Weaviate Studio

Weaviate Studio is a Visual Studio Code extension that brings a graphical interface for managing and querying Weaviate vector databases—directly inside your code editor. It’s designed to fill the UI gap for self-hosted users, while also providing cloud users with a convenient, integrated experience.

Why Use Weaviate Studio?

• No Official UI: Self-hosted Weaviate lacks a robust, built-in graphical UI for data exploration and management.
• All-in-One Tool: Manage, query, and monitor your Weaviate instance from within VSCode—no need to switch between browser tabs or use only APIs.
• Supports Both Self-Hosted and Cloud: Connect to any Weaviate instance, whether running locally, on-premises, or in the cloud.

Screenshots

GraphQL Query Interface

Connection Management

Add Collection

Detailed Schema

Features

Connection Management

• Connect to multiple Weaviate instances simultaneously
• Secure credential storage with VS Code's built-in secret storage
• Support for both local and cloud-hosted Weaviate deployments
• Connection health monitoring and automatic reconnection

Advanced Data Visualization

• Table View: Intelligent flattening of nested JSON data into readable tables
• JSON View: Syntax-highlighted, collapsible JSON viewer
• Schema Explorer: Interactive browsing of your Weaviate schema
• Real-time Results: Live query execution with instant feedback

Intelligent GraphQL Editor

• Syntax Highlighting: Full GraphQL syntax support with Monaco Editor
• Auto-completion: Context-aware suggestions based on your schema
• Schema-Aware Queries: Automatic generation of sample queries with proper reference handling and geo-coordinate support
• Error Detection: Real-time validation and error highlighting
• Enhanced Query Templates: 9 comprehensive templates covering all major Weaviate operations
• Reference Field Support: Intelligent detection and proper sub-selection generation for cross-references
• Type-Safe Generation: Handles all Weaviate data types including geoCoordinates, vectors, and primitives

Schema Management

• Browse collections and their properties
• View detailed schema information including data types and relationships
• Support for cross-references and nested object structures
• Visual representation of your data model

Enhanced Tree View

The Weaviate Explorer provides comprehensive information at both connection and collection levels:

Connection-Level Information

• Server Information: Weaviate version, git hash, hostname
• Cluster Health: Connection status, collection count, health indicators
• Available Modules: Installed modules with versions (text2vec-openai, generative-openai, etc.)
• Collections Overview: Organized collection grouping with counts

Collection-Level Information

• Properties: View all collection properties with their data types and descriptions
• Vector Configuration:
  • Vectorizer settings (text2vec-openai, text2vec-transformers, etc.)
  • Module configurations
  • Vector index type (HNSW, Flat, etc.)
• Indexes:
  • Inverted index status
  • Vector index configuration
  • Count of indexed properties
• Statistics:
  • Live object count
  • Tenant count (for multi-tenant collections)
• Sharding & Replication:
  • Sharding configuration (virtual per physical, desired/actual shard count)
  • Replication factor
  • Multi-tenancy status

🔍 Schema Analysis

Enhanced Schema Viewer

Right-click on any collection → "View Detailed Schema"

• 📋 Overview Tab: Quick stats, vector config, module settings
• 🔧 Properties Tab: Detailed property information with types and indexing
• 📄 Raw JSON Tab: Complete schema definition with copy functionality
• 🚀 API Equivalent Tab: Ready-to-use code in Python, JavaScript, and cURL
• 🐍 Creation Scripts Tab: Complete Python scripts and property details for recreation

One comprehensive viewer for all your schema analysis needs - from quick overview to complete recreation scripts!

Developer Experience

• Hot Reload: Instant updates during development
• TypeScript Support: Full type safety and IntelliSense
• Modern UI: Dark theme optimized for VS Code
• Responsive Design: Works seamlessly across different screen sizes

Query Templates

Built-in templates for comprehensive Weaviate operations:

Core Query Templates

• Basic Get Query: Simple data retrieval with metadata and timestamps
• Vector Search (nearVector): Similarity search using vectors with certainty thresholds
• Semantic Search (nearText): Text-based search with move operations and concept refinement
• Hybrid Search: Combined BM25 + Vector search with configurable balance and custom vectors

Advanced Query Templates

• Filter Query: Complex filtering with multiple operators (Equal, GreaterThan, Like, etc.)
• Aggregation Query: Comprehensive statistics by property type (text, numeric, date, boolean)
• Relationship Query: Explore object cross-references and nested relationships
• Sort Query: Multi-level sorting with primary and secondary criteria
• Explore Query: Object metadata, vectors, and AI-generated content summaries

Template Features

• Schema-Aware: Automatically detects and handles reference fields with proper sub-selections
• Type-Safe: Proper handling of all Weaviate data types including geoCoordinates
• Educational: Comprehensive examples and parameter documentation
• Error Prevention: Syntactically correct templates reduce query errors
• Customizable: Easy modification for specific use cases

Each template includes:

• Detailed parameter explanations
• Multiple usage examples
• Best practice recommendations
• Error handling guidance

Development

Prerequisites

• Node.js (v16 or later)
• npm (v8 or later)
• VS Code (v1.80.0 or later)

Setup

# Clone the repository
git clone https://github.com/muleyprasad/weaviate-studio.git
cd weaviate-studio

# Install dependencies
npm install

# Start development mode
npm run dev

Packaging and Local Testing

To create a VSIX package for local testing:

npx vsce package

This will generate a .vsix file in your project root.

To install it in VS Code:

code --install-extension weaviate-studio-1.0.1.vsix

You can also use the Extensions sidebar's "Install from VSIX..." option.

Available Scripts

# Development
npm run dev                 # Start development with watchers
npm run compile             # Compile TypeScript
npm run watch              # Watch for changes
npm run build:webview      # Build webview in development mode

# Production
npm run package            # Package for production
npm run package:webview    # Package webview for production

# Testing
npm test                   # Run all tests
npm run test:watch         # Run tests in watch mode
npm run test:coverage      # Run tests with coverage report

# Code Quality
npm run lint               # Run ESLint
npm run lint:fix           # Run ESLint with auto-fix
npm run format             # Format code with Prettier
npm run format:check       # Check code formatting

Testing

The project includes comprehensive test coverage using Jest:

Test Structure

The project follows Jest best practices with colocated test files:

src/
├── WeaviateTreeDataProvider/
│   ├── WeaviateTreeDataProvider.ts
│   └── __tests__/
│       └── WeaviateTreeDataProvider.test.ts
├── services/
│   ├── ConnectionManager.ts
│   └── __tests__/
│       └── ConnectionManager.test.ts
├── query-editor/webview/
│   ├── graphqlTemplates.ts
│   └── __tests__/
│       └── graphqlTemplates.test.ts
├── webview/
│   ├── formatGraphQL.ts
│   └── __tests__/
│       └── formatGraphQLQuery.test.ts
└── test/
    ├── setup.ts
    └── mocks/
        ├── vscode.ts
        ├── monaco-editor.ts
        └── weaviate-client.ts

Test Coverage

• ConnectionManager: Connection validation, management, and error handling
• GraphQL Templates: Template generation, schema-aware queries, and type safety
• WeaviateTreeDataProvider: Tree view structure, data providers, and UI interactions
• Utility Functions: GraphQL formatting and helper methods

All tests use proper mocking for VS Code APIs, Monaco Editor, and Weaviate client dependencies.

Quality Assurance

The project maintains high code quality through:

• Comprehensive Unit Tests: Complete test coverage for all core functionality
• Integration Tests: Service interactions and component behavior
• Type Safety: Full TypeScript coverage with strict type checking
• Code Coverage: Continuous monitoring of test coverage
• Linting: ESLint configuration for code consistency
• Formatting: Prettier integration for consistent code style

Contributing

We welcome contributions! Please see CONTRIBUTING.md for guidelines.

For Contributors

1. Fork and clone the repository
2. Install dependencies: npm install
3. Run tests: npm test to ensure everything works
4. Make changes with tests for new functionality
5. Submit a pull request with a clear description

Testing Your Changes

# Run tests before committing
npm test

# Check code coverage
npm run test:coverage

# Run linting
npm run lint

# Format code
npm run format

License

MIT License - see LICENSE file for details.

Support

• Issues: GitHub Issues
• Marketplace: VS Code Marketplace
• Open VSX: Open VSX Registry

Happy querying with Weaviate Studio! 🚀
