Database Viewer

A powerful VS Code extension for viewing, filtering, and exploring SQLite and MongoDB databases with an intuitive interface and smart filtering capabilities.

✨ Features

• SQLite Support: Connect to SQLite database files (.db, .sqlite, .sqlite3)
• MongoDB Support: Connect to MongoDB instances using connection strings
• Smart Filters:
  • Numbers: Use operators like >100, <50, >=10, <=20, 10-20 (range)
  • Dates: Filter with >2024-01-01, <2024-12-31, 2024-01-01 to 2024-12-31 (range)
  • Text: Simple substring matching
• Interactive Data Grid:
  • Click column headers to sort
  • Per-column filtering with search icon
  • Pagination for large datasets
  • Syntax-highlighted values (numbers, strings, booleans, null)
• Tree View Explorer: Browse databases and their tables/collections in the sidebar
• Persistent Connections: Automatically save and restore database connections
• Auto-Open SQLite Files: Automatically detect and open .db files when clicked

📸 Screenshots

Interactive data grid with sorting and filtering

Smart filtering for number columns with operators

Date filtering with ranges and comparison operators

🚀 Installation

Install from the VS Code Marketplace:

ext install mmoussa.database-viewer

Or search for "Database Viewer" in the Extensions view (Ctrl+Shift+X).

📖 Usage

Adding Database Connections

1. Open the Database Explorer in the VS Code sidebar (database icon)
2. Click the database icon (➕) to add a SQLite database
3. Click the server icon to add a MongoDB connection
4. Or simply open any .db file - it will be added automatically!

Viewing and Filtering Data

1. Expand a database connection in the explorer
2. Click on a table/collection to view its data
3. Click the filter icon (🔍) on any column header to filter:
   • For numbers: Type >100, <50, >=10, 10-20, etc.
   • For dates: Type >2024-01-01, 2024-01-01 to 2024-12-31, etc.
   • For text: Type any substring to search
4. Press Enter or click the 🔍 button to apply the filter
5. Click column headers to sort ascending/descending
6. Use pagination controls at the bottom to navigate large datasets

Filter Examples

Number Filters:

• >100 - Greater than 100
• <50 - Less than 50
• >=10 - Greater than or equal to 10
• 10-20 - Between 10 and 20 (range)
• !=5 - Not equal to 5

Date Filters:

• >2024-01-01 - After January 1, 2024
• <2024-12-31 - Before December 31, 2024
• 2024-01-01 to 2024-12-31 - Date range
• 2024-06 - Contains "2024-06" (partial match)

Configuration

The extension stores database connections in VS Code settings under databaseViewer.connections.

Dependencies

• sqlite3: SQLite database driver
• mongoose: MongoDB object modeling tool

Development

• npm run compile: Compile TypeScript to JavaScript
• npm run watch: Watch for changes and recompile automatically

📝 Changelog

[0.0.164] - 2024-12-24

Added:

• Database icon for marketplace listing
• 3 professional screenshots showcasing features
• Enhanced README with badges and better documentation
• Categories and keywords for improved discoverability

Improved:

• Smart filter UI with search button icon (🔍)
• Date filters now support ranges and comparison operators
• Number filters support multiple operator types
• Filter help text shows supported operators

[0.0.163] - 2024-12-24

Added:

• Smart filtering system with operator support
• Number filters: >, <, >=, <=, =, !=, ranges
• Date filters: comparison operators and date ranges
• Filter submission via Enter key or button click
• Per-column filter inputs with type detection

Improved:

• Filter UI with dedicated input fields per column
• Better filter user experience with visual feedback

[0.0.1] - Initial Release

Added:

• SQLite database support (.db, .sqlite, .sqlite3)
• MongoDB connection support
• Interactive data grid with pagination
• Column sorting (ascending/descending)
• Global search across all columns
• Tree view explorer for databases and tables
• Persistent connection storage
• Auto-open SQLite files on click
• Syntax highlighting for different data types

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

🤝 Contributing

Contributions are welcome! Feel free to submit issues and pull requests on GitHub.

💬 Support

If you encounter any issues or have suggestions, please open an issue on GitHub.
