UXML & USS Language Tools - VS Code extension

Language support for Unity's UI Toolkit file formats:

• .uxml - XML-based UI layout (think HTML/XAML for Unity)
• .uss - CSS-like stylesheets for UXML

VS Code | Open Vsx

Features

• Syntax highlighting for both formats. Unity element names like Button, Toggle, ScrollView are highlighted distinctly from custom controls; -unity-* USS properties get their own scope.
• Snippets for common scaffolding (uxml, button, toggle, style, template, instance, flex, bg, unityfont, …).
• IntelliSense / completion:
  • In UXML: element names, attributes for the element under the cursor (including inherited VisualElement attributes), and value enums (true/false, Position/Ignore, …).
  • In USS: property names (CSS + -unity-*) and value enums for properties with finite value lists (flex-direction, -unity-text-align, …).
• Hover docs for elements, attributes, and USS properties.
• Diagnostics: unknown elements, unknown attributes, invalid enum values (UXML); unknown properties and invalid values (USS). Custom CSS variables (--*) and user-defined non-Unity-namespaced controls are correctly excluded.
• Quick fixes: every diagnostic with a "did you mean …?" suggestion comes with a one-click Replace with … code action, powered by edit-distance matching.
• Auto-closing brackets, tag matching, and CSS-style block folding.

Install

From the Marketplace

ext install helizac.uxml-uss-language-tools

…or open the Extensions panel and search for UXML & USS Language Tools.

From a .vsix

Download the .vsix from the Releases page and:

code --install-extension uxml-uss-language-tools-<version>.vsix

Development

Prerequisites

• Node.js 18 or later
• npm (bundled with Node)

Build

git clone https://github.com/helizac/uxml-uss-language-tools.git
cd uxml-uss-language-tools
npm install
npm run compile     # one-shot
npm run watch       # rebuild on change

Run locally

1. Open the repo in VS Code.
2. Press F5 (or pick Run Extension from the Run and Debug view).
3. A second VS Code window opens - the Extension Development Host - with the extension loaded.
4. Open examples/example.uxml and examples/example.uss.

Run tests

npm test

The suite has three layers:

1. Pure unit tests (contextDetection.test.ts) for the cursor-context heuristics.
2. Provider integration tests (extension.test.ts) that open in-memory documents and call vscode.executeCompletionItemProvider / vscode.executeHoverProvider.
3. Diagnostics + quick-fix tests (diagnostics.test.ts) that lint sample documents and exercise the code action provider.

You can also pick Extension Tests from the Run and Debug view to run them with breakpoints.

Versioning

We follow SemVer:

• Patch for bug fixes and grammar/snippet additions.
• Minor for new features (new diagnostics, new providers).
• Major for breaking changes to defaults (e.g. changing what we flag).

Always update CHANGELOG.md before tagging. The release workflow uses the GitHub-generated notes by default, but a human-curated changelog is much more useful for users.

Contributing

PRs are very welcome. See CONTRIBUTING.md for the dev setup, project layout, and review expectations.

The most impactful contributions are usually:

• Adding missing elements or attributes to src/unityElements.ts.
• Adding missing USS properties to src/ussProperties.ts.
• Fixing false positives in the diagnostics - open an issue with a minimal .uxml or .uss snippet that is incorrectly flagged.

Project layout

uxml-uss-language-tools/
├── package.json                       Extension manifest
├── tsconfig.json
├── language-configuration-uxml.json   Bracket / comment behavior for UXML
├── language-configuration-uss.json    Bracket / comment behavior for USS
├── syntaxes/
│   ├── uxml.tmLanguage.json           TextMate grammar for UXML
│   └── uss.tmLanguage.json            TextMate grammar for USS
├── snippets/
│   ├── uxml.json
│   └── uss.json
├── src/
│   ├── extension.ts                   Activation: registers all providers
│   ├── unityElements.ts               Element + attribute metadata
│   ├── ussProperties.ts               USS property metadata
│   ├── uxmlProviders.ts               Completion + hover for UXML
│   ├── ussProviders.ts                Completion + hover for USS
│   ├── uxmlDiagnostics.ts             Linter + quick-fix provider for UXML
│   ├── ussDiagnostics.ts              Linter + quick-fix provider for USS
│   ├── util.ts                        Shared helpers
│   └── test/...
├── examples/
│   ├── example.uxml
│   └── example.uss
└── .github/
    ├── workflows/                     CI + Release pipelines
    ├── ISSUE_TEMPLATE/
    └── PULL_REQUEST_TEMPLATE.md

License & Disclaimer

This extension is provided "as is" under the MIT License, without warranty of any kind. It is not affiliated with, endorsed by, or sponsored by Unity Technologies. "Unity" and "UI Toolkit" are trademarks of Unity Technologies. The author is not liable for any issues arising from use of this software.

Found a bug?

You can file an issue directly on the GitHub Repo > UXML & USS Language Tools > Issues
