OpenCV Debug C++

A Visual Studio Code extension for visualizing OpenCV data structures during C++ debugging.

Modifications based on CV DebugMate C++ .

Usage

1. Start a C++ debug session in VS Code
2. Set a breakpoint where OpenCV variables are in scope
3. In the Variables or Watch panel, right-click on a supported variable (cv::Mat or std::vector<cv::Point3f>)
4. Select "Show Image Data" from the context menu
5. The visualization will open in a new tab

Features

🖼️ Mat Visualization

• View cv::Mat images directly in VS Code during debugging
• Support for grayscale, RGB, and multi-channel images
• Support for various data types: CV_8U, CV_32F, CV_64F, etc.
• Zoom in/out with mouse wheel
• Pan by dragging
• Pixel value display on hover
• Grid overlay when zoomed in

📊 Point Cloud Visualization

• View std::vector<cv::Point3f> as 3D point clouds
• Interactive 3D rotation with mouse
• Powered by Three.js

💾 Export Options

• Save PNG: Export image as PNG file
• Save TIFF: Export image as TIFF file (supports floating-point data)

Screenshots

Mat Visualization

Point Cloud Visualization

Supported Debuggers

Known Limitations

• cppvsdbg license: If you are using closed-source VS Code forks like Cursor, Qoder, or similar IDEs, you may need to use CodeLLDB for debugging MSVC-compiled code, as cppvsdbg may not be available in these environments. Note that point cloud visualization will not work in this case due to LLDB's limited support for MSVC STL.

Supported Types

cv::Mat

• Grayscale images (1 channel)
• Color images (3 channels, BGR)
• RGBA images (4 channels)
• Depth types: CV_8U, CV_8S, CV_16U, CV_16S, CV_32S, CV_32F, CV_64F

Point Clouds

• std::vector<cv::Point3f>
• std::vector<cv::Point3d>

Keyboard & Mouse Controls

Image Viewer

3D Point Cloud Viewer

How It Works

Overview

CV DebugMate C++ leverages the VS Code Debug Adapter Protocol (DAP) to extract and visualize OpenCV data structures during active debugging sessions. The extension acts as a bridge between the debugger and custom visualization UI.

Key Concepts

1. Debug Adapter Protocol (DAP)

• What: A standardized protocol for communication between VS Code and debuggers
• Role: Provides APIs to inspect variables, evaluate expressions, and read memory during debugging
• Supported Debuggers: Works with any DAP-compliant debugger (cppvsdbg, cppdbg, CodeLLDB)

2. Variable Inspection Pipeline

Step 1: Context Menu Trigger

• User right-clicks on a variable (cv::Mat or std::vector<cv::Point3f>) in Variables/Watch panel
• Extension receives the variable's metadata (name, type, value, variablesReference)

Step 2: Type Detection

• On Windows (MSVC): Type information available directly from the debugger
• On macOS/Linux (LLDB): Extension calls evaluate() request to get full type information
• Regex matching identifies supported types: cv::Mat, std::vector<cv::Point3f>, etc.

Step 3: Data Extraction

For cv::Mat:

1. Extract metadata via DAP variables request:
   - rows, cols (image dimensions)
   - channels (1=grayscale, 3=BGR, 4=BGRA)
   - depth (CV_8U, CV_32F, etc.)
   - step (bytes per row)

2. Get data pointer address:
   - Evaluate expression: mat.data
   - Parse memory address (e.g., 0x12345678)

3. Read raw image data:
   - Use DAP readMemory() request
   - Calculate total bytes: rows × step
   - Data returned as Base64-encoded buffer

4. Decode and render:
   - Decode Base64 → raw bytes
   - Parse according to depth/channels
   - Render to HTML5 Canvas

For Point Clouds:

1. Parse vector size from debug info:
   - Extract from value string: "{ size=1234 }"

2. Attempt fast path (readMemory):
   - Get data pointer: vec.data()
   - Read all points at once: size × 12 bytes (3 floats)
   - Parse binary data: [x1,y1,z1, x2,y2,z2, ...]

3. Fallback path (variables request):
   - If readMemory fails, iterate through vector elements
   - Expand [0], [1], [2], ... via variablesReference
   - Parse each Point3f's x, y, z fields
   - Stop when reaching target size

4. Validate points:
   - Only accept objects with all three fields (x, y, z)
   - Respect size limit to avoid phantom points

5. Render with Three.js:
   - Create BufferGeometry with point positions
   - Apply color mapping (solid/by axis)
   - Interactive 3D controls

3. Webview Rendering

• Extension creates a VS Code Webview panel
• HTML/JS/CSS injected with visualization UI
• For images: HTML5 Canvas with pan/zoom controls
• For point clouds: Three.js WebGL renderer
• Data passed from extension → webview via message passing

Architecture Diagram

    User Action (Right-click variable)
         |
         v
   [Extension Host] ────────────> [Debug Adapter]
         |                            |
         |  1. Get variable metadata  |
         |  2. Evaluate expressions   |
         |  3. Read memory (DAP)      |
         |<───────────────────────────|
         |
         v
   [Data Parser]
    - Mat: Extract rows/cols/data pointer
    - PointCloud: Parse size, read points
         |
         v
   [Webview Panel]
    - Canvas (Mat)
    - Three.js (PointCloud)
         |
         v
   User sees visualization

Platform Differences

Note: LLDB + MSVC combination has limited STL support, making vector parsing unreliable.

Implementation Details by Debugger

1. cppvsdbg (Windows MSVC)

• Mat Visualization: Uses variablesReference to get metadata, then evaluates mat.data to get pointer
• Point Cloud Visualization:
  • Fast path: Evaluates &vec[0] to get data pointer, then uses readMemory to read all points at once
  • Fallback: Uses variablesReference with [More] expansion for large vectors

2. cppdbg (Linux/macOS GDB)

• Mat Visualization: Same approach as cppvsdbg
• Point Cloud Visualization:
  • Fast path: Evaluates vec._M_impl._M_start (GDB's internal structure) to get data pointer, then uses readMemory
  • Fallback: Same as cppvsdbg

3. lldb (CodeLLDB)

• Mat Visualization: Uses evaluate() to get full type information, then reads data via memory
• Point Cloud Visualization:
  • Due to LLDB's limited support for MSVC STL, vec.size() often returns 0
  • Must use variablesReference approach, iterating through elements
  • Performance is slower for large point clouds due to multiple DAP requests

Installation

From VSIX

1. Download the .vsix file
2. In VS Code, go to Extensions view (Ctrl+Shift+X)
3. Click ... menu → "Install from VSIX..."
4. Select the downloaded file

From Source

git clone <repository-url>
cd cv-visualizer
npm install
npm run compile
# Press F5 to run in Extension Development Host

Requirements

• VS Code 1.93.0 or higher
• A C++ debugger extension:
  • C/C++ Extension (for cppdbg/cppvsdbg)
  • CodeLLDB (for lldb)

Acknowledgments

This extension is modifications based on CV DebugMate C++, a popular Visual Studio Code extension for viewing images during debugging, meanwhile it's available for cross-platform C++ development.

License

MIT

Contributing

Contributions are welcome! Please feel free to submit issues and pull requests.
