VSCode Layered Settings

"Onions have layers. Ogres have layers. Onions have layers... You get it? We both have layers."

— Mike Myers dba Shrek

A VSCode extension that lets you split your settings.json into multiple Jsonnet files and automatically merges them together.

Install it from the VSCode extension marketplace.

Look at this VSCode issue for background on what problem this tries to solve.

Prerequisites

Install the Jsonnet CLI:

# macOS
brew install jsonnet

# or from source
go install github.com/google/go-jsonnet/cmd/jsonnet@latest

Optionally, install the Jsonnet NG extension to get syntax highlighting.

Quickstart

1. Install the extension and the prerequisites above. Make sure you're not working in a remote VSCode session.
2. Run "Preferences: Open User Settings (JSON)" from the command palette.
3. In the settings.json file that opens, run "File: Save As..." from the command palette.
4. Name the file settings.original.jsonnet and save.

After these steps, any changes you make to settings.original.jsonnet will be merged into settings.json. If you manually edit settings.json to be different from settings.original.jsonnet, those manual changes will be preserved; see below for merge semantics. You can check settings.original.json into version control.

Use-cases

Sharing settings between machines

1. Run "Preferences: Open User Settings (JSON)" in the command palette; this will open settings.json.
2. Create settings.60_user.jsonnet next to this settings.json file.
3. Copy settings that you want to share from settings.json into settings.60_user.jsonnet.
4. Check settings.60_user.jsonnet into your dotfiles repo, like this.
5. After syncing settings.60_user.jsonnet to a new machine, run "Layered Settings: Overwrite settings.json" from the command palette.

Then, when extensions dump random non-config state into your settings.json, it stays there and doesn't need to be added to your dotfiles.

Defining default settings for your team and allowing individuals to override them

1. Create <git root>/.vscode/settings.20_team.jsonnet in your team's shared repo.
2. Users can change settings in <git root>/.vscode/settings.json and their changes will take precedence.
3. Optionally, users can create e.g. <git root>/.vscode/settings.60_user.jsonnet to have more control over their settings.

Defining base settings for a monorepo and allowing sub-projects to override them

1. Create <git root>/.vscode/settings.20_team.jsonnet with common org-wide settings.
2. In each sub-project, symlink <git root>/.vscode/settings.20_team.jsonnet to <git root>/subproject/.vscode/settings.20_team.jsonnet and also create <git root>/subproject/.vscode/settings.40_project.jsonnet.

Why jsonnet?

Jsonnet has a built-in grammar for extending objects from other objects with its +: syntax. This allows things like

# settings.20_team.jsonnet
{
    abc: {
        def: 1,
        ghi: 2,
    }
}

# settings.60_user.jsonnet
{
    abc+: {
        def: 3,
    }
}

which merges to

// settings.json
{
    "abc": {
        "def": 3,
        "ghi": 2,
    }
}

How are settings combined?

Whenever any settings.*.jsonnet file changes, the extension automatically:

1. Combines all settings.*.jsonnet files by sorting them lexicographically and combining them with Jsonnet's + operator.
2. Diffs settings.json and the previous result of combining settings.*.jsonnet (before your change) to capture any manual edits you've made.
3. Applies that diff on top of the new combined file.
4. Writes the result to settings.json and the new combined settings.*.jsonnet file to settings_generated.json.

This means you can still edit settings.json directly in VS Code's settings UI — your manual changes are preserved across merges.

The settings_generated.json file tracks the result of combining the settings.*.jsonnet files, so that the extension knows what you manually edited in settings.json. You should not edit this file.

This merging process means that if a setting differs between settings.json and settings.*.jsonnet, it will be "sticky": changing settings.*.jsonnet won't have any effect on it. If you update settings.json to match settings.*.jsonnet (or run "Layered Settings: Overwrite settings.json" to do this for all settings), the setting will then "unstick" and start tracking settings.*.jsonnet.

Scopes

Layered settings work in user, workspace, and remote settings directories.

If you use VSCode remotely, the extension will install on the remote host and will only be able to manage the workspace and remote settings. To manage the client-side user settings, open a new non-remote window and also install the extension there. The local user settings.*.jsonnet files will only be auto-merged into the local user settings.json file while you have a local VSCode window open. This is a limitation of VSCode extensions.

Commands

• Layered Settings: Generate Diff — Show a read-only Jsonnet overlay representing the diff between settings.*.jsonnet and settings.json, useful for seeing what manual edits exist
• Layered Settings: Overwrite settings.json — Overwrite settings.json with the combined settings.*.jsonnet files, discarding all manual edits

Development

npm install
npm run compile   # build with esbuild
npm run check     # type-check
npm run test      # run tests
npm run watch     # rebuild on change
npm run package   # produce .vsix
