CLAD Audit (VS Code / Cursor)

Repository: https://github.com/Underwood-Inc/clad-audit-vscode
Marketplace: https://marketplace.visualstudio.com/items?itemName=underwoodinc.clad-audit-vscode

Thin editor extension that runs the full @underwoodinc/clad-audit engine in-process and publishes findings as Problems panel entries and inline squiggles — same UX as ESLint or TypeScript diagnostics.

Self-contained

The packaged .vsix is fully self-contained for anyone who installs it:

Included in the VSIX	Not required on the machine
Bundled `clad-audit` engine (rules, import graph, ts-morph, fast-glob, yaml, …) in `dist/extension.js`	`clad-audit` CLI
All audit logic runs inside the extension host	Separate monorepo checkout or CLI install
Zero runtime `node_modules` in the VSIX	Separate `@underwoodinc/clad-audit` npm install for end users

The extension does not shell out to scripts. It only reads your project's source tree and optional .clad-audit.yaml.

In your repo: add .clad-audit.yaml when you need aliases, tier paths, or allowlists. No config → generic CLAD defaults apply when cladAudit.auditWithoutConfig is enabled.

To build the VSIX (maintainers only): npm run package:vsix bundles extension + auditor via esbuild.

Initialize config (smart presets)

CLAD: Initialize Config analyzes the open workspace folder and drafts .clad-audit.yaml:

Detects Svelte / React / Vue / generic from package.json
Finds srcRoot by scoring src/, lib/, app/ for CLAD tier folders
Maps import aliases from tsconfig.json / jsconfig.json paths (falls back to $tier/ from folder names)
Suggests extraViewPaths when UI markup lives outside views/
Adds stack-appropriate ignoreGlobs (.svelte-kit, .next, .nuxt, …)

You pick a preset (Recommended, Minimal, or stack-specific), preview the YAML, then confirm before anything is written.

Security: files are created only inside workspace folders you select, only via workspace.fs after explicit confirmation — no shell commands, no network, no overwrite without approval.

Explorer: right-click folder → Initialize Config. Sidebar toolbar: Initialize Config icon.

When audit runs with no config, the extension offers to initialize.

Features

Activity bar sidebar — Explore (filter + group/sort) and Findings tree
Findings Explorer — optional full-page tab with collapsible tree; syncs filter/group/sort with the sidebar
Filter query language — field prefixes (rule:, tier:, file:), exclusions (-), regex (/pattern/i)
Project config — optional editor.findings block in .clad-audit.yaml (extension-only; auditor ignores it)
VS Code settings — cladAudit.findings.* for defaults; workspace session persists active filter
Precise ranges — squiggles anchor to imports, $props(), <script>, impurity tokens, and allowlist constants (not always line 1)
Rich remediation — related info for suggested move paths; copy config-exception YAML from quick fixes
Problems panel + inline squiggles — standard diagnostic UX
Language status item — CLAD summary in the editor status area for TS/JS/Svelte/Vue files
Quick fixes — copy remediation advice or open full remediation steps from a diagnostic
Output channel — CLAD Audit log for each run (View → Output)
Progress notification while auditing
Discovers every .clad-audit.yaml under workspace folders (e.g. monorepo apps/mappy/.clad-audit.yaml)
Runs audit on workspace open and on save (debounced)
Explorer context menu: Audit CLAD Root for Folder
Status bar shortcut → opens findings view

Install

Extension branding uses two assets under media/:

File	Used for
`media/clad-audit.png`	Extensions list and Marketplace (`icon` in `package.json`) — PNG, ideally 128×128 or 256×256
`media/clad.svg`	Activity bar sidebar button — must stay a monochrome SVG (`currentColor`); VS Code does not accept PNG here

To swap the Marketplace icon, replace media/clad-audit.png and rebuild the VSIX.

From a clone of this repository:

git clone https://github.com/Underwood-Inc/clad-audit-vscode.git
cd clad-audit-vscode
npm install
npm run package:vsix
code --install-extension clad-audit-vscode.vsix

Cursor:

cursor --install-extension clad-audit-vscode.vsix

Or: Extensions → ⋯ → Install from VSIX… → pick clad-audit-vscode.vsix.

Reload the window. Open a workspace that contains .clad-audit.yaml (or enable cladAudit.auditWithoutConfig).

Dev without installing: clone this repo, run npm install && npm run build, and press F5 (Extension Development Host).

Development

git clone https://github.com/Underwood-Inc/clad-audit-vscode.git
cd clad-audit-vscode
npm install
npm run build

Press F5 in VS Code/Cursor with this folder open to launch an Extension Development Host.

Auditor source: @underwoodinc/clad-audit from npm. For side-by-side work with the CLI repo, place clad-audit as a sibling directory (../clad-audit) and rebuild — the bundler prefers that source tree when present.

Settings

Setting	Default	Description
`cladAudit.enable`	`true`	Master switch for diagnostics
`cladAudit.runOnSave`	`true`	Re-audit after saving source files
`cladAudit.runOnOpen`	`true`	Audit when workspace loads
`cladAudit.debounceMs`	`1500`	Save debounce (ms)
`cladAudit.depth`	`standard`	`quick` · `standard` · `deep` · `exhaustive`
`cladAudit.configFileName`	`.clad-audit.yaml`	Config file name
`cladAudit.auditWithoutConfig`	`false`	Audit workspace roots with generic defaults when no config exists

Findings sidebar (`cladAudit.findings.*`)

Setting	Default	Description
`groupBy`	`severity`	`severity` · `rule` · `tier` · `file` · `root`
`sortBy`	`count-desc`	`count-desc` · `count-asc` · `alpha` · `severity`
`nestedGroupBy`	`rule`	Under `root`: `none` · `rule` · `tier` · `severity` · `file`
`defaultFilter`	`""`	Initial filter (session filter in toolbar overrides)
`showInfo`	`true`	Include info-severity rows in the sidebar
`useProjectConfig`	`true`	Merge `editor.findings` from `.clad-audit.yaml`

Project YAML (`editor.findings`)

Optional block in .clad-audit.yaml — ignored by the CLI auditor, read by the extension when useProjectConfig is true:

editor:
  findings:
    groupBy: rule
    sortBy: count-desc
    filter: tier:apps
    showInfo: true

When multiple audit roots exist in one workspace, per-project overrides apply only when a single root is active; otherwise workspace settings win.

Filter syntax

Form	Example
Free text	`import-boundary`
Field	`rule:import-boundary` · `tier:apps` · `file:views/`
Exclude	`-severity:info`
Regex	`/import.*apps/i`

Terms are AND-ed. Command palette: CLAD: Filter Syntax Help. With Explore or Findings focused: Ctrl+Alt+L filter, Ctrl+Alt+G cycle group-by. Use the Configure panel for grouping, nested root buckets, and audit settings.

Notes

Findings include line + column ranges when the rule can locate the violation (imports, impurity matches, Svelte props, file anchors).
File-tier placement rules anchor to the first import, <script> block, or first code line — not blindly line 1.
Import-boundary diagnostics highlight the specifier token, not the whole line.
Full-repo scan runs per audit root; large repos may prefer longer debounce or runOnSave: false with manual CLAD: Audit Workspace.

Changelog

0.5.7

Findings Explorer — full-page tab (like Filter Syntax help): searchable tree, group/sort controls, click-to-reveal
Open via Open full explorer… in Explore, the preview icon in Findings/Explore toolbars, or CLAD: Open Findings Explorer

0.5.6

Fix settings lockup — gear opens a lightweight quick pick instead of the native Settings UI (which could freeze Cursor)
Smarter re-audit — changing group/sort/filter no longer triggers a full workspace audit; only audit-engine settings do (debounced)

0.5.5

Layout picker replaces cycle — Ctrl+Alt+G and the tree toolbar button open a quick pick (group, sort, nested, show info)
Configure panel removed — Explore has compact Group/Sort dropdowns; gear opens VS Code settings
Simpler sidebar — two panels: Explore + Findings

0.5.4

Fix Configure → Findings wiring — workspace settings now override editor.findings in project YAML (YAML was silently winning before)
Live apply — grouping/sort/filter controls update the Findings tree immediately
Clearer chrome — tree subtitle shows sort mode; banner when YAML defaults are active

0.5.3

Filter syntax help — structured editor tab with quick recipes, field reference, Copy/Try actions (replaces plain modal dialog)

0.5.2

Configure panel — dedicated sidebar webview for findings tree layout (including nested root grouping), filters, audit engine, and saving editor.findings to .clad-audit.yaml
Explore simplified — live filter only; Configure grouping & audit… button opens the new panel
Findings toolbar — gear opens Configure instead of raw VS Code settings JSON

0.5.1

Toolbar fixes — re-run audit, filter, group, sort, and clear actions show status-bar feedback
Filter shortcut — Ctrl+Alt+L / Cmd+Alt+L (no longer steals Ctrl+Shift+F from Find in Files)
Filter button — focuses the Explore search box instead of a detached input
Streamlined Findings header — primary actions first; init config moved to overflow menu
private: true + npm auto-detect off for the extension folder (fixes spurious npm parse errors)

0.5.0

Explore toolbar webview — live filter input, group/sort/nested controls, show-info toggle
Findings grouping — severity, rule, tier, file, audit root (+ nested under root)
Filter query language — field prefixes, exclusions, regex; workspace-persisted filter
editor.findings in .clad-audit.yaml — project defaults (extension-only)
Settings under cladAudit.findings.*; keybindings when Findings view focused
Mappy ships editor.findings.groupBy: rule as a starter preset

0.4.2

Bundles @underwoodinc/clad-audit 0.5.2 — fixes config resolution when --root and --config are not nested (e.g. pnpm clad:audit --root apps/mappy --config apps/mappy/.clad-audit.yaml no longer silently falls back to generic defaults)

0.4.1

Marketplace / Extensions list icon (media/clad-audit.png)

0.4.0

Precise diagnostic ranges (column, endLine, endColumn) from auditor 0.5.0
Related locations for suggested move targets and cycle paths
CLAD: Copy config exception YAML quick fix
Expanded remediation markdown (reasoning, config snippets, suggested paths)
