md for Visual Studio Code

Markdown with mathematics, chemistry, charts and diagrams — drawn entirely on your own machine, inside the preview you already use.

What this is

md is a Markdown preview for people who write documents and not only READMEs. Formulas and chemical equations, charts drawn from the function you write, Mermaid flowcharts, Graphviz graphs, PlantUML drawings, data pasted straight out of a spreadsheet, footnotes, front matter and highlighted code all render as you type, and the finished document exports to HTML, PDF, EPUB, LaTeX or SVG.

The first thing worth knowing: it extends VS Code's built-in Markdown preview rather than opening a window of its own. Open Preview (⇧⌘V, Ctrl+Shift+V), Open Preview to the Side, the two-way scroll sync and every keybinding you have already learned keep working exactly as before, and one document renders the same way however you opened it. Nothing asks you to lower markdown.preview.security either — the extension is built around that strict default rather than around an exception to it.

Everything is drawn on your own machine: by engine files carried inside the extension, and, in the case of the charts, by the extension's own renderer. There is no account, no server of ours and no network round trip.

Screenshots

A chart beside the formula that produced it, in a dark colour theme — mathematics and chemistry set by KaTeX, and the chart drawn by the extension itself, with no engine behind it. Its ink follows the theme, so the same fence reads correctly light or dark.

The same document in a light theme. The page follows your colour theme and your Markdown preview fonts by default.

A .puml file previewing as the diagram it describes, source still fully editable, through Preview Diagram in the editor title bar.

Features

Mathematics, and chemistry with it

TeX and LaTeX mathematics inline as $…$, displayed as $$…$$, or in a fenced ```math block, typeset by KaTeX. Chemical equations and physical units come with it through the bundled mhchem extension: \ce{…} and \pu{…} set the way a textbook would. A lone $ in prose is left alone, so "$5 and $10" stays a sentence about money rather than becoming a formula.

Charts, from a fence

A fenced ```plot block is a chart. Write sin(x) and you get the curve. x: -10..10 sets the window and y: auto, which is the default, fits the vertical axis to what the function actually does; title:, xlabel:, ylabel:, legend:, grid:, axes:, width:, height: and samples: set the rest. One figure holds as many series as you like, each drawn in its own colour and named in the legend — envelope = exp(-abs(x)/5) — and a series can equally be a parametric curve, (cos(t), sin(t)) for t in 0..2*pi, or measured numbers, points: 0,0 1,2 2,1. The expressions are ordinary arithmetic and comparisons, the trigonometric, hyperbolic and inverse functions, sqrt, cbrt, abs, exp, exp2, ln, log2, log10, floor, ceil, round, atan2, pow and hypot, and the constants pi and e.

Nothing is bundled to draw them. The diagram engines carried inside the extension are megabytes of JavaScript apiece; a chart uses none of them. It is drawn by the extension's own renderer, in the same pass that renders the Markdown, so the engine files shipped here are exactly the files that were there before charts existed. That is also what settles where a chart runs. Graphviz is WebAssembly and has to be laid out in the extension host, where it takes a moment to compile before the first graph appears; Mermaid and PlantUML are scripts that run in the page itself. A chart is neither, so the preview is handed a finished drawing rather than something that has to draw one — nothing to fetch, nothing to warm up, nothing to fall back to, and no script in the page for the preview's default security to allow or refuse.

Being a drawing from the outset is also why a chart survives the trip out of the document. It is vector in the preview, in the self-contained HTML, in the PDF and in an exported EPUB — the first vector figure md has put into a book on any of its platforms, where every other rich block is a picture — and Export Diagram as SVG… offers it beside the diagrams. LaTeX is the exception: a .tex file cannot take a vector drawing without a conversion step it has no way to carry, so a chart travels there as the source you wrote, under a comment, exactly as a Mermaid, Graphviz or PlantUML block does.

A block that cannot be read keeps its own source on the page under a single plot: … line saying what is wrong — an unknown function, a range that does not increase, a bracket that was never closed. Never a hole, never an error box.

Mermaid

A fenced ```mermaid block draws a Mermaid diagram — flowcharts, sequence and class diagrams, state machines, Gantt charts and the rest of what Mermaid 11 can draw — and follows the light or dark theme of the page it sits on.

Graphviz

A fenced ```dot, ```graphviz or ```gv block is laid out by Graphviz. Every layout program can be named as the block's language instead — neato, circo, fdp, sfdp, twopi, osage and patchwork — so the same graph becomes a hierarchy, a spring model, a circle or a radial fan by changing one word.

PlantUML

A fenced ```plantuml or ```puml block draws the UML family and the good deal more PlantUML can draw beside it: sequence, class, component, activity, state, mind maps, work breakdowns and Gantt charts.

CSV and TSV blocks

A fenced ```csv or ```tsv block is drawn as a table, quoted fields and all, with all-number columns lined up on the right. The source stays the data you pasted, so next month's numbers replace it wholesale instead of being re-typed into pipes and dashes.

Front matter

YAML or TOML front matter at the very top of a file — --- … --- or +++ … +++ — is recognised as metadata and hidden from the page and from every export, instead of surfacing as a horizontal rule followed by stray text.

Footnotes

Write [^id] in the text and [^id]: the note on a line of its own. The notes gather under a rule at the foot of the page, numbered in the order a reader meets them, each reference linking down to its note and each cited note linking back.

Task lists, tables and the everyday rest

Headings, bold, italic, inline code, links, strikethrough, block quotes including nested ones, bullet and numbered lists with nesting, task lists (- [ ] and - [x]), GitHub-style tables with column alignment, fenced code blocks that scroll sideways rather than wrap, thematic breaks and \newpage page breaks for the exports. Author notes — an HTML comment whose text begins with note:, written on a line of its own — stay in the file and never reach the page.

Syntax highlighting

A fenced block that names its language reads with its keywords, comments and strings set apart, in md's own quiet three-tone palette rather than a bright editor one that would fight the page. Forty-odd languages are covered. A fence with no language, or one whose language is unknown, stays plain rather than being guessed at.

Diagram files preview as diagrams

A .puml, .plantuml, .iuml or .pu file, and a .gv or .dot one, opens as its own language with syntax highlighting and a Preview Diagram button in the editor title bar. The panel beside it shows the diagram the file describes and follows every edit, while the source stays fully editable.

Exports

Export as HTML… writes one self-contained file that opens anywhere with nothing beside it — diagrams as drawings, formulas as selectable text. Export as PDF… prints that same page at A4, A5, US Letter or Legal, or at a print-on-demand trim size (6 × 9″, 5 × 8″, 5.5 × 8.5″). Export as EPUB… builds an e-book whose table of contents is the document's own headings, with an identifier derived from the title, so re-exporting updates the reader's copy instead of stacking up beside it — and a chart travels into that book as vector, while a diagram arrives as a picture. Export as LaTeX… writes .tex in which your mathematics is still the $…$ you typed rather than a picture of it; a diagram or a chart travels as the source you wrote, under a comment naming its language. Export Diagram as SVG… saves one diagram, or one chart, as a real vector file.

Commands

All six appear in the Command Palette under the md category.

Mathematics is not on the SVG list, because KaTeX sets a formula as HTML and text and there is no vector drawing to hand over.

Settings

Every setting is resource-scoped, so it can be set for the user, for a workspace or for one folder.

Turning an engine off leaves the block readable as the source you wrote. It is never blank and never an error box. Charts are the odd one out among those switches: there is no engine behind them, so turning md.diagrams.plot off loads nothing less — it is there for when the numbers behind a figure are what you would rather read.

Themeing

By default the preview looks like the rest of your editor. It takes the colours of your current colour theme and the typography of the built-in Markdown preview — your markdown.preview.fontFamily, markdown.preview.fontSize and markdown.preview.lineHeight — with your editor.fontFamily for code. Change your theme and the page changes with it, diagrams included.

Set md.preview.theme to paper and the page becomes md's own instead: warm "fresh paper" in a light theme, "carbon paper" in a dark one, set in American Typewriter with Courier New for code, matching the iPhone, iPad, Mac and Android apps. md.preview.bodyFont and md.preview.codeFont override either theme's faces where a machine lacks them.

Privacy

Everything renders on your machine, from engine files that live inside the extension. md has no account, no telemetry and no servers of ours to send anything to. It reads the document you are previewing and writes only the file you name when you ask for an export. The single thing that can reach the network is an image your own document names by URL, which the preview fetches so it can show it, exactly as a browser would. Visual Studio Code's own telemetry is the editor's, governed by your telemetry.telemetryLevel and by Microsoft's privacy statement. This extension adds nothing to it and reads nothing from it. The full policy is in PRIVACY.md.

Requirements

• Visual Studio Code 1.95 or later.
• Desktop VS Code. The mathematics, highlighting and Graphviz engines run in the extension host and read their files from disk, which the browser extension host cannot do, so there is no vscode.dev build rather than one that silently renders half a document.
• A trusted workspace. The extension declares no support for untrusted ones and leaves that restricted default alone.

Known limitations

Said plainly, because each one is a decision rather than an oversight.

• A deliberate subset, not a CommonMark engine. The renderer is the apps' renderer and inherits their omissions on purpose: raw HTML is escaped rather than passed through, so tags render as the characters you typed, there are no reference-style links, and a four-space indent continues a paragraph rather than starting a code block.
• PDF output is not byte-identical to the apps'. Same page sizes, same margins, same content, a different rasterizer — and American Typewriter does not exist away from Apple, so the glyphs themselves differ.
• An exported EPUB keeps its code plain. The e-book is built from the document before any colouring is applied, on every platform md ships on.
• An author note is hidden only on a line of its own. Written inline, it renders.
• View modes belong to VS Code, not to md. The iPhone, iPad, Mac and Android apps remember whether each file was last open in the editor, the preview or a split, because they own their whole window. Here the editor owns it: Open Preview and Open Preview to the Side place the preview, View: Toggle Editor Group Layout rearranges the columns, and VS Code restores your groups and tabs itself. md keeps no memory of its own, adds no setting for one and opens no preview uninvited.

What changed

Every release is listed in the Changelog tab of this page, and in CHANGELOG.md on GitHub.

The rest of the family

md is also a native app elsewhere, sharing this renderer and these export formats:

• md for iPhone and iPad
• md for macOS
• md for Android

Questions and bug reports are welcome at github.com/nettrash/md.vscode/issues.

Licence

MIT — see LICENSE. © 2026 nettrash.

The mathematics, diagram and highlighting engines are open-source projects carried inside the extension, under their own licences:

Mermaid's own bundle carries DOMPurify under the Apache License 2.0 and the Mozilla Public License 2.0, and js-yaml, Lodash and parts of Cytoscape under MIT.
