ggsql for VS Code

Syntax Reference | Gallery | VS Code Marketplace

ggsql is a SQL extension for declarative data visualization based on the Grammar of Graphics: a single, composable query describes both the data and the chart. This extension runs ggsql right in VS Code including first-class dbt support for charts on top of your dbt models.

New to ggsql? Build your first plot or pick something from the gallery. Create a file with the .ggsql extension, paste the example, and run it right in your editor.

Note: ggsql and this VS Code extension are still in early development and all functionality is subject to change.

Example

VISUALISE
  bill_len AS x,
  bill_dep AS y,
  species AS fill
FROM ggsql:penguins
DRAW point
SCALE x
  RENAMING * => '{} mm'
LABEL
  title => 'Relationship between bill dimensions in 3 species of penguins',
  x => 'Bill length',
  y => 'Bill depth'

Why ggsql?

Many data analysts are naturally at home in SQL and spend more time there than in Python or R. Having to extract data, switch to another language, import the data, and set up a plotting library is cumbersome when all you want is to understand the data you are working with right now.

ggsql is built for immediate familiarity with SQL and stands on the Grammar of Graphics known from ggplot2, giving you a composable syntax that scales from a quick scatter plot to arbitrarily complex visualizations. The syntax is easy to learn, read, and write. This also means that it is a great fit for AI agents to produce as the output query is immediately easy to understand and validate by the user so that you can have certainty in its validity.

Getting started

1. Install the extension from the VS Code Marketplace (or manually).
2. Create a file called demo.ggsql and paste the example above.
3. Hit the Run button (or Cmd/Ctrl+Enter) and the chart opens in a panel beside your editor.

Queries run on an engine bundled with the extension (DuckDB and ggsql, compiled to WebAssembly). Your SQL executes on DuckDB with full file support resolved relative to your file. The VISUALISE clause is rendered by ggsql.

Extension Features

• Complete syntax highlighting for ggsql queries (.ggsql/.gsql files, plus VISUALISE clauses inside your dbt files).
• Zero-setup query execution on the bundled engine: full DuckDB SQL against your CSV/JSON/Parquet files and the built-in datasets; tables you create stay available for later runs.
• Rendered charts appear in a results panel next to your editor, powered by Vega-Lite, with export to SVG, PNG, or the Vega-Lite spec as JSON.
• dbt support: render a VISUALISE clause in a SQL file of your dbt project, executed against your configured dbt target.
• Cancellable runs and an explain-style run log in the ggsql output channel.

Using with dbt

Files with language sql or jinja-sql that live inside a dbt project (a dbt_project.yml is found upward from the file) and contain a VISUALISE/VISUALIZE clause get an additional "Render ggsql Visualization" button in the editor toolbar. This works well for exploratory charts in your project's analyses/ folder:

SELECT
  order_date,
  revenue,
  region
FROM {{ ref('fct_orders') }}

VISUALISE
  order_date AS x,
  revenue AS y,
  region AS color
DRAW line
LABEL title => 'Revenue by region'

When run, the SQL part (everything before VISUALISE) is compiled and executed by the dbt CLI (dbt show) against your project's target, so refs, macros, and profiles resolve exactly like a normal dbt run. The VISUALISE part is rendered by ggsql reading that file through its duckdb reader.

This requires the dbt executable (configure ggsql.dbtPath if it lives in a virtualenv).

Note that Jinja inside the VISUALISE part itself is not compiled.

Optional: using the ggsql CLI

By default everything runs on the bundled engine. For querying real databases, it is recommended to let dbt handle the database connection. However, setting ggsql.engine to cli runs queries through the ggsql CLI instead, which is mainly for advanced users:

• Custom data sources via ggsql.reader: use a persistent DuckDB database, SQLite, or ODBC connections.
• If you hit a problem with the standalone engine, the CLI mode is a reliable fallback.

Install the CLI on your PATH or point ggsql.executablePath at it. You need to restart VS Cod for the PATH to update after the CLI installation.

Settings

Manual installation

You can download the extension from the GitHub releases and install it manually:

1. Download vscode-ggsql-0.4.0.vsix from GitHub Releases
2. Install via the command line:

code --install-extension vscode-ggsql-0.4.0.vsix

Or install from within the editor: open the Extensions view, click the ... menu, select "Install from VSIX...", and choose the downloaded file.

Learn more

Visit ggsql.org for the full documentation with interactive examples, or try ggsql in the browser on the playground.

This project is a fork of the official ggsql-vscode extension focused on extensive VS Code and dbt features.
