PYTHA Lua Support

VS Code IntelliSense for the PYTHA 3D-CAD Lua plugin API.

Features

• Autocomplete and inline documentation for the full pytha, pyui, pyio, pyux, pygeo, pyplot namespaces and the pyloc function — every entry links straight to the PYTHA Lua API Wiki.
• Open wiki from the editor: place the cursor on any pytha.* / pyui.* / pyloc symbol and run PYTHA: Open wiki for symbol under cursor (Ctrl+F1) or right-click → "PYTHA: Open wiki…". The command palette also exposes PYTHA: Open API Wiki as a shortcut to the wiki home.
• pyloc linting: warns when pyloc() is called with a non-literal argument — the translation extractor cannot resolve variables, so a non-literal call silently produces an untranslatable string.
• Debugging (attach to PYTHA): breakpoints, conditional breakpoints & logpoints, call stack, variables (locals/upvalues, expandable tables), watch/hover/REPL, stepping, stop-on-error and print to the Debug Console. See Debugging below.
• config.xml schema: ships an XSD validated against the wiki documentation. Combined with the Red Hat XML extension you get autocomplete and validation for plugin config files.
• Code snippets: scaffolds for dialogs, group boxes, primitive creation, identify calls and persistent storage (prefixes start with pytha-).
• Type checking via sumneko.lua (declared as a hard dependency). Element handles, control handles, materials etc. are modelled as distinct ---@class types so wrong handles get flagged.
• Workspace setup on first activation:
  • Lua.runtime.version is set to Lua 5.3 (PYTHA's Lua version)
  • Lua.runtime.builtin.io is disabled (PYTHA does not expose io)
  • the bundled API stub folder is added to Lua.workspace.library
  • PYTHA globals (pytha, pyui, ...) are added to Lua.diagnostics.globals
• Idempotent activation — settings are only written when they actually differ, so the extension does not churn settings.json on every reload.

Debugging

Debug your Lua plugins directly in VS Code while they run inside PYTHA. The debugger attaches over TCP to a debug server embedded in PYTHA.

1. Enable it in PYTHA. In PYTHA's settings, go to the Developer page, turn on Enable Lua Debugger and note the Lua Debugger Port (default 4711). The server starts (or restarts on a port change) immediately — no PYTHA restart needed. It listens on localhost only.

2. Match the port in VS Code (only if you changed it from the default):

// settings.json
"pytha-lua.port": 4711,
"pytha-lua.host": "127.0.0.1"

3. Debug. Open the plugin folder and press F5 — PYTHA Lua (attach) is offered without any setup. Set breakpoints in the plugin's .lua files, then run the plugin in PYTHA. Execution stops at your breakpoints.

No launch.json is required. If you want one anyway (to pin a port per project, or to keep several configurations side by side), add it via Run → Add Configuration → PYTHA Lua:

{
  "version": "0.2.0",
  "configurations": [
    { "type": "pytha-lua", "request": "attach", "name": "PYTHA Lua (attach)" }
  ]
}

A port/host set directly in the launch configuration overrides the settings above.

What works:

• Breakpoints, including conditional breakpoints and logpoints (right-click a breakpoint → Edit Breakpoint…). A logpoint writes to the Debug Console instead of stopping, and substitutes expressions in curly braces: part {i} of {count}.
• Call stack, and variables per frame — locals, upvalues and expandable tables. Values can also be changed in place while stopped.
• Watch, hover and the Debug Console as a Lua REPL evaluated in the selected frame.
• Stepping (over / into / out), continue and pause.
• Stop-on-error: an uncaught Lua error breaks at the throw site with the message shown.
• print(...) is streamed to the Debug Console while debugging (normally disabled in PYTHA).

Notes:

• Only plugins started while the debugger is attached are debugged — attach first, then run the plugin.
• While stopped at a breakpoint the PYTHA window is frozen (this is expected); it resumes on continue/step. Logpoints never stop, so they do not freeze PYTHA.
• Protected (encrypted) plugins cannot be debugged.

A step-by-step guide is also in the wiki: Debugging with VS Code.

Requirements

The extension activates automatically when a .lua file is opened. No additional setup is required beyond installing this extension; sumneko.lua will be pulled in automatically.

Known Issues

• API stubs are generated by hand from the wiki and may lag behind the very latest PYTHA release.
• Some functions whose wiki documentation is ambiguous use any for parameters — those are marked with a TODO comment in libs/pytha.lua.

Contributing

Stubs live in libs/pytha.lua and follow the LuaLS ---@meta convention. To add or fix a function:

1. Find the matching .md file in the API wiki.
2. Add or update the function in libs/pytha.lua using the existing format (short bold description, wiki link, @param/@return annotations).
3. Use ---@overload for alternative signatures rather than duplicate function declarations.

Release Notes

See CHANGELOG.md.
