Quiote for VS Code

Route explorer, triad navigation, and live introspection for apps built on the Quiote PHP framework.

Available on the VS Code Marketplace. Core navigation, route exploration, diagnostics, and scaffolding all work end-to-end, but some polish (hover previews, telemetry-informed defaults) is still ahead. See Known limitations for what's missing today.

Features

• Triad navigation — jump between an Action, its View, and its Template (Modules/{Module}/Actions/{Action}Action.php ↔ Views/{Action}{View}View.php ↔ Templates/{Action}{View}.{php,tal,xsl,twig}, matching whichever renderer the app configures per output type — PHPTAL, XSLT, and Twig templates are recognized alongside plain PHP). Available via:
  • right-click → Quiote: Go to Related in the editor (or the default keybinding Alt+O), while a triad file is open
  • CodeLens links at the top of any triad file (needs editor.codeLens: true, VS Code's default)
  • right-click an Action node in the Route Explorer → Open View / Open Template / Describe Action — Open View/Open Template prefer real, per-output-type paths from live introspection (Artifact/Console/Probe, whichever answers) over convention-guessing, and prompt with a picker when a view renders more than one output type's template (e.g. html via PHPTAL alongside xml via plain PHP)
  • a status-bar breadcrumb showing Module · Action · Role for the active file
• $(list-tree) Quiote status bar item — always visible (not gated on having a triad file open); click it for a QuickPick of every Quiote command (List Routes, Refresh, Validate Config, the four scaffolding commands, Go to Related). This — plus the Command Palette (Quiote: ...) — is the answer to "how do I do anything with this extension."
• Route Explorer — a Quiote activity-bar view listing every route the app knows about, grouped Module → Action → Route. Backed by a four-rung introspection ladder (fastest first) that degrades gracefully:
  1. Artifact — reads cache/introspection/app.json straight off disk, zero PHP spawn. Written by the framework's own routes:compile command — no assistant needed, just a Quiote app.
  2. Probe — the quiote-mcp-assistant's probe.php, batched via its overview/diagnostics capabilities (one app bootstrap for routes+modules+triads+diagnostics together). Auto-detected if the target app has it installed via composer require --dev quioteframework/quiote-mcp-assistant (searched from the app dir upward, since vendor/ isn't always a direct child of the app dir); override with quiote.probePath otherwise.
  3. Console — the app's own vendor/bin/quiote routes:compile --json (framework-only, no assistant needed — this also refreshes the Artifact as a side effect).
  4. Static — a filesystem convention scan (no PHP invoked at all), used for instant paint and as the last-resort fallback.
• Problems panel diagnostics — route/triad problems (MISSING_VIEW, SHADOWED_CONFIG, duplicate routes, ...) plus config validation where the Probe rung is available, via Quiote: Validate Config or automatically on save.
• Scaffolding — Quiote: New Module / New Action / New Plugin / New DB Connection, each a dry-run preview → confirm → write flow that never overwrites an existing file. Needs the Probe rung. New Action resolves the target app's real configured renderer for the html format and writes a minimal, engine-correct starter template in whichever syntax that renderer actually uses — PHPTAL, Twig, XSLT, or plain PHP — rather than assuming PHP. Only a renderer with no starter to offer (a fully custom, app-registered one) is skipped, reported back in the confirm dialog/completion message with the extension to author by hand.
• Tasks — routes:list, cache:warmup, and about show up under Tasks: Run Task as quiote tasks (needs the Console rung — vendor/bin/quiote found). No problem matcher is attached: these commands' diagnostics render as Symfony Console's boxed, colored text, not a reliable regex target — use Quiote: Validate Config (or the automatic Problems-panel refresh) for structured diagnostics instead.
• Cassette Explorer — a Cassettes activity-bar view listing recorded replay (VCR-style record/replay) cassettes, backed by the target app's own cassette:list/cassette:show --json (needs the Console rung — vendor/bin/quiote). Clicking a cassette opens a tabbed, Postman-style detail view (Overview, Request, Session/User, Effects, Response, Exception, Log) with a per-body "Load full body" action for anything the console excerpted. The view's Quiote: Select Cassette Environment title-bar action (backed by env:list --json) picks which environment's cassettes are listed — e.g. an object-store-backed replay plugin partitions recordings by environment, so cassettes recorded in staging won't show up while development is selected. Defaults to whatever the target app's own .env/$QUIOTE_ENV resolves to. Quiote: Analyze Cassette with Copilot builds a prompt from the cassette and opens it in Copilot Chat — referencing the app's own MCP server (mcp:serve, auto-registered to Copilot Chat when the target app has McpPlugin active) when available, or embedding the cassette JSON directly otherwise. Pre-fills the prompt for review by default; see quiote.copilot.autoSendPrompt to send immediately instead.
• File decorations — Action/View/Template files get an A/V/T badge in the explorer.
• Snippets — PHP (action/view/config), XML (settings/route), and YAML (settings/module) snippets for common Quiote authoring patterns.

Requirements

• VS Code ^1.101.0 (the Cassette Explorer's Copilot integration needs the stable Language Model/MCP-provider APIs; everything else works on older VS Code too, but the extension declares one floor).
• A workspace containing a Quiote app, detected via .quiote.json (an {"app_dir": "..."} marker, resolved relative to the marker file) or a Config/settings.{php,yaml,yml,xml} file.
• PHP on PATH (or configured via quiote.phpPath) if you want the Artifact/Console/Probe rungs — the extension works without PHP at all via the Static rung, just with less detail (no route paths/methods).
• quioteframework/quiote-mcp-assistant as a dev dependency of the target app (composer require --dev quioteframework/quiote-mcp-assistant) — this is required for the Probe rung, which in turn is required for scaffolding (New Module/New Action/New Plugin/New DB Connection) and config-validation diagnostics. Without it, everything else still works at the Artifact/Console/Static rungs, but those commands report "needs the assistant."
• phpstan/phpstan as a dev dependency of the target app (with vendor/bin/phpstan present) if you want to enable quiote.phpstan.enable, which cross-checks Action/View execute*() declared return types against what they actually return. Off by default; see Configuration.

Installing it

From the Marketplace (recommended)

Search for Quiote in the Extensions view (Ctrl/Cmd+Shift+X), or install directly:

code --install-extension jakamo.quiote-vscode

From source (for developing the extension itself)

Option A — Run it from source (fastest, for trying it out or developing)

1. Clone this repo and install dependencies:

   git clone <this-repo-url>
   cd quiote-vscode
   npm install


2. Open the folder in VS Code.
3. Press F5 (or Run → Start Debugging). This launches an Extension Development Host window — a second VS Code instance with the extension loaded. Open a Quiote app folder in that window to try it.

Changes to src/ are picked up after re-running npm run compile (or npm run watch in a terminal) and reloading the dev host window (Cmd/Ctrl+R inside it, or Developer: Reload Window from the command palette).

Option B — Install a packaged .vsix into your everyday VS Code

This installs it into your real VS Code, not just a throwaway dev host:

npm install
npx @vscode/vsce package

This produces quiote-vscode-<version>.vsix in the project root. Then either:

• Command line:

  code --install-extension quiote-vscode-<version>.vsix


• UI: Extensions view (Ctrl/Cmd+Shift+X) → ... menu (top-right) → Install from VSIX... → select the file.

Reload VS Code (or just restart it) afterwards. To update after pulling new changes, repackage and reinstall the same way — VS Code overwrites the previous version.

To remove it: Extensions view → find "Quiote" → Uninstall.

Configuration

Commands

Development

npm run compile        # typecheck + bundle
npm run lint
npm run test-unit         # pure-logic tests, no VS Code needed
npm run test-integration  # runs in a real headless VS Code instance
npm test                  # both

Known limitations

• quiote.cache.regenerateOnSave invalidates unconditionally on any matching save rather than rehashing the artifact's dependency manifest to check real staleness — cheaper, and the next live rung recomputes anyway.
• Scaffolding needs the Probe rung (the assistant installed via Composer) — Console/Static/Artifact have no equivalent, so these commands show "needs the assistant" without it. Config-validation diagnostics specifically are also Probe-only; route/triad diagnostics work at every rung down to Console.
• Route Explorer targets the first detected Quiote app in a multi-root workspace.
• Template-extension detection without a live rung (CodeLens, Go to Related, file decorations, and the Alt+O index all work purely off disk, no PHP round-trip) only recognizes the framework's four built-in renderer extensions (.php, .tal, .xsl, .twig) — an app-registered custom renderer with a different extension won't be picked up there. Any rung with a live introspection artifact (Artifact/Console/Probe) instead reports the app's real configured extension per output type, no guessing involved.
• No hover previews yet, and no telemetry to inform future defaults — both are planned but not implemented in 0.1.0.
