Catalog Lens ^{VS Code}

Show versions inline for PNPM, Yarn, and Bun catalog: fields.

Features

• ✅ Support for PNPM catalogs (via pnpm-workspace.yaml)
• ✅ Support for Yarn catalogs (via .yarnrc.yml)
• ✅ Support for Bun catalogs (via package.json with catalog or catalogs fields)
• ✅ Multi-root workspace support - Works seamlessly with VS Code multi-root workspaces
• ✅ Inline version display with color-coded named catalogs
• ✅ Hover information with catalog name and version
• ✅ Go-to-definition support to jump to catalog definition
• ✅ Works with both default (catalog:) and named catalogs (catalog:name)

Multi-Root Workspace Support

This extension fully supports VS Code's multi-root workspaces. When you have multiple workspace folders open, the extension will:

• Automatically detect the correct workspace configuration file for each package.json being edited
• Use findUp to traverse from the current file to locate the nearest workspace root
• Support different package managers in different workspace folders (e.g., PNPM in one folder, Bun in another)
• Cache workspace lookups for performance

Bun Catalogs Support

This extension supports Bun's catalog feature as documented at https://bun.sh/docs/install/workspaces#catalogs

Bun catalogs can be defined in your root package.json in two ways:

1. At the top level

{
  "name": "my-monorepo",
  "catalog": {
    "react": "^19.0.0",
    "react-dom": "^19.0.0"
  },
  "catalogs": {
    "testing": {
      "jest": "30.0.0"
    }
  }
}

2. Within the workspaces object

{
  "name": "my-monorepo",
  "workspaces": {
    "packages": ["packages/*"],
    "catalog": {
      "react": "^19.0.0",
      "react-dom": "^19.0.0"
    },
    "catalogs": {
      "testing": {
        "jest": "30.0.0"
      }
    }
  }
}

Then reference them in workspace packages:

{
  "name": "my-package",
  "dependencies": {
    "react": "catalog:",
    "jest": "catalog:testing"
  }
}

Configs

Development

Prerequisites

This extension uses pnpm for dependency management and vsce (VS Code Extension Manager) for packaging and publishing.

# Install pnpm if you don't have it
npm install -g pnpm

# Install @vscode/vsce for publishing
npm install -g @vscode/vsce

Setup

# Clone the repository
git clone https://github.com/tobiashochguertel/vscode-catalog-lens.git
cd vscode-catalog-lens

# Install dependencies
pnpm install

Testing

The extension includes a test suite using Vitest:

# Run tests
pnpm test

# Run tests in watch mode
pnpm test --watch

Building

# Build the extension
pnpm build

# Type checking
pnpm typecheck

# Linting
pnpm lint

Development Workflow

# Watch mode for development (rebuilds on file changes)
pnpm dev

Then press F5 in VS Code to launch the extension development host.

Publishing

This project has an automated publish workflow with simulation mode for safe testing.

Quick Start

# Test the publish workflow locally (simulation mode)
pnpm act:publish:simulate

# Or run simulation on GitHub
gh workflow run publish.yml -f mode=simulate -f version_increment=patch

Detailed Publishing Guide

See docs/ci/PUBLISH_WORKFLOW_GUIDE.md for comprehensive documentation on:

• 🔍 Simulation Mode - Test without actually publishing
• 🚀 Real Mode - Actual publishing
• 📝 Main Branch Sync - How changes are properly merged
• 🧪 Act Integration - Local workflow testing
• 💡 Best Practices - Step-by-step workflows
• 🔧 Troubleshooting - Common issues and solutions

Manual Commands

# Package the extension (creates .vsix file)
pnpm package

# Publish to VS Code Marketplace (requires authentication)
pnpm ext:publish

# Or publish to Open VSX
npx ovsx publish

# Create a new release (bumps version and creates git tag)
pnpm release

Note: The automated workflow is recommended over manual commands as it:

• Generates changelogs automatically
• Runs all quality checks
• Publishes to multiple marketplaces
• Creates GitHub releases
• Syncs changes back to main branch

Local CI Validation

This project supports local validation of GitHub Actions workflows before pushing changes, significantly reducing CI failures and feedback time.

Prerequisites

Install the required tools:

# Install actionlint (workflow YAML validator)
brew install actionlint  # macOS
# or: go install github.com/rhysd/actionlint/cmd/actionlint@latest

# Install act (local GitHub Actions runner)
brew install act  # macOS
# or: curl -s https://raw.githubusercontent.com/nektos/act/master/install.sh | sudo bash

# Docker is required for act
# Ensure Docker Desktop is running

Available Commands

Workflow Validation (Recommended - Fast & Reliable):

# Validate all workflow YAML files (actionlint) - Takes <1s
pnpm workflow:lint
# or use the script directly:
./scripts/lint-workflows.sh

# Comprehensive validation (actionlint + basic act check)
pnpm workflow:validate

Local Workflow Execution with act (Advanced):

⚠️ Note: Local execution with act requires Docker and may need large images (~2-20GB). Some complex workflows may not work perfectly locally. For most cases, workflow validation with actionlint is sufficient.

# List all available jobs
./scripts/act-test.sh

# Run specific jobs locally (simulates GitHub Actions environment)
pnpm act:lint        # Run linting job (simple, works well)
pnpm act:typecheck   # Run type checking job (requires Node.js image)
pnpm act:build       # Run build job (requires Node.js image)
pnpm act:test-unix   # Run Unix tests (complex, may have issues)
pnpm act:ci          # Run complete CI pipeline (very resource intensive)

Docker Image Options: The project is configured to use catthehacker/ubuntu:js-* images (includes Node.js, ~5GB). Alternative configurations in .actrc:

• act-* - Lightweight (~500MB) but missing many tools
• js-* - Includes Node.js (~5GB) - Default for this project
• full-* - Complete environment (~20GB) - Most compatible but very large

Pre-commit Hook Integration

The project uses Husky pre-commit hooks that automatically validate workflows before each commit:

• Step 7/7: Workflow validation with actionlint
• Non-blocking warnings if actionlint is not installed
• Validates all .yml/.yaml files in .github/workflows/

To skip pre-commit hooks (not recommended):

git commit --no-verify -m "your message"

Troubleshooting

act fails with "Cannot connect to Docker daemon":

# Ensure Docker Desktop is running
docker ps
# If fails, start Docker Desktop and try again

actionlint not found during pre-commit:

# Install actionlint
brew install actionlint
# or install globally with Go
go install github.com/rhysd/actionlint/cmd/actionlint@latest

act fails with "node: executable file not found" or similar:

# You may need larger Docker images with more tools pre-installed
# Edit .actrc and change from 'js-*' to 'full-*' images:
# -P ubuntu-latest=catthehacker/ubuntu:full-latest
# Warning: full images are ~20GB and take time to download

# Alternative: Focus on workflow validation instead
pnpm workflow:lint  # This always works and catches most issues

act workflow execution fails or behaves differently than GitHub:

# Some workflows use GitHub-specific features that don't work locally
# Recommendation: Use act for simple jobs (lint, typecheck, build)
# Trust GitHub Actions for complex workflows (tests, deployments)

# To debug: enable verbose logging
act -j lint -W .github/workflows/ci.yml -v

For more details: See docs/research/ci-local-validation/README.md

Documentation

Complete documentation is organized in the docs/ directory:

• Documentation Index - Complete documentation index
• CI/CD & Workflows - GitHub Actions, Act testing, publishing workflows
• Development - Git hooks, formatting, implementation details
• Testing - Testing strategies, E2E tests, test results
• Guides & References - Quickstarts, publishing, release process
• Research - In-depth research and analysis

Quick Links

• Quick Start Guide
• Testing Guide
• CI Validation Guide
• Publishing Workflow
• Release Process

Credits

This extension is a fork of vscode-pnpm-catalog-lens by Anthony Fu, with added support for Bun catalogs.

Logo is modified from Catppuccin Icons (pnpm.svg), licensed under MIT.

License

MIT License © 2022-2024 Anthony Fu & Tobias Hochgürtel
