reqstudio 🚀

reqstudio is a powerful, open-source HTTP and REST API client that lives directly inside Visual Studio Code. It provides a rich, graphical interface for creating, sending, and testing API requests, all managed through simple, text-based .req files.

Stop switching windows to test your APIs. Keep your API requests version-controlled alongside your code.

Features

• 📝 Custom Editor for .req Files: A full-featured UI for any file ending in .req.
• ** graphical interface**: Build requests visually—no need to write JSON by hand.
• ✔️ All HTTP Methods: Supports GET, POST, PUT, DELETE, and more.
• ⚙️ Full Request Control: Manage URL parameters, headers, and complex request bodies with ease.
• 🔄 Multiple Body Types: Send data as JSON, XML, Text, x-www-form-urlencoded, and multipart/form-data with file uploads.
• 📁 Binary File Uploads: Send binary data directly from a file.
• ✅ Toggable Parameters: Temporarily enable or disable params and headers with a single click without deleting them.
• 🌊 Streaming Responses: Handles large API responses gracefully by streaming the data, keeping the UI responsive.
• 📊 Rich Response Viewer: View response status, time, headers, and the formatted response body.
• 🔧 Environment Variables: Supports environment variables that can be substituted into URLs, headers, and request bodies.
• 💾 Version Control Friendly: Since requests are saved as simple JSON in .req files, you can commit them to Git and track changes over time.

Requirements

• Visual Studio Code version 1.103.0 or newer.

Installation

1. Open Visual Studio Code.
2. Press Ctrl+Shift+X (or Cmd+Shift+X on Mac) to open the Extensions view.
3. Search for reqstudio.
4. Click Install.

Getting Started

1. Create a file in your project with the .req extension (e.g., api.req).
2. Open the file in VS Code. The reqstudio UI will automatically appear.
3. Build your request using the graphical interface:
   • Select the HTTP method (GET, POST, etc.).
   • Enter the request URL.
   • Add any necessary parameters, headers, or a request body.
4. Click "Send" to execute the request.
5. View the response in the panel on the right.
6. Click "Save" or press Ctrl+S / Cmd+S to save your request configuration to the .req file.

The .req File Format

Your requests are saved in a clean, human-readable JSON format. This allows you to easily view diffs in Git or even create requests programmatically.

{
  "method": "POST",
  "url": "[https://api.example.com/users](https://api.example.com/users)",
  "params": [
    {
      "key": "isActive",
      "value": "true",
      "enabled": true
    }
  ],
  "headers": [],
  "bodyType": "application/json",
  "bodyText": "{\n  \"name\": \"Alex\"\n}",
  "bodyUrlEncoded": [
    {
      "key": "",
      "value": "",
      "enabled": true
    }
  ],
  "bodyMultipart": [
    {
      "key": "",
      "value": null,
      "type": "text",
      "enabled": true
    }
  ]
}

Using Environment Variables

You can manage environment variables to reuse values across multiple requests. This is useful for switching between development, staging, and production configurations without modifying each .req file.

Creating an environment file

Create a .reqenv file in your workspace root for global environments, or create a file named <filename>.reqenv next to a specific .req file for per-request environments.

Example .reqenv file:

URL=http://localhost:3456
DATA1=456

Substituting variables

Inside your .req file, reference variables with double curly braces:

{
  "method": "GET",
  "url": "{{baseUrl}}/users/{{userId}}",
  "headers": [
    {
      "key": "Authorization",
      "value": "Bearer {{apiKey}}"
    }
  ]
}

Variable substitution works in the URL, headers, and request body text fields.

Selecting an environment in the UI

When a .req file is open, use the environment selector dropdown in the request UI to pick the active environment. The active environment variables are applied automatically before the request is sent.

🤝 Contributing

This is an open-source project, and contributions are very welcome! If you'd like to help improve reqstudio, please feel free to file issues or submit pull requests.

Development Setup

1. Fork and clone the repository.
2. Install dependencies: npm install
3. Start the TypeScript compiler in watch mode: npm run watch
4. Open the project in VS Code and press F5 to launch the Extension Development Host window.
5. Open or create a .req file in the new window to test your changes.

Making a Contribution:

1. Create a new branch for your feature or bug fix: git checkout -b my-new-feature.
2. Make your changes.
3. Commit your changes and push them to your fork.
4. Submit a Pull Request to the main repository.
