PgLens

Visualize your PostgreSQL database schemas as interactive ER diagrams directly inside VS Code.

Features

Click-to-inspect — Click any table node in the graph to open a tabbed details card showing columns, indexes, and relations.
Edge highlighting — Selecting a table highlights its outgoing foreign keys in one color and incoming references in another, while dimming unrelated edges.
Pan, zoom & fit — Navigate large schemas freely. The minimap in the top-right gives a bird's-eye view.
Context menu — Right-click on the canvas for quick actions: Fit View, Reset Selection, Reload.

Connection panel — Add, remove, select, and deselect PostgreSQL connections. URLs are stored securely in your OS keychain via VS Code SecretStorage.
Schemas panel — Browse all schemas for the active connection. Click the graph icon to visualize any schema.
Tables panel — Lists every table in the loaded schema. Expand a table to browse its columns, indexes, and foreign key relations.

Graph → Sidebar — Click a table node in the ER diagram to automatically reveal and expand it in the Tables panel.
Sidebar → Graph — Click the eye icon on any table in the Tables panel to highlight that table in the graph.

Each column in the details card shows:

Icons indicating Primary Key, Foreign Key, Identity, Unique constraint, or Index
Data type (e.g., int4, varchar, timestamptz)
Nullability — Hollow dot for nullable, filled dot for NOT NULL
DEFAULT value when present

The entire UI — graph nodes, edges, sidebar panels, and detail card — automatically adapts to your VS Code color theme using standard CSS variables.

Open the PgLens sidebar from the activity bar (database icon).
Click Add Connection and enter a PostgreSQL connection URL:
```
postgres://user:password@localhost:5432/dbname
```
Select a connection to browse its schemas in the Schemas panel.
Hover over a schema and click the Visualize Schema (graph) icon to open the interactive ER diagram.
Click any table node in the graph to see its details in the floating card and in the Tables panel.

PgLens accepts standard PostgreSQL connection URLs:

postgres://username:password@hostname:port/database
postgresql://username:password@hostname:port/database

If the connection fails during setup, you can choose to save it anyway and test later.

Setting	Default	Description
`pglens.showInternalSchemas`	`false`	Include `pg_catalog`, `information_schema`, `pg_toast`, and other internal schemas in the schema browser.

No schemas appear after selecting a connection

Check that pglens.showInternalSchemas is enabled if you want to see system schemas.
Verify your connection URL and that the database is reachable.

Graph layout looks broken

Connection URL is rejected
