OCI Layout Explorer

Visual Studio Code extension for exploring OCI image layout folders from the OCI Explorer view.

Features

• Explore images from one unified Explore Image action:
  • Open an existing OCI layout folder
  • Pick an image from the local Docker daemon
  • Enter a remote registry reference (tag or digest)
• Browse oci-layout, index.json, indexes, manifests, configs, layers, and attestations in a linked tree.
• Attestation nodes use concise display labels such as SLSA, SBOM (SPDX), SBOM (CycloneDX), Trivy Report, and VEX.
• Customize node labels with the ociExplorer.customLabels setting (match by mediaType, predicateType, and/or artifactType).
• Open blobs and descriptor files directly in the VS Code text editor.
• JSON descriptor blobs open as pretty-printed read-only documents through the oci-explorer-blob: virtual file system.
• Open linked OCI files directly for raw inspection.
• OCI descriptor files opened as text are detected as JSON (when parseable), support Ctrl/Cmd-click digest navigation to linked blobs, and show digest hover previews.
• Use refresh actions on both OCI Layout and Docker Images views.
• A prerequisite warning surfaces in the OCI Layout view when oras is not installed, with a one-click Show OCI Layout Prerequisites help page.
• Integrates with the Container Tools extension when available.

How It Works

When you choose a daemon or registry image, OCI Layout Explorer materializes an OCI layout directory and opens it in the tree.

Export strategy is selected automatically:

• Registry images:
  • Use direct registry copy with oras cp --recursive ... --to-oci-layout ...
  • Shorthand references are normalized automatically (for example, nginx:latest -> docker.io/library/nginx:latest)
• Docker daemon images:
  • Use docker save + oras cp --recursive --from-oci-layout <archive>:latest --to-oci-layout <layout>:latest
  • Attempt multi-platform export first, and retry with a concrete platform only if conversion requires it
  • If docker save (or conversion) fails outright, automatically fall back to pulling the same reference directly from its registry with oras cp

When ociExplorer.docker.exportPath is configured, the intermediate .tar produced by docker save is written next to the layout (named <image>.tar) instead of a temp directory, making repeat exports of the same image faster.

Export metadata is written to .oci-explorer.json in each exported layout folder.

Requirements

• VS Code ^1.120.0
• For image export functionality, install ORAS.
• For local daemon exploration:
  • Docker daemon access (docker CLI)
• For remote registry exploration:
  • oras (used for direct registry-to-layout copy)

Getting Started

Install from the VS Code Marketplace, or search for OCI Layout Explorer in the Extensions view.

1. Open the OCI Explorer activity bar view.
2. Click Explore Image.
3. Choose one of:
   • Open OCI layout folder
   • Use image from Docker daemon
   • Pull image from registry
4. The selected/exported layout is opened automatically in OCI Layout Explorer.

Configuration

• ociExplorer.docker.socketPath
  • Docker daemon socket path.
  • If empty, uses DOCKER_HOST or the platform default.
• ociExplorer.docker.exportPath
  • Directory where OCI layouts are exported.
  • If empty, a temporary directory is used.
• ociExplorer.jsonDetectionMaxSizeMB
  • Maximum file size (in megabytes) for automatic OCI JSON detection and pretty-printing.
  • Default is 8 (8 MB). Files larger than this remain in their default language mode.
• ociExplorer.customLabels

  • Custom label rules for OCI nodes in the tree. Each rule may match on mediaType, predicateType, and/or artifactType; the * wildcard is supported. The first matching rule wins.

  • Example:

      "ociExplorer.customLabels": [
      	{
      		"label": "Custom Attestation",
      		"mediaType": "application/vnd.in-toto+json",
      		"predicateType": "https://example.com/my-predicate/*"
      	},
      	{
      		"label": "Helm Chart",
      		"artifactType": "application/vnd.cncf.helm.config.v1+json"
      	}
      ]


Prerequisites Help

If oras is missing, OCI Layout Explorer surfaces a warning entry in the OCI Layout view. Clicking it (or running the OCI Explorer: Show OCI Layout Prerequisites command) opens a help page with install instructions.

Development

# Install dependencies
npm install

# Build (type-check + bundle)
npm run compile

# Watch mode (esbuild + tsc in parallel)
npm run watch

# Lint
npm run lint

# Run unit tests
npm test

# Run VS Code integration tests
npm run test:vscode

# Production bundle
npm run package

Trademarks and Notices

The activity bar icon is the official Open Container Initiative™ logo, redistributed verbatim from opencontainers/artwork under the Apache License 2.0. OCI™, Open Container Initiative™, and the OCI logo are trademarks of The Linux Foundation®. This extension is an independent community project and is not produced, endorsed, or sponsored by The Linux Foundation or the Open Container Initiative. See NOTICE.md for full attribution and trademark information, and the Linux Foundation Trademark Usage page for the governing policy.
