MLIR Inc Previewer - VS Code Extension

MLIR Inc Previewer is a powerful VS Code extension designed specifically for MLIR (Multi-Level Intermediate Representation) developers that provides intelligent previewing and management of .inc files directly within your source code.

MLIR Inc Previewer Usgae Example

0. Quick Start

Open a C/C++ file containing .inc include statements
Use one of these methods:
- Place cursor near #include "xxx.inc" and press Ctrl+Shift+U to expand a single preview block
- Press Ctrl+Shift+Y to expand all preview blocks
- Press Ctrl+S (Cmd+S for MacOS) to clean all preview blocks and save file
- Right-click -> See MLIR menu to choose one of the following actions:
  - Expand/Collapse Preview (Macro-aware)
  - Expand All Preview Content (Macro-aware)
  - Expand/Collapse Preview (Macro-unaware)
  - Expand All Preview Content (Macro-unaware)
  - Clean All Preview Content
  - Clean All and Save
  - Navigate to Next Preview
- Command palette -> Search "mlir inc" to find the MLIR Inc commands
The difference between macro-aware and macro-unaware previewing:
- The macro-unaware mode expands the full content of the .inc file, regardless of whether the content depends on macros or not.
- However, the macro-aware mode attempts to expand .inc content based on macro definitions in the current file. For example, if only GET_OP_LIST is defined, content that depends on GET_OP_CLASSES will not be expanded.
  - Please refer to this example to see the difference between macro-aware and macro-unaware previewing.

Keyboard Shortcuts

Shortcut	Action
`Ctrl+Shift+U`	Expand/Collapse Preview (Macro-aware)
`Ctrl+Shift+Y`	Expand All Preview Content (Macro-aware)
`Ctrl+Shift+J`	Expand/Collapse Preview (Macro-unaware)
`Ctrl+Shift+H`	Expand All Preview Content (Macro-unaware)
`Ctrl+S`	Clean All and Save

1. Detailed Usage Instructions

1.1 Example

Before using this extension, you cannot see the .inc file content directly:

// Other Code ...
#include "mlir/Dialect/Arith/IR/ArithOpsDialect.h.inc"
// Other Code ...

After using this extension, you can preview the .inc file content inline:

// Other Code ...
/// #include "mlir/Dialect/Arith/IR/ArithOpsDialect.h.inc"
/// --- [MLIR_INC_PREVIEW_START] ---

/*===- TableGen'erated file -------------------------------------*- C++ -*-===*\
|*                                                                            *|
|* Dialect Declarations                                                       *|
|*                                                                            *|
|* Automatically generated file, do not edit!                                 *|
|* From: ArithOps.td                                                          *|
|*                                                                            *|
\*===----------------------------------------------------------------------===*/

namespace mlir::arith {

/// The arith dialect is intended to hold basic integer and floating point
/// mathematical operations. This includes unary, binary, and ternary arithmetic
/// ops, bitwise and shift ops, cast ops, and compare ops. Operations in this
/// dialect also accept vectors and tensors of integers or floats. The dialect
/// assumes integers are represented by bitvectors with a two's complement
/// representation. Unless otherwise stated, the operations within this dialect
/// propagate poison values, i.e., if any of its inputs are poison, then the
/// output is poison. Unless otherwise stated, operations applied to `vector`
/// and `tensor` values propagates poison elementwise.
class ArithDialect : public ::mlir::Dialect {
   explicit ArithDialect(::mlir::MLIRContext *context);

   void initialize();
   friend class ::mlir::MLIRContext;
public:
   ~ArithDialect() override;
   static constexpr ::llvm::StringLiteral getDialectNamespace() {
      return ::llvm::StringLiteral("arith");
   }

   /// Parse an attribute registered to this dialect.
   ::mlir::Attribute parseAttribute(::mlir::DialectAsmParser &parser,
                                    ::mlir::Type type) const override;

   /// Print an attribute registered to this dialect.
   void printAttribute(::mlir::Attribute attr,
                       ::mlir::DialectAsmPrinter &os) const override;

   /// Materialize a single constant operation from a given attribute value with
   /// the desired resultant type.
   ::mlir::Operation *materializeConstant(::mlir::OpBuilder &builder,
                                          ::mlir::Attribute value,
                                          ::mlir::Type type,
                                          ::mlir::Location loc) override;
};

} // namespace mlir::arith
MLIR_DECLARE_EXPLICIT_TYPE_ID(::mlir::arith::ArithDialect)

/// --- [MLIR_INC_PREVIEW_END] ---
// Other Code ...

1.2 Menu/Commands/Status Bar

You can right-click on any C/C++ file containing .inc includes to open the MLIR Inc Previewer menu:

MLIR Inc Previewer Menu

You can search mlir inc in the command palette to find the MLIR Inc commands:

MLIR Inc Previewer Commands

The status bar displays the number of uncleaned preview blocks in the current file:

MLIR Inc Previewer Status Bar

1.3 Basic Usage

1.3.1 Expand/Collapse Preview (Macro-aware)

Place your cursor near a line like: #include "SomeGenerated.inc"
- Intelligent detection works within +3/-3 lines of the #include statement
- No need to place cursor exactly on the #include line
Press Ctrl+Shift+U (or right-click -> MLIR Inc: Expand/Collapse Preview (Macro-aware)) to expand the preview block
Press Ctrl+Shift+U (or right-click -> MLIR Inc: Expand/Collapse Preview (Macro-aware)) again to collapse the preview block
- Intelligent detection works both ways: Cursor can be anywhere:
  - Within +3/-3 lines of the original #include statement
  - Or anywhere inside the expanded preview block

1.3.2 Expand All Preview Content (Macro-aware)

Press Ctrl+Shift+Y (or right-click -> MLIR Inc: Expand All Preview Content (Macro-aware)) to expand all preview blocks

1.3.3 Expand/Collapse Preview (Macro-unaware)

Use Ctrl+Shift+J instead of Ctrl+Shift+U to preview all code contents ignoring macro definations
Right-click -> MLIR Inc: Expand/Collapse Preview (Macro-unaware) instead of MLIR Inc: Expand/Collapse Preview (Macro-aware) to preview all code contents ignoring macro definations

1.3.4 Expand All Preview Content (Macro-unaware)

Use Ctrl+Shift+H instead of Ctrl+Shift+Y to preview all code contents ignoring macro definations
Right-click -> MLIR Inc: Expand All Preview Content (Macro-unaware) instead of MLIR Inc: Expand All Preview Content (Macro-aware) to preview all code contents ignoring macro definations

1.3.5 Clean All Preview Content

There are several ways to clean all previews:

Place the cursor near each preview block individually, and then follow the method in 1.3.1 to collapse each preview block
Right-click -> MLIR Inc: Clean All Preview Content to clean all preview blocks
As mentioned in the Status Bar in 1.2, click the status bar to collapse all preview blocks
Most importantly, we currently do not allow saving expanded preview blocks to files. Therefore, if you execute Save (Ctrl+S for Windows and Cmd+S for macOS), we will first clean all preview blocks and then perform the regular Save operation.

1.3.6 Navigate to Next Preview

Right-click -> MLIR Inc: Navigate to Next Preview to jump to the next preview block in the file

2. Advice on Better Preview Experience

For better preview experience, we recommend formatting your generated .inc files with clang-format when generating them:

We provide a cmake function to format your generated .inc files:

# AddTableGenFormat.cmake
if(_ADD_TABLEGEN_FORMAT_INCLUDED)
   return()
endif()
set(_ADD_TABLEGEN_FORMAT_INCLUDED TRUE)

function(add_mlir_tablegen_format target_name)
   find_program(clang_format clang-format)
   if(clang_format AND TABLEGEN_OUTPUT)
      list(REMOVE_DUPLICATES TABLEGEN_OUTPUT)
      foreach(gen_file ${TABLEGEN_OUTPUT})
            get_filename_component(fname ${gen_file} NAME)
            add_custom_command(
               TARGET ${target_name}
               POST_BUILD
               COMMAND ${clang_format} -i "${gen_file}"
               COMMENT "[Post] Formatting ${fname}..."
               VERBATIM
            )
      endforeach()
   elseif(NOT clang_format)
      message(WARNING "clang-format not found, skipping TableGen formatting.")
   elseif(NOT TABLEGEN_OUTPUT)
      message(WARNING "No TableGen outputs found, skipping TableGen formatting.")
   endif()
endfunction()

You can add the following snippet to your CMakeLists.txt:
```
include(AddTableGenFormat)
add_mlir_tablegen_format(PUBLIC_TABLEGEN_TARGET_NAME)
```
This will automatically format all generated .inc files after they are built.

Example:

set(LLVM_TARGET_DEFINITIONS Passes.td)
mlir_tablegen(Passes.h.inc -gen-pass-decls -name TritonGPU)
# The public tablegen target
add_public_tablegen_target(TritonGPUTransformsIncGen)

include(${PROJECT_SOURCE_DIR}/cmake/AddTableGenFormat.cmake)
# This name must match the name of the public tablegen target
add_mlir_tablegen_format(TritonGPUTransformsIncGen)

We recommend instaling the clangd extension for accurate .inc file navigation

3. Known Issues

Macro-Aware Expansion Limitations: The macro-aware mode attempts to expand .inc content based on macro definitions in the current file. For example, if only GET_OP_LIST is defined, content that depends on GET_OP_CLASSES will not be expanded:

Before:

void TritonDialect::initialize() {
  registerTypes();
  addOperations<
#define GET_OP_LIST
#include "triton/Dialect/Triton/IR/Ops.cpp.inc"
      >();
}

After:

void TritonDialect::initialize() {
  registerTypes();
  addOperations<
#define GET_OP_LIST
/// #include "triton/Dialect/Triton/IR/Ops.cpp.inc"
/// --- [MLIR_INC_PREVIEW_START] ---
/*===- TableGen'erated file -------------------------------------*- C++ -*-===*\
|*                                                                            *|
|* Op Definitions                                                             *|
|*                                                                            *|
|* Automatically generated file, do not edit!                                 *|
|* From: TritonOps.td                                                         *|
|*                                                                            *|
\*===----------------------------------------------------------------------===*/

#ifdef GET_OP_LIST
#undef GET_OP_LIST

::mlir::triton::CallOp, ::mlir::triton::FuncOp,  // Other Ops...
#endif // GET_OP_LIST

#ifdef GET_OP_CLASSES
#endif // GET_OP_CLASSES  // These contents are not expanded!

/// --- [MLIR_INC_PREVIEW_END] ---
      >();
}

However, this functionality is limited by the extension's ability to detect all macros, particularly those macros defined in included files that are not recursively analyzed.

NOTE: When expanding .inc files out of order (expanding a later .inc before earlier ones in the same file), the macro context may be incomplete, leading to potentially inaccurate filtering. Basically, this feature works accurately when using Expand All Preview Content (Macro-aware) sequentially from top to bottom. Also you can choose to use Expand All Preview Content (Macro-unaware) to expand all .inc files at once.

4. Installation

There are two ways to install this extension:

VS Code UI: Extensions view -> Search for "MLIR Inc Previewer" -> Click Install
Manual Install:
- Download the .vsix file from one of the following locations:
- Then install with one of the following options:
  - code --install-extension mlir-inc-previewer-version?.vsix
  - VS Code UI: Extensions view -> Views and More Actions... -> Install from VSIX...

5. Contributing

This extension is open for contributions. Please submit issues and pull requests on the GitHub repository.
