vsCRT — Vaulted Secure Console & Remote Transfer

Vaulted — Argon2id+AES-GCM credential vault, host-key TOFU, never argv-leaked passwords. Secure — encrypted-at-rest profiles, signed session records, defensible defaults. Console · Remote · Transfer — saved SSH sessions with ProxyJump, port forwards, SFTP, launch profiles. One window. One profile tree. One credential store. Inside the editor you already have open.

Why vsCRT

Remote work has historically meant juggling two tools per server — a terminal emulator for the shell and a separate GUI for file transfer. Different profile trees. Passwords typed twice. No awareness of each other.

vsCRT folds the whole stack into VS Code.

• Your saved sessions live in a hierarchical tree next to your code.
• Your credentials live in one vault — OS keychain or portable Argon2id-encrypted bundle you can sync across machines.
• Your SFTP browser, your launch profiles, your ProxyJump chains, and your audit log are all one click away from the file you're editing.

Stop context-switching. Stop retyping. Ship faster.

At a glance

Install

From the VS Code Marketplace:

ext install kynoci.vscrt

Or search vsCRT in the Extensions side-bar and click Install.

Open the vsCRT icon in the Activity Bar — you'll see the Connection and Status views immediately. If this is a fresh machine, the Status view tells you what (if anything) is missing (ssh, sshpass, WSL, an agent) and links to copy-pasteable install instructions.

Host dependencies

The Status view shows each of these with a traffic-light icon and — where relevant — a one-click install-help modal.

Quick start

1. Click the vsCRT icon in the Activity Bar.
2. Add a folder (toolbar → folder icon) — group by environment, customer, or project.
3. Add a server (toolbar → +) — or run vsCRT: Import from ~/.ssh/config to bulk-import every Host block you already have.
4. Double-click a server to open a terminal — or right-click for Test Connection, Open SFTP Browser…, Run Command…, Change Password, Change Icon, and more.
5. Press Ctrl+Alt+S (⌘⌥S on macOS) for a fuzzy Quick Connect over every server you've saved, with a "Recent" group at the top.

For file transfer: right-click any server → Open SFTP Browser… (or press Ctrl+Alt+F / ⌘⌥F) for a two-pane upload / download / preview experience that respects the same auth + ProxyJump + host-key policy as the terminal.

What's inside

Saved session tree

Group by environment / customer / project. Unlimited nested subfolders. Drag-and-drop reorders rows with before/after/inside drop positions. Multi-select with Ctrl+click or marquee to bulk-connect, bulk-test, or bulk-delete. Per-folder and per-server icon overrides (codicons or bundled SVGs — Apple, Windows, FreeBSD, Finder, laptop, load-balancer, switch, Wi-Fi, …).

Expand/collapse state persists across VS Code restarts. The tree lives next to your code, not in its own window — no alt-tabbing.

SSH that handles the tricky bits

First-class fields for everything ~/.ssh/config gives you and then some:

• Auth modes — password (sshpass-driven), publickey, ssh-agent, manual prompt. The resolver picks the right one automatically.
• ProxyJump — -o ProxyJump=<chain>, comma-separated multi-hop bastions (alice@bastion1,bob@bastion2).
• Port forwards — -L, -R, -D (local, remote, dynamic SOCKS) with schema-regex validation so nothing injects extra argv.
• Timeouts & keepalive — ConnectTimeout, ServerAliveInterval.
• Agent integration — optional agent-forwarding (-A), AddKeysToAgent=yes|no|ask|confirm, IdentitiesOnly.
• Escape hatches — arbitrary -o Key=Value directives plus a raw extraArgs fragment when you need something exotic.
• Env vars — per-node environment for the spawned terminal process (not forwarded to the remote; use SetEnv via extraArgs for that).
• IPv6 aware — [::1]:22 and user@[2001:db8::1]:2222 parsed correctly.

Non-interactive Test Connection reports one of connected, auth-failed, timeout, no-credentials, cancelled, error — and offers a one-click jump to the output log when anything but "connected" comes back.

Credential vault

Two storage backends, picked per server:

The passphrase vault uses:

• Argon2id (32-byte derived key; parameters embedded in each ciphertext so rotating them never breaks old blobs).
• AES-256-GCM (12-byte random IV, 16-byte auth tag — tampering is detected on decrypt).
• A strength gate (vsCRT.passphraseMinStrength, 0–4) at enrolment and rotation, with no heavy-weight dep bundled.
• Auto-lock after 5 min / 15 min / 30 min / 1 hr of idle, or on window focus-loss, or never.
• A status-bar indicator that shows locked/unlocked state (only when a passphrase is enrolled, so OS-keychain-only users see no clutter) and announces to screen readers via explicit accessibility labels.

Passwords never touch argv in the default delivery path. vsCRT ships three sshpass delivery modes:

Crash-resilient: orphan tempfiles older than 24 h are swept at activation; on deactivate() a synchronous sweep tears down anything still outstanding.

Host-key TOFU done right

Choose how vsCRT treats unknown hosts:

• prompt-on-first (default) — pre-scan the host via ssh-keyscan, compute the SHA-256 fingerprint, show it in a native VS Code modal before ever writing known_hosts. Subsequent connections are strict. ProxyJump chains can't be pre-scanned, so they fall back to ssh's interactive in-terminal prompt.
• auto-accept — OpenSSH's accept-new behaviour.
• strict — refuse any host not already trusted.

A pre-shared fingerprint manifest (knownFingerprints[] in the config) acts as a skip-list: match → modal suppressed; mismatch → user is alerted to a possible rotation or compromise.

If a server is rebuilt and presents a new key, Remove Host Key on the node context menu wraps ssh-keygen -R with a .old backup — no shell trip required.

Two-pane SFTP browser

Right-click any server → Open SFTP Browser… — a dedicated webview panel (one per node; reopening reveals the existing panel rather than duplicating it).

• Remote pane + local pane side-by-side; drag between them.
• Upload via toolbar, OS drag-drop, or local-pane drag-drop.
• Download to workspace, Downloads, Home, or a custom folder — with last-location persistence per server.
• Bulk download, bulk delete, bulk local delete.
• ls, mkdir, rename, delete, chmod (POSIX mode string), follow symlink, copy path, copy scp path.
• Live transfer progress with bytes/sec + ETA; Cancel SIGTERMs every active ssh child via a per-session tracker.
• Inline read-only text preview with syntax highlighting (language guessed from the file extension).
• Every operation is audit-logged when connection logging is on.
• Works under password auth too: when sshpass can't feed sftp -b - (its internal ssh child hardcodes BatchMode=yes), vsCRT transparently falls back to ssh 'cat > remote' < local.

Launch profiles

Named sets of servers that start together. Morning routine: prod-web-1, prod-web-2, prod-db, prod-cache — all in one click, with optional millisecond stagger between each launch so ten simultaneous password prompts don't race.

Add via vsCRT: Add Launch Profile…, run via vsCRT: Run Launch Profile…, delete via vsCRT: Delete Launch Profile….

Saved commands per server

Attach shell snippets to any node:

{
  "name": "Prod Web",
  "endpoint": "deploy@prod-web",
  "commands": [
    { "name": "tail nginx",     "script": "sudo tail -f /var/log/nginx/access.log" },
    { "name": "restart app",    "script": "sudo systemctl restart myapp" },
    { "name": "disk usage",     "script": "df -h | head -20" }
  ]
}

Right-click the node → Run Command… → pick one → it's sent via terminal.sendText into that node's session. Shell features (pipes, heredocs, quoting) work normally because the remote shell interprets the string. If no terminal is open for the node yet, vsCRT spawns one and queues the snippet after a short auth-settle delay.

CLI companions

Two binaries ship alongside the extension:

# From any shell — extension-driven
vscrt connect Prod/Web           # open in a new VS Code terminal
vscrt sftp --browser Prod/Web    # open the SFTP browser panel
vscrt ls --filter prod           # search saved profiles
vscrt diag                       # platform + binary availability report

# Headless — CI, scripts, remote exec
vscrt-remote connect  Prod/Web --password-stdin
vscrt-remote test     Prod/Web --timeout 5
vscrt-remote install-key Prod/Web --public-key ~/.ssh/id_ed25519.pub

Exit codes on the headless CLI are scriptable (0 success, 65 profile not found, 66 secret unavailable, etc.).

Portable profile bundles

Move a curated server list between machines without copy-pasting JSON:

• Re-key mode — re-encrypts every stored password under a fresh Argon2id key derived from a passphrase you choose at export time. The receiving machine prompts once at import, verifies the check token, then re-seals each password under its local secret store.
• Strip mode — emits a password-free bundle. Safe to commit to a shared git repo; import, then populate passwords via Change Password on each node.

Bundle format: vscrt-bundle/v1, a single JSON file with embedded salt, check token, and folder tree.

Read-only team overlays

Point vsCRT.sharedConfigPaths at one or more extra vscrtConfig.json files (e.g. a repo-scoped ${workspaceFolder}/team-servers.json). vsCRT merges each into a synthetic top-level Shared (read-only) folder, strips every password-bearing field, and permits only publickey or implicit-agent auth through it. The overlay never round-trips into your personal config. Gated on workspace.isTrusted.

Diagnostics & audit

• vsCRT: Show Diagnostics — dumps extension version, VS Code version, platform, Node, binary availability, vault state, and config counts into a Markdown block safe to paste into a bug report. No endpoints, no passwords, no salts — ever.
• Connection log (~/.vscrt/connections.log) — opt-in JSONL audit trail, 5 MB rotation, minimal or verbose verbosity.
• Session recordings (~/.vscrt/sessions/) — opt-in per-session metadata (*.meta.json) and optional full terminal transcript (*.cast).
• vsCRT: Show Session History — renders metadata + log rows as one time-sorted Markdown document in an editor tab (VS Code's Markdown preview gives you a zero-webview summary).
• Rolling backups (~/.vscrt/backups/) — every save snapshots the prior file; cap of 10 keeps the folder bounded. vsCRT: Restore Config from Backup… picks one and swaps it in.

Settings

All settings live under vsCRT in Preferences.

Terminal-location precedence (higher wins): node terminalLocation field → file-level vsCRT.*TerminalLocation → VS Code setting → default.

Commands & keybindings

Keybindings

Every other command is on the Command Palette (Ctrl+Shift+P → vsCRT) or the view's context menus.

Command groups

• Session tree — Open Config, Add Folder, Add Server, Edit Server, Duplicate, Rename Folder, Delete Server / Folder, Refresh, Change Icon.
• Connect — Connect, Connect All in Folder, Test Connection, Quick Connect, Connect Selected Servers.
• SFTP — Open SFTP Browser… (direct), Open SFTP Browser… (picker).
• Credentials — Change Password, Change Password Storage Mode, Lock Passphrase, Reset Passphrase Setup, Rotate Passphrase KDF Parameters, Clear All Stored Passwords, Generate SSH Key Pair, Vault Menu.
• Hosts — Remove Host Key from known_hosts.
• Import / export — Import from ~/.ssh/config, Load Example Configuration, Export Profile to Encrypted Bundle…, Import Profile from Encrypted Bundle….
• Launch profiles — Run / Add / Delete Launch Profile….
• Snippets — Run Command… on selected node.
• Telemetry — Show Connection History, Show Session Recordings, Show Session History.
• Help & diag — Show Diagnostics, Show Output Log, Show Help, Validate Config, Restore Config from Backup….

Security model

• Passwords never live in argv by default. Delivery goes through a mode-0600 tempfile or a token-authed loopback/named pipe with a 60-second TTL. argv is a last-resort fallback.
• Host keys get a human check. The default prompt-on-first policy never writes to known_hosts without showing you the SHA-256 fingerprint first. Strict mode afterwards — ssh itself cannot silently auto-accept anything else.
• Authenticated encryption. Passphrase-mode ciphertexts are AES-256-GCM; tampering is detected on decrypt, not after. KDF parameters are embedded in the blob so you can rotate them any time.
• No telemetry leaves your machine. Connection logs and session recordings are local-only and opt-in. Diagnostics are pull-only and secret-free.
• Safe shell embedding. Every dynamic value gets single-quoted for the target shell (bash vs PowerShell) before it's spliced into the terminal command.
• Input validation at the edit layer. JSON schema regexes gate jumpHost, portForwards, and extraSshDirectives so untrusted config can't inject argv.
• Workspace-trust gating. Shared overlays are only loaded in a trusted workspace.

Data paths

Everything vsCRT writes lives under ~/.vscrt/:

~/.vscrt/
  vscrtConfig.json          main config (schema-stamped, auto-migrated)
  connections.log           JSONL audit trail (rotated at 5 MB → .1)
  backups/                  rolling config backups (newest 10 kept)
    vscrtConfig.<ISO>.json
  sessions/                 session recordings (opt-in)
    *.meta.json             structured metadata
    *.cast                  transcripts (only when recording = full)

The main config is a plain JSON file with a JSON Schema (schemas/vscrtConfig.schema.json). Edit it by hand or via the UI — vsCRT watches for external changes and reloads automatically.

Roadmap & known limitations

• Serial / RS-232 — not yet supported. SSH only today; serial console access is on the roadmap for network-device operators.
• Telnet / raw TCP — the data model is open to them; only SSH is wired through the connect path at present.
• Deep-link reveal — the /open deep link focuses the Connection view but doesn't yet scroll-and-highlight the target node. Tracked.
• Windows SSH backend toggle — when both native sshpass.exe and a WSL-based one are on PATH, vsCRT picks the first that works. A user-facing selector is planned.

Open an issue on github.com/kynoci/vscrt/issues to prioritise something.

License

GPL-3.0-only © Kynoci.

vsCRT — Visual Secure Console Remote Terminal. A VS Code extension.
