GitCharm

English | 简体中文

Bring the IntelliJ IDEA Git UI and workflow to VSCode / Qoder.

GitCharm three-panel git log UI

GitCharm provides a three-panel Git log view:

Left · Branch tree — hierarchical tree grouped by HEAD / Local / Remote, with ahead/behind arrows (▲▼) and commit-count badges
Center · Commit list — Canvas-rendered commit graph showing message first line, author avatar and relative time, with message / author / date-range filters
Right · Commit details — full commit info, changed file list (added/deleted line counts) and diff entry

Features

Git Operations

Branches: create, checkout, rename, delete, merge into current, rebase onto, push, pull, fetch, update (safe fast-forward for non-current branches)
Commits: show diff, cherry-pick (multi-select batch + conflict-resumable), interactive rebase, squash, drop commit, amend message, reset to commit
Files: compare file with another branch, view diff introduced by a single commit
Blame: inline annotation of last author & date per line, full commit info on hover, click to jump to the commit

Performance

Instant open: three-phase progressive loading (skeleton → branches → commits), startup < 10ms
Filesystem refs: parses .git/refs (loose + packed-refs) directly — hundreds of branches stay smooth, no flood of git rev-parse subprocesses
Smart cache: branch info persisted to workspace state (Memento), instantly available after restart; invalidated on Git operations
Canvas graph: pixel-precise commit graph rendered on Canvas with high-DPI support, several times faster than SVG/DOM

Experience & Reliability

Bilingual UI: fully localized interface, follows editor language or set manually
IDEA-style visuals: 6–12px radii, smooth transitions, hover micro-animations, yellow tag badges
Pre-rebase check: detects uncommitted changes before rebasing to avoid failures
Unified conflict handling: merge / rebase / cherry-pick conflicts detected in one place, top status bar with Continue / Abort, conflicts delegated to the native SCM view
Shell-free execution: every git command runs via argv spawn, eliminating argument injection

Requirements

VSCode ≥ 1.95.0, or Qoder latest
Git ≥ 2.0.0
Built-in vscode.git extension enabled (default)

Installation

From the Marketplace (recommended)

Search GitCharm in the extensions panel (full name GitCharm — IDEA Git Log & Graph, publisher liugui) and install.

From a VSIX file

Download git-charm-<version>.vsix
Run Extensions: Install from VSIX… from the command palette
Pick the file and reload the window

Usage

Open a workspace containing a Git repository
Click the GitCharm tab in the bottom panel to reveal the three-panel log view
Tree nodes: single-click folders to expand, double-click a branch to switch; right-click a node or commit row for context actions

Common Actions

Action	Entry
Switch branch	Double-click branch in tree, or right-click → Checkout
View commit details	Click a commit row
Show commit diff	Right-click commit → Show Diff
Merge / Rebase	Right-click branch → Merge into Current / Rebase onto
Push / Pull	Right-click branch → Push / Pull
Cherry-pick	Multi-select commits → right-click → Cherry-Pick
Squash / Interactive rebase	Multi-select commits → right-click
Drop / Amend commit	Right-click commit row (only near HEAD)
Compare file with branch	Editor / Explorer right-click → Compare with Branch
Toggle blame	Editor right-click → Toggle Blame, or click the line-number area

Settings

Search idea-git in settings:

Setting	Description	Default
`idea-git.cache.enabled`	Cache branch info for faster startup (persisted; refreshed on repo changes or Git operations)	`true`
`idea-git.pullStrategy`	Update strategy when pulling: `merge` or `rebase`	`merge`
`idea-git.language`	UI language: `auto` / `zh-cn` / `en`	`auto`
`idea-git.debug`	Enable debug logging to the extension host console	`false`

Development

npm install        # install dependencies (includes @vscode/vsce)
npm run compile    # compile TypeScript to out/
npm run lint       # ESLint
npm test           # node:test unit tests
npm run package    # build VSIX

Press F5 in VSCode / Qoder to launch the Extension Development Host (config in .vscode/launch.json).

Note: after changing out/ or media/, fully restart the development host — it runs the previously loaded code.

Tech Stack

TypeScript · VSCode Extension API · Git CLI · Webview (Canvas rendering)

License

MIT · Full history in CHANGELOG.md

简体中文

在 VSCode / Qoder 中复刻 IntelliJ IDEA 的 Git UI 与工作流。

GitCharm 三栏式提交图谱界面

GitCharm 提供一个三栏式的 Git 日志面板：

左栏 · 分支树：按 HEAD / 本地 / 远程 分组的层级树，带超前/落后箭头（▲▼）与提交数徽标
中栏 · 提交列表：Canvas 绘制的提交图谱，含消息首行、作者头像、相对时间，支持消息 / 提交人 / 日期区间筛选
右栏 · 提交详情：选中提交的完整信息、变更文件列表（增删行数）与差异入口

特性一览

Git 操作

分支：新建、检出、重命名、删除、合并到当前分支、变基到…、推送、拉取、获取、更新（非当前分支可快进时安全更新）
提交：显示差异、精选提交（Cherry-Pick，支持多选批量 + 冲突持久化恢复）、交互式变基、压缩提交、删除提交、编辑提交信息、重置到此提交
文件：与其他分支对比此文件、查看单次提交引入的差异
Blame：行内注解每行的最后修改者与日期，悬停查看完整提交信息，点击跳转到对应提交

性能

秒开：三阶段渐进式加载（骨架屏 → 分支 → 提交），启动 < 10ms
直读 refs：直接解析 .git/refs（loose + packed-refs），数百分支也不卡死，避免大量 git rev-parse 子进程
智能缓存：分支信息持久化到工作区状态（Memento），重启后立即可用；Git 操作后自动失效更新
Canvas 图谱：提交图用 Canvas 像素级绘制，高 DPI 自适应，比 SVG/DOM 高效数倍

体验与可靠性

中英双语：界面全量本地化，跟随编辑器语言或手动指定
IDEA 风格视觉：圆角 6–12px、平滑过渡、悬停微动效、tag 黄色徽章
变基前检查：自动检测未提交更改，避免变基失败
冲突统一处理：合并 / 变基 / 精选冲突统一检测，顶部状态栏提供"继续 / 终止"，冲突自动交原生 SCM 视图解决
无 shell 命令执行：所有 git 命令走 argv spawn，杜绝参数注入

环境要求

VSCode ≥ 1.95.0，或 Qoder 最新版
Git ≥ 2.0.0
内置 vscode.git 扩展保持启用（默认开启）

安装

方式一：扩展市场（推荐）

在 VSCode / Qoder 扩展面板搜索 GitCharm（完整名 GitCharm — IDEA Git Log & Graph，发布者 liugui）并安装。

方式二：VSIX 离线安装

下载 git-charm-<版本>.vsix
命令面板执行 Extensions: Install from VSIX…
选择文件，重新加载窗口

使用方法

打开一个 Git 仓库工作区
在底部面板点击 GitCharm 标签，即可看到三栏日志视图
树节点：文件夹单击展开、分支双击切换；右键节点或提交行呼出对应操作菜单

常用操作

操作	入口
切换分支	分支树双击分支，或右键 → 检出
查看提交详情	单击中栏提交行
查看提交差异	提交行右键 → 显示差异
合并 / 变基	分支右键 → 合并到当前分支 / 变基到…
推送 / 拉取	分支右键 → 推送 / 拉取
精选提交	多选提交 → 右键 → 精选提交
压缩 / 交互式变基	多选提交 → 右键
删除 / 改提交信息	提交行右键（仅 HEAD 附近可用）
对比文件	编辑器 / 资源管理器右键 → 与其他分支对比此文件
显示 Blame	编辑器右键 → 显示提交信息，或点击行号区域

设置项

在设置中搜索 idea-git 可调整：

配置	说明	默认
`idea-git.cache.enabled`	启用分支信息缓存以提高启动速度（缓存持久保存，仅在仓库变化或执行 Git 操作时更新）	`true`
`idea-git.pullStrategy`	拉取远程分支的更新策略：`merge`（合并式）或 `rebase`（变基式）	`merge`
`idea-git.language`	界面显示语言：`auto` / `zh-cn` / `en`	`auto`
`idea-git.debug`	启用调试日志（输出到扩展宿主控制台）	`false`

开发

npm install        # 安装依赖（含 @vscode/vsce）
npm run compile    # TypeScript 编译到 out/
npm run lint       # ESLint 检查
npm test           # node:test 单元测试
npm run package    # 打包 VSIX

在 VSCode / Qoder 中按 F5 启动"扩展开发宿主"进行调试（配置见 .vscode/launch.json）。

提示：改动 out/ 或 media/ 后，开发宿主跑的是旧代码，需完全重启宿主再验证。

技术栈

TypeScript · VSCode Extension API · Git CLI · Webview（Canvas 渲染）

许可证

MIT

完整版本历史见 CHANGELOG.md。
