UMLMark for Visual Studio Code

UMLMark turns source code into navigable class and sequence diagrams inside VS Code, so architecture stays reviewable even when AI writes code faster than teams can read it.

UMLMark makes VS Code a complete workspace for code-to-architecture review:

• Configure: right-click a .py, .java or .ts file and choose Create UMLGen Class Config or Create UMLGen Sequence Config to get a ready-to-run diagram config in uml/.
• Generate: right-click a diagram config and choose Generate UML Diagram to produce class and sequence diagrams directly from your codebase.
• Explore: preview diagrams live, click any element to jump to its source, and export shareable artifacts for reviews and documentation.

Why UMLMark

With AI-assisted development, the bottleneck has moved from writing code to understanding it. Line-by-line review rarely reveals structural change: new dependencies, shifted responsibilities, or altered call paths. Typical diagram workflows fall short in three ways:

• Drift: hand-maintained diagrams fall out of sync with the code they describe.
• Disconnection: diagrams are static images with no path back to the implementing source.
• Friction: rendering and exporting diagrams for reviews and documentation is manual and repetitive.

UMLMark closes these gaps with a single code-to-diagram workflow:

• Generated from source: class and sequence diagrams are derived from the code, so they reflect what is actually built.
• Traceable: every diagram element links back to its source location in VS Code.
• Live: the preview updates as you edit, with zoom and pan for large diagrams.
• Shareable: export the current diagram, a document, or the whole workspace in one step, rendered locally or through a PlantUML server.

Key Capabilities

• Create a UMLGen class or sequence config from selected source files via the Create UMLGen Class Config / Create UMLGen Sequence Config context menus.
• Generate class and sequence diagrams from source code via the Generate UML Diagram context menu on a .yaml diagram config.
• Open PlantUML preview with Alt+D (Option+D on macOS).
• Auto-update preview while editing.
• Zoom and pan controls for large diagrams.
• Source-code navigation using UML class or sequence diagrams
• Export commands:
  • umlmark.exportCurrent
  • umlmark.exportDocument
• URL utilities:
  • umlmark.URLCurrent
  • umlmark.URLDocument

Supported File Types

*.wsd, *.pu, *.puml, *.plantuml, *.iuml

Preview and Navigation Demos

Preview interaction (zoom, pan, control bar actions):

Code navigation from PlantUML hyperlinks:

• Class diagram navigation:
• Sequence diagram navigation:

Install

From VS Code Marketplace

• Open Extensions in VS Code.
• Search for UMLMark.
• Install the extension published by petercai.

Direct link:

• https://marketplace.visualstudio.com/items?itemName=petercai.umlmark

CLI Install

code --install-extension petercai.umlmark

Quick Start

1. Open a .puml (or other supported PlantUML) file.
2. Press Alt+D (Option+D on macOS) to open preview.
3. Edit diagram code and observe live updates.
4. Use embedded hyperlinks to jump between diagram and source code.
5. Export outputs from command palette via: umlmark.exportCurrent, umlmark.exportDocument.

Create UMLGen Configs

A UMLGen config is a .yaml file that tells the generator which source files to read and which diagram to draw. Instead of writing one by hand, right-click your source code and let UMLMark create it.

From the editor

Right-click inside a .py, .java or .ts file and choose Create UMLGen Class Config or Create UMLGen Sequence Config.

• Class config: covers the whole file.
• Sequence config: uses the method or function under the cursor as the entry point, so place the cursor inside the method you want to trace first. The config name includes the method, for example engine-clean-seq.yaml.

From the Explorer

Select one or more source files in the Explorer, right-click, and choose the same commands. All selected files go into a single config.

• The first selected file sets the language and the config name.
• Folders, unsupported files, and files in another language or workspace folder are skipped; a warning lists them and Output › UMLMark shows details.

What gets created

• uml/<name>-cls.yaml or uml/<name>-seq.yaml, opened in the editor so you can review it. The diagram is written to uml/<name>-cls.puml (or -seq.puml).
• uml/filter-v3.yaml and uml/parsers.lock.yaml support files, copied once.
• Existing files are never overwritten. Running the command again on the same source opens the existing config. If the name belongs to a different source, UMLMark adds the parent folder to the name, for example adapters-engine-cls.yaml.

When the config is ready, choose Generate Now in the notification, or right-click the .yaml file and choose Generate UML Diagram.

TypeScript configs can be created today, but UMLGen does not generate diagrams from TypeScript yet.

Developer Flow (UMLMark Suite)

Recommended end-to-end workflow for Design as Code / Architecture as Code:

1. Once: clone uml-gen, create its .venv, and set umlmark.umlgen.sourcePath (and umlmark.umlgen.venvPath if the venv lives elsewhere).
2. Write or update source code.
3. Right-click the source files and choose Create UMLGen Class Config or Create UMLGen Sequence Config (once per diagram). In the editor, the sequence command uses the method under the cursor as the entry point.
4. Choose Generate Now, or right-click the .yaml diagram config and choose Generate UML Diagram. The command runs in a dedicated UMLGen terminal.
5. Open generated .puml diagrams in UMLMark preview.
6. Navigate from diagram elements back to source files.
7. Iterate: update source, regenerate diagrams, and re-verify in preview.

Flow summary:

source code -> Create UMLGen Config -> Generate UML Diagram -> .puml preview in UMLMark -> code navigation back -> iterate

Rendering Modes

UMLMark supports two rendering modes:

• Local (default)
• PlantUMLServer: renders remotely via umlmark.server, no local Java or Graphviz needed (see Configuration Highlights)

Local Render Requirements

• Java runtime
• Graphviz
• plantuml.jar

Quick install on Windows:

@REM Chocolatey package manager
choco install temurin
choco install graphviz

@REM Windows package manager (winget)
winget install EclipseAdoptium.Temurin.21.JDK
winget install Graphviz.Graphviz

Quick install on macOS:

brew install --cask temurin
brew install graphviz

Download plantuml.jar from https://plantuml.com/download

Configuration Highlights

Recommended VS Code configuration (settings.json):

{
  "umlmark.jar": "c:\\app\\plantuml-1.2026.6.jar",
  "umlmark.exportFormat": "png",
  "umlmark.exportIncludeFolderHeirarchy": false,
  "umlmark.exportOutDir": "uml",
  "umlmark.exportSubFolder": false,
  "umlmark.render": "Local"
}

Tip: umlmark.java, umlmark.jar, umlmark.server, umlmark.includepaths, umlmark.commandArgs, umlmark.jarArgs, umlmark.umlgen.sourcePath, and umlmark.umlgen.venvPath are restricted in untrusted workspaces for security.

Ecosystem: UMLMark Suite

Diagram generation is built into UMLMark for VS Code. The same generation engine is also available as a standalone CLI for scripting and CI:

License

This project follows a dual-license model across the UMLMark Suite.

• Free for Non-Commercial Use: LICENSE.txt
• Commercial Use Requires License: COMMERCIAL_LICENSE.txt

If you need commercial usage guidance for your deployment scenario, contact the maintainer.

Support

If UMLMark helps your team, support the project here:

• Support me: https://paypal.me/petercaica

For Contributors

Useful local commands:

# install dependencies
npm install

# compile code
./node_modules/.bin/tsc -p .
# OR use the package.json script
npm run compile

# Package the extension
npx @vscode/vsce package

# Install the .vsix file
code --install-extension umlmark-1.1.0.vsix

Issue tracker:

• https://github.com/petercai/vscode-umlmark/issues
