Isotope Language Support for VS Code

A comprehensive Visual Studio Code extension providing full language support for Isotope specifications with IntelliSense, validation, syntax highlighting, and integrated build tools.

✨ Features

🎨 Rich Language Support

• Syntax Highlighting: Custom TextMate grammar with semantic highlighting
• IntelliSense: Context-aware auto-completion for all Isotope keywords
• Stage-Aware Completions: Smart suggestions based on current build stage
• Hover Documentation: Instant help for keywords and instructions

🔍 Real-Time Validation

• Live Error Detection: Real-time validation using the Isotope CLI
• Diagnostic Integration: Errors and warnings displayed inline
• Save-Time Validation: Automatic validation when saving files
• Problem Panel Integration: All issues shown in VS Code's Problems panel

🚀 Integrated Build Tools

• One-Click Building: Build ISOs directly from VS Code
• Progress Tracking: Real-time build progress with cancellation support
• Build History: Track and review previous builds
• Output Management: Automatic output directory handling

📁 Dedicated Sidebar

• Specification Explorer: Browse all Isotope files in workspace
• Build History: View recent builds with success/failure status
• Template Gallery: Quick-start templates for common configurations
• Context Actions: Right-click build, validate, and test operations

🛠️ Advanced Features

• JSON Conversion: Convert legacy JSON configurations to Isotope format
• Template System: Built-in templates for Ubuntu, Windows, and custom builds
• Multi-Workspace Support: Works across multiple workspace folders
• Command Palette Integration: All features accessible via Ctrl/Cmd+Shift+P

🔧 Installation

From VS Code Marketplace

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X)
3. Search for "Isotope Language Support"
4. Click Install

From VSIX

1. Download the latest .vsix from releases
2. Run: code --install-extension isotope-lang-1.0.0.vsix

⚙️ Configuration

Configure the extension via VS Code settings:

{
  "isotope.executable.path": "isotope",
  "isotope.validation.enabled": true,
  "isotope.validation.onSave": true,
  "isotope.autoCompletion.enabled": true,
  "isotope.build.outputDirectory": "./output",
  "isotope.build.showProgress": true,
  "isotope.logging.level": "info"
}

Settings Reference

🚀 Getting Started

1. Create Your First Specification

Use Ctrl+Shift+P → "Isotope: New Isotope Specification" to create from templates:

# Ubuntu Server with Docker
FROM ./ubuntu-22.04-server.iso
CHECKSUM sha256:a4acfda10b18da50e2ec50ccaf860d7f20ce1ee42895e3840b57b2b371fc734

LABEL name="ubuntu-docker"
LABEL version="1.0.0"

STAGE init
VM provider=qemu
VM memory=4G
VM cpus=2

STAGE os_install
WAIT 30s
PRESS enter
# ... installation automation

STAGE os_configure
RUN apt-get update
RUN apt-get install -y docker.io
COPY ./configs/setup.sh /usr/local/bin/

STAGE pack
EXPORT ./output/ubuntu-docker.iso
BOOTABLE true

2. Use IntelliSense

• Type STAGE → auto-complete with stage options
• Type VM → get property suggestions (provider, memory, cpus, etc.)
• Type PRESS → get key name completions (enter, tab, esc, etc.)
• Hover over keywords for instant documentation

3. Build Your ISO

• Command Palette: Ctrl+Shift+P → "Isotope: Build ISO"
• Context Menu: Right-click .isotope file → "Build ISO"
• Sidebar: Click build button (🚀) next to specification
• Keyboard: F5 when editing .isotope file

4. Monitor Progress

Watch real-time build progress in:

• Notification popup with progress bar
• Build History sidebar panel
• Terminal output (if enabled)

📚 Language Features

Stage-Aware Completions

The extension provides intelligent completions based on your current stage:

Smart Validation

Real-time validation catches errors as you type:

• ✅ Syntax Validation: Proper keyword usage and formatting
• ✅ Semantic Validation: Stage-appropriate instructions
• ✅ Value Validation: Valid providers, formats, durations
• ✅ File Validation: Source file existence and checksums

Rich Hover Information

Hover over any keyword for comprehensive documentation:

WAIT - Waits for a duration or condition

Examples:
• WAIT 30s
• WAIT 5m FOR "Installation complete!"

Supported units: s (seconds), m (minutes), h (hours)

🎨 Syntax Highlighting

Custom theme with semantic highlighting for:

• Keywords: FROM, STAGE, RUN, etc. (bold blue)
• Stage Names: init, os_install, etc. (teal)
• Properties: provider, memory, etc. (light blue)
• Values: strings, numbers, booleans (various colors)
• Comments: # prefixed lines (green, italic)
• Templates: ${VAR} variables (orange)

🗂️ Sidebar Integration

The Isotope sidebar provides three panels:

📋 Specifications

• Browse all .isotope files in workspace
• Click to open files
• Right-click for build/validate/test actions
• File modification indicators

📊 Build History

• Recent build results with timestamps
• Success/failure status indicators
• Build duration and error details
• Click to view detailed logs

📄 Templates

• Pre-built specification templates
• Ubuntu Server, Windows 11, minimal Linux
• One-click template insertion
• Custom template support

⌨️ Keyboard Shortcuts

Note: Shortcuts only active when editing .isotope files

🔧 Commands

All commands available via Command Palette (Ctrl+Shift+P):

• Isotope: Build ISO - Build current specification
• Isotope: Validate Specification - Validate syntax and semantics
• Isotope: Test VM Boot - Test VM boot without full build
• Isotope: Convert JSON to Isotope - Convert legacy configurations
• Isotope: New Isotope Specification - Create from templates
• Isotope: Open Output Directory - Open build output folder
• Isotope: Refresh Specifications - Refresh sidebar views

📋 Requirements

• VS Code: Version 1.74.0 or higher
• Isotope CLI: Installed and accessible in PATH
• System Requirements: Based on chosen VM provider (QEMU, VirtualBox, etc.)

Installing Isotope CLI

# Install via cargo
cargo install isotope

# Or build from source
git clone https://github.com/OmniCloudOrg/isotope.git
cd isotope
cargo build --release

🐛 Troubleshooting

Validation Not Working

1. Ensure Isotope CLI is installed: isotope --version
2. Check executable path in settings
3. Verify workspace has .isotope files
4. Check Problems panel for specific errors

Build Fails

1. Validate specification first
2. Check output directory permissions
3. Ensure source ISO files exist
4. Review build logs in Build History

IntelliSense Not Working

1. Ensure file has .isotope extension
2. Check isotope.autoCompletion.enabled setting
3. Reload VS Code window
4. Check for conflicting extensions

Sidebar Not Showing

1. Ensure workspace contains .isotope files
2. Click Isotope icon in Activity Bar
3. Run "Isotope: Refresh Specifications"
4. Check View → Open View... → Isotope

🤝 Contributing

We welcome contributions! Please see our Contributing Guide.

Development Setup

# Clone the repository
git clone https://github.com/OmniCloudOrg/vscode-isotope.git
cd vscode-isotope

# Install dependencies
npm install

# Compile TypeScript
npm run compile

# Package extension
vsce package

Testing

# Run tests
npm test

# Open extension development host
F5 in VS Code

📄 License

MIT License - see LICENSE file for details.

🔗 Links

• Isotope CLI - Main Isotope project
• Documentation - Complete documentation
• Issues - Bug reports and feature requests
• Marketplace - VS Code Marketplace
