TikZJax for VS Code

Render precise and beautiful TikZ diagrams directly in your Markdown files. Create mathematical diagrams, circuit schematics, chemical structures, commutative diagrams, and more — all with live preview. Works with both standard Markdown preview and Marp slide decks, with one-click export to editable PPTX.

For Marp presentations, the extension also provides a Slide Navigator with thumbnail sidebar and a speaker notes panel — features not available in the standard Marp VS Code extension.

What's New (since v0.4.0)

• External File Include — Reference TikZ files with %!include directive; auto-refreshes on file changes
• Editable PPTX Export — One-click export of Marp slides with native math objects (OMML), not images
• Slide Navigator & Speaker Notes — Thumbnail sidebar and live speaker notes panel for Marp decks
• Dark Mode Text Fix — Correct font loading and color inversion for TikZ text in dark themes
• Windows Compatibility — Fixed infinite render loop caused by CRLF line endings

Gallery

TikZ diagrams in Marp slides with one-click PPTX export

PCIe board layout

Log-log trade-off chart	Wafer die layout	Package floorplan

More TikZ diagram examples can be found in this article: Decoding the Taalas HC1 — A Quantitative Analysis

Features

• Live Preview: See your TikZ diagrams rendered in real-time as you type
• Marp Compatibility: TikZ diagrams render inside Marp slide decks (marp: true), export to editable PPTX
• Slide Navigator ✦: Thumbnail sidebar with three view modes (small/large thumbnails, outline) and click-to-navigate — synced with the main slide view
• Speaker Notes Panel ✦: Live speaker notes extracted from Marp HTML comments, displayed alongside the slide preview
• Rich Package Support: Use chemfig, circuitikz, pgfplots, tikz-cd, and more
• Dark Mode: Automatic color inversion for seamless dark theme integration
• External File Include: Reference TikZ files with %!include — keep Markdown clean, edit diagrams separately
• Smart Caching: Previously rendered diagrams load instantly
• Error Handling: Clear error messages with retry options
• Syntax Highlighting: LaTeX syntax highlighting in tikz code blocks

Quick Start

1. Create or open a Markdown file in VS Code
2. Add a tikz code block:

```tikz
\begin{document}
\begin{tikzpicture}
  \draw[thick, ->] (0,0) -- (2,0) node[right] {$x$};
  \draw[thick, ->] (0,0) -- (0,2) node[above] {$y$};
  \draw[blue, thick] (0,0) circle (1);
\end{tikzpicture}
\end{document}
```

3. Open the Markdown preview (Ctrl+Shift+V / Cmd+Shift+V)
4. Your diagram appears in the preview panel!

Marp Slide Decks

TikZ diagrams work inside Marp slide decks. Add marp: true to your frontmatter and use tikz code blocks as usual:

---
marp: true
---

# My Presentation

```tikz
\begin{document}
\begin{tikzpicture}
  \node[circle, draw] (a) at (0,0) {A};
  \node[circle, draw] (b) at (3,0) {B};
  \draw[->] (a) -- (b);
\end{tikzpicture}
\end{document}
```

Diagram sizing in Marp

Marp renders slides at a fixed 1280x720 resolution, then scales the entire slide to fit the preview pane. This means TikZ diagrams may appear smaller than in standard Markdown preview, since they occupy a smaller proportion of the 1280px-wide slide.

To make diagrams larger in Marp slides, use TikZ's scale option:

```tikz
\begin{document}
\begin{tikzpicture}[scale=2]
  \draw (0,0) rectangle (3,2);
  \node at (1.5,1) {\Large Hello!};
\end{tikzpicture}
\end{document}
```

A scale=2 factor generally makes diagrams appear at a similar visual size to the standard Markdown preview.

External File Include

Keep your Markdown clean by storing TikZ diagrams in separate .tikz files. Use the %!include directive to reference them:

```tikz
%!include diagrams/circuit.tikz
```

The included file should contain complete TikZ code (with \begin{document} / \end{document}):

% diagrams/circuit.tikz
\usepackage{circuitikz}
\begin{document}
\begin{circuitikz}
  \draw (0,0) to[battery1, l=$V$] (0,3)
        to[R=$R_1$] (3,3)
        to[R=$R_2$] (3,0)
        -- (0,0);
\end{circuitikz}
\end{document}

• Relative paths are resolved from the Markdown file's directory
• Absolute paths are also supported
• Auto-refresh: The preview updates automatically when you edit and save the included file
• Per-file caching: Unchanged files are not re-read or re-rendered

This is especially useful for AI-assisted workflows — each diagram can be maintained independently in its own file.

Usage

Basic TikZ Diagram

Create geometric shapes and drawings:

```tikz
\begin{document}
\begin{tikzpicture}
  % Rectangle
  \draw[thick] (0,0) rectangle (2,1.5);

  % Circle
  \draw[fill=blue!20] (4,0.75) circle (0.75);

  % Triangle
  \draw[fill=red!20] (6,0) -- (7.5,0) -- (6.75,1.5) -- cycle;
\end{tikzpicture}
\end{document}
```

Graph with Nodes

```tikz
\begin{document}
\begin{tikzpicture}[node distance=2cm]
  \node[circle,draw] (A) {A};
  \node[circle,draw] (B) [right of=A] {B};
  \node[circle,draw] (C) [below of=A] {C};
  \node[circle,draw] (D) [right of=C] {D};

  \draw[->] (A) -- (B);
  \draw[->] (A) -- (C);
  \draw[->] (B) -- (D);
  \draw[->] (C) -- (D);
\end{tikzpicture}
\end{document}
```

Supported Packages

The extension supports a wide range of LaTeX packages for specialized diagrams:

Chemistry - chemfig

Draw chemical structures and molecules:

```tikz
\usepackage{chemfig}
\begin{document}
\chemfig{H_3C-CH_2-OH}
\end{document}
```

Circuits - circuitikz

Create electronic circuit diagrams:

```tikz
\usepackage{circuitikz}
\begin{document}
\begin{circuitikz}
  \draw (0,0) to[battery1, l=$V$] (0,3)
        to[R=$R_1$] (3,3)
        to[R=$R_2$] (3,0)
        -- (0,0);
\end{circuitikz}
\end{document}
```

Plots - pgfplots

Plot mathematical functions and data:

```tikz
\usepackage{pgfplots}
\pgfplotsset{compat=1.18}
\begin{document}
\begin{tikzpicture}
  \begin{axis}[
    xlabel=$x$,
    ylabel=$y$,
    domain=-2:2,
    samples=100
  ]
    \addplot[blue, thick] {x^2};
    \addplot[red, thick] {x^3};
  \end{axis}
\end{tikzpicture}
\end{document}
```

Commutative Diagrams - tikz-cd

Create category theory diagrams:

```tikz
\usepackage{tikz-cd}
\begin{document}
\begin{tikzcd}
  A \arrow[r, "f"] \arrow[d, "g"] & B \arrow[d, "h"] \\
  C \arrow[r, "k"] & D
\end{tikzcd}
\end{document}
```

3D Diagrams - tikz-3dplot

Draw three-dimensional figures:

```tikz
\usepackage{tikz-3dplot}
\begin{document}
\tdplotsetmaincoords{60}{110}
\begin{tikzpicture}[tdplot_main_coords]
  \draw[thick,->] (0,0,0) -- (3,0,0) node[anchor=north east]{$x$};
  \draw[thick,->] (0,0,0) -- (0,3,0) node[anchor=north west]{$y$};
  \draw[thick,->] (0,0,0) -- (0,0,3) node[anchor=south]{$z$};
\end{tikzpicture}
\end{document}
```

Mathematics - amsmath, amstext, amsfonts, amssymb

Full support for advanced mathematical notation and symbols.

Arrays - array

Create complex array and table structures within diagrams.

Commands

Access these commands via the Command Palette (Ctrl+Shift+P / Cmd+Shift+P):

Command	Description
TikZ: Open TikZ Preview	Open the preview panel to see rendered diagrams
TikZ: Refresh TikZ Diagrams	Re-render all diagrams in the current document
TikZ: Clear TikZ Cache	Clear cached diagrams and force fresh rendering
TikZ: Reset TikZJax Engine	Reset the rendering engine (useful after errors)
TikZ: Toggle Slide Thumbnails	Show/hide the slide thumbnail sidebar in Marp preview
TikZ: Export Marp Slides to PPTX	Export the current Marp deck to editable PPTX
TikZ: Toggle Speaker Notes Export	Toggle whether speaker notes are included in PPTX export

All commands are available when editing Markdown files.

Configuration

Customize the extension behavior through VS Code settings:

tikzjax.marpPptxNotes

Type: boolean Default: true

Include speaker notes (HTML comments <!-- ... -->) when exporting Marp slides to PPTX. When enabled, notes appear in the PowerPoint notes pane for each slide. Toggle quickly with the TikZ: Toggle Speaker Notes Export command.

{
  "tikzjax.marpPptxNotes": true
}

tikzjax.invertColorsInDarkMode

Type: boolean Default: true

Automatically invert diagram colors when using a dark theme. Black colors become the current text color, and white colors match the background.

{
  "tikzjax.invertColorsInDarkMode": true
}

tikzjax.renderTimeout

Type: number (milliseconds) Default: 15000 Range: 1000 - 60000

Maximum time to wait for a diagram to render before timing out. Increase this for complex diagrams.

{
  "tikzjax.renderTimeout": 20000
}

tikzjax.autoPreview

Type: boolean Default: false

Automatically open the preview panel when opening a Markdown file containing TikZ diagrams.

{
  "tikzjax.autoPreview": true
}

tikzjax.previewPosition

Type: "side" | "below" | "window" Default: "side"

Default position for the preview panel:

• "side": Open beside the editor (recommended)
• "below": Open below the editor
• "window": Open in a separate window

{
  "tikzjax.previewPosition": "side"
}

Marp Slide Navigator

When previewing a Marp slide deck, a slide navigator appears in the preview pane:

• Thumbnail sidebar: Click the hamburger button (top-left) to open. Thumbnails stay synced with your scroll position.
• Three view modes: Switch between small thumbnails, large thumbnails, and outline view using the toolbar icons.
• Speaker notes: Toggle the notes panel from the toolbar to see speaker notes for the current slide. Notes are extracted from HTML comments in your Markdown (<!-- Your notes here -->). Use TikZ: Toggle Speaker Notes Export to control whether notes are included in PPTX export.
• Click to navigate: Click any thumbnail or outline item to smoothly scroll to that slide.
• Command palette: Use TikZ: Toggle Slide Thumbnails to toggle the sidebar.

Export Marp Slides to Editable PPTX

For Marp slide decks containing TikZ diagrams, you can export directly to editable PPTX from VS Code. When a Marp file is open (marp: true in frontmatter), an export button appears in the editor title bar — visible in both the editor and preview modes.

Click the button to:

1. Render all TikZ diagrams to SVG
2. Run marp-cli with --pptx-editable to produce an editable .pptx file
3. Post-process the PPTX to inject native math objects and fix layout
4. Save the output next to the source file (timestamped)

The exported PPTX contains editable text and shapes — not just images. CSS backgrounds, images, and colored slide backgrounds are preserved. The export shows progress in a notification with cancel support, and offers "Open File" / "Reveal in Finder" actions on completion.

Math Formula Support in PPTX

LaTeX math formulas ($...$ inline and $$...$$ display) in Marp slides are converted to native PowerPoint math objects (OMML) — not images. This means formulas are fully editable in PowerPoint and render crisply at any zoom level.

• Display math ($$...$$) is centered and automatically given sufficient vertical space
• Inline math spacing with \quad, \qquad is preserved
• Bold/italic math (\mathbf, \mathit) uses native PowerPoint bold/italic styling
• Accents (\hat, \tilde, \vec, etc.) render correctly using combining diacritics
• N-ary operators (\sum, \prod, \int, etc.) with limits render as native PowerPoint nary elements

Prerequisites: Install marp-cli (npm install -g @marp-team/marp-cli) and LibreOffice (required for editable PPTX conversion).

CLI Export

You can also export from the command line using the bundled marp-tikz.js script:

node marp-tikz.js slides.md -- --pptx --allow-local-files --html
node marp-tikz.js slides.md -- --pdf --allow-local-files --html

Tips and Tricks

Multiple Diagrams

You can include multiple tikz code blocks in a single Markdown file. Each diagram renders independently.

Error Handling

If a diagram fails to render, the extension displays an error message inline. Common issues:

• Syntax errors: Check your LaTeX syntax
• Missing packages: Ensure you've included the correct \usepackage{} statement
• Timeout: Increase tikzjax.renderTimeout for complex diagrams

Use the Retry button or Reset TikZJax Engine command to recover from errors.

Performance

• Caching: Rendered diagrams are cached automatically. Unchanged diagrams load instantly.
• Incremental Updates: Only modified diagrams are re-rendered when you edit.
• Clear Cache: Use the Clear TikZ Cache command if you need to force re-rendering.

Dark Mode

The extension automatically adjusts diagram colors for dark themes. If you prefer original colors, disable this feature:

{
  "tikzjax.invertColorsInDarkMode": false
}

Troubleshooting

Diagrams not rendering

1. Ensure you're editing a Markdown file (.md extension)
2. Check that your code block uses the tikz language identifier
3. Open the Markdown preview (Ctrl+Shift+V / Cmd+Shift+V)
4. Check the error message if displayed

Slow rendering

1. Increase the timeout: "tikzjax.renderTimeout": 30000
2. Simplify complex diagrams
3. Use the cache — unchanged diagrams load instantly

Preview not updating

1. Use TikZJax: Refresh TikZ Diagrams to force an update
2. Try TikZJax: Reset TikZJax Engine if issues persist
3. Close and reopen the preview panel

Colors look wrong in dark mode

1. Toggle tikzjax.invertColorsInDarkMode setting
2. Use explicit colors in your diagrams if needed
3. Refresh the preview after changing themes

Requirements

• VS Code 1.85.0 or higher
• No internet connection required — rendering is fully offline
• For editable PPTX export (optional):
  • marp-cli v4.1.0+ (npm install -g @marp-team/marp-cli)
  • LibreOffice (used by marp-cli for ODP→PPTX conversion)

License

MIT License - see LICENSE.md for details.

Acknowledgments

• node-tikzjax by @drgrice1 - Server-side TikZ rendering engine
• obsidian-tikzjax by @artisticat1 - Original Obsidian plugin
• TikZJax by @kisonecat - Browser-based TikZ compiler

---

Enjoy creating beautiful diagrams! If you encounter issues or have suggestions, please file an issue on GitHub.
