VS Code Language Server for Spring Boot
VSCode extension and Language Server providing support for working with Spring Boot
application.properties
, application.yml
and .java
files.
Note: this extension has a dependency on VS Code extension of Language Support for Java™ by Red Hat.
Usage:
The extension will automatically activate when you edit files with the following
name patterns:
*.java
=> activates Spring Boot specific support editing .java
files.
application*.properties
=> activates support for Spring Boot properties in .properties
format.
application*.yml
=> activates support for Spring Boot properties in .yml
format.
You can also define your own patterns and map them to the language-ids
spring-boot-properties
or spring-boot-properties-yaml
by defining files.associations
in workspace settings. See vscode documentation for details.
Functionality for .java
Navigating the source code - Go to symbol in file/workspace
Easy navigation to Spring-specific elements of your source code.
Shortcuts
- Mac: Cmd-Shift-O (symbols in file), Cmd-T (symbols in workspace)
- Linux/Windows: Ctrl-Shift-O (symbols in file), Ctrl-T (symbols in workspace)
Examples
@/
shows all defined request mappings (mapped path, request method, source location)
@+
shows all defined beans (bean name, bean type, source location)
@>
shows all functions (prototype implementation)
@
shows all Spring annotations in the code
Quick-access for running apps
Easy navigation to the provided request mappings of running apps.
Shortcuts
- Mac: Cmd-Shift-O (symbols in file), Cmd-T (symbols in workspace)
- Linux/Windows: Ctrl-Shift-O (symbols in file), Ctrl-T (symbols in workspace)
Examples
//
shows all request mappings of all running Spring Boot apps and opens a browser for the selected endpoint
The Spring Tools 4 can connect to running Spring processes to visualize internal information of those running Spring processes inline with your source code. This allows you to see, for example, which beans have bean created at runtime, how they are wired, and more.
The Spring Tools 4 shows hints by highlighting sections of source code with a light green background. Hovering over the highlights with the mouse pointer, data from the running app is displayed in a popup.
For some types of information, STS 4 may also show a 'quick summary' as a codelens. Codelenses are only supported in Eclipse and Vscode at the moment, not in atom. For Eclipse this has to be enabled via Preferences >> Language Servers >> Spring Language Servers >> Spring Boot Language Server.
If there are multiple instances of the app running on your machine, the live data from all those instances will show up in the hover information.
Examples
@Profile
: shows information about the active profiles on the running apps
@Component
, @Bean
, @Autowired
: shows detailed information about the beans and their wiring from the live app
@ConditionalOn...
: shows information about the conditions and their evaluation at runtime
Application Requirements for Spring Boot projects
Live information is scraped from running apps using JMX to connect to Spring Boot Actuator Endpoints. This means that spring-boot-actuator
must be added as a dependency to your application and enabled. The easiest way to accomplish this is to add the spring-boot-starter-actuator
dependency to your application's pom.xml
or build.gradle
as explained here.
Spring Boot 2.2 and beyond
⚠️ The JMX versions of the actuator endpoints (which the tooling uses under the hood to retrieve live data from the running applications) is not enabled by default anymore since Spring Boot 2.2. In order to allow Spring Tools 4 to continue to visualize live data from the running applications, you need to start the boot app with -Dspring.jmx.enabled=true
in order to activate the JMX endpoints.
Managing Live Data Connections
Press CTRL-SHIFT-P
(or CMD-SHIFT-P
on Mac) and select the command to
"Manage Live Spring Boot Process Connections". A choice of actions to connect/refresh/disconnect
to local processes found on your machine will then be presented.
Code templates
Write Spring code with templates, available via regular code completion.
Examples
@GetMapping
@PostMapping
@PutMapping
Smart code completions
Additional code completions for Spring-specific annotations
Examples
@Value
: code completion for Spring Boot property keys
@Scope
: code completion for standard scope names
Functionality for .properties
and .yml
This extension analyzes your project's classpath and parses and indexes any Spring Boot
Properties Metadata it finds. Both Maven and Gradle projects are supported.
The data in the index is used to provide validation, code completions and information
hovers while editing Spring Boot Properties in either .properties
or .yml
format.
Validation
Code Completions
Issues and Feature Requests
Please report bugs, issues and feature requests on the Github STS4 issue tracker.
Releases:
Released versions of this extension can be installed directly from the vscode marketplace.
There are also development snapshots available with the latest fixes and improvements as a .vsix
file
that can be donwloaded from
here. To install it
open vscode, press CTRL-SHIFT-P
and search for VSIX, then select Extension: Install from VSIX
Version: 1.58.0-PRE-RELEASE
