English | 简体中文

Starling Agent

VS Code monitor and workspace for Claude Code, Codex, and Pi sessions: live status, catalogs, projects, model profiles, resume, and fork.

It works with the Starling CLI and turns local agent history into focused Monitor, Catalog, Projects, and Models views, plus Starling Chat in VS Code's right sidebar.

Current release: 0.2.0

• VS Code Marketplace: huangsh.starling-ai
• GitHub Release: v0.2.0
• CLI package: starling-ai

The GitHub release includes the packaged VSIX:

starling-ai-0.2.0.vsix

Requirements

The extension requires VS Code 1.106 or newer so Starling Chat can be contributed directly to the secondary (right) sidebar.

Install the Starling CLI first:

npm install -g starling-ai

Then make sure VS Code can find the starling command:

starling --help

If VS Code cannot find starling on PATH, set starling.cliPath to the npm-installed starling entry point in VS Code settings. Starling Chat needs that wrapper to locate its SDK Host; a standalone native binary requires explicit STARLING_PI_SDK_HOST and STARLING_PI_SDK_NODE environment variables.

When the extension starts and cannot find the Starling CLI, it prompts you to install it with:

npm install -g starling-ai

You can also use the prompt to open the starling.cliPath setting.

Starling Chat requires the current starling-ai npm package on Node.js 22.19 or newer. The CLI includes a fixed Pi SDK dependency and hosts it directly; it does not launch pi --mode rpc, so a separate Pi CLI installation is unnecessary for Chat. The VS Code extension itself does not bundle or import the SDK.

Views

Starling Chat

Open Starling: Open Starling Chat to show it in VS Code's secondary (right) sidebar. The view connects to the Starling CLI's direct Pi SDK host and supports:

• Streaming assistant text and thinking.
• Live tool start, progress, result, and error cards.
• Follow-up messages while Pi is busy.
• Stopping the current turn and starting a fresh session.
• Resuming a historical Pi session by its absolute session-file path.
• Pi extension confirm, select, input, editor, and notification requests through native VS Code UI.

The chat uses the first workspace folder as its working directory. Set starling.chatPiSetting to a Starling Pi model-profile name, or leave it empty to use the SDK's default model settings. Closing the view cancels pending UI requests and closes the managed SDK host through stdin before using process signals as a timeout fallback.

The view follows VS Code Workspace Trust. An untrusted workspace is passed to the SDK Host as untrusted, so project-local Pi settings, packages, and extensions are not activated.

Catalog

Browse hierarchical Starling catalogs and the sessions assigned to them.

Right-click a catalog session to:

• Resume the session.
• Show session details.
• Open the session project in a new VS Code window.
• Copy the project path.
• Copy the session ID.
• Remove pin metadata.
• Delete the session.

Right-click a catalog folder to:

• Rename the catalog.
• Delete the catalog without deleting session files.

Projects

Browse projects as a directory tree with session counts.

Right-click a project to:

• Show project details.
• Open the project in a new VS Code window.
• Copy the project path.

Project session nodes support the same session actions as the Monitor view.

Models

Browse Starling-managed Claude, Codex, and Pi model profiles.

Use the Models view title bar to create a model profile template. The extension creates:

~/.starling/settings/claude/<name>.json
~/.starling/settings/codex/<name>.toml
~/.starling/settings/pi/<name>.json

and opens the profile file in VS Code for editing.

Right-click a model profile to:

• Open the model settings file.
• Start a new agent session.
• Start a new agent session in a catalog.
• Delete the Starling model profile.

Monitor

Monitor pinned, active, and recent Claude Code, Codex, and Pi sessions with live status, context, token, CPU, memory, and task details.

The Monitor view is backed by starling top --json and refreshes in the background. It groups sessions into:

• Needs attention: sessions waiting for user input or approval.
• Active sessions: sessions currently running or waiting.
• Pinned monitor: pinned sessions in the configured Monitor sort order.
• Recent monitor: recent unpinned sessions in the configured Monitor sort order.
• Static sessions: fallback session list if live monitor data is temporarily unavailable.

Use Starling: Set Monitor Sort or the Monitor view title button to sort by activity, recent activity, tokens, creation time, memory, CPU, context, skills, or tools. Use Starling: Set Monitor Agent Filter to show all agents, only Claude, only Codex, or only Pi.

On Linux, Pi hides one-shot CLI arguments from the process list after startup. Pi sessions launched through Starling carry managed identity and are mapped reliably; for Pi started outside Starling with a custom session root, persist that root with PI_CODING_AGENT_SESSION_DIR or Pi settings.json.

Session states are shown with colored VS Code theme icons:

• Running: the agent is actively processing work.
• Waiting: the agent is waiting for user input or approval.
• Aborted: the current turn was interrupted or cancelled.
• Idle: the agent process exists, but the model is not currently processing.
• Running?: the last running signal is stale and may need a refresh.
• Failure: the last runtime signal reported a failure.
• Stopped: no active process is associated with the session.

Right-click a session to:

• Resume the session.
• Show session details.
• Pin it to a catalog.
• Open its project in a new VS Code window.
• Copy the project path.
• Copy the session ID.
• Remove pin metadata.
• Delete the session.

Commands

Open the Command Palette and search for Starling.

Common commands:

• Starling: Open Starling Chat
• Starling: New Starling Chat
• Starling: Resume Starling Chat
• Starling: Stop Agent Turn
• Starling: Refresh
• Starling: Set Monitor Agent Filter
• Starling: Set Monitor Sort
• Starling: Resume Session
• Starling: Show Session Details
• Starling: Pin Session
• Starling: Pin to Catalog
• Starling: Remove Pin
• Starling: Delete Session
• Starling: List Sessions
• Starling: Session Index Status
• Starling: Rebuild Session Index
• Starling: List Models
• Starling: Add Model
• Starling: Open Model Settings
• Starling: Start Agent Session
• Starling: Start Agent Session in Catalog
• Catalog context menu: Run Agent > Pi
• Starling: Rename Catalog
• Starling: Delete Catalog
• Starling: Catalog Tree
• Starling: List Projects
• Starling: Open Project in New Window
• Starling: Copy Project Path
• Starling: Copy Session ID

Settings

{
  "starling.cliPath": "starling",
  "starling.homePath": "",
  "starling.chatPiSetting": "",
  "starling.cacheTtlSeconds": 30,
  "starling.monitorRefreshSeconds": 5,
  "starling.monitorCommandTimeoutSeconds": 60,
  "starling.monitorCacheTtlSeconds": 2,
  "starling.monitorSort": "activity",
  "starling.monitorAgent": "all",
  "starling.projectSessionLimit": 30,
  "starling.sessionTreeLimit": 50
}

starling.cliPath

Path to the Starling CLI executable. Use an absolute path if the VS Code extension host cannot find starling on PATH.

starling.homePath

Optional Starling data directory. Leave empty to use ~/.starling. When set, the extension passes this path as STARLING_HOME to the Starling CLI.

starling.chatPiSetting

Optional Starling Pi model-profile name used by the right-sidebar chat. Leave empty to use Pi's default model settings.

starling.cacheTtlSeconds

How long CLI query results are cached. Set to 0 to disable cache.

starling.monitorRefreshSeconds

How often the extension refreshes live session status in the background. The default is 5 seconds. A small random jitter prevents multiple VS Code windows from polling at exactly the same time.

starling.monitorCommandTimeoutSeconds

Maximum time to wait for each starling top command. The default is 60 seconds. Increase it for very large session indexes or heavily loaded hosts.

starling.monitorCacheTtlSeconds

How long live monitor snapshots are cached. The extension keeps the last good snapshot and applies retry backoff when a refresh fails, so transient CLI errors do not blank the Monitor view or start overlapping commands.

starling.monitorSort

Sort mode used for the Monitor view. Supported values are activity, recent, tokens, created, memory, cpu, ctx, skills, and tools.

starling.monitorAgent

Agent filter used for the Monitor view. Supported values are all, claude, codex, and pi.

starling.projectSessionLimit

Number of sessions shown per project node before requiring "Load more". Set to 0 to show all.

starling.sessionTreeLimit

Number of sessions loaded per batch in the Monitor view's static session fallback. Set to 0 to load all.

Local Data

Starling stores metadata and indexes under:

~/.starling/

Set starling.homePath to use a different directory.

The extension reads this data through the Starling CLI. It does not upload session contents.

Logs and Problems

The extension writes diagnostic logs to the VS Code Output panel:

Output -> Starling

CLI failures, monitor refresh failures, and JSON parsing errors are also reported to VS Code Problems diagnostics when they affect a view. Successful refreshes clear the related diagnostics.

Useful CLI Commands

starling session ls
starling session show <session-id>
starling session index status
starling session index rebuild
starling catalog tree
starling project ls
starling model ls
starling top
starling top --json
starling run status

Repository

https://github.com/huang-sh/Starling-ext

The CLI repository is:

https://github.com/huang-sh/Starling
