PHREEQC Runner

Run PHREEQC on the input file you are editing with one click.

Installation

You need:

VS Code 1.80 or later.
PHREEQC for Windows, installed from the USGS PHREEQC page. The default location, C:\Program Files\USGS, is found automatically.
Recommended: the PHREEQC extension by Vitor Cantarella, for syntax highlighting, autocomplete and hover help. If it isn't installed, PHREEQC Runner offers to install it at startup. Choose Don't Ask Again to stop the offer.

In VS Code, open the Extensions view (Ctrl+Shift+X), search for PHREEQC Runner and click Install. It is also on the Visual Studio Marketplace and on Open VSX. Or install it from a terminal:
```
code --install-extension Amphos21ConsultingSL.phreeqc-runner
```
Open a .pqi file: the ▷ Run PHREEQC button should appear at the top right of the editor.

If PHREEQC is installed somewhere other than C:\Program Files\USGS, run Select PHREEQC Installation Folder… from the Command Palette (Ctrl+Shift+P), or set phreeqcRunner.installationPath (see Settings).

VS Code installs updates automatically. To uninstall, go to the Extensions view, find PHREEQC Runner and click Uninstall.

Usage

Open a .pqi, .ppi, .phr or .phrq file and click the ▷ Run PHREEQC button at the top right of the editor, or press Ctrl+F5.
You can also right-click the file in the Explorer and choose Run PHREEQC. From the Command Palette, Run PHREEQC works on any file.
While a run is going, the button turns into ■ Stop PHREEQC.
Input files (.pqi, .ppi, .phr, .phrq) get the blue PHREEQC icon, and output files (.out, .pqo) the green one, in the Explorer and on editor tabs. Some file icon themes, such as Material Icon Theme, show their own icons instead. Output and database (.dat) files keep the PHREEQC extension's highlighting, but not its autocomplete or hover help.

PHREEQC runs in the input file's folder. It writes <name>.pqo next to the input, and selected output files are written there too. When the run ends, a notification shows how long it took and has buttons to open the output. Everything PHREEQC prints appears in the PHREEQC output panel. If the run fails, that panel opens automatically.

Settings

Setting	Default	Purpose
`phreeqcRunner.installationPath`	(empty)	Your PHREEQC installation folder (e.g. `C:\Program Files\USGS\phreeqc-3.7.3-15968-x64`) or the `phreeqc.exe` itself. If empty, the newest installation under `C:\Program Files\USGS` is used, then `phreeqc` on the PATH. The command Select PHREEQC Installation Folder… sets it for you.
`phreeqcRunner.database`	(empty)	Database for inputs without a `DATABASE` line: absolute, or relative to the input's folder. If empty, the installation's `database\phreeqc.dat` is used. A `DATABASE` line in the input always wins.
`phreeqcRunner.outputExtension`	`.pqo`	Extension of the output file.
`phreeqcRunner.inputExtensions`	`.pqi .ppi .phr .phrq`	Which files get the Run button and `Ctrl+F5`.
`phreeqcRunner.saveBeforeRun`	`true`	Save the input before running.
`phreeqcRunner.openAfterRun`	`output`	Open the `.pqo` (`output`) or the selected output (`selectedOutput`) after a successful run.

Notes

If PHREEQC can't open a file (for example a database named in DATABASE that doesn't exist), it asks for another name on the console. The extension then stops the run and shows the error, rather than leaving PHREEQC waiting.
The default executable is bin\Release\phreeqc.exe, which doesn't draw USER_GRAPH charts. To get charts, set the installation path to bin\ClrRelease\phreeqc.exe, the .NET build that phreeqc.bat uses. A console window then stays open while PHREEQC runs. This setup hasn't been tested.

Changing the extension

Clone the repository, edit extension.js or package.json, then build and install a local package. With Python 3 (no Node.js needed):

git clone https://github.com/amphos21-consulting/PHREEQC-Runner.git
cd PHREEQC-Runner
py package_vsix.py
code --install-extension phreeqc-runner-<version>.vsix

With Node.js you can use npx @vscode/vsce package --no-dependencies instead of py package_vsix.py.

Releasing

Every push and pull request is packaged by GitHub Actions. The .vsix can be downloaded from the run's artifacts. To publish a new version to the Visual Studio Marketplace and Open VSX:

Raise version in package.json and add an entry to CHANGELOG.md.
Merge or push the change to main.

Each push to main publishes the package to both registries and creates a GitHub release v<version> with the .vsix attached. If that version is already published, the push publishes nothing, so remember to raise version for every release. Pushes to other branches and pull requests are only packaged. The workflow needs the VSCE_PAT and OVSX_PAT secrets in the repository's release environment.

Author

Developed by Miquel de la Iglesia at Amphos 21 Consulting S.L.

License

PHREEQC Runner is free software, released under the GNU General Public License v3.0 or later.
