Phoenix Pulse

The complete IDE companion for Phoenix LiveView development

Phoenix Pulse provides intelligent IntelliSense, validation, and navigation for Phoenix 1.6+ and 1.7+ applications. Work faster with smart completions for components, templates, routes, and assigns—all powered by deep understanding of your Phoenix project structure.

Powered by Elixir's own AST parser for 100% accurate code analysis with intelligent caching for lightning-fast performance.

⚙️ Recommended Settings

For the best experience with Phoenix Pulse, add these settings to your VS Code settings.json:

{
    // Disable word-based suggestions to prevent pollution
    "editor.wordBasedSuggestions": "off",

    // Allow snippets in quick suggestions
    "editor.suggest.snippetsPreventQuickSuggestions": false,

    // Instant completions (no delay)
    "editor.quickSuggestionsDelay": 0,

    // Better completion ordering
    "editor.suggest.localityBonus": true,

    // Exclude build directories from search
    "search.exclude": {
        "**/.elixir_ls": true,
        "**/.lexical": true,
        "**/deps": true,
        "**/_build": true
    }
}

Note: These settings are recommended but not required. Phoenix Pulse works without them, but the experience is noticeably better with them.

☰ Phoenix Pulse Project Explorer

Phoenix Pulse provides a comprehensive Project Explorer in the VS Code sidebar that gives you instant visibility into your entire Phoenix application structure. Click the Phoenix Pulse icon in the Activity Bar to access it.

Features

📊 Statistics Overview

Get a bird's-eye view of your Phoenix project with real-time metrics:

Overview - Total counts: components, routes, schemas, templates, LiveView modules
Route Breakdown - Routes grouped by HTTP verb (GET, POST, PUT, DELETE, etc.)
Component Metrics - Components categorized by complexity
Top Schemas - Top 5 schemas by total fields and associations

🗂️ Schemas

Browse all your Ecto schemas with field and association counts:

Expand schema → View all fields (with types) and associations
Click field/association → Jump to schema definition
Right-click → Copy schema name, module name, table name, or file path

🧩 Components

Explore all function components grouped by file:

Expand component file → See all components in that file
Component info → Shows attribute and slot counts
Expand component → View all attributes and slots with types
Click component → Jump to component definition
Right-click → Copy component name, module name, tag (<.component>), or file path

🛣️ Routes

Navigate your Phoenix router with grouped routes:

Routes grouped by controller for better organization
Route info → Shows HTTP verb, path, and action
Click route → Jump to route definition in router
Right-click → Copy route name, path, or file path

📄 Templates

View all templates (file-based and embedded):

Expand template file → See all templates in that file
Template info → Shows format (HTML, JSON, etc.)
Click template → Jump to template file or function definition
Right-click → Copy template name or file path

⚡ LiveView

Complete visibility into your LiveView architecture:

LiveView modules grouped by name
Expand module → See all lifecycle functions organized by type
Function count badge - Shows total functions in each module
Click function → Jump directly to function definition

Search icon in toolbar → Filter all sections by name, path, or action
Multi-word search → Find items matching multiple terms
Clear icon → Reset filter and show all items
Auto-expand → Matching categories expand automatically

📋 Copy Actions

Right-click any item to copy useful information to clipboard:

Copy Name - The item's name
Copy Module Name - Full module path
Copy File Path - Absolute path to the file
Copy Component Tag - Ready-to-use component tag
Copy Route Path - Route path
Copy Table Name - Database table name for schemas

📊 ERD Diagram

Graph icon in toolbar → View Entity-Relationship diagram of your schemas
Interactive Mermaid diagram showing all schema relationships
Visual representation of associations and fields

✨ Features

🧩 Component Intelligence

Smart Completions

Type <. to see all available function components
Autocomplete component attributes with type information and documentation
Slot completions (<:slot_name>) with attribute suggestions
Special attribute completions (:for, :if, :let, :key)

Real-Time Validation

❌ Missing required attributes
⚠️ Unknown attributes (respects attr :rest, :global)
⚠️ Invalid attribute values (validates against values: [...] constraints)
❌ Missing required slots with nested slot support
❌ Component not imported in HTML module

Navigation & Documentation

F12 / Ctrl+Click on component name → Jump to definition
Hover over components → See full documentation, attributes, slots, and usage examples
Works with nested components and function clauses

Example:

<.input
  field={@form[:email]}
  type="email"
  label="Email Address"
  required
/>
<!-- All attributes validated, autocompleted, and documented -->

📄 Template Features (Phoenix 1.7+)

Template Completions

Type render(conn, : in controllers to see available templates
Shows both file-based (.heex) and embedded function templates
Template suggestions include location and type information

Template Validation

❌ Template not found in HTML module
Suggests creating template file or embedded function
Validates template name conventions

Navigation

F12 / Ctrl+Click on :template_name → Jump to template file or function definition
Hover → See template type, file location, and parent module
Supports both Phoenix 1.6 (:view) and 1.7+ (:html) patterns

🛣️ Route Intelligence

Comprehensive Router Support

✅ All HTTP verbs (get, post, put, patch, delete, options, head, match)
✅ Phoenix 1.7 verified routes (~p"/users/#{user.id}")
✅ Nested resources with proper path generation
✅ Singleton resources (singleton: true)
✅ Custom parameter names (param: "slug")
✅ Live routes and forward routes
✅ Resource action filtering (only:, except:)
✅ Pipeline tracking and scope management

Smart Completions

Route helper completions with parameter hints
Action completions filtered by resource options
Verified route path completions
Navigation component route validation

Navigation & Documentation

F12 / Ctrl+Click on route helpers or verified routes → Jump to router definition
Hover → See HTTP verb, full path, parameters, controller/LiveView, and pipeline

📦 Controller-Aware Assigns

Schema-Aware Completions

Type @ in templates to see assigns passed from controller render() calls
Drill down into Ecto schemas: @user.email, @post.author.name
Works in both .heex templates and ~H sigils in .ex files
Detects has_many associations and suggests :for loop patterns

Ecto Schema Integration

Automatically discovers all Ecto schema fields and associations
Shows field types in completion documentation
Resolves belongs_to, has_one, has_many, and many_to_many associations
Handles schema aliases across module namespaces

Example:

<!-- Type @ to see controller assigns -->
<h1><%= @user.name %></h1>
<p>Email: <%= @user.email %></p>
<!-- All fields autocompleted from User schema -->

⚡ Phoenix Attributes & Events

Phoenix LiveView Attributes

All 29 phx-* attributes with rich documentation
Context-aware: phx-click, phx-submit only shown when events exist
Hover documentation includes usage examples and HexDocs links

Event Completions

Inside phx-click="" → Shows available handle_event functions
Distinguishes between primary (same file) and secondary (LiveView) events
Supports both string and atom event names
Validates event name exists in LiveView module

JS Command Support

JS.push, JS.navigate, JS.patch, JS.show, JS.hide, etc.
Pipe chain completions
Parameter suggestions for each command

🔄 Smart :for Loop Validation

Context-Aware Key Requirements

Regular :for loops require :key attribute
Stream iterations (:for={{id, item} <- @streams.items}) skip :key requirement
Warns if :key added to stream (unnecessary, uses DOM id)

:for Loop Variable Completions

Type inference for loop variables: <div :for={user <- @users}>{user.█}</div>
Shows Ecto schema fields for loop variables
Supports nested field access: user.organization.name
Handles tuple destructuring: {id, item} <- @streams.items

🔍 Go-to-Definition (F12)

Supported Navigation:

✅ Component names (<.button>)
✅ Nested components (<.icon> inside <.banner>)
✅ Slot names (<:actions>, <:header>)
✅ Template atoms (:home in render(conn, :home))
✅ Route helpers (Routes.user_path)
✅ Verified routes (~p"/users")

Fast & Cached:

First navigation: ~500ms (parses file)
Subsequent: ~1-2ms (uses cache)
Content-based caching for instant repeat lookups

💡 Hover Information

Rich Documentation for:

✅ Components (all attributes, slots, documentation blocks)
✅ Component attributes (type, required status, default value, allowed values)
✅ Phoenix attributes (phx-* with examples and links)
✅ Templates (type, file location, module info)
✅ Routes (HTTP verb, full path, parameters, controller, pipeline)
✅ Events (handle_event function signature and location)
✅ JS commands (all JS.* functions with parameters)
✅ Schema associations (shows target schema and available fields)

📦 Installation

From VS Code Marketplace (Recommended)

Open VS Code
Press Ctrl+Shift+X (or Cmd+Shift+X on Mac)
Search for "Phoenix Pulse"
Click Install

Via Command Line

code --install-extension onsever.phoenix-pulse

📋 Requirements

Minimum Requirements

VS Code: 1.75.0 or higher
Phoenix: 1.6+ or 1.7+ project
Node.js: 16+ (for LSP server)

Supported File Types

.ex - Elixir source files
.exs - Elixir script files
.heex - HEEx template files
~H sigils - Embedded HEEx in .ex files

🎯 Supported Phoenix Versions

Feature	Phoenix 1.6	Phoenix 1.7+
Function Components	✅	✅
Component Attributes & Slots	✅	✅
Templates (`:view` modules)	✅	✅
Templates (`:html` modules)	-	✅
Verified Routes (`~p`)	-	✅
Route Helpers	✅	✅
LiveView Events	✅	✅
Ecto Schemas	✅	✅
Controller Assigns	✅	✅
Nested Resources	✅	✅
Singleton Resources	✅	✅

⚙️ Configuration

Phoenix Pulse includes configurable settings. Access them via:

Ctrl+, (or Cmd+, on Mac) → Search "Phoenix Pulse"
Or edit settings.json directly

Available Settings

{
  // Use Elixir's AST parser (requires Elixir installed)
  "phoenixPulse.useElixirParser": true,

  // Parser concurrency (1-20, default: 10)
  "phoenixPulse.parserConcurrency": 10,

  // Show progress notifications during workspace scanning
  "phoenixPulse.showProgressNotifications": true
}

🐛 Troubleshooting

Completions not working?

Check 1: Phoenix Project Detection

Ensure mix.exs exists in workspace root
Phoenix dependency should be in deps
Check "Phoenix Pulse" output channel for "✅ Phoenix project detected!"

Check 2: File Types

HEEx templates must use .heex extension
Elixir files must use .ex or .exs
Components must be in *_web/components/ directory

Check 3: Reload VS Code

Ctrl+Shift+P → "Developer: Reload Window"

Template features not working?

Phoenix 1.7+ (:html modules)

HTML module must use: use YourAppWeb, :html
Controller name must match convention: PageController → PageHTML
Templates in page_html/ directory or embedded functions

Phoenix 1.6 (:view modules)

View module must use: use YourAppWeb, :view
Controller name must match: PageController → PageView
Templates in templates/page/ directory

Routes not showing?

Check Router Location

Router file must match pattern: *_web/router.ex
Standard location: lib/my_app_web/router.ex

Check Router Syntax

Ensure router.ex compiles without errors
Run mix compile to check for syntax errors

Performance issues?

Enable Performance Logging

export PHOENIX_LSP_DEBUG_PERF=true
code .

Check the "Phoenix Pulse" output channel for slow operations:

Good: < 50ms for completions, < 100ms for hover
Slow: > 200ms indicates issue

Solutions:

Lower concurrency: "phoenixPulse.parserConcurrency": 5
Disable progress notifications: "phoenixPulse.showProgressNotifications": false
Check Elixir is installed: elixir --version

Still having issues?

Check GitHub Issues: https://github.com/phoenix-pulse/phoenix-ls/issues
Open New Issue: Include:
- VS Code version
- Phoenix version
- Extension version
- Logs from "Phoenix Pulse" output channel
- Sample code that reproduces the issue

🤝 Contributing

We welcome contributions! See the monorepo repository for contribution guidelines.

Development Setup:

git clone https://github.com/phoenix-pulse/phoenix-ls
cd phoenix-ls
npm install
npm run compile

See CONTRIBUTING.md for detailed development documentation.

📄 License

MIT License - See LICENSE for details.

💖 Credits

Built with ❤️ for the Phoenix community by Onurcan Sever.

Inspired by the amazing Phoenix framework, LiveView, and the developers pushing Elixir web development forward.

Special Thanks:

Phoenix Framework team for creating an incredible web framework
Elixir community for continuous inspiration
All contributors and users who provided feedback

Enjoy the pulse! 💥

GitHub • Issues • VS Code Marketplace • npm Package

Phoenix Pulse

Onurcan Sever

Phoenix Pulse

⚙️ Recommended Settings

☰ Phoenix Pulse Project Explorer

Features

📊 Statistics Overview

🗂️ Schemas

🧩 Components

🛣️ Routes

📄 Templates

⚡ LiveView

🔍 Search & Filter

📋 Copy Actions

📊 ERD Diagram

✨ Features

🧩 Component Intelligence

📄 Template Features (Phoenix 1.7+)

🛣️ Route Intelligence

📦 Controller-Aware Assigns

⚡ Phoenix Attributes & Events

🔄 Smart :for Loop Validation

🔍 Go-to-Definition (F12)

💡 Hover Information

📦 Installation

From VS Code Marketplace (Recommended)

Via Command Line

📋 Requirements

Minimum Requirements

Recommended

Supported File Types

🎯 Supported Phoenix Versions

⚙️ Configuration

Available Settings

🐛 Troubleshooting

Completions not working?

Template features not working?

Routes not showing?

Performance issues?

Still having issues?

🤝 Contributing

📄 License

💖 Credits
