HED Annotation Tools

Language Server Protocol implementation for HED (Hierarchical Event Descriptors), providing intelligent editing support for annotating neuroimaging data in BIDS datasets.

Features

Real-time Validation

Validates HED strings against the official HED schema with inline error and warning markers.

Schema-aware Autocomplete

Context-aware tag suggestions from the HED hierarchy with semantic search.

Definition Tracking

Navigate from Def/Name references to their Definition/Name declarations with Go to Definition (F12).

Hover Documentation

View tag descriptions, full paths, and related tags on hover.

Semantic Search & Warnings

Type natural language terms to find relevant HED tags. Warnings help catch deviations from HED, like tag extension.

Supported File Types

• JSON sidecars (*_events.json, dataset_description.json)
• TSV files (*_events.tsv)

Installation

From VS Code Marketplace

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X / Cmd+Shift+X)
3. Search for "HED Language Support"
4. Click Install

From VSIX

Download the .vsix file from GitHub Releases and install:

code --install-extension hed-lsp-0.3.0.vsix

Configuration

Configure the HED schema version in your VS Code settings:

{
  "hed.schemaVersion": "8.3.0"
}

The extension automatically detects schema versions from dataset_description.json when present.

Supported Schemas

• Standard Schema: HED 8.x (default: 8.3.0)
• Library Schemas: SCORE, LANG, and other HED libraries

Usage

Autocomplete

• Type / after a tag to see child tags
• Type , or ( to see top-level tags
• Type natural language terms (e.g., "button press") for semantic suggestions
• After Def/, see definitions from the current document

Validation

• Errors appear as red squiggles with diagnostic messages
• Warnings appear as yellow squiggles
• {column} placeholders are automatically skipped during validation

Navigation

• Hover: View tag documentation
• Go to Definition (F12): Jump from Def/Name to Definition/Name

Development

# Clone the repository
git clone https://github.com/hed-standard/hed-lsp.git
cd hed-lsp

# Install dependencies
npm install

# Compile
npm run compile

# Run tests
cd server && npm test

# Package extension
npx @vscode/vsce package

Project Structure

hed-lsp/
├── client/              # VS Code extension client
│   └── src/
│       └── extension.ts
├── server/              # LSP server implementation
│   └── src/
│       ├── server.ts        # LSP connection and handlers
│       ├── validation.ts    # HED validation
│       ├── completion.ts    # Autocomplete provider
│       ├── hover.ts         # Hover documentation
│       ├── embeddings.ts    # Semantic search
│       └── definitionProvider.ts
├── docs/                # Architecture documentation
└── .github/             # CI/CD workflows

Contributing

Contributions are welcome! Please see CONTRIBUTING.md for guidelines.

Reporting Issues

Use the issue templates for bug reports and feature requests.

License

MIT License. See LICENSE for details.

Related Projects

• HED Resources - HED documentation and tutorials
• hed-python - Python HED tools (hedtools on PyPI)
• hed-javascript - JavaScript HED validator (hed-validator on npm)
• hed-schemas - HED schema definitions

Acknowledgments

Developed by Seyed Yahya Shirazi for the HED Working Group.
