PlantUML Local

Render ```plantuml code blocks in the built-in Markdown preview, and .puml files in a preview of their own — no Java, no server, no network connection. Your diagram source is processed locally and is not sent to a rendering service. Built for design docs you can't send anywhere — write, preview, done.

Status: Active (best-effort maintenance)

Table of Contents

• Features
• Installation
• Quick Start
• Why PlantUML Local
• Usage
• Known Limitations
• Configuration
• How It Works
• Security and Privacy
• Platform Requirements
• Troubleshooting
• Contributing
• Support & Maintenance Policy
• License
• Acknowledgments

Features

• Built-in Preview: Diagrams appear in the same Markdown preview you already use
• .puml Files: PlantUML files open as their own language, with folding, an outline and a preview beside the editor that zooms, exports PNG and copies it to the clipboard
• Local Includes: !include, !includesub and !theme … from read shared definitions, sections and themes from the files of your workspace folder, in a trusted workspace; their paths complete, and Ctrl+Click opens the file
• Syntax Highlighting: ```plantuml blocks and .puml files are coloured in the editor, following the syntax the bundled engine accepts
• Offline Rendering: No Java, no PlantUML server, no network connection required — nothing to install besides the extension
• Fault-Tolerant: A syntax error shows up inline at the broken diagram; the rest of the page stays intact
• Problems Panel: Errors, warnings and unsupported syntax in the diagrams of open Markdown files are listed with their line, preview or not
• Writing Help: Completion for start lines, directives, themes and icons, templates for six kinds of diagram, and a quick fix that names a diagram for export
• Export: Diagrams can be written to SVG or PNG files — one, a whole document or a whole folder — and referenced from the Markdown, for hosts such as GitHub that do not draw PlantUML
• Multi-Diagram Pages: Any number of diagrams per page; renders are serialised so results never mix
• Dark-Mode Aware: Diagrams re-render to match your colour theme, or pin the palette via settings
• Full-Width Text Support: Japanese and other full-width characters are measured and laid out correctly
• Non-Intrusive: All other fenced code blocks (```js, ```mermaid, …) are left untouched
• Local by Design: Rendering is isolated in a worker thread; only sanitised SVG reaches the preview

Installation

Install from VS Code Marketplace (recommended)

• Open the Extensions view (Ctrl+Shift+X)
• Search for PlantUML Local
• Click Install

You can also open the Marketplace page directly:

• https://marketplace.visualstudio.com/items?itemName=kkdev92.plantuml-local

Build from Source (for contributors)

If you just want to use PlantUML Local, installing from the Marketplace is the easiest option.

git clone https://github.com/kkdev92/plantuml-local.git
cd plantuml-local
npm install
npm run install-local

Quick Start

1. Open any Markdown file

2. Add a fenced code block with the plantuml language (puml works too):

   ```plantuml
   @startuml
   Alice -> Bob : Hello
   @enduml
   ```


3. Open the preview: the preview button at the top right of the editor, or Markdown: Open Preview (Ctrl+Shift+V by default)

4. The block renders as a diagram — edit and save, and it follows

See sample.md for a tour of diagram types, including error handling, and sample.puml for a PlantUML file of its own.

Why PlantUML Local

Previewing PlantUML in VS Code usually means one of two things: installing a Java runtime to run plantuml.jar locally, or handing your diagram source to a PlantUML server. The server route is often the public one at plantuml.com, which means the source of every diagram is encoded into a URL and sent out on each preview — not always acceptable for confidential or internal design documents.

PlantUML Local takes a third route: it renders ```plantuml blocks on your own machine and inserts the resulting SVG into VS Code's built-in Markdown preview.

• No Java runtime
• No PlantUML server
• No separate preview panel for Markdown
• No network connection required to render

The extension bundles the official @plantuml/core JavaScript build of PlantUML; Graphviz layout is provided locally by Viz.js compiled to WebAssembly.

Usage

PlantUML Local renders most diagram types available in the bundled PlantUML browser engine, including sequence, use-case, class, state, activity and component diagrams.

The first render after startup is the slow one — around 0.4 s on a typical development machine while the WebAssembly engine initialises. Later renders are considerably faster, though timings depend on the machine and on how complex the diagram is.

If a diagram looks stale, run PlantUML Local: Clear Render Cache and Re-render from the Command Palette.

A changed diagram is drawn again as you type. For a large one, plantumlLocal.preview.updateMode can wait instead: onSave draws it again when the file is saved, and manual only with Clear Render Cache and Re-render. Until then the Markdown preview and the .puml preview keep the diagram they show, with a note that it is not updated. A diagram shown for the first time is drawn whatever the mode; the Problems checks still follow every change, and export always uses the current text.

A diagram whose @enduml line is missing is drawn as if the block ended with one, with a note above it saying so; the export writes it the same way. Lines above @startuml in a block are left out of the drawing, as the engine reads it, and a note above the diagram says so too.

Syntax highlighting

```plantuml and ```puml blocks are also coloured in the editor, including ones inside block quotes and list items. As with the preview, only these two languages count, exactly — ```PlantUML and ```uml stay plain. The grammar follows the syntax supported by the bundled PlantUML engine, and covers every diagram type that engine renders:

• the JSON and YAML inside @startjson / @startyaml are coloured by VS Code's own JSON and YAML grammars
• diagram types the bundled engine does not render (@startditaa, …) are marked invalid
• some older forms the engine accepts only with a warning — a colour in front of an activity (#pink:text), label on first column in a Gantt chart — are marked deprecated

Tokens carry the usual TextMate scope names with a .plantuml suffix (keyword.other.plantuml, entity.name.type.plantuml, …), so any colour theme applies, and editor.tokenColorCustomizations can adjust them.

Files ending in .puml, .plantuml, .pu, .iuml or .wsd open as the language PlantUML, with the same colouring. Toggle Line Comment uses ' and Toggle Block Comment uses /' … '/. A .puml file has a preview of its own (below), and its diagrams can be exported to SVG or PNG.

In a .puml file, each diagram folds from its @start… line, and so do block comments, multi-line notes, legends, headers, footers, titles and ref over blocks, { … } bodies, preprocessor sections (!if, !procedure, !foreach, …), sequence groups (alt, loop, …) and activity blocks (if, while, fork). A file with none of these folds by indentation; to fold every PlantUML file that way, set "editor.foldingStrategy": "indentation" under "[plantuml]" in the settings.

The Outline view, the breadcrumbs and Go to Symbol in Editor (Ctrl+Shift+O; Cmd+Shift+O on macOS) list the diagrams of a .puml file, each by its id or its start line, and what each declares with a keyword: participant, actor and the other participants of a sequence diagram, class, interface, enum, annotation, component, node, package, namespace, state and usecase. A declaration is listed by its alias, with the name the diagram shows beside it, and what a { … } body declares sits under it. A name that only appears in a relation, or that a procedure creates, is not listed.

Previewing .puml files

PlantUML Local: Open Diagram Preview to the Side — the preview button in the title bar of a .puml file's editor — opens a panel showing the diagram under the cursor. The panel stays with that file while the focus moves elsewhere, lists the file's diagrams when it holds several, and draws the diagram again as the file changes. Running the command again in the same file brings its panel back rather than opening another. Open Diagram Preview does the same in the editor's own group (or hold Alt on the button). A panel left open comes back when VS Code restarts, on the same diagram when that diagram has a name, and otherwise asking which one to show.

The diagram is first fitted to the panel, never past 100% — the size the diagram gives itself, which PlantUML's scale sets. The buttons above it zoom out and in, fit it, and show it at 100%; so do the keys -, +, 0 and 1. Ctrl+wheel (Cmd on macOS) or a pinch zooms at the pointer, the wheel scrolls, dragging moves the diagram, and the arrow keys move it by 40 pixels (200 with Shift). Each diagram keeps its zoom and position while it is redrawn, while the panel is hidden, and across a restart. The PNG button beside them exports the diagram shown as Export Diagram as PNG does, at its own size and scale rather than the zoom of the panel, and in the palette of exports: light, whatever the editor theme, unless plantumlLocal.exportTheme says otherwise.

The Copy button puts that same PNG on the clipboard instead of in a file, to paste into a chat, a slide or a document; so do Ctrl+C (Cmd+C on macOS) in the panel and Copy in its context menu. The panel says when the image is on the clipboard, or why it is not: a diagram the PNG button would not export, such as one with an error or one past the size limit of a PNG, is not copied either.

The panel shows the SVG as an image, so nothing in it can run, and loads nothing but its own script and stylesheet.

Completion

In a diagram — a ```plantuml block or a .puml file — suggestions open on:

• @ at the start of a line: the start line of each diagram type the bundled engine draws, or inside a diagram, its end line
• ! at the start of a line: the preprocessor directives
• !theme : the themes that ship with the extension
• <&: the names of the OpenIconic icons
• !include and a / in its path: the folders and the files it can include (see Including files)

Where a diagram can start, puml- offers a template of a sequence, class, activity, state, component or use case diagram, with its names to tab through: a whole ```plantuml block in the text of a Markdown file, the bare diagram in an empty block or between the diagrams of a .puml file. PlantUML Local: Insert Diagram Template does the same from the command palette: pick the kind, and the template goes on lines of its own at the cursor, inside the block quote or list item the cursor is in, as one edit that one Undo takes back. In a block that already holds a diagram, it asks to add a new block after it; in a diagram, a comment or a block of another language, it says why it does not.

Markdown turns quick suggestions off, so in a Markdown file the list opens on those characters, or with Trigger Suggest (Ctrl+Space) — type puml and press it for the templates.

Problems

The diagrams of open Markdown files are checked, whether or not a preview is open, and what is wrong with them is listed in the Problems panel on the line it is on:

• the engine's errors and warnings;
• an included file that is not read, and why (see Including files);
• what the bundled engine cannot do: a library other than azure, a URL, emoji;
• content the bundled engine does not render: a second diagram in a block, the pages after newpage;
• a diagram with no @enduml line, which is drawn anyway, and lines above @startuml, which the drawing leaves out.

The engine stops at the first error, so a diagram shows at most one, and it names a line but no column, so the whole line is marked. Its warnings name no line at all and are put on the diagram's @startuml line. A document is checked again half a second after it last changed, and its problems disappear as soon as it changes. plantumlLocal.diagnostics.enabled turns the checks off.

Including files

!include, !include_once and !include_many read files of the workspace, as in PlantUML:

```plantuml
@startuml
!include styles/common.puml
!include ../shared/actors.iuml
Alice -> Bob
@enduml
```

A path is looked for next to the file it is written in — for a Markdown block, the Markdown file. One starting with ./ or ../ is looked for there only; a bare name such as common.puml or styles/common.puml is then looked for in the folders of plantumlLocal.includePaths, in order. Includes may nest and take their path from a variable, and a file on a branch the diagram does not take is never read. With the bundled engine, a repeated !include of a file is skipped, !include_many includes it again and !include_once reports the second one as an error. A file holding a whole @startuml … @enduml diagram contributes the inside of it. With several diagrams in the included file, !include file.puml!1 chooses the second diagram and !include file.puml!ID chooses an @startuml(id=ID) diagram. Without a selector the first diagram is used; text outside the selected diagram is ignored. Different selectors of the same file are included separately. !includesub file.puml!PART includes a named !startsub PART / !endsub section. A selector or sub that is not found reports an error.

!theme name from themes reads themes/puml-theme-name.puml under the same file access rules. Includes inside a theme resolve relative to the file that requests the theme.

Files are read only in a trusted workspace, and only from the workspace folder of the document: text in UTF-8, ending in .puml, .plantuml, .pu, .iuml, .wsd, .inc or .txt. An absolute path or a URL, a path that leaves the workspace folder or passes through a symbolic link or a junction, a .git, .hg or .svn folder are refused, and the preview, the Problems panel and the export say why. A document open in the editor is read with its unsaved changes.

A diagram is drawn again when a file it includes changes — edited, saved, or changed, created or deleted on disk — under plantumlLocal.preview.updateMode, as when its own text changes: at once with onChange; once the file is saved with onSave, until when it is marked as not updated; with manual, marked until Clear Render Cache and Re-render. The Problems panel checks it again at once. One exception: a change made outside VS Code to a file in a folder that files.watcherExclude leaves out with a pattern ending in /** (such as **/generated/**) is not noticed, as VS Code reports no change there; run Clear Render Cache and Re-render after one.

Ctrl+Click on the path of an !include or an !includesub, or Go to Definition (F12), opens the file the diagram reads there: the one the preview draws, next to the including file or in a search folder. On !theme name from themes, the name and the folder both open the theme's file. A path the engine works out — from a variable, a function, or a name the diagram defines with !define or !name = — is not followed, nor one written in a procedure, which is looked for next to the file that calls it: a drawing tells which files it read, not which line asked for each. After !include or !includesub the path completes with the folders it can go into and the files of the kinds read, each from the first place that has it; a name from a search folder shows the folder. After the from of a !theme, the folders complete. In Restricted Mode, and in a document outside the workspace folders, neither is offered.

Icons and sprites

Sprites render, including the Azure icon set, which ships inside the extension:

```plantuml
@startuml
!include <azure/AzureCommon>
!include <azure/Compute/AzureFunction>
!include <azure/Databases/AzureCosmosDb>

AzureFunction(fn, "Orders API", "Functions")
AzureCosmosDb(db, "Orders", "Cosmos DB")
fn --> db
@enduml
```

The library is Azure-PlantUML and the include paths are its own, so existing diagrams work unchanged — and, as everywhere else here, nothing is downloaded to render them. Sprites written directly into the diagram with sprite $name […] { … } work too.

Azure is the only icon set bundled. The AWS and GCP libraries both place their icons under CC-BY-ND 2.0 with only the macros under MIT, and this extension ships nothing but MIT / BSD / EPL; Azure-PlantUML has no such split. Other !include <…> libraries report that they are unavailable rather than being fetched — but their sprite definitions can be pasted into the diagram, which renders identically.

PlantUML's own icons and themes ship as well: the OpenIconic icons creole draws with <&check>, and the !theme library (!theme cerulean) — all of it but four themes, mars, toy and vibrant (Apache License 2.0) and sunlust (GPL 3+), for which the engine reports that it cannot load the theme. Emoji (<:smile:>) do not ship: their images, from Twemoji, are under CC-BY 4.0, so a diagram using one shows a message saying emoji are not supported.

Exporting for GitHub and other hosts

The preview is the only place a ```plantuml block becomes a diagram — GitHub renders one as source, not as a picture. To be readable there too, export the SVG and reference it. One command does both. Name the block:

```plantuml orders-api
@startuml
Alice -> Bob : Hello
@enduml
```

Export All Diagrams as SVG and Update Image Links then writes images/orders-api.svg and, directly below the block, a Markdown image reference whose target is images/orders-api.svg#plantuml-local.

The first four are also in the editor's right-click menu: the single exports appear with the cursor inside a block, the other two whenever the file contains a diagram — so the menu of an ordinary Markdown file stays untouched. Run from the command palette while the preview has focus, they use the only open Markdown document, or ask which one when several are open. The message each export ends with offers Show in Explorer, which selects the file it wrote, or the first of them, in the Explorer. One that reports a problem offers a way on instead: Show Problems for a diagram with an error, Export as SVG for a PNG that cannot be made, Open Settings for a setting to change, Show Output for the reasons a bulk export lists there, and Name Diagram… when blocks were left out for want of a name.

The word after the language — orders-api above — names the output file. It is what ties a block to its SVG across edits, which a position could not: inserting a diagram above would silently repoint everything below it. Naming is therefore required for the bulk commands, and the single-diagram one asks when the block has none — or when its name could not be a file name, since names are limited to 128 ASCII letters, digits, hyphens and underscores, and cannot be a Windows device name such as CON. The bulk commands report such a block as failed.

With the cursor on the opening line of a block that has no usable name, the light bulb offers Name this diagram for export…: it asks for a name and writes it on that line, as one edit that Undo takes back. In a .puml file it does the same on the start line of any diagram, as (id=…) after @startuml, @startmindmap and the rest. Nothing is written if the document changed in the meantime.

All but the reference update also work in a .puml file, which writes each of its diagrams to a file of its own. A diagram is named by an id on its start line, @startuml(id=orders-api) or @startmindmap(id=roadmap); a file holding a single diagram may leave it out, and the diagram is named after the file. References are inserted into Markdown only.

A file already at the target is replaced only when you say so, or when the export put it there. If it holds the diagram already, nothing is written. If the export wrote it from the same document and it has not changed since, it is replaced without a question, so exporting an edited diagram again just updates its file. Anything else — a file put there by hand, another document's export, a file changed since or open with unsaved edits — the command asks about first, once for all the files it would replace, and the bulk commands can keep those files and write the rest. What the export wrote is kept in the workspace's state on this machine: each file, its document and a SHA-256 of the contents, no diagram. On another machine, the first export asks. A file that changes while the export runs — while its question is open, say — is left as it is and reported, whatever the answer. Each file is written under a temporary name beside the target and then renamed over it, so an export that fails part way never leaves half an image behind.

The #plantuml-local fragment on the inserted reference does two jobs. GitHub ignores it and renders the SVG, while this extension's preview hides marked images — the block above them already renders, and without that the same diagram would appear twice (plantumlLocal.hideExportedImages turns this off, for checking how the exported file itself looks). It also marks the line as machine-managed: renaming a block or changing the export directory rewrites the line on the next run, while every line without the marker — including a hand-written reference to the same file — is never touched. The update command is idempotent: running it twice changes nothing, and one Undo reverts whatever it wrote. A block inside a block quote or a list item gets its reference inside the same quote or item. If the document changes while the export runs, the files are written but the references are left alone; run the command again.

Exports use the light palette regardless of your editor theme, since the files face hosts whose background this extension does not control; plantumlLocal.exportTheme pins dark or follows the preview instead. Each exported SVG also carries an opaque background of its palette — the engine leaves the canvas transparent, and a dark host page would otherwise show through it.

Exported SVGs do not carry the diagram source. PlantUML embeds it in every SVG it draws, so that an image can be decoded back into a diagram — comments, preprocessor variables and hidden elements included, none of which the picture shows — and the engine bundled here has no option to leave it out (PlantUML's command line has -nometadata). The extension removes it, together with the element names the engine records in data-* attributes. Keep the Markdown as the source of a diagram: an exported file cannot be turned back into one.

A block that does not render is reported rather than exported. PlantUML answers a syntax error, an include it cannot resolve or an empty diagram with a drawing of the error in place of the diagram; instead of saving that as the block's SVG, the export commands count the block as failed and show PlantUML's message with the line of the document it points to. No file or reference is written for it.

Export Diagram as PNG writes the diagram as a PNG instead, for where an SVG does not go, such as a slide or a chat. It is drawn at plantumlLocal.exportPngScale times the diagram's own size — 1, 2 or 4, 2 by default — on the background of its palette, into the same directory. The extension host has no canvas to draw it on, so a panel opens beside the editor for the time the drawing takes and closes itself; closing it stops the export. A PNG larger than 8192 pixels a side or 16 million in all is refused rather than shrunk, and the message names the largest scale it would fit at. Its text is drawn with the fonts of the machine that exports it, where an SVG's is drawn with those of whoever views it. The PNG export covers one diagram at a time and inserts no reference.

Export All Diagrams in Folder as SVG, also on a folder's right-click menu in the Explorer, does what Export All Diagrams in File as SVG does for every Markdown and PlantUML file under a folder, each into its own export directory, with the unsaved edits of open files. It skips .git, .hg, .svn, node_modules, dist and build folders, follows no symbolic link or junction, and leaves out a PlantUML file without a start line, which only other files include. It asks before drawing, naming the documents, and then once for all the files it would replace. A diagram headed for the same file as another — two documents beside each other naming a block alike — is reported instead of written over it. A folder of more than 500 documents or 2,000 named diagrams is refused rather than exported in part, and cancelling while it draws writes nothing. Export All Diagrams in Folder as PNG, beside it in the menu, writes PNGs instead, as Export Diagram as PNG does, drawing them one after another in a single panel that closes once the last is drawn.

plantumlLocal.exportDirectory (default images) decides where files go, relative to the Markdown file rather than to the workspace root, so moving a document keeps its diagrams beside it. Exporting writes files, so it needs a trusted workspace — the preview does not.

Two things to keep in mind. The SVG is a snapshot: after editing a block, re-run the command (commit the images/ directory alongside the document, or the references point at nothing). And this flow is for hosts that do not render PlantUML — one that does, like GitLab, renders the block itself and would show the referenced image as a second copy.

Known Limitations

• Only the azure standard-library entry is bundled; other !include <…> libraries are unavailable
• !include of a URL is not supported: URL-based directives are rejected with an inline message. Files are included only from the document's workspace folder, in a trusted workspace (see Including files)
• Remote themes and other network resources are not supported
• Images (<img:…>) are not loaded, local or remote: the engine draws an [img TBD…] placeholder in their place
• Emoji (<:smile:>) are not supported: their images are not bundled, and a diagram using one shows an inline message instead
• A block draws one diagram, on one page: a block holding a second @startuml … @enduml, or a diagram using newpage, shows a message instead, since the engine would draw only the first diagram or page
• Functions that read the machine return nothing: %getenv(), %filename() and %dirpath() are empty and %file_exists() is 0
• Hyperlinks ([[https://…]]) are drawn as text, not as links
• A diagram wider or taller than 8192 pixels is not drawn; an error is shown instead
• Only the first error in a diagram is reported
• Start and end lines must be lowercase and begin with @: @StartUml and \startuml fail
• Four !theme themes are not bundled: mars, sunlust, toy and vibrant
• Features excluded from the bundled PlantUML browser build are unavailable. Among them: embedded diagrams ({{ … }} inside a note, a legend or a class body) and formulas (<math>, <latex>) are accepted but not drawn
• Text is measured with approximate metrics (Node has no Canvas), so element widths, line wrapping and placement can differ slightly from plantuml.com
• A render that exceeds 30 seconds is terminated
• With the bundled PlantUML 1.2026.9, a diagram that includes more than 20 files, nested includes counted, shows an error instead: the engine draws the diagram once more for each included file it has not loaded yet and stops after 20 rounds (plantuml/plantuml#2943)
• Highlighting cannot tell which diagram type a @startuml block will turn into, so it colours the syntax of all of them: a line the engine rejects in one diagram type can still be coloured. Nor can it tell which names !procedure and !function define: a call written without $ stays plain
• Other PlantUML extensions register the same language for the same file extensions. With one of them installed too, which grammar colours a .puml file depends on the order VS Code loads the extensions; disable one of them to choose

Configuration

A diagram that picks a !theme is drawn in that theme's colours, and most themes paint no background of their own, leaving the diagram on the backdrop of the palette. When the theme's text would be hard to read on that backdrop, the diagram is drawn in the other palette instead — a theme made for a white page, such as plain or cerulean, gets the light palette in a dark editor. So does a diagram with the Azure icons and no theme, whose boxes are white whatever the palette, and one whose own colours — set with skinparam, a style, or on an element as in class Foo #pink — leave its text hard to read in the dark palette: a diagram drawn in the dark palette is looked at once drawn, and drawn in the light one when that reads better. This applies to the preview and to exports alike, and counts a theme or the Azure icons that a diagram gets from a file it includes: such a diagram is drawn once more in the other palette when that file turns the choice. The .puml preview says when it shows a diagram in the other palette. In the dark palette, links ([[…]]) are drawn in a light blue, as the engine's own blue is hard to read there.

How It Works

Rendering inside the preview webview — the way Mermaid extensions work — is not an option for PlantUML: use-case, class and state layouts come from Graphviz, which ships as WebAssembly, and the preview's Content-Security-Policy does not grant wasm-unsafe-eval.

So the engine runs in a worker thread on the extension host (no CSP there), and only the finished, sanitised SVG is injected into the preview. PlantUML Local contributes no scripts to the Markdown preview — the sanitised SVG is the only thing it adds to the rendered document.

markdown-it's fence rule is synchronous while rendering is not; they meet through a cache: the first pass shows a placeholder and starts rendering, completion triggers one debounced preview refresh, and the second pass serves the SVG from cache.

Security and Privacy

PlantUML Local is designed to render diagrams without sending their source to an external rendering service.

• Local Rendering: The engine, the Graphviz WebAssembly, the bundled icon library and all runtime assets ship inside the VSIX and load from disk
• No Telemetry: The extension collects no usage data and makes no intentional network requests
• Network Guard: fetch / XMLHttpRequest / WebSocket / EventSource are replaced with throwing stubs inside the render worker — a network attempt fails the render instead of making a request
• Remote References Rejected: !include https://… / !theme … from https://… render an explanatory message instead of reaching the engine
• Worker Isolation: The engine's browser shims live in a worker thread, never on the extension host globals
• Render Timeout: A render exceeding 30 s is abandoned; the worker is terminated and restarted, and draws the renders that were waiting behind it
• Graphviz Crash Recovery: A diagram that makes Graphviz crash shows the engine's crash report, and the worker is restarted, so the diagrams after it are laid out by a fresh Graphviz
• No Embedded Source: The copy of the diagram source that PlantUML embeds in every SVG, and the element names it records in data-* attributes, are removed before an SVG reaches the preview or an exported file
• Image-Only Panels: The .puml preview, and the panel a PNG is drawn in, show the SVG as an image under a strict content security policy, so nothing in a diagram can run there
• Included Files Checked: The engine reads no file itself; the extension hands it the file of a local !include only from the document's workspace folder, through no symbolic link or junction, and only as UTF-8 text with one of the extensions listed under Including files
• Untrusted Workspaces: No file is read for an !include until the workspace is trusted, and no processes are spawned

These controls reduce the extension's attack surface, but they have limits worth being explicit about: a worker thread is an isolation boundary for globals, not a process- or OS-level security sandbox, and stubbing browser-style network APIs is not the same as closing every network path available to Node.js.

CI verifies each package: verify-vsix unpacks the VSIX, checks for leaked key material and rendering-service URLs, and renders a diagram from the packaged worker.

For the full threat model and for vulnerability reporting, see SECURITY.md.

Platform Requirements

• VS Code 1.138 or later
• Windows, macOS or Linux, on x64 or ARM64

That's it — no Java runtime, no Graphviz install, no external tools.

Upgrading? The minimum is now 1.138 — it was 1.137 from 0.9.0, 1.136 from 0.8.0, 1.134 from 0.7.0, 1.125 from 0.4.0, and 1.101 before that. Older installations keep the version they have and stop receiving updates.

CI runs the test suite on Windows, macOS and Linux (x64 on Windows and Linux, ARM64 on macOS). The extension is plain JavaScript and WebAssembly, so other combinations are expected to work; please open an issue if one does not.

In a remote window (WSL, a Dev Container, SSH), PlantUML Local is installed on the remote machine and runs there, so that is where diagrams are rendered and exported files are written. The previews, and the panel a PNG is drawn in, stay on your own computer: SVGs travel to them, and PNGs back, over VS Code's own connection to that machine, and a PNG's text is drawn with your computer's fonts. A diagram copied from the .puml preview goes to your own computer's clipboard. No rendering service is involved either way.

Troubleshooting

• Stuck on "Rendering diagram…": Check Output → PlantUML Local for worker errors, then run PlantUML Local: Clear Render Cache and Re-render
• A red syntax-error box appears: The message comes from the PlantUML engine — only that diagram is affected, and the rest of the page still renders
• "An error has occurred!" with "For some reason, dot/GraphViz has crashed.": Graphviz could not lay out that diagram (packages nested a hundred deep are one way to get there). Only that diagram is affected, and it is an error, as a syntax error is: the preview says what to do, and it is not exported. Simplify it, or add !pragma layout smetana, which lays out the diagram without Graphviz
• Colours look wrong after switching themes: Backgrounds follow the palette the diagram was rendered with. If you pinned plantumlLocal.theme, that palette wins by design
• Exported images have different colours from the preview: Exports, the PNG and Copy buttons of the .puml preview included, use the light palette by default, whatever the editor theme (plantumlLocal.exportTheme). Set it to preview to export in the palette the preview uses, or set plantumlLocal.theme to light to preview diagrams in the colours they are exported in
• Layout differs from plantuml.com: Text is measured with approximate metrics in the Node renderer, so box widths, line wrapping and element placement can differ slightly
• Setting logLevel: debug shows nothing new: The channel is a LogOutputChannel now, and VS Code decides what one of those shows — an extension cannot raise its own channel's level. Run Developer: Set Log Level and pick PlantUML Local; that choice is per channel and survives a restart. plantumlLocal.logLevel is a floor on top of it for the rendering entries, so it can only make those quieter

Contributing

Contributions are welcome — thank you for helping make PlantUML Local better 🙌 Please see CONTRIBUTING.md for guidelines.

If you're planning a larger change, opening an issue first is appreciated (it helps align direction and avoids duplicate work). Note that features requiring Java, a server or network access are out of scope by design.

Support & Maintenance Policy

PlantUML Local is a personal hobby project maintained in spare time. The project is active, but support is best-effort: I'll do my best to review issues and PRs, and releases may be a bit slow sometimes — thank you for your patience.

Helpful things when reporting bugs:

• OS / architecture / VS Code version
• The smallest PlantUML source that reproduces the issue
• Output from Output → PlantUML Local, with the level set to Debug via Developer: Set Log Level

Security-related reports should follow SECURITY.md. Really appreciate you using PlantUML Local 💛

License

PlantUML Local is licensed under the MIT License — see LICENSE.

The bundled engine @plantuml/core is MIT-licensed from version 1.2026.6 onwards (earlier versions are GPL-3.0-or-later). This extension's dependency range for it starts no lower than 1.2026.6 (see package.json), so it only ever resolves to MIT-licensed releases; the exact version a build used is recorded in package-lock.json.

Copyright and licence notices for the third-party code shipped inside the VSIX are collected in THIRD_PARTY_NOTICES.md.

Acknowledgments

• Diagram rendering powered by PlantUML and its @plantuml/core TeaVM build — this extension is a third-party project, not affiliated with or endorsed by the PlantUML project
• Graphviz layout by Viz.js, a WebAssembly build of Graphviz shipped inside @plantuml/core
• DOM for the engine by happy-dom
• Extension framework by @kkdev92/vscode-ext-kit
