otak-proxy

Dead-simple proxy toggling for VSCode & Git

Switch your proxy on and off with a single click. No hassle, no config files.

What it does

• Three-mode system - Auto (system), Manual, or Off
• Auto mode - Syncs with your system/browser proxy in real-time with smart monitoring
• Manual mode - Use your own fixed proxy settings
• One-click cycling - Click status bar to cycle: Off → Manual → Auto
• Live monitoring - Auto mode checks for system proxy changes with configurable intervals and retry logic
• Connection testing - Verify proxy works before enabling
• Smart detection - Finds proxy from browser, system, or environment with customizable priority
• npm support - Automatically configures npm proxy settings alongside VSCode and Git
• Secure validation - Protects against command injection with strict input validation
• Multi-language UI - Automatically displays in English or Japanese based on your VSCode language

Getting started

Quick setup

The extension asks how you want to configure proxy on first launch:

• Auto (System) - Automatically uses your browser/system proxy
• Manual Setup - Set your own proxy URL
• Skip - Configure later

Three modes explained

Off Mode

Proxy disabled - no proxy settings applied

Manual Mode

Uses your configured proxy URL - stays fixed until you change it

Auto Mode

Automatically syncs with system proxy:

• Detects browser/system proxy settings
• Configurable polling interval (10-300 seconds, default 30 seconds)
• Checks immediately when switching back to VSCode
• Automatic retry with exponential backoff on detection failures
• Detailed logging of proxy changes and detection sources
• Perfect for network switching scenarios

Using it

• Click status bar - Cycles through Off → Manual → Auto
• Command palette (F1):
  • "Toggle Proxy" - Cycle modes
  • "Test Proxy" - Test current proxy
  • "Import System Proxy" - Detect and use system proxy
  • "Configure Manual" - Set manual proxy URL

Status indicators

• $(circle-slash) Proxy: Off - Proxy disabled
• $(plug) Manual: http://... - Using manual proxy
• $(sync~spin) Auto: http://... - Using system proxy (auto-sync)
• $(sync~spin) Auto: No system proxy - Auto mode, but no system proxy detected

Prerequisites

• VSCode 1.9.0+
• Git installed and in PATH

Language Support

The extension automatically detects your VS Code display language and shows messages in:

• English (default)
• Japanese (日本語)

Language is detected from your VS Code Language Pack. No configuration needed - it just works!

Architecture

The extension follows a modular architecture for maintainability and testability. After a comprehensive refactoring, the codebase has been reorganized from a single 1335-line file into focused, testable modules.

Refactoring Results

• Before: extension.ts (1335 lines)
• After: extension.ts (160 lines, 88% reduction)
• Total modules: 30+ focused files
• Test coverage: 389 passing tests (unit + property-based)
• All files: Under 300 lines each

Folder Structure

src/
├── extension.ts          # Entry point (160 lines)
│
├── core/                 # Core business logic
│   ├── types.ts         # Shared type definitions (ProxyMode, ProxyState, CommandContext)
│   ├── ProxyStateManager.ts    # State persistence with in-memory fallback
│   ├── ProxyApplier.ts         # Proxy configuration orchestration
│   └── ExtensionInitializer.ts # Initialization and setup logic
│
├── commands/            # Command implementations
│   ├── types.ts         # Command-specific types
│   ├── CommandRegistry.ts      # Centralized command registration
│   ├── ToggleProxyCommand.ts   # Toggle between Off/Manual/Auto modes
│   ├── ConfigureUrlCommand.ts  # Manual proxy URL configuration
│   ├── TestProxyCommand.ts     # Proxy connection testing
│   ├── ImportProxyCommand.ts   # System proxy detection and import
│   └── index.ts         # Module exports
│
├── ui/                  # User interface
│   └── StatusBarManager.ts     # Status bar management with i18n support
│
├── config/              # Configuration managers
│   ├── GitConfigManager.ts     # Git global proxy configuration
│   ├── VscodeConfigManager.ts  # VSCode workspace proxy settings
│   ├── NpmConfigManager.ts     # npm proxy configuration
│   └── SystemProxyDetector.ts  # Multi-platform system proxy detection
│
├── monitoring/          # Proxy monitoring (Auto mode)
│   ├── ProxyMonitor.ts         # Polling-based proxy change detection
│   ├── ProxyMonitorState.ts    # Monitor state management
│   └── ProxyChangeLogger.ts    # Proxy change event logging
│
├── validation/          # Input validation and security
│   ├── ProxyUrlValidator.ts    # URL format and security validation
│   └── InputSanitizer.ts       # Command injection prevention
│
├── errors/              # Error handling
│   ├── ErrorAggregator.ts      # Multi-source error collection
│   └── UserNotifier.ts         # User-facing error notifications
│
├── i18n/                # Internationalization
│   ├── types.ts         # i18n type definitions
│   ├── I18nManager.ts          # Translation manager (singleton)
│   └── locales/                # Translation files (en, ja)
│       ├── en.json
│       └── ja.json
│
├── models/              # Data models
│   └── ProxyUrl.ts             # Proxy URL parsing and validation
│
├── utils/               # Shared utilities
│   ├── Logger.ts               # Centralized logging
│   └── ProxyUtils.ts           # Proxy-related utility functions
│
└── test/                # Test suites
    ├── *.test.ts               # Unit tests
    ├── *.property.test.ts      # Property-based tests (fast-check)
    ├── generators.ts           # Test data generators
    └── helpers.ts              # Test utilities

Key Design Principles

1. Single Responsibility: Each module handles one specific concern

   • Commands are isolated in separate files
   • State management is centralized in ProxyStateManager
   • Configuration logic is separated by target (Git, VSCode, npm)

2. Dependency Injection: Components receive dependencies through constructors

   • Enables easy testing with mocks
   • Clear dependency graph
   • No hidden global state

3. Error Aggregation: Multiple configuration errors are collected and displayed together

   • ErrorAggregator collects errors from Git, VSCode, and npm
   • UserNotifier presents consolidated error messages
   • Users see all issues at once, not one at a time

4. State Management: Centralized state with automatic fallback

   • ProxyStateManager handles all state operations
   • Automatic in-memory fallback if globalState fails
   • Transparent migration from legacy state formats

5. Command Pattern: Commands are isolated and independently testable

   • Each command is a pure function receiving CommandContext
   • CommandRegistry centralizes registration logic
   • Easy to add new commands without modifying existing code

6. Property-Based Testing: Core logic is verified with property-based tests

   • 15+ property-based tests using fast-check
   • Tests verify universal properties across random inputs
   • Complements unit tests for comprehensive coverage

Component Interactions

┌─────────────────────────────────────────────────────────────┐
│                      extension.ts                           │
│                    (Entry Point)                            │
└────────────────────────┬────────────────────────────────────┘
                         │
                         ├─→ ExtensionInitializer
                         │   └─→ Initial setup & migration
                         │
                         ├─→ CommandRegistry
                         │   ├─→ ToggleProxyCommand ──┐
                         │   ├─→ ConfigureUrlCommand ─┤
                         │   ├─→ TestProxyCommand ────┤
                         │   └─→ ImportProxyCommand ──┤
                         │                             │
                         │                             ↓
                         │                    ┌────────────────┐
                         │                    │ ProxyApplier   │
                         │                    └────────┬───────┘
                         │                             │
                         │                    ┌────────┴────────┐
                         │                    │                 │
                         │                    ↓                 ↓
                         │            GitConfigManager  VscodeConfigManager
                         │                    ↓
                         │            NpmConfigManager
                         │                    │
                         │                    ↓
                         │            ErrorAggregator
                         │
                         ├─→ ProxyStateManager
                         │   └─→ State persistence & migration
                         │
                         ├─→ StatusBarManager
                         │   └─→ UI updates with i18n
                         │
                         └─→ ProxyMonitor (Auto Mode)
                             ├─→ SystemProxyDetector
                             └─→ ProxyChangeLogger

Module Responsibilities

Core Modules

• extension.ts: Minimal entry point that orchestrates initialization and command registration
• ExtensionInitializer: Handles first-run setup, state migration, and component initialization
• ProxyStateManager: Manages ProxyState persistence with automatic fallback and migration
• ProxyApplier: Orchestrates proxy configuration across Git, VSCode, and npm

Command Modules

• CommandRegistry: Centralizes all command registration and event listener setup
• ToggleProxyCommand: Cycles through Off → Manual → Auto modes
• ConfigureUrlCommand: Prompts user for manual proxy URL
• TestProxyCommand: Tests proxy connectivity before enabling
• ImportProxyCommand: Detects and imports system proxy settings

Configuration Modules

• GitConfigManager: Manages git config --global http.proxy
• VscodeConfigManager: Manages VSCode workspace proxy settings
• NpmConfigManager: Manages npm proxy configuration
• SystemProxyDetector: Multi-platform system proxy detection (Windows/macOS/Linux)

UI & Monitoring

• StatusBarManager: Updates status bar text, tooltip, and icons based on current state
• ProxyMonitor: Polls for system proxy changes in Auto mode
• ProxyChangeLogger: Logs proxy change events for debugging

Validation & Error Handling

• ProxyUrlValidator: Validates proxy URL format and security
• InputSanitizer: Prevents command injection attacks
• ErrorAggregator: Collects errors from multiple sources
• UserNotifier: Displays user-friendly error messages with suggestions

Testing Strategy

The extension uses a dual testing approach:

1. Unit Tests: Verify specific examples and edge cases

   • 200+ unit tests covering individual functions
   • Mock external dependencies (Git, npm commands)
   • Fast execution for rapid feedback

2. Property-Based Tests: Verify universal properties

   • 15+ property-based tests using fast-check
   • Generate random inputs to find edge cases
   • Validate correctness properties from design document
   • Examples:
     • State persistence fallback works for any state
     • Command error handling is consistent across all commands
     • Status bar reflects any ProxyState accurately

3. Integration Tests: Verify end-to-end workflows

   • Test complete command execution flows
   • Verify component interactions
   • Use real Git/npm commands where necessary

Test Performance:

• Development mode: ~30 seconds (reduced iterations)
• CI mode: ~2 minutes (full iterations)
• Parallel execution enabled
• 389 tests passing

Configuration

Manual proxy URL

Set your manual proxy in settings:

{
  "otakProxy.proxyUrl": "http://proxy.example.com:8080"
}

Auto mode settings

Customize auto mode behavior:

{
  "otakProxy.pollingInterval": 30,
  "otakProxy.detectionSourcePriority": ["environment", "vscode", "platform"],
  "otakProxy.maxRetries": 3
}

• pollingInterval: How often to check for proxy changes (10-300 seconds)
• detectionSourcePriority: Order to check proxy sources
• maxRetries: Maximum retry attempts on detection failure

Auto mode detection sources

Auto mode checks these sources (customizable order):

1. Environment variables (HTTP_PROXY, HTTPS_PROXY)
2. VSCode's existing proxy setting
3. Windows: Internet Explorer settings (registry)
4. macOS: System network preferences (Wi-Fi, Ethernet, etc.)
5. Linux: GNOME proxy settings (gsettings)

Troubleshooting

Proxy won't enable?

• Check the URL format (needs http:// or https://)
• Run "Test Proxy" to verify connection
• Make sure Git is installed (git --version)
• Verify npm is installed if you need npm proxy support (npm --version)

Settings not applying?

• VSCode might need a restart for some proxy changes
• Check you have permission to modify Git global config
• Verify npm configuration permissions if npm proxy fails

Auto mode not detecting changes?

• Check the polling interval setting (default 30 seconds)
• Verify system proxy is properly configured
• Check extension output log for detection errors
• Try adjusting detection source priority

Security and validation errors?

• Proxy URLs are validated for security (no shell metacharacters allowed)
• Credentials in URLs are automatically masked in logs and UI
• Invalid URLs are rejected before configuration

More from otak

System & Performance

• otak-monitor - Live CPU, memory & disk monitoring in your status bar
• otak-restart - Quick restart buttons for Extension Host and VSCode

Productivity

• otak-committer - AI-powered commit messages in 25+ languages
• otak-pomodoro - Pomodoro timer for focused work sessions
• otak-clock - Dual timezone clock for remote teams

Workflow

• otak-zen - Distraction-free coding mode

License

MIT

Issues? Report on GitHub | Source: GitHub
