XAML / AXAML / Razor / HTML Visual Designer
A VS Code extension that provides a full WYSIWYG visual designer for .xaml, .axaml, .razor, .html, and .htm files.
Design UIs by dragging controls onto a canvas — no hand-editing markup required. Changes sync back to the source file automatically.
Now on Vs Code marketplace:
https://marketplace.visualstudio.com/items?itemName=jugih-official.wysiwyg-designer
License Notice
This project is source-available.
Forking, redistribution, publishing modified versions,
or republishing this extension in any marketplace is
strictly prohibited without explicit permission from
the author.
See the LICENSE file for full terms.
Table of Contents
- Overview
- Features at a Glance
- Prerequisites
- Compile & Package from Source
- Install the Extension
- Using the Designers
- XAML / AXAML Designer
- Razor Designer
- HTML Designer
- Live Preview
- Keyboard Shortcuts
- Toolbar Reference
- Context Menu Reference
- Development Guide
- Project Structure
Overview
XAML/AXAML/Razor/HTML Visual Designer is a VS Code custom editor extension that replaces the raw text view of markup files with an interactive design canvas. It is aimed at developers working with:
| File Type |
Framework / Use-case |
.xaml / .axaml |
Avalonia UI (WPF-like cross-platform UI framework) |
.razor |
Blazor (ASP.NET Core component model) |
.html / .htm |
Plain HTML / static web pages |
The extension is read-write: it parses the existing markup into a visual representation and can write the resulting layout back to disk as valid, formatted markup.
Features at a Glance
| Feature |
Details |
| Drag-and-drop toolbox |
50+ XAML controls, 18 Blazor components, 60+ HTML elements |
| Visual canvas |
Absolute-positioned drag surface with pixel-accurate placement |
| Resize handles |
8-point handles (4 corners + 4 edges) on every selected control |
| Resizable panes |
Drag the splitter borders between the Toolbox, Canvas, and Properties panels to resize them |
| Properties panel |
Dynamic panel showing all editable attributes for the selected control |
| Undo / Redo |
Full per-session undo stack (up to 50 entries) — Ctrl+Z / Ctrl+Y |
| Keyboard control |
Delete, Duplicate, Arrow-key nudging (1 px / 10 px with Shift), Escape |
| Z-order management |
Bring to Front / Send to Back per control |
| Context menu |
Right-click any control for common operations |
| Auto-sync |
Visual changes are written back to the source file automatically after a 300 ms idle period; a pulsing badge in the toolbar confirms each sync |
| Bi-directional sync |
External file edits update the canvas automatically |
| Bidirectional cursor sync |
Clicking a control in the designer highlights the matching element in the text editor, and moving the text-editor cursor highlights the matching control on the canvas |
| Zoom & Pan |
Ctrl+Scroll to zoom the canvas (10%–500%); middle-mouse-button drag to pan; click the zoom badge to reset to 100% |
| Control nesting (XAML) |
Container controls (StackPanel, Grid, Canvas, Border, etc.) accept child controls via drag-and-drop, producing proper parent–child XAML markup |
| Three designer modes |
Separate, purpose-built designers for XAML, Razor, and HTML |
| HTML Live Preview |
Preview HTML files in a side panel inside VS Code with auto-refresh |
| XAML / Razor Preview |
Preview XAML/AXAML and Razor files with approximate HTML rendering in a side panel |
| Explorer context menu |
Right-click files in the Explorer to open directly with the designer |
Prerequisites
| Requirement |
Version |
| VS Code |
1.80.0 or later |
| Node.js |
18.x or later (for compiling from source) |
| npm |
Included with Node.js |
| TypeScript |
Installed locally via npm install |
Compile & Package from Source
Quick Start
git clone https://github.com/jugih-official/vs-code-wysiwyg.git
cd vs-code-wysiwyg
npm install
npm run compile
npm run package
code --install-extension xaml-axaml-designer-x.z.y.vsix
That's it!
Step-by-step Breakdown
1. Clone the Repository
git clone https://github.com/jugih-official/vs-code-wysiwyg.git
cd vs-code-wysiwyg
2. Install Dependencies
npm install
This installs TypeScript, the VS Code type definitions, and @vscode/vsce (the VS Code Extension packager).
3. Compile TypeScript
npm run compile
The compiler reads tsconfig.json and outputs JavaScript to the out/ directory.
The entry point for the extension is out/extension.js.
Watch mode — during active development you can run npm run watch instead.
This keeps the TypeScript compiler running in the background and recompiles on every save.
4. Package as VSIX
npm run package
After a successful run you will find a .vsix file in the project root, e.g. xaml-axaml-designer-0.1.0.vsix.
Install the Extension
Install from VSIX File
- Open VS Code.
- Open the Extensions view (
Ctrl+Shift+X / Cmd+Shift+X).
- Click the
··· (More Actions) button at the top-right of the Extensions panel.
- Select Install from VSIX…
- Navigate to the
.vsix file produced in the previous step and click Install.
- Reload VS Code when prompted.
Alternatively, install via the command line:
code --install-extension xaml-axaml-designer-x.y.z.vsix
Run in Extension Development Host
For development and testing without packaging, press F5 in VS Code with the repository open. VS Code will launch a second window — the Extension Development Host — with the extension loaded from source.
Using the Designers
Opening a Designer
Each designer is registered as a Custom Editor with "priority": "option", meaning it never overrides the default text editor.
There are three ways to open the visual designer:
- Open any supported file in VS Code.
- Click the "Open With…" button in the editor title bar (the split-screen icon), or right-click the file in the Explorer and choose Open With….
- Select the appropriate designer from the list:
XAML/AXAML Visual Designer — for .xaml / .axaml filesRazor Visual Designer — for .razor filesHTML Visual Designer — for .html / .htm files
Right-click any supported file in the Explorer file tree to see the relevant designer command directly in the context menu:
.xaml / .axaml → Open with XAML Visual Designer and Preview XAML/AXAML in Side Panel.razor → Open with Razor Visual Designer and Preview Razor in Side Panel.html / .htm → Open with HTML Visual Designer and Preview HTML in Side Panel
This allows you to open the designer without opening the file first.
3. Command Palette
You can also run the corresponding command from the Command Palette (Ctrl+Shift+P / Cmd+Shift+P):
| Command |
Action |
Open with XAML Visual Designer |
Opens the active .xaml/.axaml file in the XAML designer |
Open with Razor Visual Designer |
Opens the active .razor file in the Razor designer |
Open with HTML Visual Designer |
Opens the active .html/.htm file in the HTML designer |
Preview HTML in Side Panel |
Opens a live HTML preview beside the editor |
Preview XAML/AXAML in Side Panel |
Opens an approximate HTML preview of a XAML/AXAML file beside the editor |
Preview Razor in Side Panel |
Opens an approximate HTML preview of a Razor file beside the editor |
Designer Layout
Every designer shares the same three-pane layout. Drag the splitter borders between panes to resize them:
┌─────────────────────────────────────────────────────────┐
│ Toolbar [↶ Undo] [↷ Redo] [🗑 Delete] [⬆ Front] │
│ [⬇ Back] [● Auto-Sync] │
├──────────────┬──────────────────────────┬───────────────┤
│ │ │ │
│ Toolbox │ Design Canvas │ Properties │
│ │ │ │
│ (controls │ (drag-and-drop surface) │ (selected │
│ palette) │ │ control │
│ │ │ attributes) │
│ │ │ │
└──────────────┴──────────────────────────┴───────────────┘
Working with Controls
| Action |
How to perform it |
| Add a control |
Drag a control from the toolbox on the left and drop it onto the canvas |
| Select a control |
Click it on the canvas — a blue border with resize handles appears |
| Move a control |
Drag the selected control, or use the Arrow keys |
| Resize a control |
Drag any of the 8 resize handles on the selection border |
| Edit properties |
Select a control and modify the fields in the Properties panel on the right |
| Delete a control |
Select it and press Delete or Backspace, or use the toolbar / context menu |
| Duplicate a control |
Press Ctrl+D, or use the toolbar / context menu |
| Undo last action |
Press Ctrl+Z, or click ↶ in the toolbar |
| Redo last action |
Press Ctrl+Y, or click ↷ in the toolbar |
| Deselect |
Press Escape or click on an empty area of the canvas |
| Change z-order |
Use Bring to Front / Send to Back in the toolbar or context menu |
| Zoom canvas |
Hold Ctrl and scroll the mouse wheel — zoom range is 10% to 500% |
| Reset zoom |
Click the zoom-percentage badge in the toolbar to reset to 100% |
| Pan canvas |
Hold the middle mouse button and drag |
Zoom & Pan
The canvas supports smooth zoom and pan so you can work comfortably with large or complex layouts.
| Interaction |
Action |
| Ctrl + Scroll wheel |
Zoom in / out — range 10% to 500% |
| Click zoom badge |
Reset zoom to 100% |
| Middle-mouse-button drag |
Pan the canvas in any direction |
All coordinate operations (drop, drag, resize) are automatically adjusted for the current zoom level, so controls are always placed at the correct pixel position regardless of how far you are zoomed in or out.
Bidirectional Cursor Sync
The designers keep the visual canvas and the text editor in sync at all times:
- Visual → Text: Click a control on the canvas; the text editor jumps to the corresponding markup element and selects it.
- Text → Visual: Move the cursor (or click) in the text editor; the matching control on the canvas is highlighted with a coloured overlay.
This makes it easy to navigate between the visual representation and the raw markup without losing context.
Syncing Changes to Source
Changes made on the canvas are written back to the source file automatically. After any visual operation (drag, resize, property edit, add, delete, undo/redo), a 300 ms debounce timer starts. When it expires, the designer serialises the current layout back to the markup file. A small Auto-Sync badge in the toolbar pulses briefly to confirm each sync.
The extension also listens for external file changes: if the .xaml, .razor, or .html file is edited in another editor tab, the canvas will refresh automatically.
XAML / AXAML Designer
The XAML designer generates Avalonia UI-compatible XAML markup.
All control coordinates are expressed as Canvas.Left / Canvas.Top absolute positions with explicit Width and Height attributes.
XAML Available Controls
Common Controls
| Control |
Description |
| Button |
Clickable button |
| TextBlock |
Read-only text label |
| TextBox |
Editable single-line text input |
| Label |
Labelling element |
| CheckBox |
Boolean checkbox |
| RadioButton |
Exclusive selection in a group |
| ToggleSwitch |
On/off toggle |
| ComboBox |
Drop-down selection list |
| ListBox |
Scrollable list of items |
| Slider |
Range-value slider |
| ProgressBar |
Progress indicator |
| Image |
Displays a bitmap or vector image |
| HyperlinkButton |
Clickable hyperlink |
| RepeatButton |
Button that fires repeatedly while held |
| ToggleButton |
Two-state pressable button |
| SplitButton |
Button with an attached drop-down |
| Control |
Description |
| NumericUpDown |
Numeric spinner control |
| DatePicker |
Calendar-based date selection |
| TimePicker |
Time selection widget |
| Calendar |
Inline calendar |
| AutoCompleteBox |
Text input with suggestions |
| ColorPicker |
Color selection panel |
Containers
| Control |
Description |
| Expander |
Collapsible content section |
| TabControl |
Tabbed pages |
| Menu |
Application menu bar |
| TreeView |
Hierarchical tree list |
| DataGrid |
Tabular data grid |
| ScrollViewer |
Scrollable content area |
| SplitView |
Two-pane layout with a collapsible pane |
| Carousel |
Sliding panel carousel |
| NavigationView |
Navigation drawer/menu |
| HeaderedContentControl |
Content with a header |
| ContentControl |
Single-item content host |
| ItemsControl |
Collection-based items host |
Layout Panels
| Control |
Description |
| StackPanel |
Stacks children vertically or horizontally |
| WrapPanel |
Wraps children to the next row/column |
| DockPanel |
Docks children to edges |
| Grid |
Row-and-column grid layout |
| UniformGrid |
Equal-cell grid |
| Canvas |
Absolute-position surface |
| Border |
Draws a border around content |
| Viewbox |
Scales its child to fit |
| Panel |
Base panel |
| RelativePanel |
Positions children relative to each other |
| ItemsRepeater |
Virtualised list of repeated items |
Shapes
| Shape |
Description |
| Rectangle |
Filled or stroked rectangle |
| Ellipse |
Filled or stroked ellipse / circle |
| Line |
Straight line between two points |
| Path |
Arbitrary vector path |
| Separator |
Horizontal rule / divider |
| Polygon |
Closed polygon |
| Polyline |
Open polyline |
| Arc |
Arc segment |
Control Nesting
Container controls (e.g. StackPanel, Grid, Canvas, Border, DockPanel, WrapPanel) can hold child controls. When you drag a new control from the toolbox and drop it onto a container, the container highlights to show it will become the parent. The generated XAML reflects this as properly indented, parent–child markup:
<StackPanel Canvas.Left="40" Canvas.Top="60" Width="200" Height="150">
<Button Content="Click Me" Width="120" Height="32"/>
<TextBlock Text="Hello" Width="120" Height="24"/>
</StackPanel>
Nested controls are rendered above their parent in z-order and their positions are relative to the parent container's origin.
Properties Panel — XAML
When a XAML control is selected, the following fields are available in the Properties panel:
| Property |
XAML Attribute |
Description |
| Name |
x:Name |
Unique identifier for the control |
| Content |
Content |
Text or inner content (where applicable) |
| X |
Canvas.Left |
Horizontal position on the canvas |
| Y |
Canvas.Top |
Vertical position on the canvas |
| Width |
Width |
Control width in pixels |
| Height |
Height |
Control height in pixels |
| Foreground |
Foreground |
Text / foreground colour |
| Background |
Background |
Background fill colour |
| FontSize |
FontSize |
Text font size |
Razor Designer
The Razor designer generates Blazor-compatible Razor markup (.razor).
It supports both standard HTML elements and Blazor-specific components in a single canvas.
Razor Available Elements
HTML Structure
div, span, p, h1–h6, a, hr, br, blockquote, pre, code
input, textarea, select, button, label, form, fieldset
HTML Lists & Tables
ul, ol, li, table, tr, th, td
HTML Semantic / Layout
nav, header, footer, section, article, aside, main
Blazor Components
| Component |
Description |
EditForm |
Form bound to a model with validation |
InputText |
<input type="text"> bound with @bind |
InputNumber |
<input type="number"> |
InputDate |
<input type="date"> |
InputSelect |
<select> bound to a model property |
InputCheckbox |
<input type="checkbox"> |
InputTextArea |
<textarea> |
InputFile |
File-upload input |
InputRadio |
Single radio button |
InputRadioGroup |
Group of radio buttons |
ValidationSummary |
Shows all validation messages |
ValidationMessage |
Shows validation message for a single field |
AuthorizeView |
Shows content based on authorisation state |
CascadingValue |
Provides a cascading parameter down the tree |
Virtualize |
Efficient rendering of large lists |
PageTitle |
Sets the HTML page <title> |
HeadContent |
Injects content into <head> |
ErrorBoundary |
Catches render errors in child content |
Properties Panel — Razor
| Property |
Attribute |
Description |
| id |
id |
Element identifier |
| class |
class |
CSS class(es) |
| X |
style: left |
Horizontal position |
| Y |
style: top |
Vertical position |
| Width |
style: width |
Element width |
| Height |
style: height |
Element height |
| @onclick |
@onclick |
Blazor click event handler |
| disabled |
disabled |
Disabled state |
| Custom attributes |
Any |
Blazor binding directives (@bind, etc.) |
HTML Designer
The HTML designer generates standard HTML5 markup (.html / .htm).
HTML Available Elements
Structure
div, span, p, h1–h6, a, hr, br, blockquote, pre, code
input, textarea, select, button, label, form, fieldset, legend, output, meter, progress, datalist
img, video, audio, canvas, svg, iframe, picture, source, figure, figcaption
Lists & Tables
ul, ol, li, dl, dt, dd, table, thead, tbody, tfoot, tr, th, td, caption, colgroup, col
Semantic / Layout
nav, header, footer, section, article, aside, main, details, summary, dialog, template, slot
Properties Panel — HTML
| Property |
Attribute |
Description |
| id |
id |
Element identifier |
| class |
class |
CSS class(es) |
| X |
style: left |
Horizontal position |
| Y |
style: top |
Vertical position |
| Width |
style: width |
Element width |
| Height |
style: height |
Element height |
| type |
type |
Input / button type |
| Custom attributes |
Any |
Any standard HTML attribute |
Live Preview
The Live Preview feature lets you preview markup files directly inside VS Code, in a side panel next to the editor. The preview updates automatically when the file is edited or saved.
HTML Preview
HTML files (.html, .htm) are rendered directly in the preview panel.
| Method |
Steps |
| Explorer context menu |
Right-click an .html / .htm file in the Explorer → Preview HTML in Side Panel |
| Command Palette |
Open an HTML file, then run Preview HTML in Side Panel from the Command Palette (Ctrl+Shift+P / Cmd+Shift+P) |
XAML / AXAML Preview
XAML and AXAML files are converted to an approximate HTML representation for preview. Avalonia UI controls are mapped to their closest HTML equivalents — for example, Button becomes <button>, TextBox becomes <input>, StackPanel becomes a flex container, and so on. Layout attributes such as Canvas.Left, Canvas.Top, Width, Height, Background, and Foreground are translated to inline CSS.
| Method |
Steps |
| Explorer context menu |
Right-click a .xaml / .axaml file in the Explorer → Preview XAML/AXAML in Side Panel |
| Command Palette |
Open a XAML/AXAML file, then run Preview XAML/AXAML in Side Panel from the Command Palette |
Note: The XAML preview is an approximation. Complex control templates and bindings cannot be executed in a browser — the preview focuses on layout and visual structure.
Razor Preview
Razor files (.razor) are transformed for preview by stripping C# directives (@code, @using, @page, etc.) and converting Blazor components to their HTML equivalents — for example, EditForm becomes <form>, InputText becomes <input type="text">, and so on.
| Method |
Steps |
| Explorer context menu |
Right-click a .razor file in the Explorer → Preview Razor in Side Panel |
| Command Palette |
Open a Razor file, then run Preview Razor in Side Panel from the Command Palette |
Note: The Razor preview shows the HTML structure only. C# code blocks, event handlers, and data bindings are removed for the preview.
Preview Features
| Feature |
Description |
| Side-by-side view |
The preview opens beside the current editor so you can edit and preview simultaneously |
| Auto-refresh |
The preview refreshes automatically when the source file is edited or saved |
| Refresh button |
Click the ↻ Refresh button in the preview toolbar to manually reload |
| Sandboxed rendering |
The preview runs inside a sandboxed iframe for safety |
| File-type badge |
A coloured badge in the toolbar indicates whether the preview is showing HTML, XAML, or Razor content |
Keyboard Shortcuts
These shortcuts are active whenever the design canvas has focus.
| Shortcut |
Action |
Delete / Backspace |
Delete the selected control |
Ctrl+Z |
Undo the last change |
Ctrl+Y |
Redo the last undone change |
Ctrl+D |
Duplicate the selected control |
Escape |
Deselect the current control |
↑ ↓ ← → |
Move the selected control by 1 px |
Shift+↑ Shift+↓ Shift+← Shift+→ |
Move the selected control by 10 px |
Ctrl+Scroll Up |
Zoom in |
Ctrl+Scroll Down |
Zoom out |
The toolbar appears at the top of every designer.
| Button / Indicator |
Shortcut |
Action |
| ↶ Undo |
Ctrl+Z |
Undo the last action |
| ↷ Redo |
Ctrl+Y |
Redo the last undone action |
| 🗑 Delete |
Delete |
Delete the selected control |
| ⬆ Bring to Front |
— |
Move the selected control to the top of the z-order |
| ⬇ Send to Back |
— |
Move the selected control to the bottom of the z-order |
| ● Auto-Sync badge |
— |
Pulses green whenever the designer writes the current layout back to the source file (triggered automatically after a 300 ms idle period) |
| xx% zoom badge |
— |
Displays the current zoom level; click to reset to 100% |
Right-click any control on the canvas to open the context menu.
| Menu Item |
Action |
| Delete |
Remove the control from the canvas |
| Duplicate |
Create a copy of the control |
| Bring to Front |
Move above all other controls |
| Send to Back |
Move below all other controls |
Development Guide
Recommended VS Code Extensions
- ESLint — JavaScript/TypeScript linting
- Prettier — Code formatting
Available npm Scripts
| Script |
Command |
Description |
compile |
npm run compile |
Run tsc -p ./ — compiles TypeScript to out/ |
watch |
npm run watch |
Run tsc -watch -p ./ — recompile on every save |
package |
npm run package |
Package the extension as a .vsix file |
Launch in Extension Development Host
- Open the repository folder in VS Code.
- Press F5 (or run Run → Start Debugging).
- A new VS Code window labelled [Extension Development Host] opens with the extension active.
- Open any
.xaml, .axaml, .razor, .html, or .htm file in that window and use Open With… to launch the designer.
Making Changes
- Edit source files in
src/.
- Run
npm run compile (or keep npm run watch running).
- Reload the Extension Development Host window with Ctrl+R / Cmd+R to pick up the new build.
Packaging a Release Build
npm install
npm run compile
npm run package
The output file is xaml-axaml-designer-<version>.vsix in the project root.
Project Structure
vs-code-wysiwyg/
├── src/
│ ├── extension.ts # Extension entry point — registers all custom editors and commands
│ ├── xamlDesignerProvider.ts # CustomTextEditorProvider for .xaml / .axaml
│ ├── razorDesignerProvider.ts # CustomTextEditorProvider for .razor
│ ├── htmlDesignerProvider.ts # CustomTextEditorProvider for .html / .htm
│ ├── htmlPreviewProvider.ts # HTML live preview panel provider
│ ├── previewProvider.ts # Unified preview provider for XAML/AXAML, Razor, and HTML files
│ ├── xamlDocument.ts # XAML document model / parser helpers
│ ├── webviewContent.ts # Webview HTML + embedded JS for the XAML designer
│ ├── razorWebviewContent.ts # Webview HTML + embedded JS for the Razor designer
│ └── htmlWebviewContent.ts # Webview HTML + embedded JS for the HTML designer
├── out/ # Compiled JavaScript output (generated by tsc)
├── package.json # Extension manifest, scripts, and dependencies
├── tsconfig.json # TypeScript compiler configuration
├── LICENSE # MIT License
└── .vscodeignore # Files excluded from the VSIX package
