SVG Path Helper

A VS Code extension for hand-writing and editing SVG paths: a live preview that highlights the path segment under your cursor, cursor-aware syntax colouring inside <path d="…">, draggable points, and absolute⇄relative conversion. Runs in desktop VS Code and in the browser — vscode.dev, github.dev, code-server.

As the cursor sweeps through <path d="…">, the editor decorations and the preview overlay update together — command letters, end-point / control-point coordinates, the current segment, the selected point, control handles, and the calibrated rulers. Captured live from the extension running in VS Code for the Web.

Features

Live preview

The preview opens automatically beside an .svg file (or run SVG Path: Open Preview / click the preview icon in the editor title bar). A toolbar gives you zoom (− / % / + / Fit), the background (checkerboard / light / dark), and a grid toggle. Driven by the cursor position, the preview overlays:

• the element under the cursor — move the cursor onto any tag (<rect>, <circle>, <g>, …) and its oriented bounding box is outlined;
• the current path (faint blue outline);
• the current segment (red, thick);
• the points of the current segment — end point (red) and control points (orange, with dashed handles);
• the selected point (yellow, enlarged) when the cursor is on a coordinate.

Moving the cursor through the source outlines whatever element it lands on — the background <rect>, a transformed <g>, the path inside it, an arc.

The preview toolbar — zoom (− / % / + / Fit), background (checkerboard / light / dark), and the grid + rulers toggle.

Click to select: click an object in the preview to select its full opening tag — and the matching closing tag, if any — in the editor; right-click to get a menu of the whole stack of objects under the pointer (hover an entry to highlight it), so you can reach an element hidden behind others.

Clicking the rectangle selects its tag in the editor; right-clicking lists every object under the pointer, with hover-to-highlight.

The overlay is drawn through each path element's live CTM, so it tracks the geometry through parent <g transform>s and the path's own transform — translate, rotate, scale, skew, nested, all of it:

The purple square lives inside <g transform="translate(120 20) rotate(25) scale(0.6)">. As the cursor moves along its d, the overlay (outline, segment, selected corner) stays locked to the rendered, rotated-and-scaled shape.

Opening SVG files

VS Code opens .svg files in its built-in Image Preview by default, which has no source text for this extension to work on. To keep editing fluid:

• the SVG Path: Open Preview button reopens the current image-preview tab as source code, then opens the preview beside it;
• while the preview is open, picking another .svg in the Explorer reopens it as source too, so the preview keeps following it — built-in image preview only, third-party SVG editors are left alone (svgPathHelper.openSvgFilesAsSource);
• the preview's editor group is locked so files you open from the Explorer land in your code column instead of on top of the preview (svgPathHelper.lockPreviewGroup);
• a view-only SVG Path Studio Preview is offered under Open With… (right-click an .svg → Open With) — it shows the same preview as a tab and never changes your default .svg editor; click an element in it to open the source and select that element.

Right-click → Open With… → SVG Path Studio Preview opens the file as a preview tab (priority: "option", so your default .svg editor is untouched).

Rulers & coordinate readout

Top and left rulers are calibrated to the root viewBox coordinate space and indicate, with guide lines projected toward the rulers:

• the bounding box of the whole current path (cyan bracket + dashed box);
• the current segment's next (end) point (red caret + crosshair);
• the live mouse position (yellow caret + crosshair).

The mouse coordinates are also shown in a corner badge. For paths inside a transform the indicators are projected into root coordinates, so the rulers stay truthful even when the geometry is rotated or scaled (see the second screenshot).

Tracing the curve with the mouse: the badge reads out viewBox coordinates while the yellow carets and crosshair track the pointer on both rulers.

Cursor-aware syntax highlighting

Inside every <path d="…"> the extension colours:

• segment command letters (M, C, q, …);
• the coordinates of each end point (one colour) and control points (another colour);
• the segment under the cursor (background highlight);
• the point coordinates under the cursor (strong highlight + bold).

These are editor decorations, recomputed live — they react to cursor movement, which a static TextMate grammar cannot do.

Drag points in the preview

Grab any point of the current segment in the preview and drag it — the matching coordinate in the d attribute updates. The drag is committed as a single undo step on release, and the cursor lands on the coordinate you edited. Relative segments receive a delta from the segment start; H/V edit a single number; arcs keep their rx ry rotation large-arc sweep flags.

Dragging a cubic's control handle: the curve deforms live (with a coordinate badge) and the matching number in d is rewritten as a single undo step on release.

Absolute / relative conversion

Right-click in an .svg/XML/HTML file (or use the command palette):

• Convert selected path(s) to Absolute coordinates — easier for working with individual points.
• Convert selected path(s) to Relative coordinates — easier for moving groups of segments around.

Every <path> whose d attribute is touched by a selection (or contains a cursor) is converted. Command kinds are preserved (S stays S, H stays H); only letter case and numbers change. The first moveto is always kept absolute, per the SVG convention.

M30,30 q40,-20 80,0 t80,0 ⇄ M 30 30 Q 70 10 110 30 T 190 30 — same geometry, command kinds preserved, only case and numbers change.

Transform operations

Put the cursor on a transform="…" attribute value (or select it) and right-click — four commands appear:

1. Convert this transform to matrix() — collapse the transform list (translate/scale/rotate/skewX/skewY/matrix) of this element to a single matrix(a b c d e f).
2. Convert to matrix() (incl. nested) — same, plus every descendant's own transform.
3. Resolve (bake into geometry) — make the transform disappear by applying it to the content. The element (and basic shapes — rect, circle, ellipse, line, polyline, polygon) becomes a transform-free <path>; on a <g> the transform is pushed one level into the direct children (nested transforms are preserved, composed). Styling (presentation attributes + inline style) is carried over.
4. Resolve (incl. nested) — recursively flatten the whole subtree so no transforms remain anywhere; all shapes become baked <path>s.

<!-- before: cursor on the transform value, "Resolve" -->
<rect transform="translate(20 20) rotate(15)" x="0" y="0" width="50" height="30" rx="6" fill="#89b4fa"/>
<!-- after -->
<path fill="#89b4fa" d="M 25.8 25.2 A 6 6 0 0 1 ... Z"/>

The <g>'s translate(…) rotate(…) scale(…) is first collapsed to a single matrix(…), then resolved away entirely — the path's d is rewritten and the rendered image doesn't move a pixel.

Arcs are transformed correctly under any affine matrix (rotation, non-uniform scale, skew, reflection) via a closed-form transform of the arc's ellipse; H/V are preserved under axis-aligned matrices and become L otherwise. Open example-transforms.svg to try it.

Develop / run

npm install
npm run build      # or: npm run watch
npm test           # unit tests (node:test + tsx)

Then press F5 ("Run SVG Path Helper") to launch an Extension Development Host, open example.svg, run SVG Path: Open Preview, and move the cursor through a d attribute (or drag a point in the preview).

npm run build bundles the extension for both the Node and the browser extension hosts (dist/extension.js + dist/web/extension.js). The static figures come from tools/gen-demo.ts (the real media/preview.* + parser, shot with headless Chrome); the animated demos are captured from the real extension running in web VS Code by tools/screencast.mjs (@vscode/test-web + Playwright → GIF/APNG).

Settings

Supported path commands

M L H V C S Q T A Z in both absolute and relative forms, including implicit repeated arguments (e.g. M0 0 1 1 2 2), smooth-curve control-point reflection (S/T), and arc flag parsing.

Known limitations

• The preview renders the document's outer <svg>. Inline SVG inside HTML/JSX, and files with several <svg> blocks, are handled as the first/outer one.

Releasing

CI builds a .vsix on every run (downloadable from the run's artifacts). Pushing a version tag publishes it:

npm version patch          # bump package.json version + create the tag
git push --follow-tags     # triggers .github/workflows/publish.yml

The publish workflow packages the extension and pushes it to the VS Code Marketplace and Open VSX, then creates a GitHub Release with the .vsix. Set the repo secrets VSCE_PAT (Marketplace) and/or OVSX_PAT (Open VSX) first; whichever is missing is skipped.

License

MIT
