Mica for Visual Studio Code

The editor face of Mica, the high-efficiency mathematics and systems language: every stage of the compiler a view you can read and draw, one-click run, debug and profile across Mica and C, a runtime view in which the stopped program explains its own tasks, and notebooks whose outputs are verified facts. From formula to native code and GPU in one language.

mica-dev.com · Language & compiler documentation · Blog · VS Code extension · YouTube

Mica is a statically typed mathematics and systems language that compiles to native Linux x86-64 and AArch64 binaries. Numerical code is ordinary Mica: vectors, matrices and tensors are types whose shapes the compiler checks, the autograd tape is a language construct, and a run prints the same digits every time - which is why AI is one of Mica's core capabilities rather than a library beside it. This extension teaches Visual Studio Code the whole of it.

Each version of this extension accompanies one compiler release, which the change log names. In the editor every stage the compiler passes through opens as a viewer in colour, a function's control flow is drawn beside its listing, a program's time is shown on the line it goes to, a Mica program that calls C debugs as one program, and a stopped program draws its own tasks and its autograd tape. The language server this extension talks to is the compiler itself, so everything the editor answers is what the installed compiler knows. The place to learn Mica is the website: the Learn area walks from the first program to a GPT trained on a graphics card, the technical reports state the design whole, and the blog announces every release with its measurements. Follow the blog, and read this extension's change log for the editor's half of each release.

Here is the headline in one picture - the compiler, open in the editor. Show Placement draws where a function keeps its values: its activation record as the prologue builds it, and its registers and stack slots over time, one bar per name while it lives there. A click on a bar moves the editor to the source lines the value lives across, and a line's number above the bars selects that line's instructions in the listing beside it:

Run, debug, and the runtime view

• Nothing needs configuring. F5, or Debug above a program, builds the file you are in (or the mica.project it belongs to) at the debug tier and stops on its breakpoints, with locals, stepping and watch; Run above the program runs it like a script. No launch.json and no tasks.json are involved.
• The Launch Card above a program is where you set how it runs. Pick a configuration (Debug, Release O2 checked, Profile, Thread checker, Address sanitizer, Undefined behaviour, Fixed arena, or one of your own made with New from this one…), set the program's tasking and memory class, which the card writes into mica.project, and this run's optimization, sanitizer, arguments, folder, standard input, architecture and runtime flags. Run, Debug and F5 all start the configuration the card shows, and Debug always builds it at the debug tier. The card shows the exact command Run starts, with a Copy button, and before anything runs it says what that start resolves: carriers and worker processes and why, output mode, the products record, the GPU card, usable processors, memory class and tasking, read from the program itself, or the runtime's own sentence for a flag it refuses, with Keep flags open for this run where a release build seals them.
• A configuration is yours in this workspace until you tick Share with the team, which writes it into .vscode/launch.json as a mica configuration, where F5's own list shows it. Beside micaRuntimeFlags, args and cwd, such a configuration takes micaOptimize, micaSanitize, micaStackSize, micaProcesses, micaRuntimeFlagPolicy, micaTasking, micaMemoryClass, micaPlatform, micaRemarks and micaStdin. Each configuration written there also gets its own Debug action above the program.
• While a program is stopped, each variable's value appears at the end of the lines that use it.
• The Mica Runtime view draws what the stopped program itself narrates: the task tree under the scopes that own it, each task's state in colour, shape and words, every generator's suspension point, and the autograd tape's recording window as a strip — read live from the process at every stop, and kept dimmed while the program runs on.
• A program's memory class and tasking live in its mica.project ("memory-class", "tasking"), which every road reads, and the status bar shows the classes in force. A folder that still names them in the old settings mica.build.memoryClass and mica.build.tasking is offered, once, a move into its mica.project.
• While a program is stopped, every suspended task appears in the Call Stack as a thread of its own, and its stack opens down to the Mica line it waits on.
• Attach to Running Program draws a program that is running without a debugger: start it with +mica rtp=listen -mica ahead of its arguments, attach, and watch its task tree as tasks begin and end — suspend it, continue it, or cancel a task's scope from the view.
• Show What the Program Holds opens the view's Memory section: what the program holds in one sentence, in the order memory is owned ("1 region holds 1.2 KB in one 64 KB block"), its cells summed by the type they hold with the line that made each type, and every region block drawn as two bars, each with its caption: the block's fill, then its used part, cell by cell. A legend says what each colour means: a value in use; released, waiting for reuse; the region's own table of free lists. A program stopped at a breakpoint is read again at every stop; a running program you attached to is stopped for each reading's moment and read again at every refresh. A release-tier program names its regions and says which tier shows its cells.

Debugging Mica and C together

A project whose mica.project names a contract for a C library debugs as one program. Build the C archive with -g beside the sources, and one Debug session follows calls across the boundary in both directions:

• Breakpoints can be set in .mica and .c files alike, and so can function breakpoints on the name C calls an exported Mica routine by (Program__Routine).
• The Call Stack lists Mica and C frames in one chain, each at its own file and line. Selecting a frame shows that frame's variables in its own language.
• Step Into goes from Mica into C and from C into Mica, stopping at the routine's first line with its parameters in place. Step Out returns to the caller in either language, and the returned value appears under Locals as $ReturnValue.
• Hover and watch expressions evaluate in Mica frames as they do in C frames, and inline values appear in Mica files at every stop, including in a Mica routine that C called.

The compiler's case tests/cases/debug/CrossLanguageStepping is the example: Mica and C call each other four times, down to a C leaf thirteen frames deep. npm run scenario:cross-language walks that chain through the C/C++ extension's debugger and gdb and checks every stop.

The compiler's reading of a program

Export File asks the compiler for everything it makes of a source — the tokens, the syntax tree, the Spectra intermediate language before and after static single assignment, the control flow graph, dominance, liveness, reaching definitions, where every value is placed, the assembly, what each optimization pass did, and what the heap will hold — and opens an overview beside the source. It draws the road the export took through the compiler, one box per component in the order the compiler runs them with the files each writes beneath it, every file a link that opens it: the debug road, or the release road that O1 and O2 take through static single assignment, with the other road one click away. Below the drawing every stage stands in the order the compiler's phases ran, each with one short line on what it holds:

Every stage opens as a language of its own, coloured and outlined:

• Spectra listings colour each operation by what it does, fold and outline by function and basic block, and say in a hover what an operation means, in the compiler's own words. Go to Definition jumps from a label or a temporary to where it is defined; on a source-line comment it opens the source line.
• Every line knows where it came from. Hover any line of any stage to see the source line that produced it, its routine and block, and what the stage states for it — the block, the live range, the register or stack slot. A line no source line produced, such as the data the program carries or a routine of the standard library, says so in words.
• Every number explains itself. Hover a #34 to learn what it counts in that stage — the value id one unit gives the value an instruction defines, with the stages that quote the same number, a name's version in static single assignment form, or an AArch64 immediate — which routine it belongs to, and follow the link to the line that defines it, in the listing of the unit the number belongs to.
• Links above every routine and block open its source line, its control flow, its placement and the next stage at the same place, and the outline and breadcrumbs list the routines of every stage.
• Go to Definition (F12) and Peek Definition work from anywhere on a line and open its source line; on a Spectra label or temporary they jump to its definition in the listing. The context menu offers Go to Source Line, Show Control Flow and Show Placement only on a line they apply to.
• Open Export Stage moves to another stage of the same unit and lands on the same routine and source line.
• The grammars and hovers are generated from the compiler's own tables, so they cannot fall behind it.

From a source line to its assembly and back

1. Open a Mica source, run Mica: Export File and pick Debug; the index opens beside the source.
2. Click the assembly stage in the index. The outline lists the routines; the links above each one read Source line · Control flow · Placement · Next stage.
3. Hover any instruction: the hover quotes the source line it came from.
4. Press F12 on the instruction, or pick Go to Source Line from its context menu: the source opens at that line.
5. Back in the stage, Open Export Stage to spectra lands on the same routine and source line, so the instruction and the intermediate code it came from stand side by side.

A stage beside its source

Open Export Stage Beside, from the context menu of a Mica source or of any stage, stands the source and a stage of its export side by side and ties them together: every source line and the stage lines it became share a colour band. Move the cursor in the source and the stage lines it became are outlined and scrolled into view; move it in the stage and its source line is outlined the same way. The bands follow a fresh export of the same source, and they work for every stage whose lines name source lines — the tokens, the syntax tree, the Spectra listings, the placement and the assembly among them.

Diagrams of an export

Four diagrams draw a program as the compiler sees it: the call graph of a unit, and the control flow, the dominator tree and the placement of each routine. Each opens beside any stage of an export — from the editor's title bar, the stage's context menu, or the Command Palette — and a routine's diagram draws the routine under the cursor, or asks which one to draw. Graphviz lays the graphs out inside the extension, so they draw offline and in the editor's colours.

Show Call Graph draws which routine of the unit runs which: a call, a task spawned, a generator opened, a device kernel launched or a routine's address taken, each edge with its count. A routine defined in another unit is a dashed box, a routine the optimizer inlined everywhere stands alone, a recursive routine carries an edge back to itself, and a click on a routine draws its control flow.

Show Control Flow draws the routine's control flow graph. Each basic block is a box holding its instructions, each edge says which way the branch went — taken, falls through, jump table — and the edges that close a loop are marked as loops. A block's colour is the source line it starts on, and its header names its lines. A click on an instruction moves the editor to the source line it came from, and a click on the block's name opens its label in the Spectra listing. An export writes two graphs, the one code generation consumed and the one static single assignment was built on, and an optimized build numbers their blocks differently: asked from the Spectra unit, the dominance, the reaching definitions or the SSA form, the drawing shows the graph before SSA whose blocks those stages name, and from every other stage the graph code generation consumed. The header says which.

Show the dominator tree, the link in the drawing's header, draws the routine's blocks under their immediate dominators, each box naming its dominance frontier — where the block's dominance ends, and where static single assignment places its merges. The tree is drawn over the graph before SSA, the graph the dominance numbers.

Show Placement draws where the routine keeps its values: its activation record as a strip of cells down from the frame pointer — the static link, the saved registers, the parameter homes and every value the allocator gave a stack home, each at its offset and the size its type states — and below it a lane for every register and every stack slot over the routine's instructions, with a bar for each value while it lives there, grouped under the source line each instruction came from. A click on a bar moves the editor to the source lines the value lives across; a click on a line's number above the lanes selects that line's instructions in the out-of-SSA listing.

Profiling

Profile File builds the program with its profiling tables, runs it under valgrind's callgrind, and writes each source line's instruction count and share beside it, hotter lines in hotter colours. The program starts as Run File starts it, with the runtime flags, arguments, standard input and folder of the configuration chosen on its launch card; a configuration with a sanitizer is refused, since callgrind would count the sanitizer's checks as the program's own instructions. The Mica Profile view ranks the procedures that carry the instructions. The counts are exact and repeat on every run, so a change's effect is the difference between two profiles. Profile Compile shows where the compiler's own time went, phase by phase.

Mica Notebooks

A Mica notebook is a plain markdown file (.mica.md) in which every ```mica fence is a cell holding one complete program and the ```output fence under it is a recorded fact. The file renders unchanged on GitLab and the website, and git diffs show edits and nothing else.

• Run a cell and the fresh output lands under it, through the installed compiler's own runner.
• Verify Notebook re-runs every cell and holds the fresh output against the recorded fence: a success mark for promises kept, a recorded-versus-this-run diff for drift, one summary line for the document. Verify proves outputs and never rewrites them.
• Verify Notebooks in Folder, from a folder's context menu in the explorer, sweeps a whole course: every .mica.md below the folder, cell by cell, without opening a single editor. The result is one verdict line, a transcript in the Mica Notebook Verify output, and one problem per cell that broke its promise — click it and the notebook opens at that fence. Each cell also keeps its run's status line, so a document opened later already says what the sweep found.
• A loss-column sparkline draws the falling line of a training run directly under the output that printed it, from the printed digits.
• Every cell stays one whole program. VS Code's own Split Cell cuts a cell at the cursor, which leaves two halves of a program that cannot compile on their own; Join With Next Cell puts them back together.

The editor

• Semantic highlighting — every identifier colors by what the compiler resolved it to, not by its spelling. tracked values render italic and code inside a tape window renders bold, so autograd code reads quietly different from plain arithmetic.
• Hover states the whole contract: a tensor's type with its shape — tracked matrix[64, 48] of float64 — and a fallible function's signature with its fails domain. A tensor declared through an alias carries its shape as a quiet badge at the end of the line.
• Diagnostics appear when a file opens, a moment after you stop typing, saved or not, and on every save, at the exact positions the compiler reports; go to definition and the document outline ride the same resolved program.
• Format Document lays the file out in the house style, exactly as mica --format does: only white space changes, every line break you wrote stays, and a file whose blocks do not close is left as it is, with the reason shown.
• Glyph input — type \alpha for α, \times for ×, \leq for ≤, w_1 for w₁: the formula names and operators the compiler accepts in source, offered as you type.
• Syntax highlighting for the complete current language, generated from the compiler's own lexical tables, with begin/end folding, automatic indentation, and word selection that understands 0x, 0b, and 1_000_000.

What works without what

The language features are provided by the Mica compiler itself running as a language server, so what the editor underlines is exactly what the build would report for the text on screen. The compiler is available from mica-dev.com/learn/install; a different location can be set with mica.languageServer.path. Without the compiler, the extension stays with highlighting and shows a single notice.

Extension settings

Licence

This extension is licensed under the MIT licence. The Mica compiler is a separate product with its own licence — see mica-dev.com.
