Agent Center

Agent Center

Pengsen

|
31 installs
| (1) | Free
Codex/Claude quotas, provider switching, GPU/CPU monitoring, Google connectivity, Clash controls, file-link recovery and file watcher diagnostics.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

Agent Center

Language: English (default) | 简体中文

Agent Center puts Codex and Claude usage quotas, Codex provider switching with shared history, live GPU/CPU monitoring, VS Code internet connectivity, and Clash/Mihomo controls in the status bar. It also recovers file links from Codex conversations through code -r. It supports local workspaces, Remote SSH, WSL and Dev Containers.

GitHub: github.com/mapengsen/Agent-Center

Plugin: marketplace.visualstudio.com/items?itemName=pengsen.codex-claude-agent-status

All features

Feature What you can do
Codex provider switching and shared history Choose official ChatGPT login or directly select a configured API such as beeapi, with no repeated typing. Manual ID entry and first-use API setup remain available. Every switch makes all indexed local history available to the selected provider, with backups and failure recovery.
Codex usage quotas See remaining or used percentages, short/long windows, reset times, account email and plan in the status bar and hover.
Claude usage quotas Inspect 5-hour, 7-day, Opus and Sonnet windows when returned by the service, plus subscription and reset details.
Quota display and refresh Choose remaining/used mode for each provider, see colored usage markers, click to refresh, and use automatic refresh with failure retries.
Live GPU/CPU monitor Hover over GPU for a native floating card; move away to hide it. Read 可用服务器.md from the current workspace root and click a server name to switch CPU/GPU monitoring. Refresh the selected machine every two seconds, with pause/resume and single refresh.
File watcher diagnostics Check that the existing workspace watcher delivers file events. Give slow startup scans time to finish and show matching current-session errors with a reload action.
VS Code internet connectivity Request only Google's public website from the extension host. Any HTTP response shows ✅️; no response shows ❌. The single icon sits before the Clash globe. Checks run at startup and every 5 hours, with manual checks available.
Clash node and latency See Google latency, the final active node, nested selection chain and routing mode. Read controller settings automatically from Clash/Mihomo, including custom Linux/WSL installations. Default test interval: 5 minutes.
Switch Clash nodes Click a node in the bottom-right hover card or search the full node list. Verify the selection and test latency after switching.
Test all Clash nodes in parallel Manually test all concrete nodes loaded by the current Clash core, up to five at a time. Show sorted results in the existing hover, support cancellation and send no node-selection commands.
Test and select the best node Run a fresh batch and select the successful node with the lowest Google latency reachable through the current group's manual selectors. Support nested selectors, verify the effective node and attempt recovery on failure.
Start and stop the proxy Use native Clash controls in the same hover, verify the controller starts or stops, retain subscriptions and keep the start action available while stopped.
Update the current subscription Download, force-load and verify the active source, preserving available manual choices. After success, immediately refresh Google connectivity, current-node state and all loaded node delays without selecting a new node. Restore on update failure; updates while stopped keep the service stopped.
Use subscription DNS Fetch fresh subscription DNS, falling back to a per-host cache refreshed every five days. Remove conflicting overrides and verify DNS while retaining host listeners, IPv6, nodes and rules. Includes backup, restore and a separate webpage check. Linux/WSL only.
Add, switch and delete subscriptions Paste a URL to detect its name, save without switching or apply immediately, view the active subscription, and delete any subscription. Deleting the active source switches to the next enabled one; without a replacement, Clash stops. Requires compatible clash-for-linux.
Recover Codex file links Open supported absolute file links with code -r, including images, PDF, SVG, Markdown, CSV, TOML and Office files: 30 default formats, with a configurable list. Recover failed opens and clean text tabs; preserve unsaved edits and prevent reopen loops.
Remote use, settings and diagnostics Run in the current local or remote extension host, configure feature switches, credentials and proxies, and inspect quota, connectivity, Clash and file-link diagnostics.

Getting started

  1. Install Agent Center from the VS Code Marketplace and reload the window. For Remote SSH, WSL or a container, install it in that workspace environment.
  2. For quotas, sign in with codex login or claude /login in the same environment. Agent Center reads that environment's existing CLI credentials. A provider's quota item stays hidden when its credentials are unavailable or unusable.
  3. Google connectivity works without Clash or an API key. For node status and switching, run Clash/Mihomo with an accessible controller; subscription management additionally needs compatible clash-for-linux.
  4. Hover over a quota item for details; click it to refresh. Hover over or click the Google/Clash item to open the native card above the bottom-right status bar, with network, node and subscription actions.
  5. Click the OpenAI 官方 / provider ID status item or run Agent Center: Switch Codex Provider. This feature requires Python 3.8+ with sqlite3 in the extension host. Reload the VS Code window after switching.
Automatic task Default schedule Manual action
Codex quota At startup, three more checks 60 seconds apart, then every 2 minutes (120 seconds); failed regular checks retry every 30 seconds, up to five attempts per cycle. Click the quota item or use its refresh command.
Claude quota At startup, three more checks 60 seconds apart, then every 15 minutes; failed regular checks retry every 30 seconds, up to five attempts per cycle. Click the quota item or use its refresh command.
VS Code host → Google At startup, then every 5 hours, and immediately after a successful subscription update. Choose “立即检测联网” in the hover card.
Clash node → Google At startup, then every 5 minutes; also after node or subscription switches. Successful subscription updates additionally test all loaded nodes in parallel. Choose “刷新测速” in the hover card.
Current subscription DNS cache Cache on discovery, then refresh every 5 days, checking overdue work after reconnecting. Failed downloads retain prior data and retry at most hourly. Requires the extension to be running. “DNS 使用订阅配置” always tries a fresh download before falling back to cache.
GPU/CPU monitor Sample at startup, then 2 seconds after each completed read, without overlap. Hidden cards keep sampling until paused. Pause/resume and single-refresh links in the native hover.
File watcher diagnostics First check about 90 seconds after startup. Retry missed events up to five times, with increasing delays. Reload the window from the warning hover when a matching error is logged.

Agent Center status bar preview

The image shows the quota items. A combined connectivity and Clash example is ✅️ 🌐 √ Google(1605 ms): the leading icon is the extension-host check, and the latency is the independent Clash node test.

File watcher diagnostics

Agent Center waits about 90 seconds after startup, creates a temporary file in each workspace root, and waits up to five seconds for VS Code to report its creation. Each check cleans up the temporary files and event listener. A root that misses the event is retried after 30 seconds, then after 1, 2, 4 and 8 minutes. Checks stop as soon as VS Code delivers the events, or after the last retry. An unwritable root is reported as unavailable in diagnostics.

A missed event triggers a bounded log read. For Remote SSH, WSL and Dev Containers, the diagnostic looks after the latest extension-host connection record and matches only affected workspace roots. A matching error shows 文件监视异常 and offers 重新加载窗口. Without a matching error, the status bar shows 等待文件监视 while retries remain and 文件监视未确认 when the checks end. Agent Center: Show Diagnostics lists the probe results under fileWatcher. Disable the check with agentStatus.fileWatcher.enabled.

Live GPU/CPU monitoring

Hover over the bottom-right GPU item to show a native floating card above the status bar; move away from the item and card to hide it. CPU usage appears above the complete original nvidia-smi table. The card is independent of Codex, opens no editor/sidebar tab and does not alter your layout. It may flicker and its scroll position may reset when VS Code rebuilds it on a data update. No terminal or persistent watch process is started.

Sampling starts automatically when the feature is enabled in a trusted workspace, then runs two seconds after each completed read. The native status-bar API has no hover visibility events, so moving away hides the card while background sampling continues. The next hover immediately displays the latest snapshot. Click 暂停监控 to stop; 继续 / 重试 or clicking GPU resumes. 刷新一次 reads one sample without restarting a paused watch. Native cards use VS Code's own sizing and dismissal behavior.

CPU uses changes in the extension host's OS CPU counters: 100% = one fully busy logical processor, so 1600% ≈ 16 logical processors fully busy, which need not mean 16 physical cores. The panel also shows the logical CPU count and normalized whole-machine percentage. For example, on 64 logical CPUs, 1600% corresponds to 25% of the machine. The first sample measures a fresh 250 ms interval; subsequent samples measure between updates. In containers, OS-visible CPU counters may cover the host and are not necessarily the container's CPU quota.

Pausing cancels the current read and retains the last CPU/GPU snapshot. Disabled features, untrusted workspaces and window closure stop polling. GPU commands have a 30-second timeout; SSH sampling allows 32 seconds for the GPU command, CPU counters and transport. Timeouts and driver/executable failures pause monitoring and show a retry action. Read operations never overlap.

Local windows query the local machine; Remote SSH, WSL and containers query their current extension host. Install Agent Center there, with a working NVIDIA driver and nvidia-smi; containers need GPU access. Default discovery uses PATH, plus common NVIDIA driver paths on Windows. Set agentStatus.gpu.nvidiaSmiPath to an executable path (supports ~/, not a full shell command), or use agentStatus.gpu.enabled to hide the button and stop monitoring. Requires a trusted workspace. Output stays in memory and the hover; the gpu diagnostics field contains state/timestamps without the full process list.

For multiple Linux servers, place 可用服务器.md in the current workspace root, for example /zengxiangxiang/mps/DNAKit/可用服务器.md, using one entry per line:

40901:ssh root@gpu1.example -p 2201 密码:your-password
40902:ssh root@gpu2.example -p 2202 密码:your-password
h20*8:ssh -i ~/.ssh/id_rsa user@gpu3.example -p 22

The hover adds 当前机器, 40901, 40902, etc. as clickable selections; a check marks the active one. A short SSH login check runs when the list loads, up to two at a time; unsuccessful entries show 40901(不能连接). Selecting an entry retries it and clears the label on recovery. Selecting a server replaces both CPU and GPU data, closes the previous SSH sampling connection and starts two-second monitoring on the selected host. Full CPU/GPU readings are queried for the selected machine. 当前机器 returns to the current extension host.

The list reloads on file creation, save or deletion. Click 重读服务器列表 beside the server selections, or run Agent Center: Reload GPU Server List, to reread the file and recheck all connections even when its contents are unchanged. Use this after edits on shared storage if automatic change notifications were missed; no full-window reload is needed. Multi-root workspaces use the active editor's workspace folder, falling back to the first folder. Removing the selected entry returns to the current machine. -p, -i and -l are supported; arbitrary SSH flags and trailing commands are rejected. Remote monitoring uses nvidia-smi on the server's PATH and Linux /proc/stat. Relative key paths resolve from the workspace root; ~/ and the SSH agent/default keys refer to the extension host running Agent Center. Passwords stay in the source file and connection memory, never command links or diagnostics. First connections pin the SSH host-key fingerprint in extension storage; subsequent connections reject a changed key. Keep the server file private if it contains passwords.

Requires VS Code 1.106+. The monitor uses VS Code's wider native code-hover layout instead of the narrower rich-text layout, while keeping the GPU table's columns preformatted. Window size and font settings still constrain available space. Sampled output is HTML-escaped; only monitor, server-selection and settings commands are trusted. Sampling output is not persisted.

Codex provider switching and shared history

Click the dedicated provider status item, use the Codex quota hover action, or run Agent Center: Switch Codex Provider. The dedicated item is available even without quota credentials.

  • OpenAI 官方(ChatGPT 登录) selects built-in openai and ChatGPT authentication, retaining existing login files. Complete ChatGPT login in Codex if needed. User-level custom OpenAI/ChatGPT endpoint overrides are removed; a custom OPENAI_BASE_URL environment override must be cleared first.
  • Configured APIs, such as beeapi, are listed directly from [model_providers.*] in the current environment's config.toml. Click the desired ID to reuse its address and credentials, without any text input. The menu shows each configured display name and marks the current provider; reopening it picks up external config edits. Only IDs and names appear in the list.
  • 输入其他 API ID… is the optional manual-entry fallback. For model_provider = "beeapi", enter beeapi, not a model or display name. An existing configuration is reused. For a new ID, enter a Responses-compatible Base URL and a masked API Key; these are saved in config.toml, never in VS Code settings or diagnostics. Custom providers requiring ChatGPT authentication must be configured for API authentication first.

Each explicit switch updates the provider label of all indexed local threads in the current CODEX_HOME so the same history is available whichever provider you select. Conversation bodies, JSONL files, pagination offsets, titles, order, archives and login files are preserved. Archived chats remain in their archived list; workspace and thread-type filters still apply. Continuing a chat after reload uses the selected provider, subject to its model and feature support. The scope is this environment's local history. The quota item still reports the saved ChatGPT account's quota, independently of custom API balances.

Backups are saved to CODEX_HOME/agent-center/provider-backups/ (default ~/.codex/agent-center/provider-backups/). The last five successful switch backups are retained; failed-switch backups are kept for recovery. SQLite backups include WAL data; cross-window locks, configuration-change checks and rollback protect existing records. Only history index labels change; transcripts are never rewritten. Stop active Codex replies before switching, then choose 重新加载窗口 after success.

Install Python 3.8+ with sqlite3 on the extension host, or set agentStatus.codexProvider.pythonPath. Automatic discovery tries python3, python and Windows py -3. POSIX config and backups use private permissions; Windows uses the Codex directory's ACLs. Incompatible indexes, legacy transcripts without an index, active config profiles and malformed TOML produce an error before switching. Managed settings or custom Codex launch flags can still override provider selection.

Codex and Claude usage quotas

Status items use compact text such as 5% left | 10-17 11:24 or 5% used | 10-17 11:24. Each provider has its own remaining/used display setting. Hover details explain the selected window and percentage, account or session, plan, reset time, last update and available actions. Colored emoji markers progress from green through yellow and orange to red as the used percentage increases. Quotas are window percentages, rather than absolute token or request counts.

Codex displays the short window when available, falling back to the long window. Claude prefers its 5-hour window and shows other returned 7-day, Opus and Sonnet windows in the hover. Reset timestamps use the extension host's time zone, which can differ between a remote server and your local computer. Manual quota refreshes show an animation; background refreshes retain the current display.

Credentials are read from CODEX_HOME/auth.json or ~/.codex/auth.json for Codex, and CLAUDE_CONFIG_DIR/.credentials.json or ~/.claude/.credentials.json for Claude. Override them with agentStatus.codex.credentialsPath or agentStatus.claude.credentialsPath. Each provider also has enabled, usageDisplayMode, usageUpdateIntervalSeconds and an optional HTTP/HTTPS proxyUrl setting. Quota requests use the existing logged-in session and the provider's quota endpoint; the Google connectivity probe is separate and needs no login.

Google website connectivity

The current VS Code extension host requests https://www.google.com/. A single connectivity icon appears before the globe in the existing Clash status item, for example ✅️ 🌐 √ Google(1605 ms):

  • ✅️: any HTTP response, including 200, redirects, 403, 429 and 5xx.
  • ❌: no HTTP response, including timeouts, DNS, connection or certificate failures.

Checks run at startup and every five hours by default. Hover or click the same item to inspect HTTP status, timing, execution environment and timestamp, or choose “立即检测联网”. The command is Agent Center: Test Google Website Connectivity. There is no separate ChatGPT status item; without Clash only the connectivity icon is displayed. Refreshes retain the previous icon; no icon is shown before the first result.

This connectivity check only contacts the Google public website, without ChatGPT, Claude, quota or chat API requests, credentials or API keys. It stops at response headers without downloading the page or following redirects. ✅️ means an HTTP response arrived; it does not establish that page features work. This is independent of Clash's core-based node test, so the two results may differ. Existing Codex/Claude quota features retain their own requests and settings.

Requests use Node HTTP(S) with VS Code's extension-host proxy and certificate support, following the effective http.proxy, http.proxySupport and environment proxy handling. Remote SSH, WSL and container windows test the remote extension host; ordinary windows test the local host. Environment variables set later in a terminal may not reach an already-running extension host. This reports Agent Center's public-page access; other extensions depend on their own requests.

Settings: agentStatus.network.enabled, testTimeoutMs (15000 ms by default), and updateIntervalSeconds (18000 seconds, or five hours, by default). The Clash node test keeps its independent five-minute default. Checks require workspace trust; disabling or disposing cancels pending requests. Agent Center: Show Diagnostics includes the latest result under network without proxy passwords.

Clash nodes and Google latency

Install Agent Center in your Remote SSH environment and reload the window. On Linux/WSL it first discovers the running Clash/Mihomo core's -f config or -d data directory, supporting custom installation paths. It also checks environment hints, Clash command launchers on PATH and literal clashctl paths in shell integration files before falling back to ~/clash-for-linux/runtime/config.yaml, ~/.config/mihomo/config.yaml and common system locations. The controller address and secret are read automatically.

  • The status bar shows √ Google(3349 ms), or × 超时 when the delay test fails.
  • Hover to see the final node, nested selection chain and routing mode. Rule mode displays the selected proxy group; other rules may use different groups.
  • Click the status bar to immediately open the same hover card above the bottom-right status item, with current-node, latency and subscription information. Click a node to switch, or “全部节点” for the searchable full list. The selection is verified and latency refreshed afterward.
  • Tests use the same Google endpoint as clashtest, https://www.gstatic.com/generate_204, with an 8-second default timeout. This measures latency in milliseconds, rather than download bandwidth.
  • Refreshes and tests latency automatically every 5 minutes (300 seconds) by default. Manual refreshes and node or subscription switches test immediately. Without a discovered Clash service, only the independent connectivity icon is shown when enabled; controller failures provide retry actions.

Test all nodes in parallel

Click 全部节点测速 in the existing bottom-right hover, or run Agent Center: Test All Clash Nodes. Each node uses the same Google endpoint and timeout as the current-node test, through its own delay API request. Up to five requests run concurrently, with remaining nodes queued. This includes proxy-provider nodes loaded by the current core, excluding policy groups and built-in Direct/Reject types. It does not download or rotate other saved subscriptions or send node-selection commands; automatic groups keep following the core's own policy.

The same hover updates each result as √ Google(3349 ms) or × 超时, sorts successful nodes by latency and puts failures last. The full node picker also displays results from this batch. Cancel from the progress notification, 取消测速 in the hover, or Agent Center: Cancel Clash Node Tests to abort waiting requests and stop the queue, retaining completed results. Results are timestamped and kept in memory; configuration updates, subscription switches and changes to the node list clear them. The five-minute automatic task still tests only the current selection. These are latency tests, not download bandwidth or a guarantee that every website works.

Usually leave configPath, installDirectory, controller and secret empty. For multiple instances, restricted process access or a controller in another environment, set agentStatus.clash.configPath in Remote Settings. Explicit configuration takes priority; specifying only installDirectory checks its runtime/hosts/<current-hostname>/config.yaml before runtime/config.yaml. Leave group empty to choose a manual group in configuration order; global mode uses GLOBAL and direct mode uses DIRECT. Set group explicitly when you want a particular rule-mode group. testTimeoutMs, updateIntervalSeconds and enabled control timeout, refresh interval and visibility.

Discovery only reads the extension host's process arguments and command registrations: it does not execute shell startup scripts, scan the entire disk, change services or persist deployment paths. Refreshes rediscover moved or restarted cores, and subscription management infers its installation from the discovered runtime config. When several cores are running, the first readable config in PID order wins; explicit settings select a particular instance.

All requests run in the extension host, so 127.0.0.1 in Remote SSH refers to the remote server. Wildcard controller bind addresses are normalized to loopback. Node selections use the controller API, whose persistence behavior is managed by Clash/Mihomo. Diagnostics include nodes and errors without the controller secret.

Commands: Agent Center: Refresh Clash Node Speed, Agent Center: Choose Clash Node, and Agent Center: Show Diagnostics (the clash field).

Test and select the best node

Click 测速并切换最佳节点 in the existing hover, or run Agent Center: Test and Select Best Clash Node. Every invocation runs a fresh batch with up to five concurrent tests, then picks the successful node with the lowest Google latency reachable through manual Selector groups from the current group. Equal delays prefer the current final node. “Best” refers to this batch's Google latency, rather than bandwidth or availability of every website.

Nested manual selectors are changed from the inside out, then the effective final node is verified. An already-selected best manual path needs no writes. Failed candidates or cancellation during testing leave selections unchanged. Before switching, the mode, relevant groups and manual choices are checked for changes. A failed switch attempts to restore this operation's writes without overwriting detected later choices from another client, and reports recovery status. Results and selection details stay in the same hover; the status bar reflects the verified node and delay.

This action does not change routing mode, subscriptions, rules, DNS or configuration files. Direct mode and an automatic-only current group require a manual selector first; automatic groups are not forcibly pinned. The existing 全部节点测速 action remains test-only, and the five-minute automatic task still tests the current node without selecting a new one.

Start, stop and update the current subscription

The existing status-bar hover includes 开启代理, 关闭代理 and 更新当前订阅, also available as the commands below. These call wnlen/clash-for-linux's native clash on, clash off and clash sub update. Updating reuses the saved source URL; “Refresh Clash Node Speed” still only tests latency.

Running updates force-load the generated configuration and verify its live nodes and groups. Manual choices that still exist are preserved. Failures attempt to restore the original configuration, subscriptions, choices and service state; updates started while stopped keep the service stopped. Native per-host runtimes and legacy scripts/cmd/clashctl.sh installations are supported for these three actions.

After a successful update, old delay results are discarded, current node/subscription state is reloaded and all newly loaded concrete nodes are tested with up to five requests in parallel. The extension-host Google check restarts alongside this workflow, cancelling any request begun before the update rather than reusing it. New results update the existing hover and timestamps immediately, without waiting for the five-minute or five-hour schedules. This is test-only; it does not select the best node.

Updates while stopped still refresh host connectivity but do not start the proxy for delay testing. A failed subscription update does not launch this full refresh. Post-update connectivity or latency errors are reported separately and do not undo a successful subscription update. Existing feature switches and periodic schedules remain in effect.

Controls operate in the current Linux/WSL extension host. Native scripts manage the service and persistent proxy state; child processes cannot rewrite environment variables of already-running terminals or VS Code. Reopen a terminal or reconnect the remote window when needed. The Google connectivity badge keeps its independent check schedule.

Add, switch and delete subscription sources

Click “添加订阅” / “切换订阅” / “删除订阅” in the status-bar hover, or run Agent Center: Add Clash Subscription / Agent Center: Choose Clash Subscription / Agent Center: Remove Clash Subscription.

  • The picker shows provider names from profile-title or download filenames, falling back to source hostnames. Details retain native identifiers and source hosts to distinguish duplicate names. Opening a subscription picker or adding a URL requests metadata; reading stops after headers without applying a configuration. Names are cached in memory for one hour (five minutes on failure), and routine latency refreshes reuse the cache.
  • Paste an HTTP/HTTPS Clash YAML subscription URL; the name is detected automatically, falling back to its hostname. Names are made safe for native storage and duplicates receive a suffix such as -2. Choose to save for later or switch immediately. Saving alone does not download or replace the active configuration.
  • Switching uses the remote installation's native use command to download, compile and restart Clash, briefly interrupting proxy connections. Failed switches attempt to restore the previous subscription and manual node selections, and report whether recovery succeeded.
  • Every subscription, including default, can be removed after confirmation. Removing the active source first applies and verifies the next enabled source in list order (wrapping to the start); if switching fails, the old source is retained. Removing an inactive source preserves the current connection. With no enabled replacement, Clash is stopped before removing the source; removing the last one clears the list. Adding and switching a new source can start it again. Agent Center uses the installation's native configuration writer and yq for storage, adapting the native script's default restriction without editing its source.
  • The URL input is masked. URLs persist in the native runtime's subscriptions.yaml; Agent Center does not include them in source code, VS Code settings or logs. It passes URLs to the native subscription writer through standard input; clash-for-linux manages subsequent downloads. Protect the server's subscription file.
  • Requires compatible clash-for-linux scripts and subscription storage on a Linux/WSL extension host. Discovery derives the installation from both runtime/config.yaml and per-host runtime/hosts/<hostname>/config.yaml, keeping subscription reads, locks and recovery in that runtime. Native commands must use the same directory; another host's runtime is rejected. Set agentStatus.clash.installDirectory if automatic discovery is unavailable. A standalone Clash controller API does not provide this subscription management.

The hover also shows the active subscription's cached name (or source hostname) and native identifier.

Opening files from Codex

Update Agent Center, reload the VS Code window, and click an existing absolute file-path link in Codex. If Codex records the supported open failure, Agent Center runs code -r with that path. No special link format or changes to Codex are required. These 30 extensions are enabled by default:

Category Extensions
Images and PDF .png, .jpg, .jpeg, .gif, .webp, .bmp, .ico, .pdf, .svg
Markdown and documents .md, .markdown, .mdx, .rst
Tabular data .csv, .tsv
Web pages .html, .htm
Notebooks .ipynb
Research documents .tex, .bib
Configuration and logs .log, .json, .jsonl, .yaml, .yml, .toml, .xml
Office documents .docx, .xlsx, .pptx

Files use the same default editor as a manual code -r command. PDF and Office preview require suitable viewer extensions; Markdown, CSV, and HTML are not forced into a rendered preview, table, or browser.

Supported files can also be opened successfully as plain text by Codex, so no failure log is produced. Agent Center detects these active text tabs, closes the unmodified text tabs for that file, and then runs code -r. Closing them first allows the CLI to select the default editor instead of reusing the text tab. Existing custom viewers, notebooks, diffs, and unsaved edits are preserved. The listener also checks the active text tab when it starts.

VS Code does not expose which extension opened a text tab. Consequently, this recovery applies to supported text tabs opened from any source, not just Codex. Turn off agentStatus.codexImageLinks.reopenTextDocuments to keep text tabs as they are, or remove individual formats from the extension list. If the default editor still returns a text tab, the listener leaves it available for editing and prevents a reopen loop, including when the CLI starts slowly.

Agent Center starts the CLI bundled with the current VS Code installation as a background process, passing the path as a literal argument. It does not type commands into your terminal. Remote sessions use the current extension host's CLI connection. On Windows, it runs the same CLI entry point as code.cmd directly, preserving spaces, Unicode, and special characters in paths. CLI failures appear in Show Diagnostics.

In Remote SSH, WSL, or Dev Containers, install Agent Center in the workspace environment where Codex handles the file. Both extensions must use the same extension host and window. This feature does not translate remote paths into local Windows paths. If you installed the separate experimental Codex Image Opener extension, disable or uninstall it first to avoid duplicate handling.

The failure-log fallback is based on the format inspected in Codex 26.917.62051, not a public Codex click-event API; future Codex versions may require an adjustment. Text-tab recovery uses VS Code editor events independently of that log. Web URLs and virtual documents are not handled. Automated tests cover both recovery paths with a mocked VS Code API, CLI selection, and literal argument delivery to real child processes; actual clicks in a remote VS Code session have not yet been verified.

Agent Center reads only new entries from the current window's existing Codex.log, skips historical entries on activation, and opens files only in a focused, trusted window. It does not copy, move, or write that log. Recent recovery diagnostics are limited to 40 entries in memory; VS Code manages the original logs.

  • agentStatus.codexImageLinks.enabled: turn automatic recovery on or off (default: true).
  • agentStatus.codexImageLinks.extensions: replace the default list of extensions for both log and text-tab recovery. Entries are case-insensitive and accept an optional leading dot; duplicates are normalized. An empty list disables all formats.
  • agentStatus.codexImageLinks.reopenTextDocuments: recover clean text tabs for the configured extensions from any source (default: true). Disable to keep the original text tabs.
  • Agent Center: Show Diagnostics: inspect codexImageLinks.status, extensions, textEditorRecovery, the detected log path, and recent results. Results identify codex-log or text-editor as their source. watching means the log is available; waiting for Codex.log means it has not appeared at the expected location. Editor-event recovery can still run while waiting for the log.
  • Agent Center: Restart Codex File Link Listener: restart after troubleshooting, then click the link again.
  • agentStatus.codexImageLinks.logFile: advanced override for the absolute path to the current window and extension host's Codex.log. Leave empty for automatic detection. It selects a file to read, not a destination for new logs.

DNS from the subscription (Linux/WSL)

Choose DNS 使用订阅配置 in the existing bottom-right Clash hover, or run Agent Center: Use Subscription DNS. This is opt-in and applies to the detected clash-for-linux installation. It supports current runtime mixins, host-specific runtime directories and the legacy resources/mixin.yaml layout.

Every click first downloads the current subscription and extracts DNS, with a 15-second total timeout. Download failures, invalid responses or missing DNS fall back to that source's local cache and report its download time. An older-than-five-day cache remains usable offline. Without a valid cache or a successful download, the action reports the problem and leaves configuration untouched.

Background caching starts when clash-for-linux is discovered and refreshes every five days, checking for overdue work during status refreshes and after reconnecting. It keeps old data on failure and retries at most hourly. Background work only saves the cache: it does not apply DNS, update nodes or start/restart Clash. A successful explicit native subscription update also caches its downloaded DNS.

Cache files live in the current Linux/WSL host runtime under .agent-center-dns-cache/<source-hash>.json. With Remote SSH this is the remote disk, not Windows. Host runtimes, source IDs, types and URLs are isolated; changing a URL cannot reuse its previous cache. Files contain only DNS resolution policy and download time, without nodes, subscription URLs or controller credentials. Directory/file modes are 700/600. Disabling Clash monitoring, losing workspace trust or disposing the extension cancels background downloads.

The action backs up the active configuration, subscription state and Mixin under the current runtime's .agent-center-backups/<timestamp>-dns-<id>/, then removes local DNS resolution overrides such as nameservers, split-DNS policy, fallback and fake-IP settings. Host DNS enable, listen and ipv6 remain local; proxy ports, controller credentials, TUN, nodes and rules are retained. Shared fallback mixins are copied into the host runtime rather than edited globally. The downloaded/cached DNS is applied to the current runtime and any existing source file, compared against the resulting policy, and force-loaded into a running core. This does not require the native updater to download nodes/rules, enabling offline DNS recovery without switching subscriptions or reverting nodes. Verification or reload errors restore original files and service state.

The Mixin change persists through native subscription updates and switches. While the policy marker is active, Agent Center start/update actions also remove accidentally reintroduced DNS overrides and verify the result. Reinstallation, manually restoring files or changing the build pipeline may require applying the action again. 恢复原 DNS 覆写 / Agent Center: Restore Clash DNS Overrides restores the original DNS resolution overrides while retaining later edits to unrelated settings and host DNS infrastructure. Download, build, verification or reload failures attempt to restore the original files, node selections and on/off state; a stopped proxy stays stopped. Backups contain configuration secrets and use private directory/file permissions.

After a running core reloads, Agent Center attempts to flush its DNS cache where supported and uses curl through the local HTTP or SOCKS proxy to download Google's public webpage (15-second limit, successful HTTP status and nonempty body required). A failed webpage check is reported separately: the verified DNS policy remains applied, and other node/routing problems may still need diagnosis. This result does not redefine the existing green latency or Google host-connectivity icon. With no curl, no local proxy port, proxy authentication or a stopped proxy, the check is explicitly marked skipped. No ChatGPT login or API key is used. DNS backups and the latest webpage result appear in diagnostics.

Commands

Open the command palette with Ctrl+Shift+P / Cmd+Shift+P and search for Agent Center. Every contributed command is listed here:

Command Purpose
Agent Center: Start NVIDIA GPU Monitor Show the native GPU/CPU hover and start/resume sampling.
Agent Center: Pause NVIDIA GPU Monitor Stop sampling and retain the last frame.
Agent Center: Refresh NVIDIA GPU Once Read one sample without restarting a paused watch.
Agent Center: Reload GPU Server List Reread 可用服务器.md from the current workspace root.
Agent Center: Switch Codex Provider Choose official ChatGPT or enter an API ID; share all indexed local history with the selected provider.
Agent Center: Refresh Codex Usage Refresh the current environment's Codex quota.
Agent Center: Choose Codex Usage Display Choose remaining or used percentage for Codex.
Agent Center: Refresh Claude Usage Refresh the current environment's Claude quota.
Agent Center: Choose Claude Usage Display Choose remaining or used percentage for Claude.
Agent Center: Test Google Website Connectivity Run the extension-host Google check immediately.
Agent Center: Refresh Clash Node Speed Read Clash state and test the selected node's Google latency.
Agent Center: Test All Clash Nodes Manually test all loaded concrete nodes in parallel and show results in the existing hover.
Agent Center: Test and Select Best Clash Node Run fresh tests, select the lowest-latency successful node reachable through the current manual group, and verify or recover.
Agent Center: Cancel Clash Node Tests Cancel the current all-node batch, retaining completed results.
Agent Center: Start Clash Proxy Start the current environment's native proxy and verify its loaded configuration.
Agent Center: Stop Clash Proxy Stop the proxy, verify the controller stops and retain subscriptions.
Agent Center: Update Current Clash Subscription Refresh the active source while preserving its on/off state; immediately refresh host/current/all-node tests after success and recover on update failure.
Agent Center: Use Subscription DNS Prefer fresh DNS, fall back to the local cache, persist and verify its policy, and report a webpage check through Clash.
Agent Center: Restore Clash DNS Overrides Restore backed-up DNS overrides while retaining later unrelated edits and the proxy's on/off state.
Agent Center: Choose Clash Node Search for and switch a node in a manual selector group.
Agent Center: Add Clash Subscription Paste a URL, detect its name, then save or switch.
Agent Center: Choose Clash Subscription Select and apply a saved subscription.
Agent Center: Remove Clash Subscription Confirm deletion, switching or stopping Clash when needed.
Agent Center: Restart Codex File Link Listener Restart log detection and text-tab recovery.
Agent Center: Show Diagnostics Inspect all monitors in the Agent Center output channel.
Agent Center: Open Settings Open this extension's settings.

Feature settings and diagnostics

Search for Agent Center in Settings, or run Agent Center: Open Settings. These switches are independent and enabled by default:

Settings group Enable/disable Other options
GPU/CPU monitor agentStatus.gpu.enabled nvidiaSmiPath
File watcher diagnostics agentStatus.fileWatcher.enabled —
Codex provider switching agentStatus.codexProvider.enabled pythonPath
Codex quota agentStatus.codex.enabled credentialsPath, usageDisplayMode, usageUpdateIntervalSeconds, proxyUrl
Claude quota agentStatus.claude.enabled credentialsPath, usageDisplayMode, usageUpdateIntervalSeconds, proxyUrl
Extension-host Google check agentStatus.network.enabled testTimeoutMs, updateIntervalSeconds
Clash nodes and subscriptions agentStatus.clash.enabled configPath, controller, secret, installDirectory, group, testTimeoutMs, updateIntervalSeconds
Codex file-link recovery agentStatus.codexImageLinks.enabled extensions, reopenTextDocuments, logFile

Each option in the last column uses its row's prefix, for example agentStatus.network.updateIntervalSeconds. With Remote SSH, WSL or containers, use the current remote environment's settings and paths. Existing legacy Notifyer quota settings are used as fallbacks when the corresponding Agent Center setting is not explicitly configured.

Agent Center: Show Diagnostics opens the output channel with codex, codexProvider, claude, network, clash and codexImageLinks results. Inspect the active provider, history count, backup location and existing monitor results. Output omits access tokens, API keys, proxy passwords, controller secrets and complete private subscription URLs. Provider switching, file-opening, network and Clash operations require a trusted workspace.

Complete source, build and downloads

This repository includes all TypeScript source in src/, automated tests in src/test/, runtime resources in resources/, manual validation tools in scripts/, and the dependency lockfile. Download the installable VSIX or the source + runtime full ZIP from GitHub Releases. The full ZIP also contains the compiled out/ modules, production node_modules/, the VSIX and a source manifest. Generated files are distributed as release assets; development dependencies are installed from the lockfile.

To build from a clean clone, use Node.js 20+ and npm:

git clone https://github.com/mapengsen/Agent-Center.git
cd Agent-Center
npm ci
npm run test:unit
npm run package

Packaging creates codex-claude-agent-status-<version>.vsix. To produce the full ZIP as well, run python scripts/build-full-bundle.py with Python 3.8+ after the working tree is committed. See the script guide for bundle options and optional live integration tests.

Related extension

Notifyer is another extension by the same publisher.

Changelog

See the complete changelog for every release.

0.1.50 - 2026-11-15

  • Give slow workspace watcher scans time to finish with bounded startup retries. Clear the status when file events arrive.

0.1.49 - 2026-11-14

  • Use a one-time file event probe to detect watcher failures and scope diagnostic logs to the current connection and affected workspace.

0.1.48 - 2026-11-14

  • Check file watcher logs once, about 90 seconds after startup.

0.1.47 - 2026-11-14

  • Show recursive file watcher failures for the current workspace in the status bar, with a window reload action.

0.1.46 - 2026-10-28

  • Add a persistent 重读服务器列表 action next to GPU server selections to reread the workspace server file and retry connectivity checks.

0.1.45 - 2026-10-27

  • Increase nvidia-smi timeout to 30 seconds (32 seconds for SSH sampling) for slower multi-GPU hosts; remove the stale loading hint after failures.

0.1.44 - 2026-10-26

  • Render the GPU server failure marker (不能连接) in red, preserving clickable retry and automatic removal after recovery.

0.1.43 - 2026-10-26

  • Enlarge aggregate CPU usage with a blue percentage, compact the core/machine summary and remove the background-monitoring footer hint.

0.1.42 - 2026-10-26

  • Check server logins when loading the list and append (不能连接) to failed entries. Retry on selection, clear recovered labels and keep GPU command failures separate from connection failures.

0.1.41 - 2026-10-26

  • Read workspace server definitions from 可用服务器.md and switch the existing hover between local/current-host and SSH CPU/GPU monitoring with one click. Keep blue CPU percentages, two-second polling and pause/refresh actions; watch list changes and protect against stale samples and credential exposure.

0.1.40 - 2026-10-26

  • Color the aggregate CPU percentage blue and remove the hover's host-information line.

0.1.39 - 2026-10-26

  • Remove the hover title, percentage explanation, refresh hint and extra update timestamp to leave more room for CPU/GPU data.

0.1.38 - 2026-10-26

  • Use the wider native code-hover layout and preserve GPU table alignment to reveal columns clipped by the rich-text hover. Keep hover behavior, CPU data and two-second monitoring.

0.1.37 - 2026-10-26

  • Show GPU/CPU in the native floating status-bar hover, visible on hover and hidden when moving away. Keep the CPU/GPU data and pause/resume/single refresh; sample automatically every two seconds.

0.1.36 - 2026-10-26

  • Open a large independent GPU/CPU editor panel; auto-close after pointer exit, with pin and Escape controls. Update aggregate CPU usage and GPU text in place without flicker.

0.1.35 - 2026-10-26

  • Replace the native GPU hover with a persistent right-side view; update changed text in place, retain scrolling and pause when hidden. Requires VS Code 1.106+.

0.1.34 - 2026-10-26

  • Add a GPU button and native live nvidia-smi hover, with one-second sampling, pause/resume, single refresh, remote execution, custom executable path, timeout and cancellation.

0.1.33 - 2026-10-24

  • Cache current subscription DNS on its Linux/WSL host every five days. Manual application prefers fresh DNS and falls back to the matching local cache without downloading nodes/rules. Report cache time and preserve backup, verification, rollback and stopped-state behavior.

0.1.32 - 2026-10-23

  • Refresh Codex quotas every 120 seconds (two minutes) by default, retaining configured overrides, startup checks, failure retries and manual refresh.

0.1.31 - 2026-10-22

  • Immediately refresh host Google connectivity, current state and all loaded node delays after a successful subscription update. Restart stale host requests without selecting a new node; retain periodic schedules, the stopped state and update recovery.

0.1.30 - 2026-10-22

  • Add “Test and Select Best Clash Node”: run a fresh batch, select the fastest successful node reachable through the current group's manual selector chain, verify the result and recover on failures. Test-only and automatic actions retain their behavior.

0.1.29 - 2026-10-22

  • Add cancellable parallel testing of all loaded proxy nodes, up to five at a time, with per-node Google delays and failures in the existing hover and no node-selection writes.

0.1.28 - 2026-10-22

  • Add opt-in subscription DNS priority and DNS-only restore to the native Clash hover, with private backups, generated-policy verification, failure recovery and an independent full-webpage proxy test.

0.1.27 - 2026-10-21

  • Refresh Codex quotas every three minutes by default (180 seconds), preserving startup checks, retries and manual refresh. Claude remains at fifteen minutes.

0.1.26 - 2026-10-21

  • Select configured Codex APIs directly from the provider menu, showing their IDs, names and current selection without repeatedly entering an ID or API credentials.

0.1.25 - 2026-10-21

  • Add Codex provider switching, first-use API setup, shared local history, backups and recovery. Update the complete feature overview on GitHub and the Marketplace.

0.1.24 - 2026-10-21

  • Start/stop Clash and update the current subscription from the native hover, with verified live reload and failure recovery.

0.1.23 - 2026-10-19

  • Support custom per-host clash-for-linux runtime directories.

0.1.22 - 2026-10-17

  • Document the full feature set, setup, refresh schedules, settings and all commands on both the GitHub and Marketplace homepages.

0.1.21 - 2026-10-17

  • Set extension-host Google checks to run every five hours, keeping Clash node tests at five minutes by default.

0.1.20 - 2026-10-17

  • Detect Google connectivity with a single ✅️ / ❌ before the Clash globe, treating any HTTP response as connected.

0.1.10 - 2026-10-15

  • Added clash-for-linux subscription saving, switching, active-subscription hover details and recovery after failed switches.

0.1.9 - 2026-10-15

  • Added Clash/Mihomo Google latency, current-node hover details and one-click switching, with automatic remote configuration discovery.

0.1.8 - 2026-09-30

  • Removed .txt from the default code -r recovery formats. Other configured formats are unchanged.

0.1.7 - 2026-09-29

  • Expanded code -r recovery to 31 formats, including Markdown, CSV/TSV, HTML, notebooks, LaTeX/BibTeX, text/configuration files (including TOML), and Office documents.
  • Added a configurable extension list shared by both recovery paths, native notebook handling, and protection against repeated text-tab reopening after a slow CLI launch.

0.1.6 - 2026-09-29

  • Fixed PDF/SVG recovery when Codex opens the file as text without logging an error: close the clean text tabs before running code -r.
  • Added an independent text-tab recovery setting, unsaved-edit protection, loop prevention, and diagnostic event sources.

0.1.5 - 2026-09-29

  • Changed recovery to execute code -r through the bundled CLI, with remote-window connection handling and bounded process execution.
  • Added PDF and SVG links, plus diagnostics for CLI failures.

0.1.4 - 2026-09-29

  • Added automatic recovery for supported absolute image links in Codex, with diagnostics and an enable/disable setting.
  • Added incremental, bounded log reading with rotation handling and duplicate suppression; recovery diagnostics stay in memory.

0.1.3 - 2026-08-24

  • Replaced monochrome hover Codicons with a distinct set of colorful emoji markers.
  • Added green, yellow, orange, and red percentage indicators based on used quota.

0.1.2 - 2026-08-24

  • Renamed the visible extension brand to Agent Center while retaining the existing Marketplace extension ID.
  • Added Codicon section markers to Codex and Claude hover details.
  • Moved the source repository to mapengsen/Agent-Center.

0.1.1 - 2026-08-20

  • Refined startup, regular refresh, and retry scheduling.
  • Limited the spinning refresh indicator to manual refreshes.

0.1.0 - 2026-08-19

  • Initial independent release extracted from Notifyer.
  • Codex and Claude credential reads, network requests, status items, tooltips, refresh animation, and scheduling now run entirely in the current workspace environment.
  • Contact us
  • Jobs
  • Privacy
  • Manage cookies
  • Terms of use
  • Trademarks
  • Your Privacy Choices
  • Consumer Health Privacy
© 2026 Microsoft
