gitSt8

One view for the git workflows the built-in Source Control view makes awkward.

Install from the Visual Studio Marketplace · Source on GitHub · Report an issue

gitSt8 puts history, branches, remotes, tags, worktrees, stashes, staging and every common history-rewriting operation into a single panel next to your terminal. Instead of switching between the SCM view, the command palette and a shell, you right-click the thing you want to change.

• Getting started
• The view at a glance
• Everyday workflows
• Advanced workflows
• Reference
• Safety and undo
• Troubleshooting
• Development

Getting started

Requirements

• VS Code 1.90 or newer
• Git 2.38 or newer on your PATH (needed for --update-refs; most other features work with 2.23+)
• The built-in Git extension enabled (gitSt8 uses it for credentials and repository discovery)

Install

Install gitSt8 from the Visual Studio Marketplace:

• In VS Code, open the Extensions view (Ctrl+Shift+X, Cmd+Shift+X on macOS), search for gitSt8 and select Install, or
• run code --install-extension tisp.gitst8 in a terminal, or
• press Ctrl+P (Cmd+P on macOS) and enter ext install tisp.gitst8.

Updates arrive automatically through VS Code. To try a specific build, download the .vsix from GitHub Releases and use Extensions → … → Install from VSIX…. To run it from source, see Development.

Open it

Any of these opens the gitSt8 tab in the bottom panel:

• Ctrl+Alt+Shift+G (Cmd+Option+Shift+G / ⌘⌥⇧G on macOS)
• the gitSt8 item in the status bar
• the gitSt8 icon in the Source Control view's title bar
• gitSt8: Open Repository View in the command palette

Prefer an editor tab? Set "gitst8.location": "editor". You can also drag the panel tab into the sidebar like any other panel.

The view at a glance

┌──────────────────────────────────────────────────────────────────────────────────────┐
│ [repo ▾] (branch)  ✓Commit ⟳Fetch ⤓Pull ⤒Push │ ⑂Branch ▣Stash ⌫Clean up ↶Reflog  🔍 │  toolbar
├────────────────┬──────────────────────────────────────────┬──────────────────────────┤
│ Filter…        │ ● Uncommitted changes · 1 staged · 2 …   │ Commit to main           │
│ ▾ STACK        │ ●─ fix parser       [main] [origin/main] │  [message…]   ✓ Commit   │
│ ▾ BRANCHES     │ │ ┃ message, author, SHA, files → diff   │  Staged changes          │
│ ▸ REMOTES      │ │ ● add tests        [feature/x]         │  Changes                 │
│ ▸ TAGS         │ ●─┘ initial                    [v1.0]    │                          │
│ ▸ WORKTREES    │                                          │  (or: compare, stash,    │
│ ▸ STASHES      │                                          │   reflog, multi-select)  │
└────────────────┴──────────────────────────────────────────┴──────────────────────────┘
   sidebar                    commit graph                        details pane

Toolbar. The repository picker comes first (see multiple repositories), then the current branch (shown in red when HEAD is detached). Next come the main actions, the All branches toggle, search, and refresh. When space is tight, buttons shrink to icons; hover to see what they do.

Sidebar. Collapsible sections with a color per kind of ref. Click an entry to jump to its commit in the graph, double-click to check it out (or to open a worktree), and right-click for everything else. Each section header has a ⋯ menu with section-wide actions. The filter box at the top filters every section by name.

Commit graph. Every branch is drawn with its own lane. Labels on a commit show the local branches (green), remote branches (blue), tags (amber) and stashes (pink) that point at it. When your working tree has changes, an Uncommitted changes row sits on top. History loads in pages of 400 commits; use Load more at the bottom.

Commit details open inline, right under the commit you click, so the commit box stays where it is. Click the commit again to close them.

Details pane. Shows the commit box (staged and unstaged changes) by default. A comparison, a stash, the reflog or a multi-selection temporarily take its place; clicking a single commit (or clearing the selection) brings the commit box back. Click any file to open VS Code's diff editor, and right-click it for Open file, File history and Copy path. Drag the divider to resize the pane. It sits to the right of the graph in the bottom panel and below it in a tall editor tab.

Selecting commits.

Everyday workflows

Commit

1. Click ✓ Commit in the toolbar, or click the Uncommitted changes row.
2. Hover a file for its buttons: + stages it, − unstages it, ↶ discards its changes, ↗ opens it. Use stage all / unstage all for everything at once.
3. Click a staged file to diff HEAD ↔ index, or an unstaged file to diff index ↔ working tree.
4. Type a message and press Ctrl+Enter (Cmd+Enter on macOS) or click the button.

Right-click a changed file to ignore it:

Rules that are already in the file aren't added twice. Ignore rules don't apply to files git already tracks. If the new rule matches tracked files, gitSt8 lists them and offers Stop tracking: git rm --cached keeps the files on disk, and your next commit removes them from the repository.

Options:

• Amend last commit replaces the last commit and pre-fills its message.
• Skip hooks runs --no-verify.
• If nothing is staged, the button turns into Stage all & commit.

Commits go through VS Code's Git extension, so commit signing and git.* settings behave exactly as in the Source Control view. Your draft message survives refreshes.

Fetch, pull, push

Right-click a toolbar button to pick a variant directly instead of going through the quick pick:

Force push comes in three strengths, from the toolbar Push menu (click or right-click) or by right-clicking a branch:

On a branch, right-click for Push, the three Force push options, and Fast-forward from upstream. The last one updates a branch you are not on, without checking it out. On a remote, right-click for Fetch & prune, which fetches just that remote.

Branches

Right-click any commit, branch or tag and choose Create branch here / from…. You can then create it, create and check it out, or create it in a new worktree.

Other branch actions: Checkout (or double-click), Rename, Delete (offers to delete the remote branch too, and falls back to a force delete if the branch isn't merged), Set / change / unset upstream, Compare with current branch / upstream / working tree.

Checking out a remote branch creates a local tracking branch. If a local branch with that name already exists, gitSt8 asks whether to switch to it or reset it to the remote.

Merge and rebase

Right-click the commit or branch you want to bring in:

• Merge into ‹current›: plain merge, --no-ff, --ff-only, or squash merge.
• Rebase ‹current› onto here: plain, with --autostash, or with --update-refs.

If a conflict stops the operation, a yellow banner appears. See resolving conflicts.

Search history

The search box has several modes:

Results show as a single line with a banner above. Files matching your search are highlighted and listed first in the details. Click Clear search to go back to the full graph. The All branches toggle decides whether search covers every branch or only HEAD.

From the editor

For inline blame annotations, use VS Code's built-in setting git.blame.editorDecoration.enabled. gitSt8 does not duplicate it.

Stashes

Stash in the toolbar asks for an optional message, then what to stash: tracked changes, tracked + untracked, or staged only. Click a stash to see its files. Right-click it to Apply, Pop, Drop, or Create branch from stash.

Compare and diff

• Ctrl+click (Cmd+click on macOS) two commits to compare them. The older commit goes on the left. The header shows how many commits are on each side; swap reverses the comparison.
• Right-click → Compare with HEAD / Compare with working tree / Compare with ‹upstream›.
• Click any file in the list to open the side-by-side diff.

Advanced workflows

Interactive rebase

Right-click the oldest commit you want to change → Interactive rebase from here. A dialog lists every commit from that one up to HEAD, oldest at the top.

• Reorder by dragging or with ▲▼.
• Pick an action per commit: pick, reword (edit the message inline), edit (stop there), squash, fixup, drop.
• Optional: --autostash, and --update-refs to move branches that sit on top of the rewritten commits.

Click Start rebase. No editor ever opens: gitSt8 hands git the prepared plan and edits messages for you. If the range contains merge commits, gitSt8 warns you first, because they will be flattened into a straight line.

Split a commit

Right-click a commit → Split commit…. gitSt8 rewinds to that commit and undoes it, leaving its changes unstaged. Commit them in pieces (from gitSt8's commit box or Source Control), then press Continue in the banner. For the latest commit this is just git reset HEAD~1. Requires a clean working tree.

Fix up an older commit

Stage the fix, right-click the commit it belongs to → Fixup staged changes into this commit. gitSt8 creates a fixup! commit and immediately folds it into the target with an autosquash rebase. If nothing is staged, it offers to stage all changes to tracked files.

Cherry-pick and revert several commits

Select commits with Ctrl+click (Cmd+click on macOS) or Shift+click, then right-click → Cherry-pick N commits onto ‹current› (applied oldest first) or Revert N commits (newest first). Merge commits must be handled one at a time.

Stacked branches

When several of your branches build on each other (main ← feature-a ← feature-b), the Stack section shows them as a chain down to the base branch, with the number of commits each adds. From the section's ⋯ menu:

• Restack onto ‹base›: rebases the top branch onto the base with --update-refs, so every branch in the stack moves along. Then returns you to the branch you were on.
• Push stack: force-pushes (with lease) every branch in the stack and sets upstreams.
• Change base branch: by default gitSt8 uses origin/HEAD, then origin/main, origin/master, main, master, develop. Saved in the gitst8.stackBase setting.

Worktrees

A worktree is a second checkout of the same repository in another folder. It lets you review a PR or hotfix another branch without stashing your current work.

• Create: Worktrees ⋯ → Add worktree, or right-click a branch → Open in new worktree, or a commit → Create worktree here. The folder defaults to ../<repo>-<branch>.
• Open: double-click (new window), or right-click → Open in this window.
• Lock / Unlock, Remove (asks before force-removing a worktree with changes), and Prune stale worktrees.

Trying to check out a branch that is already checked out in another worktree offers to open that worktree instead.

Branch cleanup

Clean up in the toolbar opens one checklist with three groups:

1. Upstream deleted ("gone"): preselected. Run Fetch first so gitSt8 can see which ones are gone.
2. Merged into ‹base›: preselected.
3. No commits for N days: not preselected. N comes from gitst8.staleBranchDays, default 60.

The current branch, the base branch and branches checked out in other worktrees never appear in the list.

Tags

Remotes

Remotes ⋯ → Add remote. Right-click a remote's name for Fetch & prune, Prune stale remote branches, Copy URL, Change URL, Rename, Remove.

GitHub and Azure DevOps

When a remote points at GitHub, GitHub Enterprise or Azure DevOps, gitSt8 shows hosting-service information next to your history. It is read-only: nothing is changed on the server.

Sign-in. gitSt8 uses the accounts VS Code already manages. Nothing is stored by gitSt8 itself.

• GitHub: the built-in GitHub account (scope repo). For GitHub Enterprise, set github-enterprise.uri.
• Azure DevOps: your Microsoft (Entra ID) account. If your organization blocks that, or you use an MSA-backed organization, use a personal access token with Code (read) and Build (read) scopes: gitSt8: Set Azure DevOps Personal Access Token. Tokens live in VS Code's secret storage, either for all organizations or for one.

Until you sign in, the chip shows a Sign in button. gitSt8 never opens a sign-in prompt on its own.

Which remote. gitst8.integrations.remote, else origin, else the first remote on a supported host.

Load on the service. Pull requests are cached for a minute and finished checks for five minutes. Running checks are re-checked every 30 seconds while the view is visible. Only the newest gitst8.integrations.commitsToCheck commits plus branch tips are queried: one GraphQL call per 40 commits on GitHub, one builds call on Azure DevOps.

Multiple repositories

In a multi-root workspace, or a folder with nested repositories, the repository picker lists every repository VS Code's Git extension has found, as name — branch (N changed). Repositories with the same folder name show their workspace-relative path. The picker updates live, including for repositories you are not currently viewing. Show Line's Commit and File History switch to the file's repository automatically.

Reference

Commands

Rebind these in Keyboard Shortcuts (Ctrl+K Ctrl+S, on macOS Cmd+K Cmd+S; search "gitSt8"). On keyboard layouts where Ctrl+Alt acts as AltGr (German, for example), the defaults may not fire.

Keys inside the view

Settings

Safety and undo

gitSt8 asks before anything destructive (hard reset, force push, deleting branches, tags, remotes or worktrees, discarding changes, pruning tags) and shows the exact effect in the dialog.

• Reset defaults to --keep: the branch moves, but git refuses rather than overwrite your local changes. --hard gets an extra confirmation.
• Force push offers --force-with-lease --force-if-includes first, then lease only, then plain --force. Each confirmation dialog says what the chosen flags protect against. Push stack always uses --force-with-lease.
• Rebase, merge, cherry-pick or revert stopped? The banner shows the operation, its progress and the conflicted files.

Resolving conflicts

For each conflicted file in the banner:

• Open: resolve it in the editor (VS Code's merge editor works as usual)
• Take upstream/ours or Take your commit/theirs: take one side wholesale and stage it
• Mark resolved: stage the file once you're done

Then click Continue, or Skip commit (rebase / cherry-pick / revert), or Abort to return to where you started.

Undo almost anything: the reflog

↶ Reflog lists every position HEAD has been at: commits, checkouts, resets, every rebase step. To undo a bad rebase, reset or merge, find the entry from just before it and choose reset here… (or branch… to keep both versions). Commits that are no longer on any branch can still be shown and recovered from here.

Troubleshooting

Development

The extension is TypeScript (strict mode) with no runtime dependencies. You need Node.js 20+.

npm install      # TypeScript, type definitions and vsce (all dev-only)
npm run watch    # compile on save (F5 starts this automatically)
npm test         # compile, then run unit + git integration tests (node:test)
npm run package  # build gitst8-<version>.vsix

Press F5 (Run gitSt8) to start a development window with your other extensions disabled. Press Ctrl+R (Cmd+R on macOS) there to reload after a change. Changes to package.json need a full restart of the debug session.

Design notes:

• Credentials. Fetch, pull (default mode), push and commit go through the built-in vscode.git extension API, so authentication, signing and settings match the Source Control view. Everything else uses the git CLI with --no-optional-locks and GIT_TERMINAL_PROMPT=0.
• No editor pop-ups. Interactive rebase, split and fixup set GIT_SEQUENCE_EDITOR to copy a prepared todo file (or to : to accept git's own), and GIT_EDITOR=:. Rewording adds an exec git commit --amend -F <file> line.
• Messages. The webview talks to the extension through postMessage. A message {type: 'x', …} is handled by RepoPanel.on_x.
• Icons come from VS Code's bundled codicon.ttf, loaded through the webview's resource roots. Code points live in ICONS in media/main.js.
• Providers implement ProviderClient (pullRequests, statuses) and never import vscode, so they can be tested with plain Node. The graph is posted first; PRs and CI status follow in a separate integration message, so a slow or unreachable service never delays the graph.

Releasing

.github/workflows/publish.yml tests, packages and publishes the extension.

To release: bump version in package.json, commit, and push a matching tag (git tag v0.0.3 && git push origin v0.0.3). The workflow refuses to publish when the tag and the version differ or the metadata is incomplete. It publishes the .vsix it just tested, attaches it to a GitHub release and keeps it as a build artifact. To build a .vsix without publishing, run the workflow manually from the Actions tab and leave publish unticked.

Publishing authenticates with Microsoft Entra ID instead of a personal access token (global PATs are retired on December 1, 2026). GitHub's short-lived OIDC token is exchanged for a token of an Azure managed identity, and vsce publish --azure-credential uses it. No secret is stored anywhere. One-time setup:

1. Azure: managed identity. In the Azure portal, create a user-assigned managed identity (any resource group). Note its Client ID, Tenant ID and Subscription ID. No role assignment is needed.
2. Azure: federated credential. On the identity, open Federated credentials → Add credential → GitHub Actions deploying Azure resources: organization tspannagel, repository gitSt8, entity Environment, environment marketplace. This results in the subject repo:tspannagel/gitSt8:environment:marketplace and the issuer https://token.actions.githubusercontent.com.
3. GitHub: environment. In the repository settings, create the environment marketplace. Add the variables (not secrets) AZURE_CLIENT_ID, AZURE_TENANT_ID and AZURE_SUBSCRIPTION_ID. Recommended: under Deployment branches and tags, allow only tags matching v*, and add yourself as a required reviewer.
4. Marketplace: member ID. Run the workflow manually with publish ticked. The Show identity step prints the identity's Marketplace ID; the publish step fails at this point because the identity is not a member yet.
5. Marketplace: membership. At marketplace.visualstudio.com/manage, open Members, add that ID and give it the Contributor role. Re-run the workflow.

License

MIT © 2026 Tim Spannagel
