <target> is modified instead.

• The xlf files gets the same ordering as g.xlf
• Translations marked as translate=no gets removed
• Modified translations gets prefixed with [NAB: REVIEW] or <target state="needs-adaptation">.
• New translations with the same source language as g.xlf gets copied to target, but prefixed with [NAB: REVIEW] or <target state="needs-review-translation">.
• New translations with other source language than g.xlf is replaced with [NAB: NOT TRANSLATED] or <target state="new">
• If the setting NAB.MatchTranslation is enabled and a not translated text is found, it tries to match the source texts to find if this text has been translated before. Read more in the NAB.MatchTranslation setting.
• If a translation tag ([NAB: NOT TRANSLATED], [NAB: REVIEW] and [NAB: SUGGESTION]) is added, there is also an added note that explains why this is done. The note can be identified by the "from" attribute that is set to "NAB AL Tools". If this note exists when the NAB: Refresh XLF files from g.xlf is executed again and the translation tag is removed, this note will be removed.
  • If the setting NAB.UseExternalTranslationTool is enabled this note is added as well. The note is then removed when the target state attribute is set to "translated".

Please create an issue if you have an opinion of how the target states should be used or if you wish to see more functionality that improves the workflow when working with translation tools.

NAB: Match translations from external XLF file

Works similar as NAB: Refresh XLF files from g.xlf, but you will first need to select another xlf file to use for matching (read more about matching in the NAB.MatchTranslation setting documentation).

• Only xlf files with the same target language as the selected xlf file will be modified.

NAB: Find next untranslated text (Ctrl+Alt+U)

Finds the next occurrence of the tags [NAB: NOT TRANSLATED] or [NAB: REVIEW] and selects the tag.

• If the tag [NAB: NOT TRANSLATED] is selected, replace it with the translated text
• If the tag [NAB: REVIEW] is selected, review the translation and update if needed, then you remove the tag
• If the tag [NAB: SUGGESTION] is selected, review the suggested translation (added by source matching) and update if needed, then you remove the tag

If the setting NAB.UseExternalTranslationTool is set to true it searches for any target with a state that is considered not completed. Which is any state except final, signed-off, translated. The [NAB:*]-tags are not used when this setting is activated.

NAB: Find untranslated texts

Uses the Find in Files feature to search for translation units in need of review or translation. Please read Known Issues below.

NAB: Find multiple targets in XLF files

Use this command to find all places where you've got multiple targets, caused by the matching finding multiple sources with different translations Please read Known Issues below.

NAB: Find translated texts of current line

Place the cursor on a AL code line that should be translated and execute this command to find any translations of the selected line. If there are only one translation file, the translation file will be opened with the translation selected. If there are more than one translation file (or if the translation could not be found in the only translation file), the Find in Files feature will be used to find all occurrences of the translations. Please read Known Issues below.

NAB: Find code source of current line ("F12" in xlf files)

Place the cursor somewhere in a trans-unit node in the xlf file and execute this command to navigate to the source code for that translation.

NAB: Sort XLF files as g.xlf

Updates all language xlf files with the same sorting as the g.xlf file

NAB: Copy <source> to <target>

Copies the content of the <source> element to the <target> element. Use this when positioned on a target line in a xlf file.

NAB: Update g.xlf

Updates the g.xlf file from AL files. Practical if you need to update translations when you don't have all symbols to compile the solution. All new trans-units will be placed in the bottom of the g.xlf file. When a build is done later, the g.xlf will be sorted in the correct way. Use the functions NAB: Sort XLF files as g.xlf or NAB: Refresh XLF files from g.xlf to sort the translated files in the same way as g.xlf. The only case where this function will remove an existing trans-unit from the g.xlf file is if a text has been changed to Locked = true.

Note: This function relies completely on text matching (hence no need for symbols). This has a couple of consequences:

• Make sure that the code is correctly formatted. Use the auto format functionality from the AL Language extension for this.
• There are probably cases that we just don't support yet. If you find one, please report an issue at GitHub with as much info as possible for us to reproduce the issue (the AL file, the g.xlf file etc.)

NAB: Update all XLF files

Runs the feature NAB: Update g.xlf followed by NAB: Refresh XLF files from g.xlf.

NAB: Download Base App Translation files

Downloads Base App translations matching the target-language of the XLF files in the current workspace. The files downloaded consists of json files with a size of 5-10mb. The files are downloaded to the VS Code extension folder and should not be visible or otherwise affect your workspace. This feature is a preview and will likely be removed in the future to be handled in the background where needed.

NAB: Match Translations From Base Application

Downloads and uses Base App translations matching the target langugage of translation files. Provides suggestions prefixed with [NAB: SUGGESTION] on untranslated trans-units where the source string is found in Base App.

Intended workflow:

• NAB: Refresh XLF files from g.xlf (*optional*)
• NAB: Match Translations From Base Application

NAB: Create translation XLF for new language

Creates and opens a new translation file for selected target language with the option to match translations from BaseApp to get you going. The new translation file is saved as <app-name>.<language-code>.xlf in workspace translation folder. Note that there is no validation of the new target language code.

Work with Dynamics 365 Translation Service (DTS)

To make the work with Dynamics 365 Translation Service (DTS) a bit easier, a few things are added. (More details can be found in issue 149)

When you want to start to work with DTS there are two things you need to do in your workspace to prepare the XLF files before you use DTS for the first time:

1. Activate the setting NAB.UseDTS
2. Add your DTS Project ID (found in the URL on DTS when you've selected a project) to the NAB.DTS ProjectId setting.
3. Execute the function NAB: Format current XLF file for DTS to format the XLF files in the same way as DTS seems to do.

Use the function NAB: Create translation XLF for new language if you want to add a new language.

After that, every time you want to translate anything with DTS, the translation flow would be something like:

1. Build your app to update the g.xlf file
2. Execute NAB: Open DTS (Dynamics 365 Translation Service) to create zip files for the xlf files in a folder called ".dts" and open DTS.
3. Upload the g.zip file on DTS
4. Upload the language xlf file (xx-YY.zip file), that was formatted as DTS above. Repeat this step for every language.
5. Let DTS do the translation
6. Download the zip file(s) with the translated xlf file(s) and save in the ".dts" folder.
7. Execute NAB: Import DTS Translations and select the output.zip files that should be imported. The xlf files in the translation folder with the same target-language that's in the selected zip files will be updated.
8. Go through all trans-units with a target-state that needs review. This extension supports at least two ways of doing this:
   1. Use the Xliff Editor
      1. Open the xlf file and execute NAB: Edit Xliff Document to open the editor.
      2. Filter on all trans-units in need of review.
      3. Review every line, modify target text if needed.
      4. Tick the "Translated" box when the translation is completed.
      5. Repeat until done.
   2. Go through the xlf file manually:
      1. Find the first trans-unit with a review need (Use Ctrl+Alt+U to quickly navigate there)
      2. Review the translation
      3. Use the function NAB: Set Translation Unit to "translated" (Ctrl+Alt+Q) to set the target state to "translated" or Use the function NAB: Set Translation Unit to "signed-off" (Ctrl+Alt+S) to set the target state to "signed-off"
      4. Now you'll be navigated to the next trans-unit that needs review.
      5. Repeat until done.

This can also be combined with the features NAB: Export Translations to .csv and NAB: Import Translations from .csv, if someone without access to the repository needs to work with the translations.

Documentation

NAB: Generate External Documentation

Generates documentation that is intended to be used as an external documentation. I.e. to be read by someone that wants to extend the app by API, Web Services or with an extension. The documentation is created as markdown files. The markdown files could be transformed to html files with the help of DocFx or other tools.

The content is generated from the AL code and the XML Comments that are written in the AL code.

In the first release the following XML Comments are supported

• <summary>
• <param>
• <returns>
• <remarks>
• <example>

The following formatting tags are supported in the first release

• <para>
• <b>
• <i>
• <c>
• <code>

The first line in the summary tag for object, procedure or event are used for all objects, procedures or events overview pages in the documentation.

There are three types of files that are created with their own index page. The different index files will only be created if there are any objects of that type.

• "Public Objects" - Objects that has either public procedures or public events. Can be Codeunits, Tables, Table Extensions, Pages, Page Extensions or Interfaces.
• "API" - API Pages and API Queries
• "Web Services" - Pages or Codeunits that are published as Web Services through a webservices.xml file

Several settings exists for customizing the documentation:

• NAB.TooltipDocsFilePath - When creating ToolTip documentation, this setting specifies the path and filename of the md file that should be used. Both absolute and relative (to the current workspace folder) can be used.
• NAB.GenerateTooltipDocsWithExternalDocs - When creating external documentation, this setting specifies if the ToolTip file should be created as well.
• NAB.DocsRootPath - When creating external documentation, this setting specifies where all md files will be created. Both absolute and relative (to the current workspace folder) can be used.
• NAB.CreateTocFilesForDocs - When creating external documentation, this setting specifies if TOC (table of contents) files should be created.
• NAB.RemoveObjectNamePrefixFromDocs - When creating external documentation, this setting will remove the specified prefix from the md files. I.e. if your objects are prefixed with "ABC ", you set this setting to "ABC" and that will be removed from the object names in the md files.
• NAB.DocsIgnorePaths - When documentation are created from al files, the files that matches the patterns specified in this setting will be ignored. The paths should use glob pattern.
• NAB.GenerateDeprecatedFeaturesPageWithExternalDocs - When creating external documentation, this setting specifies if a page with public obsoleted objects/procedures/controls should be created.
• NAB.CreateInfoFileForDocs - When creating external documentation, this setting specifies if an info.json file should be created. This file will contain version info, creation date etc.
• NAB.IncludeTablesAndFieldsInDocs - When creating external documentation, this setting specifies if all tables and fields should be included. If not enabled, only tables with public procedures will be included.
• NAB.CreateUidForDocs - When creating external documentation, this setting specifies if an UID should be created in a Yaml Header in each generated md file. The UID can then be used for linking in DocFx.

NAB: Generate ToolTip Documentation

Generates a MarkDown (.md) file with the ToolTips for all Pages and Page Extensions. All fields and action are listed per object. Empty or missing ToolTips will be included.

Fields and Actions with captions will be included in the documentation. If there are no Caption on the Page Field, the function tries to retrieve the Caption from the Source Table. This only works for tables inside the workspace.

The following naming standard in the object descriptor of Page Extensions is required to retrieve the captions from the Table Extension if there are no explicit Caption on the page field:

Pattern: pageextension [Object ID] "[Object Name]" extends "[Base Page]" // [Base Page Object Id] ([Base Table Object Id])

Example: pageextension 50000 "My Item Card" extends "Item Card" // 30 (27)

The following PageTypes are ignored:

• API
• ConfirmationDialog
• HeadlinePart
• NavigatePage
• ReportPreview
• ReportProcessingOnly
• RoleCenter
• StandardDialog
• XmlPort

Two settings can be used to ignore specific Pages or Page Extensions:

• NAB.TooltipDocsIgnorePageExtensionIds
• NAB.TooltipDocsIgnorePageIds

Formatting of XML Comments

A few functions is added to help with formatting of XML Comments.

• NAB: XML Comment - Format bold
• NAB: XML Comment - Format italic
• NAB: XML Comment - Format inline code
• NAB: XML Comment - Format code block

Command Line Interface

Some functions in this extension can be invoked from the command line with Node.js. This can for example be useful when you want to invoke a function from a pipeline.

Prerequisites

Download and install Node.js. (Tested on v14.16)

Download the latest version of NAB AL Tools manually from GitHub or VSCode Marketplace and unzip to a temporary folder, or use Get-LatestNABALTools.ps1 to automatically download and unzip.

CreateDocumentation.js

This function invokes the NAB: Generate External Documentation function from the command line.

Usage

node .\extension\dist\cli\CreateDocumentation.js <path-to-al-app-folder> <path-to-output-folder> [<path-to-workspace.code-workspace>] [<path-to-tooltip-file>]

• <path-to-al-app-folder> - The path to the folder where the app.json is located
• <path-to-output-folder> - The path to the folder where the documentation should be created
• [<path-to-workspace.code-workspace>] - The path to the .code-workspace file that is used for the app. This parameter is optional.
• [] - The path to the tooltip md file that should be updated. This parameter is optional.

All settings for the NAB AL Tool is read from the .code-workspace file if it is provided. If there are any settings in <path-to-al-app-folder>\.vscode\settings.json, they will overwrite any settings from the .code-workspace file.

CreateDocumentation.js Example

Execute this function on the app with the Workspace-file "C:\git\MyAppWorkspace\MyApp.code-workspace", the source for the app in "C:\git\MyAppWorkspace\App" (the folder containing the app.json file) and the documentation files should be created in the folder "C:\Docs\MyApp\reference". The tooltip file that should be updates is called "C:\Docs\MyApp\tooltips.md":

node .\extension\dist\cli\CreateDocumentation.js "C:\git\MyAppWorkspace\App" "C:\Docs\MyApp\reference" "C:\git\MyAppWorkspace\MyApp.code-workspace" "C:\Docs\MyApp\tooltips.md"

Other Features

NAB: Suggest ToolTips

Inserts a ToolTip stub on page fields and actions. The stub will be commented out and needs to be reviewed, updated and un-commented manually.

This function only works when you're in a file that has a Page och Page extension object.

The suggestion will copy ToolTips from any page with the same SourceTable by matching the control type, name and value.

• If it's a field we're matching with fields with the same name and value
• If it's an action we're matching with actions with the same name.

No ToolTips will be added on fields on NavigatePages or API pages

NAB: Show next suggested ToolTip

Shows the next ToolTip stub in the current Page or PageExtension. Default shortcut Ctrl+Alt+P

NAB: Uninstall dependent apps

Uninstalls dependent apps through PowerShell. Useful if you cannot install your app due to dependencies.

Only works for local installations, not Docker, not SaaS Sandbox.

NAB: Sign app file

Sign the app file (matching your current app.json). You must first have the Code Signing Certificate installed in the Current User Personal Store (Cert:\CurrentUser\My if you're importing with PowerShell).

NAB: Deploy and Run TestTool without Debugger

Useful if you're using a separate app as a test app

Requirements:

• Must be using a workspace
• The main app's workspace folder must be called "App"
• The test app's workspace folder must be called "TestApp"

When this command is executed, VSCode...

• Updates the launch.json in both App and TestApp to only contain the first configuration (the original launch.json is copied to ".vscode\launch_bak.json) to avoid the prompt
• Uninstalls all dependent apps (of your main app)
• Build and deploy Main App
• Build and deploy Test App
• Uses the first configuration in the launch.json of the TestApp to eventually launch the web client, without debugging. Tip: Configure this to run page 130401!
• Restores the original launch.json

NAB: Deploy and Run TestTool with Debugger

The same feature as above, but with debugging

NAB: Edit Xliff Document

Opens XLF-files for editing in a webview.

With the goal of reducing the clutter of XML files this feature is built for translators or non-developers in mind. Command available from right clicking a XLF-file and command palette.

Keyboard navigation:

• Arrow Up / Arrow down moves focus between lines.
• F8 copies the target text from the line above.
• TAB focus is moved between the target textarea and the complete checkbox and then the next line.
• Space can be used to toggle the complete checkbox when it's in focus.

NAB: Export Translations to .csv

Exports translation units (trans-unit elements) from a selected XLF file as tab separated values.

Steps:

1. Run NAB: Export Translations from .csv from command palette.
2. Select which XLF files to export, one or more needs to be selected.
3. File is exported.

Remarks:

• Export path:
  • If a path is set for setting NAB.XliffCSVExportPath that path is used. Otherwise it defaults to the Translation folder.
• Exported file name: [App Name].[Language].csv
• Separator: \t (TAB)
• EOL: \r\n (CRLF)

Column order:

1. Trans unit Id *
2. Source *
3. Target *
4. Developer Note
5. Max Length
6. Comment (this will be empty, used for commenting changes in Excel later on)
7. Xliff Generator Note
8. NAB AL Tool Note
9. State
10. State Qualifier

* required column.

Example

<xliff>
<file datatype="xml" source-language="en-US" target-language="sv-SE" original="AlTestApp">
    <body>
      <group id="body">
        <trans-unit id="Table 2328808854 - NamedType 12557645" size-unit="char" maxwidth="50" translate="yes" xml:space="preserve">
          <source>This is a test</source>
          <target state="final" state-qualifier="exact-match">Detta är ett test</target>
          <note from="Developer" annotates="general" priority="2">Some kind of Dev note</note>
          <note from="Xliff Generator" annotates="general" priority="3">Table MyTable - NamedType TestErr</note>
          <note from="NAB AL Tool Refresh Xlf" annotates="general" priority="3">Source has been modified.</note>
        </trans-unit>
        <trans-unit id="Page 2931038265 - NamedType 12557645" size-unit="char" translate="yes" xml:space="preserve">
          <source>Cool</source>
          <target>Sval</target>
          <note from="Developer" annotates="general" priority="2"/>
          <note from="Xliff Generator" annotates="general" priority="3">Page MyPage - NamedType TestErr</note>
        </trans-unit>
      </group>
    </body>
  </file>
</xliff>

is exported to

Id    Source    Target    Developer    Max Length    Comment    Xliff Generator Note    NAB AL Tool Refresh Xlf    State    State Qualifier
Table 2328808854 - NamedType 12557645    This is a test    Detta är ett test    Some kind of Dev note    50        Table MyTable - NamedType TestErr    Source has been modified.    final    exact-match
Page 2931038265 - NamedType 12557645    Cool    Sval                Page MyPage - NamedType TestErr

NAB: Import Translations from .csv

Imports and updates targets in translation units (trans-unit elements) of selected XLF file from a .csv file.

If the the app is configured to use an external translation tool (i.e. working with Target State attribute): Use the setting NAB.Xliff CSV Import Target State to configure how Target State should be handled during import. There are basically three type of options: Leave the State as-is, update the State from the .csv file or set the State to a configured value for all modified targets.

Requirements of the .csv file:

1. Column order must match the exported column order of NAB: Export Translations to .csv.
2. The columns in the .csv file must be separated by tabs.
3. The values in the Id and Source columns must not be modified from the exported values.

Steps:

1. Run NAB: Import Translations from .csv from command palette.
2. Select which XLF file to update.
3. Select .csv file to import.
4. File is imported, any changed target values are updated and the number of updated translation units is shown in an information box.

Snippets

• Assign text variable with CopyStr
  • Since CodeCop rule AA0139 complains on possible overflow, we need to assign text variables with a CopyStr statement
• Test Codeunit
  • Inserts a stub Test Codeunit
• Test Function
  • Inserts a stub Test Function
• Test SendNotificationHandler
  • Inserts a generic SendNotificationHandler function
• Test MessageHandler
  • Inserts a generic MessageHandler function
• Test ConfirmHandler
  • Inserts a generic ConfirmHandler function
• Declare Dictionary
  • Define variable of type Dictionary
• Declare List
  • Define variable of type List
• Declare Enum value
  • Declare enum value with caption.

Requirements

This extension requires the Microsoft AL Language Extension to fully work.

Extension Settings

This extension contributes the following settings:

• NAB.LoadSymbols: Specifies if symbols should be loaded from the .alpackages folder. This is used when documentation is generated, ToolTips are added etc.
• NAB.UseDTS: When using Dynamics 365 Translation Service, this setting makes the xliff align better with how DTS updates the xliff files.
• NAB.DetectInvalidTargets: Enables detection of some common translation mistakes. Eg. same number of OptionCaptions, blank OptionCaptions and placeholders as @1@@@@@@, #2########, %1, %2 etc . The detection will occur during several different actions, as Import from DTS or Refresh Xlf. This setting is enabled by default. If any false positives are detected (the system says it is invalid, but in fact it is correct), please log an issue on GitHub and disable this feature until it's fixed.
• NAB.MatchTranslation: If enabled, the NAB: Refresh XLF files from g.xlf function tries to match sources in the translated xlf file to reuse translations. A found match of "source" is then prefixed with [NAB: SUGGESTION] for manual review. If several matches are found, all matches are added as targets and you need delete the ones you do not want. Use NAB: Find next untranslated text (Ctrl+Alt+U) or NAB: Find multiple targets in XLF files to review all matches. This feature only works if "UseExternalTranslationTool" is disabled. Activated by default.
• NAB.MatchBaseAppTranslation: If enabled, the NAB: Refresh XLF files from g.xlf function tries to match sources in the translated xlf file with translations from the BaseApplication. A found match of source is then prefixed with [NAB: SUGGESTION] for manual review. If several matches are found, all matches are added and you need delete the ones you do not want. Use NAB: Find next untranslated text (Ctrl+Alt+U) or NAB: Find multiple targets in XLF files to review all matches. This feature only works if UseExternalTranslationTool is disabled. Disabled by default.
• NAB.TranslationSuggestionPaths: Supply any relative paths that contains xlf files that should be used when matching translations. The NAB: Refresh XLF files from g.xlf function will try to match any untranslated targets with targets in the xlf files in the provided folders that has matching target language.
• NAB.ShowXlfHighlights: If enabled, all translation tags ([NAB: NOT TRANSLATED], [NAB: REVIEW] and [NAB: SUGGESTION]) will be highlighted (Request 75). Some common issues when writing targets manually is highlighted. Details found in issue 71. Uses the style specified in NAB.XlfHighlightsDecoration.
• NAB.XlfHighlightsDecoration: Specifies the style that should be used to highlight inside xlf files.
• NAB.UseExternalTranslationTool: Modifies the state-attribute of the translation unit when running NAB: Refresh XLF files from g.xlf instead of inserting a searchable string. Useful when working with external translation software.
• NAB.ReplaceSelfClosingXlfTags: Replaces self closing tags like <tag/> with a separate closing tag </tag>. Activated by default.
• NAB.SearchOnlyXlfFiles: If enabled, the NAB:Find Untranslated texts function only searches *.xlf files. Be aware of that the *.xlf file filter remains in "Find in Files" after this command has been run. This should be enabled in large projects (as Base Application) for performance reasons.
• NAB.SigningCertificateName: The name of the certificate used to sing app files. The certificate needs to be installed to the Personal store. For instructions on how to install the pfx certificate in the Personal Store, go to Microsoft Docs.
• NAB.SignToolPath: The full path to signtool.exe, used for signing app files. If this is not set the extension tries to find it on the default locations, if the signtool.exe is not found it tries to download and install signtool.
• NAB.SigningTimeStampServer: Setup any TimeStampServer to be used when signing app files, or just use the new default one: http://timestamp.digicert.com
• NAB.Xliff CSV Export Path: sets the export path for NAB: Export Translations to .csv. Default path for export is the Translation file directory.
• NAB.Xliff CSV Import Target State Sets how the Target State property should be set when importing from a .csv file into a XLIFF file. Only the State of Targets that has been changed will get updated. This will setting will only be in effect when the setting NAB.UseExternalTranslationTool is enabled.

Contributing

You are always welcome to submit an issue on GitHub for enhancements and bugs. If you'd like to give it a swing yourself you can follow this little guide to get up and running: How To Contribute.
