KF SQL Formatter (Databricks/Spark)

A custom token-based SQL formatter for VS Code that formats Databricks/Spark SQL with 100% idempotent output.

Features

• 100% Idempotent - Format twice = same result, enforced on every golden reference
• Width-Aware Alignment - Automatic 80/120 character width preference per statement
• Content-Aware Separators - Comment separators snap to 80 or 120 dashes
• Leading Commas - SELECT list items formatted with leading commas (,col)
• Smart Keyword Casing - Configurable keyword case (lower, upper, or preserve)
• Multi-word JOIN Handling - Keeps INNER JOIN, LEFT JOIN, etc. together
• CTE Indentation - Perfect context tracking for WHERE/GROUP BY in CTEs
• Trailing Whitespace Removal - Clean, consistent output
• Spark SQL Support - Arrays, maps, structs, named_struct, explode, lateral view
• SQL Test Generator - Generate test queries to debug WHERE/JOIN filtering logic

Installation

Option 1: VS Code Marketplace (Recommended)

Search for "KF SQL Formatter" in VS Code Extensions or install from: VS Code Marketplace - KF SQL Formatter

Option 2: Direct Download

Download Latest Release (v0.6.0)

After downloading:

1. Open VS Code
2. Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (Mac)
3. Type "Extensions: Install from VSIX..."
4. Select the downloaded .vsix file

Option 3: Build from Source

git clone https://github.com/k-f-/kf.sql.formatter.git
cd kf.sql.formatter
npm install
npm run compile
npm run package

Usage

1. Open any .sql, .hql, or .spark.sql file
2. Run Format Document (Shift+Alt+F on Windows/Linux, Shift+Option+F on Mac)
3. Your SQL will be formatted with consistent style!

SQL Test Generator

Generate test queries to debug WHERE and JOIN filtering logic. Useful for identifying why data disappears between pipeline layers.

How to Use

1. Open a SQL file with a SELECT query
2. Use one of these methods:
   • Keyboard: Ctrl+Shift+T (Windows/Linux) or Cmd+Shift+T (Mac)
   • Right-click: Select KF.SQL: Generate SQL Tests from context menu
   • Command Palette: Ctrl+Shift+P → KF.SQL: Generate SQL Tests
3. A new tab opens with your test query

What It Does

• Extracts WHERE conditions → Creates TEST columns showing PASS/FAIL for each filter
• Extracts CTE conditions → Creates CTE columns (CTE1, CTE2) for conditions inside WITH clauses
• Extracts JOIN conditions → Creates JOIN columns showing PASS/FAIL/N/A for each join
• Converts INNER JOIN -> LEFT JOIN → Preserves unmatched rows for debugging
• Comments out WHERE clause → Returns ALL rows so you can see what would be filtered
• Adds dual-comment pattern → --[TEST1] markers link results to original conditions

Example

Input:

SELECT * FROM users u
INNER JOIN orders o ON u.id = o.user_id
WHERE u.status = 'active' AND o.amount > 100

Output (automatically formatted using your workspace settings):

select *
    -- [Test Indicators] ----------
        , CASE WHEN (u.status = 'active'
    and o.amount > 100) THEN 'Y' ELSE 'N' END                                               as TEST1                        --[TEST1]
    , CASE WHEN u.status = 'active' THEN 'Y' ELSE 'N' END                                    as TEST1_1                     --[TEST1.1]
    , CASE WHEN o.amount > 100 THEN 'Y' ELSE 'N' END                                         as TEST1_2                     --[TEST1.2]
    , CASE WHEN o.user_id is null THEN 'N/A' WHEN u.id = o.user_id THEN 'Y' ELSE 'N' END           as JOIN1                 --[JOIN1]
from users                                                                       as u
left join orders                                                                  as o
on u.id = o.user_id                                                                                                     --[JOIN1]
-- WHERE clause commented for testing:
-- WHERE u.status = 'active' --[TEST1.1] AND o.amount > 100 --[TEST1.2]

Key features shown:

• TEST1: Combined parent test (both conditions AND'd)
• TEST1_1, TEST1_2: Individual condition tests
• JOIN1: JOIN condition with N/A for unmatched rows
• Dual-comment pattern: --[TEST1] markers link results to original conditions
• Auto-formatted: Output uses your workspace formatter settings

Test Generator Settings

Setting	Default	Description
testGenerator.convertInnerJoins	true	Convert INNER -> LEFT JOIN for non-destructive testing
testGenerator.addJoinNullHandling	true	Add N/A for unmatched JOIN rows
testGenerator.showMetadata	true	Show notification with test counts
testGenerator.useNamedStruct	true	Use named_struct() for struct columns in test output
testGenerator.detailLevel	"summary"	Level of detail in test output ("summary" or "verbose")

Supported Features

Feature	Test ID Pattern	Example
WHERE conditions	TEST1, TEST2, etc.	WHERE status = 'active' → TEST1
JOIN ON conditions	JOIN1, JOIN2, etc.	ON u.id = o.user_id → JOIN1
CTE WHERE conditions	CTE1, CTE2, etc.	WITH cte AS (... WHERE x > 10) → CTE1
HAVING conditions	HAVING1, HAVING2, etc.	HAVING COUNT(*) > 5 → HAVING1
Subquery WHERE	SUB1, SUB2, etc.	FROM (SELECT ... WHERE x > 10) subq → SUB1
AND decomposition	Parent + children	WHERE a AND b → TEST1, TEST1_1, TEST1_2
BETWEEN decomposition	Parent + >= / <=	BETWEEN 100 AND 500 → TEST1, TEST1_1 (>=), TEST1_2 (<=)
IN list decomposition	Parent + each value	IN ('a', 'b') → TEST1, TEST1_1, TEST1_2
CTE internal JOINs	CTE_JOIN1, CTE_JOIN2	WITH cte AS (... INNER JOIN ...) → CTE_JOIN1
Subquery JOINs	SUB_JOIN1	FROM (SELECT ... INNER JOIN ...) subq → SUB_JOIN1
Complex ON clauses	JOIN1	ON LOWER(a.email) = LOWER(b.email) → JOIN1
Multi-statement SQL	S1_TEST1, S2_TEST1	Multiple SELECTs → prefixed test IDs

Note: Output is automatically formatted using your workspace formatter settings (keywordCase, indent, leadingCommas, etc.).

Configuration

Configure the formatter in VS Code settings (settings.json):

{
  "databricksSqlFormatter.keywordCase": "lower",
  "databricksSqlFormatter.functionCase": "lower",
  "databricksSqlFormatter.indent": 4,
  "databricksSqlFormatter.leadingCommas": true,
  "databricksSqlFormatter.dialect": "spark",
  "databricksSqlFormatter.maxLineLength": 120,
  "databricksSqlFormatter.aliasAlignmentScope": "cte",
  "databricksSqlFormatter.aliasMinGap": 8,
  "databricksSqlFormatter.aliasMaxColumnCap": 120,
  "databricksSqlFormatter.trimTrailingWhitespace": true
}

Quick Settings Access

• Command Palette: Cmd+Shift+P → "KF.SQL: Open Settings"
• Settings UI: Cmd+, → Search "databricks"

Available Settings

Core Formatting

Setting	Type	Default	Description
keywordCase	"lower" | "upper" | "preserve"	"lower"	SQL keyword letter case
functionCase	"lower" | "upper" | "preserve"	"lower"	Function name letter case
indent	number	4	Spaces per indent level (2-8)
leadingCommas	boolean	true	Use leading commas in SELECT lists
dialect	"spark" | "hive" | "ansi"	"spark"	SQL dialect (for future use)
trimTrailingWhitespace	boolean	true	Remove trailing whitespace from lines
maxLineLength	number	120	Line width budget for keeping clauses, lists, and subqueries on one line (40-300). Alias alignment columns are governed separately by the alias* settings

Alias Alignment

Setting	Type	Default	Description
aliasAlignmentScope	"cte" | "file" | "statement" | "none"	"cte"	Scope for alias and comment alignment. "cte" aligns per block (each CTE body and each top-level select region), "statement" merges a statement's blocks into one group, "file" aligns across the entire file
aliasMinGap	number	8	Minimum spaces between expression and AS (1-20)
aliasMaxColumnCap	number	120	Maximum column for alias alignment (40-200)
aliasColumnCapMode	"fixed" | "adaptive"	"adaptive"	Column cap behavior. "adaptive" uses 80 or 120 based on expression length, "fixed" always uses aliasMaxColumnCap
aliasAdaptiveThreshold	number	80	When aliasColumnCapMode: "adaptive", expressions >= this length use 120 column cap, shorter use 80
addExplicitAs	boolean	true	Add explicit AS keyword to all aliases

Auto-Generate Aliases

Setting	Type	Default	Description
autoGenerateAliases	boolean	true	Master switch for auto-generating aliases (must be true to enable sub-options)
autoGenerateTableAliases	boolean	true	Auto-generate table aliases from table names (e.g., customer_orders -> co)
autoGenerateSelectAliases	boolean	false	Auto-generate SELECT expression aliases for complex expressions

Formatting Examples

Before Formatting

WITH active_users AS (SELECT user_id,user_name,account_type FROM users WHERE status='active' AND created_date>='2024-01-01'),order_stats AS(SELECT user_id,COUNT(*) as order_count,SUM(amount) as total_spent,AVG(amount) as avg_order FROM orders WHERE order_date>='2024-01-01' GROUP BY user_id)SELECT u.user_id,u.user_name as customer_name,u.account_type,CASE WHEN o.order_count>10 THEN 'high' WHEN o.order_count>5 THEN 'medium' ELSE 'low' END as engagement_level,o.total_spent,o.avg_order FROM active_users u INNER JOIN order_stats o ON u.user_id=o.user_id WHERE o.total_spent>100 ORDER BY o.total_spent DESC

After Formatting

Configuration Used: default settings with autoGenerateAliases: false (this is the formatter's actual output for the input above):

with active_users as (
    select
         user_id
        ,user_name
        ,account_type
    from users
    where status = 'active' and created_date >= '2024-01-01'
)
,order_stats as(
    select
         user_id
        ,count(*)                                                               as order_count
        ,sum(amount)                                                            as total_spent
        ,avg(amount)                                                            as avg_order
    from orders
    where order_date >= '2024-01-01'
    group by user_id
)
select
     u.user_id
    ,u.user_name                                                                as customer_name
    ,u.account_type
    ,CASE
        WHEN o.order_count > 10                                                 THEN 'high'
        WHEN o.order_count > 5                                                  THEN 'medium'
        ELSE 'low'
    END                                                                         as engagement_level
    ,o.total_spent
    ,o.avg_order
from active_users                                                               as u
inner join order_stats                                                          as o
    on u.user_id = o.user_id
where o.total_spent > 100
order by o.total_spent desc

Key Features Demonstrated:

• Leading commas, with the first item padded so content aligns down the list (leadingCommas: true)
• Per-block alias alignment with the adaptive 80/120 column snap (aliasAlignmentScope: 'cte', aliasColumnCapMode: 'adaptive')
• CASE ladders with column-aligned THEN and END joining the alias column
• Consistent keyword casing, with CASE/WHEN/THEN/ELSE/END always uppercase (keywordCase: 'lower')
• ON clauses indented under their JOIN; inline GROUP BY / ORDER BY when they fit (maxLineLength: 120)
• Explicit AS on column and table aliases (addExplicitAs: true)

Understanding aliasAlignmentScope

The aliasAlignmentScope option controls how AS keywords align across your SQL file. The default, 'cte', aligns each block (each CTE body, each top-level select) independently. Here's a statement-vs-file comparison (using aliasColumnCapMode: 'fixed' to make the difference visible; actual formatter output):

With scope: 'statement' (each statement aligns independently):

select
     customer_id
    ,very_long_customer_name        as name
    ,account_balance                as balance
from customers

;select
     id          as user_id
    ,name        as user_name
from users

With scope: 'file' (all statements share one column):

select
     customer_id
    ,very_long_customer_name        as name
    ,account_balance                as balance
from customers

;select
     id                             as user_id
    ,name                           as user_name
from users

Statement 2's aliases either use their own optimal column (statement) or pad out to match statement 1's longest expression (file).

Recommendation: the default 'cte' gives each CTE and select region its own optimal column and matches the golden reference style; use 'file' when you want one uniform column across everything.

Architecture

The formatter uses a split-merge pipeline as its primary formatting engine:

1. Tokenize — SQL -> Tokens (preserves 100% of original text)
2. Normalize — Standardize whitespace and casing
3. Split — Break into logical lines at structural boundaries
4. Indent — Apply context-aware indentation (CTEs, subqueries, CASE statements)
5. Merge — Recombine short lines for density (within maxLineLength)
6. Align — Align AS keywords, CASE THEN columns, named_struct commas, and inline comments per block
7. Cosmetics — Final cleanup (keyword casing, explicit AS, trailing whitespace)
8. Generate — Tokens -> Formatted SQL

Author intent is preserved where it matters: source line breaks in boolean conditions, derived tables, and function calls survive formatting, and hand-grouped multi-line parenthesized conditions pass through verbatim.

The Goldens Are the Spec

The eight files in examples/golden-references/ are hand-authored reference outputs, and the test suite asserts byte-exact fixed-point on every one: format(golden) === golden, plus idempotence (tests/golden/fidelity.test.ts, run under the golden profile: defaults + autoGenerateTableAliases: false, autoGenerateSelectAliases: false).

This means the golden files ARE the formatter's style specification. To change the style, edit the golden files and the formatter in the same commit — the suite fails on any drift in either direction. Option variants and the real-usage profile (file scope + auto-generated aliases) are locked by snapshot suites (tests/options/variants.test.ts, tests/golden/real-usage.test.ts).

The full suite also covers pipeline stages, all configuration options, edge cases, and the SQL test generator - run it with npm test.

Project Structure

kf.sql.formatter/
├── package.json                   # Extension manifest
├── tsconfig.json                  # TypeScript config
├── esbuild.js                     # Production bundler
├── vitest.config.ts               # Test configuration
├── src/                           # Source code
│   ├── extension.ts               # VS Code extension entry point
│   ├── formatter-custom.ts        # Main formatter orchestration
│   ├── tokenizer/                 # SQL tokenizer
│   │   ├── tokenize.ts
│   │   └── token-types.ts
│   ├── transformers/              # Alias analysis (shared with pipeline)
│   │   ├── auto-generate-aliases.ts
│   │   └── symbol-table-builder.ts
│   ├── pipeline/                  # Split-merge pipeline
│   │   ├── normalize.ts
│   │   ├── split.ts
│   │   ├── indent.ts
│   │   ├── merge.ts
│   │   ├── align.ts
│   │   ├── cosmetics.ts
│   │   ├── keywords.ts
│   │   ├── render.ts
│   │   └── index.ts
│   ├── test-generator/            # SQL test query generator
│   │   ├── index.ts
│   │   ├── types.ts
│   │   ├── ast-condition-extractor.ts
│   │   ├── comment-injector.ts
│   │   ├── join-converter.ts
│   │   └── test-case-generator.ts
│   ├── utils/                     # Utilities
│   │   └── alias-generator.ts
│   └── generator/                 # SQL generator
│       └── generate-sql.ts
├── dist/                          # Compiled bundle (gitignored)
│   └── extension.js               # esbuild bundle (only VSIX file)
├── tests/                         # Test suite (vitest)
│   ├── unit/                      # Tokenizer, generator tests
│   ├── pipeline/                  # Pipeline stage tests
│   ├── options/                   # Configuration option + variant snapshot tests
│   ├── golden/                    # Strict fixed-point + idempotence + real-usage tests
│   ├── test-generator/            # Test generator tests (148 tests)
│   ├── integration/               # End-to-end formatter tests
│   └── framework/                 # Test framework utilities
└── examples/                      # SQL examples
    ├── test-cases/                # Test case files (8 files)
    ├── golden-references/         # Reference SQL (8 files)
    └── edge-cases/               # Complex SQL patterns (7 files)

Recommended Companions

For a complete SQL development workflow, we recommend using this formatter alongside:

• SQLFluff - The dialect-flexible SQL linter for modern data stacks.

While this extension handles the visual formatting and layout of your code, SQLFluff excels at linting and enforcing style rules. Using them together ensures your SQL is both beautiful and compliant with organizational standards.

Contributing

Contributions are welcome! Please see the guidelines below:

Development Workflow

Before Pushing

The repository includes a pre-push hook that automatically validates:

• TypeScript compilation (npm run compile)
• Test suite (vitest, including the strict golden fixed-point checks)
• Markdown linting (npm run lint)

If validation fails, you'll see helpful error messages with fix instructions.

The hook runs automatically before every git push and takes ~5-10 seconds.

Manual Validation

To check your changes before pushing:

npm run verify

This runs the test suite only. For the full pre-push validation (compile + lint + tests), run the commands individually.

Fixing Markdown Linting Errors

Most markdown errors can be auto-fixed:

npm run lint:fix

Some errors (like MD040 - missing code fence languages) require manual fixes.

Bypassing Pre-Push Hook

Use only in emergencies:

git push --no-verify

Warning: This will likely cause CI failures on GitHub Actions.

License

MIT License - see LICENSE file for details

Links

• VS Code Marketplace
• GitHub Repository
• Issue Tracker
• Release Notes

Version History

For full version history, see CHANGELOG.md.

---

Made for the Databricks community
