Raven Verifier

VS Code integration for the Raven intermediate verification language and verification tool.

New to Raven? nyu-acsys.github.io/raven introduces the language and what it is for.

Features

Syntax Highlighting: Proper highlighting for .rav files.
Verification: Automatic verification as you edit, with error diagnostics.
Manual Verification: Run Raven: Verify File, or use Cmd+Shift+R (Mac) / Alt+Shift+R (Windows/Linux).
Strict Mode: Warn about assumed termination, explicit free declarations and physically atomic blocks, with a yellow success indicator when warnings are present.
Diagnostics: Errors and warnings shown in the editor and Problems panel, with related locations and optional gutter icons.
Inherited Contracts: View inherited contracts above callable headers and on hover, and inherited module members on hover.
Hover and Go to Definition: See the declaration of a name on hover, and jump to it, including into the standard library.
Counterexamples: For a failed check, the values of the variables and fields it mentions appear at its end, the branch its path takes at each if before it after the condition, and hovering over a variable of the failing member shows its value there. "possibly" marks values the solver could not confirm. Hovering over a hint shows the whole counterexample; VS Code shortens long hints unless editor.inlayHints.maximumLength is 0.
Outline: Modules, members and named assertions and invariants in the Outline view, breadcrumbs and Go to Symbol in Editor, with their verification status.
Verification Status: See above each procedure, lemma, function and module whether it verified, failed or timed out.

Prerequisites

None. This extension bundles the Raven verifier and Z3 for your platform (Linux x64/arm64, macOS x64/arm64, Windows x64), so nothing needs to be installed separately.

Installation

You can install this extension directly from the Marketplace, or run the following command in VS Code:

code --install-extension nyu-acsys.raven-verifier

Usage

Verification: Verification runs automatically as you edit — no need to save first.
Manual Verification: Run Raven: Verify File from the Command Palette, or press Cmd+Shift+R (Mac) or Alt+Shift+R (Windows/Linux) when editing a .rav file.
Verify this: Click Verify this above a member, module or named assertion (assert a: ...) to verify only it, now and after each edit, while you work on its proof; the status bar names it. Click Verify all above it, or run Raven: Verify All Members (End Focus), to verify the whole file again. This needs a Raven verifier supporting LSP protocol 4 or later.

The status bar tracks the active file and its current version. Messages use the Raven: prefix: grey for not checked or outdated results, blue while verifying, green when verified, yellow when verified with strict warnings, red for errors, and orange when verification is unavailable. Editing a file marks its previous result as outdated and stops the old check.

With a recent Raven verifier, changes to saved included files also recheck the files that depend on them, including indirect includes and files outside the workspace.

Strict verification

Set ravenServer.strict to true to enable strict mode for automatic verification and Raven: Verify File. It defaults to false and can be set per workspace or folder:

{
  "ravenServer.strict": true
}

For a single strict check, run Raven: Verify File in Strict Mode from the Command Palette. This checks the active file regardless of the setting and leaves it unchanged; subsequent checks use the configured mode.

Strict warnings appear in the editor and Problems panel, with yellow gutter markers when gutter icons are enabled. Verification can succeed with warnings: the status reads Raven: Verified with warnings in yellow, with a tooltip explaining why. Verification errors still show a red failure indicator.

Strict-mode diagnostics and inherited-contract displays require a Raven verifier supporting LSP protocol 3 or later. An older verifier reports that strict-mode diagnostics are unavailable; use Raven: Update Verifier to check for a compatible update.

Staying up to date

The extension ships with a working verifier, and also keeps up with new Raven releases on its own, so you get a new verifier without waiting for a new extension. It checks at most once a day and asks before downloading anything; Raven: Show Verifier Version says what is currently in use. Run Raven: Update Verifier to check for updates on demand.

To turn this off, set ravenServer.updateChannel to bundled (or run Raven: Use Bundled Verifier). To pin a particular Raven release, set the channel to tag and name it in ravenServer.ravenVersion.

Opening `.rav` files from the file manager

Installing this extension teaches VS Code what a .rav file is, but it cannot tell your operating system — nothing an extension installs is allowed to change your system's file associations. So double-clicking a .rav file in Explorer, Finder or your file manager won't open VS Code until you say so once.

Windows

Right-click any .rav file → Open with → Choose another app → pick Visual Studio Code → tick Always use this app to open .rav files.

Equivalently, in PowerShell. This writes under HKCU, so there is no administrator prompt; adjust the path if VS Code is installed system-wide, where it lives under C:\Program Files\Microsoft VS Code:

$code = "$env:LOCALAPPDATA\Programs\Microsoft VS Code\Code.exe"
New-Item 'HKCU:\Software\Classes\.rav' -Force -Value 'VSCode.rav' | Out-Null
New-Item 'HKCU:\Software\Classes\VSCode.rav' -Force -Value 'Raven source file' | Out-Null
New-Item 'HKCU:\Software\Classes\VSCode.rav\shell\open\command' -Force `
    -Value "`"$code`" `"%1`"" | Out-Null

macOS

Select a .rav file in Finder → File ▸ Get Info (Cmd+I) → under Open with: choose Visual Studio Code → click Change All….

If VS Code isn't in the dropdown, pick Other…, set the Enable: filter to All Applications, and select it from /Applications.

Linux

.rav is not a MIME type any distribution knows, so it needs defining first — otherwise the only type a file manager can offer to reassign is text/plain, and changing that would redirect every plain-text file to VS Code.

mkdir -p ~/.local/share/mime/packages
cat > ~/.local/share/mime/packages/raven.xml <<'EOF'
<?xml version="1.0" encoding="UTF-8"?>
<mime-info xmlns="http://www.freedesktop.org/standards/shared-mime-info">
  <mime-type type="text/x-raven">
    <comment>Raven source file</comment>
    <sub-class-of type="text/plain"/>
    <glob pattern="*.rav"/>
  </mime-type>
</mime-info>
EOF
update-mime-database ~/.local/share/mime

With the type defined, either right-click a .rav file in your file manager and set Visual Studio Code as the default application, or do it from the terminal:

xdg-mime default code.desktop text/x-raven

The name to use there depends on how VS Code was installed: code.desktop for the official .deb/.rpm, code_code.desktop for the Snap, com.visualstudio.code.desktop for the Flatpak, code-insiders.desktop or codium.desktop for those builds. Snap and Flatpak keep their desktop files outside /usr/share/applications, so look everywhere XDG does rather than in one directory:

for dir in "${XDG_DATA_HOME:-$HOME/.local/share}" ${XDG_DATA_DIRS//:/ }; do
    ls "$dir/applications" 2>/dev/null
done | grep -i code | sort -u

Then confirm it took, and restart your file manager if it is still showing the old association:

xdg-mime query filetype some-file.rav   # text/x-raven
xdg-mime query default text/x-raven     # code.desktop

Check the first one against a file with something in it. Content sniffing outranks the glob for empty files, so a .rav you just created with touch reports as application/x-zerosize even when everything is set up correctly.

Learning Raven

The Raven Tutorial is a from-scratch introduction written around this extension: Part 0 starts from the extension you have just installed and a first .rav file, and a single running example grows from a plain value into a concurrent data structure. Every listing in it is real, checked source.

Configuration

This extension provides the following settings:

ravenServer.maxNumberOfProblems: The maximum number of errors Raven reports per check; 0 for no limit. Needs a Raven verifier supporting LSP protocol 4 or later.
ravenServer.smtTimeout: The time limit, in milliseconds, for each proof obligation the SMT solver checks. A member whose proof runs out of time is marked as timed out.
ravenServer.cache: Skip the checks of members verified before whose dependencies are unchanged. Needs a Raven verifier supporting LSP protocol 4 or later.
ravenServer.trace.server: Traces the communication between VS Code and the language server.
ravenServer.strict: Enable strict-mode warnings for automatic and ordinary manual verification. Defaults to false; see Strict verification.
ravenServer.executablePath: Path to the Raven executable. Leave empty to let the extension choose one; overrides the update channel.
ravenServer.updateChannel: stable (follow Raven releases), tag (use the release named by ravenServer.ravenVersion), or bundled (only ever use the shipped verifier).
ravenServer.ravenVersion: The release tag to use on the tag channel, e.g. v1.4.0.
ravenServer.checkForUpdates: Whether to check daily for a newer verifier.
ravenServer.showGutterIcons: Show red error, yellow warning and blue information icons in the editor's gutter.
ravenServer.highlightRelatedLocations: Underline a diagnostic's related locations in the editor.

Developing Raven or This Extension

Working on Raven itself and want to verify against a local build instead of the bundled binary, or want to build this extension from source? See the GitHub repo.
