Temporal for VS Code

Debug Temporal workflows by their ID or history file.

Set breakpoints in code or on history events.

Usage

Watch the demo or follow these instructions:

Install the extension
Follow the examples for:
Typescript
Go
Python
Edit the './workflows' path to match the location of your workflows file
Run Temporal: Open Panel (use Cmd/Ctrl-Shift-P to open Command Palette)
Enter a Workflow Id or choose a history JSON file
Click Start
The Workflow Execution will start replaying and hit a breakpoint set on the first event
Set breakpoints in Workflow code (the extension uses a replay Worker, so Activity code is not run) or on history events
Hit play or step forward
To restart from the beginning, click the green restart icon at the top of the screen, or if the debug session has ended, go back to the MAIN tab and Start again

Configuration

Server

When starting a replay by Workflow Id, the extension downloads the history from the Temporal Server. By default, it connects to a Server running on the default localhost:7233.

To connect to a different Server:

Open the SETTINGS tab
Edit the Address field
If you're using TLS (e.g. to connect to Temporal Cloud), check the box and select your client cert and key

Entrypoint

Typescript

By default, the extension will look for the file that calls startDebugReplayer at src/debug-replayer.ts. To use a different TypeScript or JavaScript file, set the temporal.typeScriptReplayerEntrypoint config:

Open or create .vscode/settings.json

Add the config field:

{
  "temporal.typeScriptReplayerEntrypoint": "test/different-file.ts"
}

Note that the file must be within your project directory so it can find node_modules/.

Go

Go entrypoints are started via the background process. Create a small main.go in your project that runs the Go replayer adapter in IDE mode and registers your workflow function, for example:

package main

import (
    "go.temporal.io/sdk/worker"
    replayer "github.com/phuongdnguyen/temporal-workflow-debugger/replayer-adapter-go"
    "your/module/workflows"
)

func main() {
    replayer.SetReplayMode(replayer.ReplayModeIde)
    _ = replayer.Replay(replayer.ReplayOptions{
        WorkerReplayOptions: worker.WorkflowReplayerOptions{DisableDeadlockDetection: true},
    }, workflows.YourWorkflow)
}

Configure the background process to run tdlv which builds and runs your entrypoint under Delve and exposes a DAP proxy on port 60000. Set cwd to the folder that contains your package main (the entrypoint):

{
  "temporal.debugLanguage": "go",
  "temporal.debugger.backgroundProcess.command": "tdlv",
  "temporal.debugger.backgroundProcess.args": ["--lang=go", "--install", "--quiet"],
  "temporal.debugger.backgroundProcess.options": { "cwd": "./path-to-your-entrypoint-folder" }
}

The extension automatically attaches to the proxy. If your workspace root is the Go module, you may omit options.cwd.

Python

Python entrypoints are also started via the background process. Create a small script (e.g. vscode-replay.py) that uses the Python replayer adapter in IDE mode and references your workflow:

import asyncio
from replayer_adapter_python.replayer import ReplayMode, ReplayOptions, set_replay_mode, replay
from workflow import YourWorkflow

async def main():
    set_replay_mode(ReplayMode.IDE)
    await replay(ReplayOptions(worker_replay_options={}), YourWorkflow)

if __name__ == "__main__":
    asyncio.run(main())

Configure the background process to start tdlv for Python and point it at your entrypoint script (DebugPy will be launched by tdlv and proxied via port 60000):

{
  "temporal.debugLanguage": "python",
  "temporal.debugger.backgroundProcess.command": "tdlv",
  "temporal.debugger.backgroundProcess.args": [
    "--lang=python",
    "--install",
    "--quiet",
    "--entrypoint",
    "${workspaceFolder}/vscode-replay.py"
  ]
}

Languages

You can choose which language to debug via the temporal.debugLanguage setting. Supported values:

typescript (default)
go
java
python

Set it in your workspace settings:

{
  "temporal.debugLanguage": "go"
}

Background Process

The extension supports running a background process before starting the debug session. This process will be automatically terminated when the debug session ends.

Configure through VS Code settings:

{
  "temporal.debugger.backgroundProcess.command": "npm",
  "temporal.debugger.backgroundProcess.args": ["run", "start"],
  "temporal.debugger.backgroundProcess.options": {
    "cwd": "./server",
    "env": {
      "PORT": "3000"
    }
  }
}

Common use cases:

Starting a Temporal server before debugging
Running setup scripts or initialization processes

The extension uses graceful termination (SIGTERM) first, then forceful termination (SIGKILL) if needed. Process output is logged to the VS Code console.

Adapter integration (IDE server)

When a history is loaded in the panel, the extension starts a local server used by language adapters:

Address: http://127.0.0.1:54578
Endpoints:
- GET /history – returns the workflow history (JSON bytes)
- GET /breakpoints – returns the enabled breakpoint event IDs
- POST /current-event – highlight the current event in the UI

Adapters may honor the WFDBG_HISTORY_PORT environment variable to override the default port.

Notes:

Only Workflow code executes during replay; Activity code isn’t run (effects are driven by history).
