Minecraft Resourcepack Helper

中文说明

Minecraft Resourcepack Helper is a VS Code extension for Minecraft Java resource pack authors. It understands modern resource pack layouts and adds resource-location aware navigation, completion, diagnostics, JSON validation, model preview, and reference views while you edit.

Preview

Highlights

• Go to Definition and resource path completion for blockstates, block/item models, modern item model definitions, particles, atlases, equipment, fonts, waypoint styles, post effects, sounds, and shader imports.
• Go to Definition, completion, missing-resource diagnostics, and resource graph support for CIT .properties texture and model paths, and CIT model JSON files under citresewn/.
• Missing resource diagnostics that resolve through the current pack, pack overlays and filters, configured lower-priority packs, and vanilla assets.
• Model texture variable support: jump to #texture definitions, follow variables inherited from parent models, highlight undefined variables, and report cyclic texture variables or too-deep parent chains.
• A Minecraft Resources activity bar view for current-file references, incoming references, model inheritance, child models, and blockstate -> model -> texture relationships.
• Three.js model preview for model JSON files, with texture/solid/wireframe modes, camera presets, perspective/orthographic cameras, grid and axis toggles, issue/dependency panels, live refresh, and PNG export.
• JSON schema validation for supported resource pack files, including pack metadata, models, item definitions, particles, atlases, equipment, fonts, sounds, language files, credits, GPU warnlists, regional compliancies, and PNG texture metadata.
• Extra semantic checks for pack.mcmeta, pack.png, colormap PNG sizes, sounds.json, post-effect targets, model parent/texture-variable chains, and assets/<namespace>/texts/{splashes,end,postcredits}.txt.
• English and Simplified Chinese localization for extension commands, runtime prompts, diagnostics, resource graph labels, model preview issues, and model preview webview controls.
• Commands for scaffolding a modern resource pack with namespace folders, a default pack.png, and min_format/max_format pack metadata.
• Integrated, lazy RSGL language tooling and build commands, with generated resources participating in the same project context, definitions, diagnostics, and resource graph as handwritten assets.

Quick Start

1. Install the extension from the VS Code Marketplace.
2. Open a folder that contains a Minecraft resource pack pack.mcmeta.
3. Configure McResHelper.vanillaResourcePackPath if you want navigation, completion, diagnostics, the resource graph, and model preview to fall back to vanilla assets.
4. Optional: configure McResHelper.customResourcePackPaths with absolute paths to lower-priority resource pack roots.
5. Open a supported resource pack file and use Go to Definition, path suggestions, diagnostics, the Minecraft Resources activity bar view, or model preview for model JSON files.

The extension activates for a resource pack or an .rsgl document. RSGL runtime code, its language-server process, source watchers, and build worker remain unloaded in a JSON-only workflow until an RSGL signal actually needs them.

Resource Resolution

Navigation, completion, diagnostics, the resource graph, and model preview use the same load-order model where possible:

1. The local pack currently being edited. For an RSGL project, this is the canonical output pack root selected by rsgl.config.json.outDir or pack discovery.
2. Active overlays and filters declared in pack.mcmeta.
3. Custom lower-priority packs from rsgl.config.json.customResourcePackPaths or McResHelper.customResourcePackPaths, ordered from higher priority to lower priority.
4. Vanilla assets from rsgl.config.json.vanillaResourcePackPath or McResHelper.vanillaResourcePackPath.

Existing configurations may still use the deprecated resourcePackRoots, defaultAssetsPath, McResHelper.resourcePackLoadOrder, and McResHelper.defaultMcAssetsPath aliases, but new configuration should use the canonical names above.

Physical files and live RSGL producers are resolved through the same project context. For an external/default resource ID, a JSON, shader, CIT, or RSGL reference therefore selects the same effective local/custom/vanilla layer; archive-backed custom packs and vanilla jars remain read-only.

Model Preview

Open McResHelper: open model preview from a model JSON editor, the editor title/context menu, or a model node in the Minecraft Resources view.

The preview resolves parent models, textures, texture variables, .png.mcmeta texture metadata, the configured resource-pack load order, and vanilla assets. It renders cuboid models and generated item models in a VS Code webview, then refreshes when related model, texture, metadata, active editor, or configuration changes are detected.

Preview controls include:

• View presets: 3/4, front, back, left, right, top, and bottom.
• Perspective and orthographic cameras.
• Textured, solid, and wireframe display modes.
• Grid and axis visibility toggles.
• Clickable Issues and Dependencies lists for related files and configuration.
• PNG export with custom width and height, transparent background, or a selected background color.

Current scope: model preview supports Minecraft model JSON resources and CIT .properties asset previews. Some visual details are approximated, including generated item side extrusion when texture pixels cannot be decoded, animated textures where only the first loaded PNG frame is shown, and element rotation rescale.

CIT .properties preview is an asset preview, not a full CIT runtime simulation. It resolves the main model or texture and renders the resulting model/texture where possible, but it does not evaluate every matching branch or render-layer behavior. In particular, texture.*, tile.*, model.* state variants, item condition matching, enchantment glint layers, blend behavior, and armor/equipment layer selection may differ from the in-game CIT Resewn result.

Supported References

• assets/<namespace>/blockstates/**/*.json: model references from variants and multipart entries.
• assets/<namespace>/models/**/*.json: parent model references and texture references, including texture variables.
• assets/<namespace>/items/**/*.json: modern item model definitions, nested models, special model bases, and supported special textures.
• assets/<namespace>/particles/**/*.json: particle texture references.
• assets/<namespace>/atlases/**/*.json: atlas texture and texture-directory references.
• assets/<namespace>/equipment/**/*.json: equipment layer texture references.
• assets/<namespace>/font/**/*.json: font references plus bitmap, TTF, and Unihex provider files.
• assets/<namespace>/waypoint_style/**/*.json: locator bar sprite textures.
• assets/<namespace>/post_effect/**/*.json: post-effect shader references and effect textures.
• assets/<namespace>/sounds.json: sound file references and sound event sanity checks.
• assets/<namespace>/shaders/{core,post}/**/*.{vsh,fsh}: #moj_import shader include references.
• CIT .properties: texture and model path definition, completion, missing-resource diagnostics, and resource graph support.
• CIT model JSON: model and texture references from CitResewn JSON model files under assets/<namespace>/citresewn/.

Diagnostics And Validation

The extension combines VS Code JSON schemas with resource-aware diagnostics.

• Missing resource warnings use the same resolution rules as navigation and completion.
• pack.mcmeta checks cover modern min_format/max_format usage, legacy pack_format, and packs that cross the 1.21.8 format boundary.
• Non-JSON checks cover missing or invalid pack.png, invalid or incorrectly sized colormap PNG files, and UTF-8 or formatting issues in splashes.txt, end.txt, and postcredits.txt.
• sounds.json checks cover sound file references, whitespace in sound file names, unnecessary .ogg extensions, invalid numeric fields, and undefined sound event references.
• post_effect checks verify target/pass relationships.
• Model checks cover parent-chain depth, parent cycles, missing textures, missing texture variables, and cyclic texture-variable chains.

Resource Graph

The Minecraft Resources activity bar view follows the active editor and shows the resource graph around it.

• Current file: the active resource itself.
• References: outgoing model, texture, shader, font, sound, and texture-directory references.
• Referenced By: incoming references from files in the workspace.
• Model Inheritance: parent models and child models.
• Blocks: workspace blockstates grouped as entry points into blockstate -> model -> texture chains.
• RSGL producers: live declarations and their physical materializations, including current, stale, and conflict state where applicable.
• Resource Search: the search action in the Resource Relations title bar selects a local or RSGL-generated blockstate, model, or texture and focuses its relations in the same tree. Clear the selection to resume following the active editor.

The view merges physical and RSGL outgoing/incoming edges. A physical resource can navigate to a live, unbuilt RSGL declaration, while an RSGL reference can navigate to the effective local, custom, or vanilla resource. The cached workspace indexes can be refreshed manually with McResHelper: refresh resource graph.

RSGL

RSGL is included in this extension and uses the same resource-pack project and resolution settings as JSON, shader, texture, and CIT tooling. Its runtime is isolated behind a lazy host bundle; the language server and build worker are separate processes that start only on demand.

Integrated RSGL support includes:

• .rsgl language registration, syntax highlighting, language configuration, diagnostics, completion, hover, and formatting.
• RSGL build and preview commands such as RSGL: Build Resourcepack JSON, RSGL: Preview Build, source-directory commands, and workspace build variants. Editor builds always compile the authoritative project source root before applying project-level ownership cleanup.
• Project compiler options in rsgl.config.json, including root, outDir, the Minecraft target, external-resource declarations, source maps, and evaluation limits. Project roots and output destinations resolve identically in VS Code, the language server, and the CLI.
• Safe build-to-assets transactions and complete previews. RSGL reports creates, updates, stale cleanup, ownership adoption, and conflicts; it refuses to overwrite unknown handwritten files, another project's outputs, or generated files changed since their ownership manifest. Stale outputs are removed only when ownership and the previous content hash both match.
• Cross-language navigation between physical resources and live, unbuilt RSGL producers.
• Read-only Definition and graph navigation into configured resource-pack ZIPs and vanilla client.jar files through revisioned virtual URIs; archives are never extracted into the workspace.

The language accepts canonical syntax only, including explicit model / variants / multipart / choice template dialects and canonical blockstates. It also includes structural record types and function values, typed resource IDs, bounded collection operations and spread, namespace imports, and exact quarter-turn model-geometry transforms. The independently published RSGL CLI provides the same project semantics for terminal workflows.

A mixed handwritten/generated pack can keep sources outside the pack while writing into the real pack root:

workspace/
├─ rsgl.config.json
├─ rsgl-src/
│  └─ main.rsgl
└─ pack/
   ├─ pack.mcmeta
   └─ assets/example/...  # handwritten resources may coexist here

{
  "root": "rsgl-src",
  "outDir": "pack",
  "namespace": "example"
}

root is the RSGL source root. outDir is always the complete output pack root containing assets/, never the assets directory itself, so generated paths do not become assets/assets/.... Checked extern local declarations resolve handwritten resources from that output pack; custom and vanilla declarations resolve configured lower layers. Preview commands show the ownership plan. A real build rejects unknown/cross-project/user-modified targets as conflicts, stages accepted writes, and only removes stale files whose ownership and previous hash are both proven.

Configuration

• McResHelper.vanillaResourcePackPath: absolute path to vanilla Minecraft assets. It can point at an assets folder, an assets/minecraft folder, a resource pack root containing assets/minecraft, or a vanilla client.jar.
• McResHelper.customResourcePackPaths: absolute paths to enabled resource pack directories or ZIPs below the currently edited pack, ordered from higher priority to lower priority. The current pack is checked first, then this list, then vanilla assets.
• McResHelper.tipColorForUndefinedTextureVariables: color used to highlight undefined #texture variables in model files.
• McResHelper.rsgl.enabled: auto loads RSGL only for relevant signals, on preloads its host after a project is discovered, and off keeps its runtime, processes, providers, and source watchers disabled. Static syntax highlighting remains available.

Example:

{
  "McResHelper.vanillaResourcePackPath": "C:/.minecraft/my_test/26.2/assets/minecraft",
  "McResHelper.customResourcePackPaths": [
    "C:/.minecraft/resourcepacks/base_pack"
  ],
  "McResHelper.rsgl.enabled": "auto",
  "McResHelper.tipColorForUndefinedTextureVariables": "Chartreuse"
}

Commands

• McResHelper: open folder of vanilla assets
• McResHelper: create a new pack in current folder
• McResHelper: create a new pack with the current folder as the root directory
• McResHelper: refresh resource graph
• McResHelper: open model preview
• McResHelper: export model preview image
• McResHelper: open model preview from resource graph
• McResHelper: create CIT template
• McResHelper: generate CIT for current item

The model preview commands are also available from model JSON editor menus. Resource graph model nodes provide an inline preview action. The CIT commands are accessible from the command palette; "generate CIT for current item" also appears in the editor context menu for item textures and models.

Integrated RSGL commands use the RSGL: prefix: build or preview one file, a source directory, or all configured workspace source roots, and refresh workspace resources and diagnostics.

Scaffolding

The resource-pack creation commands prompt for pack name, namespace, target resource-pack format, and description. They create pack.mcmeta, a default pack.png, and common namespace folders such as blockstates, models, items, textures, sounds, font, atlases, equipment, post_effect, shaders, and waypoint_style.

Development

npm install
npm run build
npm run lint
npm test

Useful focused commands:

npm run benchmark:model-preview
npm run build:rsgl
npm run watch
npm run package:main:vsix
npm run package:rsgl-cli

The single installable VSIX packages five entries: the lightweight activation bundle, lazy RSGL host, isolated language server, isolated build worker, and browser-only model preview. The Node 20 CLI is a sixth, VSIX-external entry. npm run watch incrementally rebuilds the five VSIX entries from the single development path.

There are two public artifacts: the combined VSIX uses vX.Y.Z, and the npm CLI uses rsgl-cli-vX.Y.Z. Use npm run release:main or npm run release:rsgl-cli; each release advances only its own manifest, changelog, artifact, and tag.

The release script atomically pushes the current branch and exactly one target tag, with bounded retries only for transport failures. If the remote connection still fails after creating the local release commit/tag, and that tag still points exactly to HEAD, resume with node scripts/release.mjs <main|rsgl-cli> current --resume; do not push only the branch, because that does not start the tag workflow.
