Typst Format Panel

Interactive side panel for Typst editing in VSCode. Provides one-click access to text formatting, mathematical symbols, environments, tables and grids — with right-click context menus for variants and modal assistants for complex structures.

Ported from latex-format-panel.

Français ? Voir README-FR.md.

Table of contents

• Features
• Requirements
• Installation
• Usage
• Configuration
• Development
• Adding a command
• Contributing
• License

Features

• Three tabs: Formats, Math, Perso (custom)
• Left click inserts the default variant of a command
• Right click opens a context menu with all available variants (long arrows, list markers, color/size presets, matrix delimiters, code block languages, …)
• Automatic math-mode detection: commands adapt to whether the cursor is inside $…$ or not; incompatible commands are cancelled cleanly without destroying the current selection
• Modal assistants for complex structures:
  • #table(…) — rows/columns, header styling, alternate row colors, empty top-left cell
  • #grid(…) — column widths, gutters, default alignment
  • Matrices — dimensions, delimiter choice (parentheses, brackets, bars, braces, …)
• Configurable Perso tab — define your own buttons and menus in VSCode settings
• taskize integration — dedicated button for the taskize package with 2/3/4-column and auto-fit variants
• Comment / Uncomment — // toggling via buttons and VSCode commands (Typst: Comment selection, Typst: Uncomment selection)
• Sticky panel — once opened, the panel stays visible even when switching to non-.typ files (PDF previews, other tabs)

Requirements

• VSCode ^1.80.0
• A Typst language provider so .typ files are recognized as typst. The recommended extension is Tinymist Typst.

If your Typst extension does not register the language automatically, add this to your settings.json:

"files.associations": { "*.typ": "typst" }

Installation

From source (development / self-install)

git clone https://github.com/mmaunier/typst-format-panel.git
cd typst-format-panel
npm install
npx vsce package
# Then in VSCode: Ctrl+Shift+P → "Extensions: Install from VSIX"
# and pick the .vsix file created under build/

For local development

git clone https://github.com/mmaunier/typst-format-panel.git
cd typst-format-panel
npm install
code .
# Press F5 to launch an Extension Development Host with the panel loaded

Usage

1. Open a .typ file.
2. The Typst Format icon appears in the activity bar.
3. Click it to reveal the panel with the three tabs.
4. Left-click a button to insert its default variant at the cursor (or wrap the current selection).
5. Right-click a button to open its context menu of variants — including the raw markup versus function forms (*bold* vs #strong[bold]), long arrows, list markers, code block languages, and more.
6. Right-click on #table …, #grid … or mat to open the corresponding modal assistant.

Selection markers used in templates:

• $1 — where the selected text goes
• $0 — final cursor position after insertion
• \n — newline

Configuration

The Perso tab is fully configurable via the VSCode setting typstFormatPanel.persoButtons. Three element types are supported:

[
  { "type": "titre", "texte": "My section" },

  { "type": "bouton",
    "texte": "Section",
    "commande": "= $1$0" },

  { "type": "bouton_variantes",
    "defaut": 1,
    "variantes": [
      { "texte": "Simple frame",
        "commande": "#block(stroke: 1pt, inset: 8pt, radius: 4pt)[$1]$0" },
      { "texte": "Colored frame",
        "commande": "#block(fill: luma(230), inset: 8pt, radius: 4pt)[$1]$0" }
    ]
  }
]

Open the settings UI (Ctrl+,) and search for Typst Format Panel to edit them with tooltips and validation.

Development

Project layout:

src/
  extension.js                 VSCode entry point
  actions/
    formatActions.js           Format commands + comment/uncomment
    mathActions.js             Math commands
    persoActions.js            Perso commands (generated from settings)
  config/
    commandFormatVariants.js   Format templates + wrapWithTable / wrapWithGrid
    commandMathVariants.js     Math templates + wrapWithMatrix
  webview/
    template.html              Layout + modals + front-end JS
    format.html                Format tab buttons
    math.html                  Math tab buttons
    styles.css                 Styles
    webviewProvider.js         Webview provider + message dispatch
utils/
  utils.js                     isInMathMode (Typst) + processTemplate

Adding a command

1. Add an entry in src/config/commandFormatVariants.js (or commandMathVariants.js):

   mycommand: {
     default: 'v1',
     variants: [
       { id: 'v1', label: '#mycmd[…]', description: 'My command',
         textMode: '#mycmd[$1]$0', mathMode: null,
         supportsText: true, supportsMath: false }
     ]
   }


2. Add its name to getFormatCommands() (or getMathCommands()).
3. Add a <button onclick="sendCommand('mycommand')">…</button> in format.html (or math.html).
4. Reload the Extension Development Host (Ctrl+R).

Contributing

Bug reports and pull requests are welcome. Please open an issue first for large changes so we can discuss the approach.

License

MIT © Mikaël Maunier. See LICENSE.txt.

Changelog

See CHANGELOG.md for the release history.
