9Router Monitor Pro

The definitive real-time token & quota monitor for 9Router AI Gateway directly in your status bar.

Supports multi-account quota aggregation, multi-model pinning, remote Cloudflare Tunnels, interactive dashboard, and zero-config local discovery.

📸 Visual Showcase & Feature Tour

1. Interactive Webview Dashboard Pro Max (3-Tab Command Center)

A comprehensive, zero-latency control center with seamless tabbed navigation:

Tab 1 · 📊 Providers & Quotas

High-performance Fluent Dark Theme grid matrix that gives you an immediate overview of all AI providers connected to 9Router. Features realtime keyword search, dynamic category filter chips (Antigravity, Gemini, Claude, Codex, etc.), multi-criteria sorting (Highest Usage, Lowest, Name, Priority), and one-click pin/hide/active controls.

Providers and Quotas Tab

Tab 2 · 📈 Usage & Analytics

Real-time aggregated monitoring with 5 KPI cards (Total Requests, Prompt Tokens, Cached Tokens, Completion Tokens, Est. Cost) and a live historical table of recent requests with HTTP status badges, token in/out ratios, model, and active accounts. Features Date Picker filtering with midnight rollover and configurable auto-reload intervals.

Usage and Analytics Tab

Tab 3 · 🖥️ Live Console Log

Stream server logs in real time over Server-Sent Events (SSE) directly into an embedded Fluent dark terminal. Features Pause/Resume, Server Clear sync, Auto-scroll, text search/filter, date range navigation, flexible pagination (100, 200, 500, All), and syntax highlighting (DONE, POST, TOKEN_REFRESH, WARN, ERROR). Automatically activates an Adaptive Tunnel Engine when connecting remotely via Cloudflare Tunnel to bypass proxy response buffering.

Live Console Log Tab

2. Dual Status Bar Widgets & Live Telemetry Pulse

Never crowd your status bar. 9Router Monitor Pro provides two complementary status bar indicators:

📊 Main Quota Widget: Sums up remaining balances and total quotas across all pinned accounts into a single condensed metric (10 ⭐ · G3.8 9.4K · GW 7.6K). Hovering reveals a high-density Markdown inspection table with aggregate totals and per-account breakdowns.
⚡ Dedicated 9R Log Widget ($(terminal) 9R Log · 10.2K req · G3.8 🟢): An independent status bar widget placed right next to the main quota bar. Shows real-time request density, current active model, and a live health pulse dot (🟢). Click to open directly into the Live Console Log.

Dual Status Bar Widgets

3. Minimalist Hover Intelligence HUD

Hover over the 9R Log status bar item to trigger the instant Hover Intelligence HUD:

KPI Snapshot Matrix: Immediate glance at total requests, input tokens, cache hits, output tokens, and estimated cost.
Recent Transactions Stream: Interactive table showing the last 10, 25, or 50 API transactions with timestamps, target models, providers, token volumes, and execution statuses.
Synchronized Action Bar: 1-click links to Quick Menu, Dashboard, Live Console Log, Usage Analytics, Tooltip Mode toggle, and Instant Refresh.

Hover Intelligence HUD

No more frustrating hover dismissals! Click the status bar metric to open an interactive, keyboard-navigable Quick Menu:

Account & Model Pinning: Multi-select accounts and AI models to track and aggregate.
Account Activation: Toggle provider account active/inactive status in 9Router on the fly.
Dedicated Timers: Configure independent auto-refresh intervals for Quota checks (5s–5m) and Fast 9R Log telemetry (3s–60s).
Display Styles: Customize both Status Bar and Tooltip detail levels with instant preview.

Account & Model Controls	Display Styles & Timers

5. Full Command Palette Integration

Every single feature is natively exposed to the VS Code Command Palette (Ctrl+Shift+P -> 9router). Manage your AI quotas entirely from the keyboard with zero context switching.

Command Palette Integration

✨ Core Highlights & Architecture

⚡ Multi-Account Quota Aggregation: Automatically computes cumulative remaining and total quota limits across all pinned accounts.
📌 Multi-Pin Flexibility: Pin multiple accounts and multiple AI models (e.g. Gemini 3.8 Flash, Claude Sonnet, Codex) simultaneously.
🌐 Flexible Multi-Machine Connectivity:
- Local Zero-Config: Automatically discovers local CLI credentials from %APPDATA%\9router when running on the same machine.
- Remote Tunnel Support: Connect securely across machines via Cloudflare Tunnel (https://*.trycloudflare.com) or custom domains using Dashboard Password authentication with auto-refreshing session tokens.
🎨 3 Configurable Display Modes:
- Compact (Default): Balanced, hides denominator /total and reset timestamps (10⭐ · G3.8 9.9K · GW 8.6K).
- Detailed: Full transparency with remaining/total ratio and reset schedule (⭐ 10 acc · G3.8 9.9K/10K (17/09 06:16 PM)).
- Minimal: Ultra-compact numbers and model names only (G3.8 9.9K · GW 8.6K), ideal for busy status bars.
🛡️ Enterprise-Grade Secret Management: Credentials and session tokens are encrypted at rest using VS Code SecretStorage.
🚀 Concurrency Pooling & Stale Fallback: Built-in HTTP connection pool (concurrency: 3) with exponential backoff and stale-cache serving prevents timeouts and eliminates upstream API flooding.
🔔 Native Feedback & Non-Intrusive Notifications: Manual refreshes show native progress notifications (withProgress), while periodic background syncs remain completely silent.

🚀 Getting Started

Scenario A: Local Machine (Zero-Config)

If 9Router is running locally on the same computer:

Install 9Router Monitor Pro.
The extension automatically detects your local CLI token from AppData.
Your provider quotas appear in the status bar immediately!

Scenario B: Remote Host (Cloudflare Tunnel or Remote IP)

If 9Router is running on a remote server, home lab, or separate machine:

Open Command Palette (Ctrl+Shift+P).
Run: 9Router Monitor Pro: Set Connection (URL & Password).
Step 1 - Base URL: Enter your Cloudflare Tunnel URL (e.g. https://rv6v39u.abc-tunnel.us) or remote IP (http://192.168.1.100:20128).
Step 2 - Dashboard Password: Enter your 9Router Dashboard password (default: 123456).
The extension authenticates, encrypts the session token in SecretStorage, and maintains persistent real-time monitoring!

🎨 Status Bar Display Styles

Customize the visual density of both the Main Quota Bar and the 9R Log Bar directly via Quick Menu or Settings:

1. Main Quota Monitor Bar (`aiTokenUsage.statusDisplayMode`)

Style	Preview (Multi-Account)	Preview (Single Account)	Best For
Compact (Default)	`10⭐ · G3.8 9.4K · GW 7.6K`	`⭐ Pro-Acc · G3.8 980`	Clean, high-density daily workflow
Detailed	`⭐ 10 acc · G3.8 9.4K/10K (06:16 PM)`	`⭐ Pro-Acc · G3.8 980/1K (06:16 PM)`	Full audit & tracking reset schedules
Minimal	`G3.8 9.4K · GW 7.6K`	`G3.8 980`	Ultra-condensed, minimal screen usage

2. Dedicated 9R Log Telemetry Bar (`aiTokenUsage.logStatusDisplayMode`)

Style	Status Bar Preview	Telemetry Metrics	Best For
Minimal	`$(terminal) 9R Log`	Clean icon and label only	Low distraction, simple shortcut
Compact (Recommended)	`$(terminal) 9R Log · 10.2K req · G3.8 🟢`	Total requests + last active model + live pulse	Balanced glanceable activity
Detailed	`$(terminal) 9R Log · 10.2K req · $1015 · G3.8 7.6K/642 🟢`	Requests + estimated cost + model token IO ratio + pulse	Comprehensive real-time telemetry

📦 Installation Guide

Option 1 · Official Marketplaces (Recommended)

Visual Studio Code

Web: Install with one click from the Visual Studio Marketplace.
In-App: Press Ctrl+Shift+X, search for 9Router Monitor Pro, and click Install.

Quick Open: Press Ctrl+P and paste:

ext install minhtalent-dev.9router-monitor-pro

Cursor, Windsurf, VSCodium, & Antigravity

Web: Available directly on the Open VSX Registry.
In-App: Open the Extensions panel (Ctrl+Shift+X), search for 9Router Monitor Pro, and click Install.

Option 2 · Command Line Interface (CLI)

Run the command for your preferred editor:

# Visual Studio Code
code --install-extension minhtalent-dev.9router-monitor-pro

# Cursor
cursor --install-extension minhtalent-dev.9router-monitor-pro

# Windsurf
windsurf --install-extension minhtalent-dev.9router-monitor-pro

# VSCodium
codium --install-extension minhtalent-dev.9router-monitor-pro

# Antigravity
antigravity --install-extension minhtalent-dev.9router-monitor-pro

Option 3 · Offline VSIX Package

For air-gapped environments or manual installations:

Download the latest 9router-monitor-pro-1.1.0.vsix from GitHub Releases.
Open Extensions view (Ctrl+Shift+X) -> click the ... menu (Views and More Actions) -> select Install from VSIX...

Or install via terminal:

code --install-extension 9router-monitor-pro-1.1.0.vsix --force

⌨️ Commands Reference

All commands are prefixed with 9Router Monitor Pro in the Command Palette (Ctrl+Shift+P):

Command	Title	Description
`aiTokenUsage.openQuickMenu`	`Open Interactive Menu`	Open interactive popup menu to pin accounts, pin models, toggle status, and configure styles
`aiTokenUsage.showDetails`	`Show Dashboard`	Open the full Webview Dashboard with search, filters, and cards
`aiTokenUsage.openConsoleLog`	`Open Live Console Log`	Open Webview Dashboard directly at the Live Console Log tab
`aiTokenUsage.openUsageAnalytics`	`Open Usage & Analytics`	Open Webview Dashboard directly at the Usage & Analytics tab
`aiTokenUsage.toggleLogStatusBar`	`Toggle Console Log Status Bar Item`	Toggle visibility of the `$(terminal) 9R Log` status bar button
`aiTokenUsage.setLogStatusDisplayMode`	`Set 9R Log Status Bar Style`	Switch 9R Log Bar between Minimal, Compact, and Detailed modes
`aiTokenUsage.setLogTooltipMode`	`Set 9R Log Tooltip Detail Mode`	Configure 9R Log hover tooltip detail: All Details, KPI Summary Only, or Logs Only
`aiTokenUsage.toggleLogTooltipMode`	`Toggle 9R Log Tooltip Mode`	1-click cycle between All, Summary, and Logs tooltip detail levels
`aiTokenUsage.setLogRefreshInterval`	`Set 9R Log Refresh Interval`	Set fast telemetry auto-refresh frequency (3s, 5s, 10s, 15s, 30s, 60s, or custom)
`aiTokenUsage.setDisplayMode`	`Set Status Bar Display Style`	Switch Quota Bar between Compact, Detailed, and Minimal styles
`aiTokenUsage.setTooltipMode`	`Set Tooltip Detail Level`	Choose between All Details, Aggregate Summary Only, or Account List Only
`aiTokenUsage.toggleTooltipMode`	`Toggle Tooltip Mode`	1-click toggle between Summary Only and All Details
`aiTokenUsage.setInterval`	`Set Refresh Interval`	Set quota auto-refresh frequency (5s, 10s, 15s, 30s, 60s, 2m, 5m, or custom)
`aiTokenUsage.showDebugLogs`	`View Live Debug Output Logs`	Open the diagnostic Output Channel for real-time socket and HTTP traces
`aiTokenUsage.refresh`	`Refresh`	Manually trigger immediate quota check with native progress notification
`aiTokenUsage.setConnection`	`Set Connection (URL & Password)`	Configure Base URL (Cloudflare Tunnel or Local) and Dashboard Password

⚙️ Configuration Reference

Customize extension behavior in your settings.json:

Setting	Type	Default	Description
`aiTokenUsage.showLogStatusBar`	`boolean`	`true`	Show dedicated `$(terminal) 9R Log` status bar item to quickly open Console Log
`aiTokenUsage.logStatusDisplayMode`	`string`	`"minimal"`	9R Log status bar style: `"minimal"`, `"compact"` (with reqs & live pulse), or `"detailed"` (with reqs & cost)
`aiTokenUsage.logTooltipDisplayMode`	`string`	`"all"`	9R Log tooltip detail: `"all"` (KPI + recent logs), `"summary"` (KPI only), or `"logs"` (recent logs only)
`aiTokenUsage.logStatusBarRefreshIntervalSeconds`	`number`	`10`	Fast telemetry refresh rate in seconds (minimum: 3s)
`aiTokenUsage.statusDisplayMode`	`string`	`"compact"`	Main Quota status bar style: `"compact"`, `"detailed"`, or `"minimal"`
`aiTokenUsage.tooltipDisplayMode`	`string`	`"all"`	Main Quota tooltip detail: `"all"`, `"summary"` (summary only), or `"accounts"` (accounts only)
`aiTokenUsage.refreshIntervalSeconds`	`number`	`60`	Quota auto-refresh frequency in seconds (minimum: 5s)
`aiTokenUsage.apiBaseUrl`	`string`	`"http://localhost:20128"`	9Router Base URL (e.g. `http://localhost:20128` or `https://*.trycloudflare.com`)
`aiTokenUsage.authMode`	`string`	`"auto"`	Authentication method: `"auto"`, `"password"`, or `"token"`
`aiTokenUsage.statusBarQuota`	`string`	`"session"`	Fallback quota for status bar when no model is explicitly pinned
`aiTokenUsage.providersPath`	`string`	`"/api/providers?..."`	Endpoint to fetch provider account connections
`aiTokenUsage.usagePathTemplate`	`string`	`"/api/usage/{id}"`	Endpoint template to fetch quota by provider ID

🛡️ Security & Privacy

Encrypted Local Storage: Your 9Router password, session token, and API keys are stored exclusively in VS Code's encrypted SecretStorage.
Zero Telemetry: 9Router Monitor Pro does not collect, track, or transmit any analytics, usage stats, or private tokens to any third-party server.
Direct Communication: Network traffic is strictly peer-to-peer between your IDE and your designated 9Router host.

📄 License & Author

Author: Minhtalent-dev
Repository: github.com/minhtalent-dev/9router-monitor-pro
VS Code Marketplace: minhtalent-dev.9router-monitor-pro
Open VSX Registry: minhtalent-dev/9router-monitor-pro
