MermaidGenie Viewer – VS Code Extension

Embed MermaidGenie - the AI‑powered Mermaid diagram editor - directly into VS Code. Upload prompts, generate diagrams, edit, version and share - all from your editor.

🚀 Features

Instant Diagram Editor
Open MermaidGenie in a side panel via Command Palette (MermaidGenie: Open Diagram Editor).
Secure, Sandboxed iframe
Loads https://mermaidgenie.vercel.app under a strict Content‑Security‑Policy. No local backend required.
Persistent Sessions
Your work (AI‑generated diagrams, edits, history) stays alive when you switch files or hide the panel.
Configurable Panel
Customize via Settings:
- Title of the Webview panel
- Editor column to open in (active, 1–3)
- iframe width & height (CSS values)
- Script permissions
- Auto‑open on startup
Zero Setup
Simply install - MermaidGenie’s own infrastructure handles the AI, storage, and collaboration.

📖 Live VS Code Extension

To easily try it out, install the extension directly from the VS Code Marketplace: https://marketplace.visualstudio.com/items?itemName=hoangsonw.mermaidgenie-viewer. Simply click Install and it will be ready to use in your VS Code!

Please give it a try and share your feedback!

📦 Installation

Clone & navigate into the extension folder:

git clone https://github.com/hoangsonww/MermaidGenie-UML-Diagram-App.git
cd MermaidGenie-UML-Diagram-App/extension

Install dependencies & compile:
```
npm install
npm run compile
```
Package as a VSIX:
```
vsce package
```
This creates mermaidgenie-viewer-0.0.1.vsix.
Install the VSIX:
- CLI:
```
code --install-extension mermaidgenie-viewer-0.0.1.vsix
```
- VS Code UI: Open Extensions view → “...” → Install from VSIX... → select the file.

🎯 Usage

Open the Command Palette (Ctrl+Shift+P / ⌘+Shift+P).
Run MermaidGenie Viewer: Open Diagram Editor.
The MermaidGenie app loads in a side panel - enter prompts, generate or edit diagrams, and share as usual.

⚙️ Configuration

Open Settings → Extensions → MermaidGenie Viewer (or search @ext:hoangsonw.mermaidgenie-viewer):

Setting	Default	Description
`mermaidgenieViewer.panelTitle`	`"MermaidGenie"`	Title of the Webview panel.
`mermaidgenieViewer.viewColumn`	`1`	Editor column to open in (0=active, 1–3).
`mermaidgenieViewer.retainContext`	`true`	Preserve panel state when hidden or switching files.
`mermaidgenieViewer.enableScripts`	`true`	Allow scripts to run inside the iframe.
`mermaidgenieViewer.iframeWidth`	`"100%"`	CSS width for the iframe (e.g. `"80%"` or `"600px"`).
`mermaidgenieViewer.iframeHeight`	`"100%"`	CSS height for the iframe (e.g. `"80%"` or `"500px"`).
`mermaidgenieViewer.openOnStartup`	`false`	Automatically open the panel when VS Code starts.

🛠 Development

Watch & rebuild
```
npm run watch
```
Debug Press F5 in this folder to launch an Extension Development Host.
Re‑package
```
npm run package
```

🐞 Troubleshooting

Blank panel Ensure https://mermaidgenie.vercel.app is reachable from your network.
CSP or load errors Confirm the iframe src URL exactly matches the frame-src directive in getHtml().
Settings not visible Reload window (Cmd+Shift+P → Developer: Reload Window) after installing/updating the VSIX.

📄 License

ℹ️ About MermaidGenie

MermaidGenie transforms text prompts into editable Mermaid diagrams powered by AI. Sketch flowcharts, UML, ERDs, mind‑maps and share with your team in a PWA‑ready workspace.

Live app & source code: 👉 mermaidgenie.vercel.app 👉 hoangsonww/mermaidgenie
