PropFlow

---

🎯 Problem Statement

In large React applications, tracing where props originate becomes a time-consuming manual process:

1. You see a prop being used: <Button variant={variant} />
2. You navigate to the parent to find where variant comes from
3. The parent passes variant={type} - it's renamed!
4. You navigate to the grandparent
5. Repeat 5-10 times until you find the source

PropFlow solves this by showing you the complete propflow lineage instantly, right where you need it.

---

✨ Features

🔍 Instant Hover Tracing

Hover over any prop to see the complete data flow from source to destination.

🌲 PropFlow Lineage Tree

Visual hierarchical sidebar showing the full component chain.

🎨 Color-Coded Visualization

• 🟢 SOURCE - Where data originates (literal values)
• 🔵 USAGE - Pass-through components
• 🟣 DEFINITION - Current component

🚀 Click-to-Navigate

Jump directly to any component in the chain with one click.

⚡ Performance Optimized

• Sub-second tracing for 5+ level deep chains
• Pull-based analysis (on-demand only)
• Efficient AST parsing with ts-morph
• Leverages VS Code's native language server

🛠️ Handles Edge Cases

• ✅ Prop renaming: <Child name={props.title} />
• ✅ Prop spreading: <Child {...props} />
• ✅ Destructured props: function Comp({ a, b })
• ✅ Default & named exports
• ✅ Import aliases

---

📦 Installation

From VS Code Marketplace

1. Open VS Code
2. Press Ctrl+Shift+X (or Cmd+Shift+X on Mac)
3. Search for "PropFlow"
4. Click Install

From VSIX File

1. Download the latest .vsix file from Releases
2. Open VS Code
3. Press Ctrl+Shift+P → Type "Install from VSIX"
4. Select the downloaded file

From Source

git clone https://github.com/rutpshah/propflow.git
cd propflow
npm install
npm run compile
npm run package
code --install-extension propflow-<version>.vsix

---

🚀 Usage

Method 1: Hover (Recommended)

1. Open any React component file (.tsx, .jsx)
2. Hover over a prop in the component parameters
3. See the complete flow instantly

Example:

function Button({ label }) {
  // ← Hover over "label"
  return <button>{label}</button>;
}

Result:

🟢 App (SOURCE)
    └─ prop: "Click Me"
        ↓
    🔵 Card
        └─ prop: "buttonText" → "label"
            ↓
    🟣 Button
        └─ prop: "label"

Method 2: Command Palette

1. Place cursor on a prop
2. Press Ctrl+Shift+P (or Cmd+Shift+P)
3. Type "PropFlow: Show Lineage"
4. View the tree in the PropFlow Lineage sidebar

Method 3: CodeLens

Look for the ⬆ Trace Props link above component definitions and click it. From notification click on "View in PropFlow Lineage Panel" to see the details in sidebar panel.

---

🎬 Demo

Tracing a Simple Prop

File Structure:

App.tsx → Card.tsx → Button.tsx

App.tsx:

function App() {
  return <Card title="Welcome" buttonLabel="Click Me" />;
}

Card.tsx:

function Card({ title, buttonLabel }) {
  return (
    <div>
      <h2>{title}</h2>
      <Button label={buttonLabel} />
    </div>
  );
}

Button.tsx:

function Button({ label }) {
  return <button>{label}</button>;
}

PropFlow Output:

🟢 App (SOURCE)
    └─ prop: "Click Me"
        ↓
    🔵 Card
        └─ prop: "buttonLabel" → renamed to "label"
            ↓
    🟣 Button
        └─ prop: "label" (CURRENT)

Handling Prop Renaming

Parent.tsx:

function Parent() {
  const userName = "Alice";
  return <Child displayName={userName} />;
}

Child.tsx:

function Child({ displayName }) {
  return <div>Hello, {displayName}</div>;
}

PropFlow Output:

🟢 Parent (SOURCE)
    └─ prop: userName → renamed to "displayName"
        ↓
    🟣 Child
        └─ prop: "displayName"

---

⚙️ Configuration

PropFlow works out-of-the-box with zero configuration. Optional settings:

User Settings (settings.json)

{
  "propflow.maxTraceDepth": 20,
  "propflow.enableHoverProvider": true,
  "propflow.enableCodeLens": true,
  "propflow.traceTimeout": 5000
}

Setting	Default	Description
maxTraceDepth	20	Maximum levels to trace (prevents infinite loops)
enableHoverProvider	true	Show hover tooltips
enableCodeLens	true	Show CodeLens links above components
traceTimeout	5000	Timeout for trace operations (ms)

---

🏗️ Architecture

Overview

┌─────────────────────────────────────────┐
│          VS Code Extension              │
├─────────────────────────────────────────┤
│  Hover Provider  │  Command Handlers    │
│  CodeLens        │  Tree View Provider  │
└─────────────┬───────────────────────────┘
              │
              ▼
┌─────────────────────────────────────────┐
│         Graph Builder                   │
│  • Recursive prop chain construction    │
│  • Workspace-wide JSX search            │
└─────────────┬───────────────────────────┘
              │
              ▼
┌─────────────────────────────────────────┐
│         AST Analyzer (ts-morph)         │
│  • Parse TypeScript/JavaScript          │
│  • Extract components and props         │
│  • Find JSX element attributes          │
└─────────────────────────────────────────┘

Core Algorithms

1. Prop Chain Building

function buildPropChain(filePath, componentName, propName):
  1. Create root node: { component, prop, type: DEFINITION }
  2. Find parent component using workspace search
  3. Parse parent's JSX to find prop usage
  4. Determine if source (literal) or usage (variable)
  5. If usage, recursively trace parent's parent
  6. Return complete chain from source → current

2. Workspace JSX Search

function findComponentUsages(componentName):
  1. Search all .tsx/.jsx files for `<ComponentName`
  2. Return file paths and line numbers
  3. Filter out false positives (comments, strings)

3. Prop Usage Detection

function findPropUsage(sourceFile, componentName, propName):
  1. Get all JSX elements in file
  2. Find elements matching componentName
  3. Extract attributes from matching element
  4. Look for propName in attributes
  5. Return prop value (literal or expression)

---

🧪 Testing

Run Tests

npm test

Test Coverage

npm run coverage

Test Structure

test/
├── suite/
│   └── index.ts          # Test runner setup
├── extension.test.ts     # Extension activation tests
├── astAnalyzer.test.ts   # AST parsing tests
└── graphBuilder.test.ts  # Prop chain building tests

Current Coverage: 15 passing tests

• 5 Extension integration tests
• 6 AST analyzer tests
• 4 Graph builder tests

---

🔧 Development

Prerequisites

• Node.js 18+
• VS Code 1.85.0+
• npm or yarn

Setup

# Clone repository
git clone https://github.com/rutpshah/propflow.git
cd propflow

# Install dependencies
npm install

# Compile TypeScript
npm run compile

# Watch mode for development
npm run watch

Debugging

1. Open the project in VS Code
2. Press F5 to start debugging
3. A new VS Code window opens with the extension loaded
4. Test your changes in the Extension Development Host

Building

# Compile
npm run compile

# Run tests
npm test

# Package extension
npm run package

This creates propflow-<version>.vsix ready for distribution.

---

🤝 Contributing

We welcome contributions! Here's how to get started:

Contribution Workflow

1. Fork the repository
2. Create a feature branch: git checkout -b feature/amazing-feature
3. Make your changes
4. Write tests for new functionality
5. Ensure tests pass: npm test
6. Commit: git commit -m 'Add amazing feature'
7. Push: git push origin feature/amazing-feature
8. Open a Pull Request

Areas for Contribution

• 🎯 Context API tracing - Trace useContext values
• 🎯 Redux integration - Trace store connections
• 🎯 Class component support - Handle legacy codebases
• 🎯 Performance improvements - Optimize for monorepos
• 🎯 Documentation - Improve guides and examples
• 🎯 Bug fixes - Check Issues

Code Style

• Use TypeScript for all new code
• Follow existing code style (ESLint)
• Add JSDoc comments for public APIs
• Write meaningful commit messages

Commit Message Format

We use conventional commits:

• feat: - New feature
• fix: - Bug fix
• docs: - Documentation only
• refactor: - Code change that neither fixes a bug nor adds a feature
• test: - Adding or updating tests
• chore: - Maintenance tasks

---

🐛 Known Issues & Limitations

Current Limitations (v1.0)

❌ Not Supported:

• Context API (useContext)
• Redux/Zustand store connections
• Class components
• Dynamic/computed prop names
• Props from external libraries (stops at boundary)

✅ Supported:

• Function components
• Hooks-based components
• Destructured props
• Prop spreading
• Prop renaming
• Default & named exports

Known Issues

See Issues for active bugs and feature requests.

---

🗺️ Roadmap (Tentative)

v1.1 (Q2 2026)

• [ ] Context API support
• [ ] Redux store tracing
• [ ] Performance optimizations for 50k+ file projects
• [ ] Configurable color schemes
• [ ] Prop documentation in hover tooltip

v1.2 (Q3 2026)

• [ ] Class component support
• [ ] Prop type information in trace
• [ ] Export diagrams as PNG/SVG
• [ ] Multi-root workspace support

v2.0 (Q4 2026)

• [ ] Vue.js component tracing
• [ ] Angular component tracing
• [ ] Real-time collaboration features
• [ ] AI-powered prop usage suggestions

---
