UiPath Artifact Designer

A community extension — not an official UiPath product. Adds visual editing for five UiPath artifact file types — agent.json, *.flow, *.bpmn, caseplan.json, and action-schema.json — directly inside VS Code, Cursor, and other VS Code-based IDEs, without needing to deploy and switch to UiPath Studio Web.

Open and edit UiPath artifacts as visual designers in VS Code — the way they look in UiPath Studio Web, without leaving your editor.

Supported artifacts

Each file type opens in its own designer automatically, as its default editor.

Maestro is UiPath's low-code agentic orchestration platform — flows, BPMN processes, and case management.

Screenshots

Low-code agent (agent.json)

Studio-Web-style node graph for an HR Helpdesk agent — ManagerApproval escalation above the agent; HRPolicyKnowledge context, GetEmployeeRecord tool, and the agent-memory node below. The inspector edits the model, prompts, and input arguments.

Maestro Flow (*.flow)

Manual trigger → action → decision → end nodes, with dagre auto-layout and per-node-type styling.

Maestro BPMN (*.bpmn)

Full BPMN 2.0 modeler embedding bpmn-js, with the native palette and context pad. UiPath uipath:* extension XML round-trips losslessly on save.

Maestro Case (caseplan.json)

Stage-graph canvas (v20 schema) with the case trigger, required Intake and Review stages, and a Dispute Handling exception lane. SLA rules and exit conditions edited in the inspector.

Coded App (action-schema.json)

Form editor for the inputs / outputs / inOuts / outcomes data contract, with a read-only .uipath/app.config.json deployment-status panel at the top.

Requirements

VS Code. Also compatible with Cursor and other VS Code based compatible editors that support standard .vsix extensions.

Installation

VS Code — install from the Visual Studio Marketplace, or run ext install marcelocruzrpa.uipath-artifact-designer from the Command Palette.

Cursor, VSCodium, Windsurf, and other Open VSX-backed editors — install from Open VSX, the registry these editors use by default.

Manual .vsix — download the latest .vsix from the Releases page, then in your editor open the Command Palette and run Extensions: Install from VSIX… and pick the file.

To build your own .vsix from source, see CONTRIBUTING.md.

Using a designer

1. Open a folder containing a UiPath project (so the designer can resolve sibling files like entry-points.json and resource definitions).
2. Open a supported file (agent.json, *.flow, *.bpmn, caseplan.json, or action-schema.json) — its designer opens automatically.
3. Select a node and edit its properties in the inspector. Save with Ctrl+S.

Edits are written straight back to the source file — it goes dirty on change, and undo / redo work normally. Each designer reloads live when its file or a sibling file changes on disk, and surfaces validation issues (missing files, unrecognized resources) in a strip at the top.

Navigating — zoom with the toolbar + / − or the + / − keys; press 0 or Fit to frame the whole diagram.

Plain text — click Raw in the toolbar, or use Reopen as Text / Open With…. To always use the plain editor for a file type, add e.g. "workbench.editorAssociations": { "*.flow": "default" } to your settings.

Known limitations

• The condition / SLA editors in the Case designer snapshot their working copy when the inspector opens. If a sibling file is edited externally while the inspector is open, the displayed values may diverge from disk until you re-select the stage. The inspector rebuilds on selection change, so this is usually only visible in long-lived overview views.
• BPMN files larger than 2 MB are rejected by the validator before writing to disk — real-world BPMN files are typically well under 500 KB; the cap protects the extension host from pathological inputs.

Changelog

See CHANGELOG.md for the release history.

Contributing

Bug reports, feature requests, and pull requests are welcome. See CONTRIBUTING.md for build instructions, an architecture overview, and the contribution workflow.
