CatGo VSCode Extension

CatGo offers a VSCode extension for rendering crystal structures and molecular dynamics (MD) or geometry optimization trajectories directly in the editor to speed up typical materials science/computational chemistry workflows.

Scope — what's in the extension vs the desktop client

The extension embeds CatGo's real interactive viewer (the same Structure and Trajectory components as the app), so it does much more than display files:

In the extension (the full single-window viewer): view & animate · edit (move / add / delete atoms, bonds, lattice, selection, measurement, undo/redo, right-click menu) · the structure toolbar — builders, analysis panes, OPTIMADE / PubChem import · save & export (format-preserving input decks) · display/theme customization · remote-SSH file viewing. CatBot and compute/database features that need a backend activate once you configure an LLM provider and/or download the optional catgo-server sidecar.

Desktop client only — the surrounding workbench shell, which the extension does not load: the multi-pane tabbed workspace (tabs / split-view / pop-out windows), the standalone visual workflow DAG editor, and the HPC terminal & job manager.

For the full workbench use the CatGo desktop client (Windows / macOS / Linux) or the web app.

✨ Features

🔬 Structure Visualization

Reads most codes, not just CIF/POSCAR — open the inputs and outputs of VASP, Quantum ESPRESSO, CP2K, ABACUS, ORCA, Gaussian, CASTEP, SIESTA, OpenMX and LAMMPS (see Supported File Formats)
Crystals & molecules — periodic slabs, bulk and isolated molecules alike
Cross-cell PBC bonds — bonds rendered correctly across periodic boundaries, with image atoms
Symmetry — moyo-driven space group + Wyckoff positions
Charge density — cube / VASP CHGCAR-family isosurfaces
Interactive 3D Viewer — rotate, zoom-to-cursor, measure, ortho/perspective cameras

🎬 Trajectory Analysis

MD / optimization / NEB / IRC — animate ASE .traj, VASP XDATCAR/OUTCAR/vasprun.xml, LAMMPS dumps, extXYZ, HDF5 and pymatgen JSON
Timeline scrubbing — frame-by-frame navigation with energy / force / per-atom property overlays
Per-frame bonds — connectivity recomputed each frame
Frame export — pull any frame out as a structure file

🎨 Customization

Color Schemes: Multiple built-in color schemes (Jmol, VESTA, Alloy, Pastel, etc.)
Visualization Modes: Ball-and-stick, space-filling, wireframe representations
Export Options: Save visualizations to PNG or export structure data to ASE XYZ and pymatgen JSON

🚀 Installation

Search for "CatGo" in the VS Code Extensions marketplace.

📋 Usage

Quick Start

Open a structure file in VS Code (.cif, .poscar, .xyz, .json, etc.)
Right-click in the explorer or editor
Select "Render with CatGo" from the context menu
Or use the keyboard shortcut: Ctrl+Shift+V (Windows/Linux) / Cmd+Shift+V (Mac)

Supported File Formats

Anything CatGo can parse renders here — far beyond CIF/POSCAR. Use right-click → Render (or Ctrl/Cmd+Shift+V) on any of the following.

Structures, by code

Code	Files
VASP	POSCAR · CONTCAR · `.vasp` · vasprun.xml · OUTCAR · CHGCAR/AECCAR/LOCPOT/ELFCAR (isosurface)
Quantum ESPRESSO	pw.x input (`.in`)
CP2K	`.inp` · `.restart`
ABACUS	STRU
ORCA	`.inp` · `.out`
Gaussian	`.gjf` / `.com` · `.log` / `.out` · cube
CASTEP	`.cell`
SIESTA	`.fdf`
OpenMX	`.dat`
LAMMPS	`.data` / `.lmp`
phonopy	YAML
Generic	CIF · mCIF · XYZ · extXYZ · mol2 · PDB · pymatgen / OPTIMADE JSON

Trajectories

ASE .traj (binary)
VASP XDATCAR, OUTCAR, vasprun.xml (multi-step)
LAMMPS dump / .lammpstrj
extXYZ multi-frame
HDF5 / H5 — torch-sim & VASP vaspout.h5
pymatgen JSON frames
.gz-compressed variants of the above

Custom Editor Integration

CatGo automatically registers as a custom editor for trajectory files such as .traj, .h5, .hdf5, .xyz.gz, etc.

Remote SSH Support

CatGo supports VSCode/Cursor remote SSH connections. Connect to your server via Remote SSH extension, and CatGo should work just like it does locally.

✅ Remote file access: Visualize structures and trajectories on remote servers (HPC clusters, cloud instances, etc.)
✅ No manual file transfer: Files are read directly from the remote filesystem
✅ File watching: Changes to remote files are automatically detected and reloaded
⚠️ File size limit: Files are currently limited to 1GB to prevent memory issues. Larger files are streamed in chunks which is only supported locally, not via remote SSH.

⚙️ Configuration & Customization

CatGo provides extensive customization options through VSCode settings. Access these via:

Settings UI: File → Preferences → Settings → Search for "CatGo"
JSON Settings: Ctrl+Shift+P → "Preferences: Open Settings (JSON)"

Common Configuration Scenarios

🎨 Visual Appearance

{
  "catgo.color_scheme": "Jmol",
  "catgo.background_color": "#ffffff",
  "catgo.background_opacity": 0.8,
  "catgo.structure.show_image_atoms": true,
  "catgo.structure.atom_radius": 1.2,
  "catgo.structure.bond_thickness": 0.8
}

🎬 Trajectory Playback

{
  "catgo.trajectory.auto_play": true,
  "catgo.trajectory.fps": 10,
  "catgo.trajectory.display_mode": "structure+scatter",
  "catgo.trajectory.show_controls": true
}

📊 Plot Customization

{
  "catgo.scatter.point_size": 5,
  "catgo.scatter.line_width": 3,
  "catgo.plot.grid_lines": true,
  "catgo.scatter.show_legend": true
}

🔧 Performance Optimization

{
  "catgo.trajectory.chunk_size": 500,
  "catgo.trajectory.bin_file_threshold": 10485760,
  "catgo.structure.sphere_segments": 16
}

Setting Categories

Category	Description	Example Settings
General	Global appearance and behavior	`color_scheme`, `background_color`
Structure	3D structure visualization	`atom_radius`, `bond_thickness`, `show_cell`, `lighting`, `show_image_atoms`
Trajectory	Animation and playback controls	`fps`, `auto_play`, `display_mode`, `show_controls`
Plots	Scatter plots and histograms	`scatter_point_size`, `plot_grid_lines`, `auto_fit_range`
Performance	Memory and processing options	`chunk_size`, `use_indexing`, `sphere_segments`

Pro Tips

Reset to defaults: Remove custom settings from your JSON config
Project-specific settings: Use workspace settings (.vscode/settings.json) for per-project customization
Theme integration: CatGo automatically adapts to your VSCode color theme
Performance: Reduce sphere_segments for better performance with large structures

⌨️ Keyboard Shortcuts

Ctrl+Shift+V / Cmd+Shift+V → Render structure/trajectory with CatGo

🐛 Bug Reporting

If you encounter any issues with CatGo, you can use the built-in bug reporting command to collect debug information:

Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P)
Run "Report CatGo Bug"
The command will open a new document with detailed debug information including:
- Your OS and version
- VSCode/Cursor version
- CatGo version
- Whether you're in a remote session
- Files currently being rendered
- System resources and memory usage
- Extension configuration
Copy the information and include it when creating a GitHub issue

📄 License

This extension is licensed under the GNU AGPL-3.0, matching the catgo-LRG repository.

Upstream CatGo / MatterViz: github.com/janosh/catgo
pymatviz: Jupyter/Marimo extension for Python notebooks. Read about widgets in pymatviz readme for details.

🤝 Contributing

We welcome contributions! Please see our Contributing Guide for details.

🛠️ Development

git clone https://github.com/Hello-QM/catgo-LRG
cd catgo/extensions/vscode
pnpm install
pnpm build
vsce package
