TYPO3 TCA Snippets Extension
TCA Snippets for TYPO3 TCA in VSCode and VSCodium.
If you want to contribute your own snippets, create a Pull Request via GitHub
If you have problems or ideas, open an Issue via GitHub
You can find the source code on GitHub
Download for VSCode from the Visual Studio Marketplace
Download for VSCodium from Open-VSX.org
Features
All snippets are compatible with TYPO3 13 and 14.
Structure
| Prefix |
Description |
tcafull |
Complete TCA base structure for a new table |
tcaoverride |
TCA override for existing table (e.g. tt_content) |
tcactrl |
ctrl block |
tcatypes |
types block with showitem and palette syntax |
tcapalettes |
palettes definition |
tcacolumns |
Empty columns scaffold |
tcacolumnwrapper |
Column definition with label, exclude, l10n_mode and config placeholder |
Text & Input
| Prefix |
Description |
tcainput |
Text input field |
tcanumber |
Number field |
tcanumberslider |
Number field with slider |
tcadatetime |
Datetime field (date, time, datetime, timesec) |
tcaemail |
Email field |
tcapassword |
Password field |
tcatextarea |
Textarea field |
tcarte |
Rich Text Editor field |
tcaslug |
Slug field |
tcacolor |
Color picker field |
tcalink |
Link field |
tcajson |
JSON editor field |
tcauuid |
UUID field |
tcanone |
None field (read-only display) |
tcapassthrough |
Passthrough field (invisible, stores data without UI) |
tcauser |
User field with custom renderType |
tcaflexform |
FlexForm field |
Checkboxes
| Prefix |
Description |
tcacheck |
Checkbox field with items |
tcacheckcols |
Checkbox field with multiple columns |
tcacheckcolsinline |
Checkbox field with inline columns |
tcachecktoggle |
Checkbox toggle |
tcachecklabeledtoggle |
Checkbox labeled toggle |
Select & Relations
| Prefix |
Description |
tcaselectsingle |
Single select field (static items) |
tcaselectmulti |
Multi-select side-by-side field (static items) |
tcaselectside |
Multi-select side-by-side field (DB relation) |
tcaselectmm |
Select field with MM (many-to-many) relation |
tcaselecttree |
Select tree field |
tcaradio |
Radio buttons field |
tcacategory |
Category tree field |
tcafalimage |
FAL image field |
tcafile |
FAL file field (configurable allowed types) |
tcagroup |
Group field (DB relation) |
tcainline |
Inline (IRRE) field |
Standard / System Fields
| Prefix |
Description |
tcahidden |
Standard hidden field |
tcastarttime |
Standard starttime field |
tcaendtime |
Standard endtime field |
tcafegroup |
Standard fe_group field |
tcasyscat |
sys_category relation field |
Misc
| Prefix |
Description |
tcadisplaycond |
Display condition |
tcal10nmode |
l10n_mode for translation handling |
tcasearchfields |
searchFields entry for ctrl |
tcasecurity |
security array for ctrl |
tcauniversal |
Field with config inherited from tt_content |
Requirements
- TYPO3 13 or higher
- VSCode
^1.90.0 or VSCodium equivalent
Installation
Via Open VSX (VSCodium)
Search for TYPO3 TCA Snippets in the Extensions tab.
Via Marketplace (VSCode)
Search for TYPO3 TCA Snippets in the Extensions tab or install via:
ext install pagea-dev.typo3tca-snippets
Manual (.vsix)
Download the latest .vsix from the Releases page and install via:
Extensions → ··· → Install from VSIX...
Contributing
Pull requests are welcome. For larger changes please open an issue first.
- Fork the repository
- Create your branch:
git checkout -b feat/my-snippet
- Commit your changes:
git commit -m 'feat: add tcainput snippet'
- Push and open a Pull Request
License
MIT
| |
