Rocky VS Code Extension

Language support for the Rocky SQL transformation engine.

Features

• Syntax highlighting for .rocky files (TextMate grammar + semantic tokens from LSP)
• Diagnostics — compile errors and warnings as you type
• Hover — column types, lineage trace, model schemas
• Go to Definition — jump to model files or upstream column definitions
• Find References — locate all usages of a model or column across the project
• Rename — rename models or columns across all files
• Completion — model names, column names, SQL functions
• Signature Help — function parameter hints with active parameter tracking
• Document Symbols — outline view with model, columns, and CTEs
• Code Actions — quick fixes for diagnostics (fuzzy suggestions, CAST wrapping)
• Inlay Hints — inferred types shown inline after expressions
• Semantic Tokens — rich highlighting for model references, columns, functions
• Code Snippets — from, where, group, derive, select, join, sort, match, window, model
• Lineage View — Rocky: Show Model Lineage renders the DAG as an interactive graph
• AI Generate — Rocky: Generate Model from Intent creates a model from natural language
• Status Bar — shows server status and error count

Prerequisites

• Rocky CLI installed and on your PATH (or configure rocky.server.path)
• VS Code 1.85.0 or later

Local Development (without publishing)

There are three ways to use this extension locally:

Option 1: Run in Extension Development Host (recommended for development)

This launches a separate VS Code window with the extension loaded.

cd editors/vscode
npm install
npm run compile

Then press F5 in VS Code (or Run > Start Debugging). This opens a new VS Code window — the "Extension Development Host" — with the Rocky extension active. Any .rocky files opened in that window will have full language support.

To set this up, create .vscode/launch.json:

{
  "version": "0.2.0",
  "configurations": [
    {
      "name": "Run Extension",
      "type": "extensionHost",
      "request": "launch",
      "args": ["--extensionDevelopmentPath=${workspaceFolder}"]
    }
  ]
}

Option 2: Install from VSIX (recommended for daily use)

Package the extension as a .vsix file and install it directly:

cd editors/vscode
npm install
npm run compile
npx @vscode/vsce package

This creates rocky-0.1.0.vsix. Install it:

code --install-extension rocky-0.1.0.vsix

Or in VS Code: Extensions > ... menu > Install from VSIX... > select the .vsix file.

To update after making changes, rebuild and reinstall:

npm run compile && npx @vscode/vsce package && code --install-extension rocky-0.1.0.vsix

Option 3: Symlink into VS Code extensions directory

Create a symlink from the VS Code extensions directory to your local clone:

ln -s "$(pwd)/editors/vscode" ~/.vscode/extensions/rocky-dev.rocky-0.1.0

Then restart VS Code. This is the least friction for iteration — changes to JSON files (grammar, snippets, language config) take effect on reload. TypeScript changes still require npm run compile.

Settings

Commands

Project Structure

editors/vscode/
├── package.json                    # Extension manifest
├── tsconfig.json                   # TypeScript config
├── language-configuration.json     # Brackets, comments, folding
├── src/
│   └── extension.ts                # LSP client, commands, status bar
├── syntaxes/
│   └── rocky.tmLanguage.json       # TextMate grammar
├── snippets/
│   └── rocky.json                  # Code snippets
├── schemas/
│   └── rocky-config.schema.json    # JSON Schema for .rocky.toml
├── themes/
│   └── rocky-semantic.json         # Semantic token colors
└── icons/
    └── rocky-icon.svg              # File icon

License

Apache-2.0
